grandMA3
consoles
QUICK MANUAL

1
2

1
3
English
Table of contents
Intended Use 4
Safety 5
Support 12
Transport 14
Limitations 17
Quick Start 19
Maintenance 23
Disposal 25
Technical Data 26
Pixel Faults 43
Declaration of Conformity 44

1
The grandMA3 consoles control all kinds of lighting genres such as conventional, moving lights, LEDs, video, and media via DMX signal
or within a network environment.
All grandMA3 components, despite different hardware solutions, use the same software.
All components are fully integrable into the network environment.
Use all grandMA3 components and accessories within closed rooms and in the permissible environmental conditions only. Installation
and connection of the devices are explicitly to be carried out by trained personnel in compliance with all safety regulations.
4
Intended Use
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Symbols and Warning Labels
Warning – Danger area
Caution– Risk of electric shock
Risk of Electric Shock
The device is to be serviced by qualified personnel only as live parts may be exposed when opening and/or removing coverings.
Touching live parts may cause electric shock.
5
Safety
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Dispose of as hazardous waste. Follow the applicable regulations. For more information see Disposal.
Recycle the battery
Declaration of conformity. For more information see Conformity.
Operating voltage ON/OFF
6
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Lithium-Ion-Battery
Warning
Safety instructions for the built-in lithium-ion battery:
The grandMA3 full-size, grandMA3 light, and their CRV versions have a rechargeable lithium-ion battery (LiFePo4) for an
uninterrupted power supply (UPS);
All grandMA3 consoles have a memory battery on the MA Central Computer Board.
Only use batteries approved by MA Lighting Technology GmbH;
Misuse or improper handling of the battery can cause it to explode or the fluid inside the battery to discharge.
Note the following instructions in order to avoid injuries:
Do not open or disassemble the battery;
Do not drill holes into the battery or damage it in any other different manner;
Do not short-circuit the battery;
Protect the battery against moisture and humidity;
Protect the battery against fire;
Keep the battery away from children;
Do not use the battery if it is defective;
Do not try to exchange the built-in battery. The exchange of the battery must be performed by a service technician or a repair center
approved by MA Lighting Technology GmbH.
We recommend charging the UPS battery at least once a year in order to avoid deep discharge. To do so, switch on the console, boot
it up, and mind the status bar of the UPS battery.
Note the transportation regulations UN 38.3. – UN Recommendations on the Transport of Dangerous Goods, 6th edition, section 38.3.
7
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
For more information see Transport.
Warning:
The device has to be grounded.
Do not ignore the safety purpose of the grounding-type plug. A grounding-type plug has two blades and a third grounding
connection. The third connection is provided for your safety.
Read all the instructions in this Quick Manual thoroughly, especially the General Safety Instructions further down and the Limitations.
Follow the instructions and keep this Quick Manual for future use.
Follow all cautions and warnings stated in this Quick Manual and indicated on the device.
Important:
All repair and service work has to be exclusively performed by qualified service technicians.
This device is state-of-the-art technology;
However, residual risks cannot be ruled out;
To avoid risks, follow the safety instructions;
This device is intended for professional use only and is not suitable for residential use.
MA Lighting Technology GmbH does not bear the damage which may occur due to the inobservance of the safety instructions.
8
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Warning:
Changes or modifications to these devices not expressly approved by the party responsible for the compliance could void
the user's authority to operate them.
Note:
These devices have been tested and found to comply with the limits of a Class A digital device, pursuant to Part 15 of the
FCC Rules and the CE Standards. These limits are designed to provide reasonable protection against possible
interference when the devices are operated in a commercial environment. These generate, use, and can radiate radio
frequency energy and, if not installed and used in accordance with this Quick Manual, may possibly cause interference to
radio communications.
Operation of these devices in a residential area is likely to cause interference in which case the user will be required to
correct the interference at their own expense.
9
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Avoid Risks Caused by Electric Current
A defective device or defective power cable can cause severe or fatal injury due to electrical shock.
Follow the safety instructions to avoid the risks caused by electric current.
Do not use a defective power cable;
Do not open screwed down covers from the housing;
Use the device only if it is in a technically impeccable condition;
Do not repair the device on your own;
Do not reverse engineer the device, and make any changes to its components, and accessories;
Do not expose the device to rain or moisture;
Do not submerge the device in water.
General Safety Instructions
To avoid injury or damage to the device:
To avoid damage to the displays, do not carry or lift the device by the monitor wing;
To avoid torsion, do not open the monitor wing lifting it up at one edge. When lifting up use both of your hands;
Do not put your hands inside the device during operation;
Device and power cable must be kept away from children under the age of 8;
Children are not allowed to play with the device;
Unplug the power plug to disconnect the power supply from electric voltage during thunderstorms;
Switch off the console via the power switch if it is unattended for a longer period of time;
Shut down the console via the Power key and switch it off via the power switch before cleaning the device;
Do not use any liquid or spray cleaner. Use a dry cloth only;
Do not use the device in the vicinity of water;
Do not expose it to a humid environment;
Do not pour any liquids over the device.
10
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Do not block or cover any ventilation holes in the housing. These are essential for the airflow within the device and protect the
device from overheating;
Do not insert any objects into the ventilation holes of the device as these could get in contact with live parts or could cause short
circuits, fire and/or an electric shock;
Do not place any objects on the power cable. Protect it from being walked on or pinched, particularly at the connector and where
the cables exit the device;
When using an extension cable, make sure the rated output of all devices connected in series does not exceed the maximum rated
output of the extension cable;
Do not support yourself on the device;
Do not place any heavy objects on top of the device;
Do not use excessive force on keys, buttons, faders, knobs, switches, connectors, or monitor wing;
If the power cable or the main power plug is defective, let a qualified technician replace it immediately;
Place the device on stable surfaces only. If it is placed on unstable surfaces, it may fall and break.
Only use power cables which are safety-marked;
Do not use high-power radio devices or cell phones near the device;
The device is provided with a safety plug. This plug can only be used with safety outlets;
As with all industrially manufactured goods, the use of substances that induce an allergic reaction such as aluminum cannot be
generally excluded. If you develop an allergic reaction (such as rash, frequent sneezing, red eyes or respiratory difficulties), consult
a physician immediately to determine the cause.
If one of the following conditions occurs, disconnect the main power plug and call your local distributor or the technical support!
Power cable or the main power plug is damaged or worn;
Ingress of liquids;
The device was exposed to rain or high ambient humidity;
The device does not function properly, even if you followed all the instructions of this Quick Manual. Only operate the controls as
stated in the Quick Manual. Incorrect control settings may damage the device;
The device fell damaging the housing.
11
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Contact us for any questions about your MA product.
MA Lighting and its extensive distributor network offer an unparalleled technical support. Call on our expertise for help with any
problem, no matter if it is about operation, software features, software installations or trouble shooting.
Help Pages
The help pages are included in every software installer package and are automatically loaded into the software (exception: Nodes and
Processing Units).
To access and read the help pages, press Help + Please . The help pop-up opens on the main screen.
To jump directly into a special help topic, use the context-sensitive help:
-Press and hold Help and tap the desired user interface element (UI element) to open the corresponding help topic.
-Tap in the control bar and tap a UI element to open the corresponding help topic.
Please note that the help topics included in the software represent the status and volume of the help pages at release date.
The help system is constantly being updated and extended. You can find the latest update of the help pages in the internet.
Online Manuals
All MA product related manuals are available as online versions. Just select your MA product and click on the according link. All further
documents can be found in our download area. Go to www.malighting.com.
Video Tutorials
Get tips and tricks from our MA experts on your MA product.
MA offers a whole range of videos on how to use your MA product in the best possible way. Just select your series and click on the
links to watch the videos on our YouTube channel. Go to www.malighting.com.
12
Support
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Community
Share your knowledge and get help from other MA users.
A community can be stronger and better than the individual. Be part of the MA community! Go to www.malighting.com.
Local Support
If you have a question regarding your MA Lighting product, please first of all contact your local MA product specialists.
Central Support
If you are in need of further assistance or manufacturer support, please fill out an email request on www.malighting.com in Training
and Support. Your request will automatically be send to [e-mail] (in English or German). This email service is
monitored during MA Lighting's regular business hours in Germany from 8.30 am until 5 pm, Monday through Friday.
Emergency Hotline
In any case of a show critical emergency please contact the MA Lighting support hotline.
Phone [phone]
Please note that this 24/7 hotline is strictly for emergency cases.
13
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Warning:
-Pay attention to temperature and humidity during transport. For more information see Limitations.
-After the transport check the device.
-If the device or its display is damaged (dented, bent or broken), do not connect the grandMA3 console to power!
Important:
Be careful when moving or lifting a grandMA3 console, otherwise you may injure your back or other parts of your body.
The grandMA3 console must be protected from environmental factors such as physical shocks and vibration during
transportation;
Remove all cables before transport;
Secure the monitor wing using the transport locking on each side of the device;
In addition to the transportation regulations UN 38.3 also follow your country's transportation regulations;
Important:
The CRV versions of the grandMA3 console do not have a transport locking.
14
Transport
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Transport locking in a grandMA3 full-size
15
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
The user is responsible for securely fastening the products for transport and for following the manufacturer's safety instructions
when transporting the device;
Noncompliance of the safety instructions can result in personal injury or material damage;
Do not place the grandMA3 console on unstable surfaces;
Do not place any objects on top of the grandMA3 console.
16
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Temperature
Operation:
0 °C up to 40 °C / 32 °F up to 104 °F
Caution:
-Temperatures that exceed or fall below the range of those stated in this Quick Manual can cause maloperation of
displays and other components.
-Higher temperatures can stress the cooling system of the device and destroy hardware components.
Storage / Transport:
-10 °C up to +50 °C / 14 °F up to 122 °F
Humidity
Operation:
20 % up to 90 % relative humidity (no condensation)
Storage / Transport:
10 % up to 90 % relative humidity (no condensation)
17
Limitations
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Environment
Follow all safety instructions;
Only use the device within its operating limits;
Only use the device indoors;
Air must be free of dust and any hazardous or explosive substances;
Avoid jolting;
This device is not protected against splash water. Do not use it near water;
Do not use the device in rain or moisture;
Do not place the device where it can come in contact with corrosive gases or saline air as this can cause maloperation.
18
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
grandMA3 connectors
grandMA3 full-size CRV rear panel
1. Desk light
2. powerCON TRUE1 connector
3. Power switch
4. DMX A-G
5. DisplayPort 1-5
6. LTC
7. USB 3.0
8. Audio Remote In
9. DC Remote Control
10. Ethernet 1-3
11. S/PDIF In & S/PDIF Out
12. USB 2.0
13. MIDI In & Out
Hint:
To display the rear panel connectors on the letterbox screens, type:
Menu "Connectorview"
19
Quick Start
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English

1
Turn on the console
1. Unpack the device.
2. Remove the packaging, cushioning material, and the dust cover.
3. Place the device indoors on a stable surface.
4. Connect external monitors to the console using a native DisplayPort connector.
5. Start the grandMA3 console:
-Insert powerCON TRUE1 into the corresponding jack.
-Connect the main power plug.
-Turn on the power switch (set it to position I.)
-The power switch lights up in red.
-Press the power key on the front panel.
-The device starts booting.
-The Mode Selection dialog appears.
-Tap to select a mode.
20
Intended Use
Safety
Support
Transport
Limitations
Quick Start
Maintenance
Disposal
Technical Data
Pixel Faults
Declaration of Conformity
English
