FEATURES
•Multivariable two-wire, 24 VDC loop-powered
transmitter for level, volume, or flow
•Performance not process dependent (changing
specific gravity and dielectric have no effect)
•26 G z operating frequency offers superior perform-
ance with better accuracy and enhanced resolution
•Antenna designs to +750 °F (+400 °C),
-14.7 to 2320 psi (-1.0 to 160 bar)
•Range up to 130 feet (40 meters)
•Quick connect/disconnect antenna coupling allows
vessel to remain sealed
•4-button keypad and graphic LCD display allow for
convenient viewing of configuration parameters and
echo curve
•Proactive diagnostics advise not only what is wrong,
but also offer troubleshooting tips
•Convenient Setup, Optimization, and Echo Rejection
Wizards (Echo Rejection setup is simple, intuitive,
and effective)
•SIL 2 suitable (93.2% SFF, with full FMEDA report
available)
•PACTware™PC Program and enhanced DTMs for
advanced configuration and troubleshooting
•Available with ART®or FOUNDATION fieldbus™
digital outputs
DESCRIPTION
The Pulsar®Model R86 radar transmitter is the latest
generation of Magnetrol®24 VDC, loop-powered, non-
contact radar transmitters. Enhanced performance,
proactive diagnostics, and various configuration wizards
bring simplicity to an often complex technology.
This latest entry into the radar level measurement field
is designed to provide unparalleled performance and
ease of use. The 26 G z PULSAR Model R86 is the per-
fect complement to the 6 G z PULSAR Model R96 and
Eclipse®Model 706 GWR transmitters. Together, this
transmitter family offers the ultimate solution set to
those difficult industrial process level applications.
TECHNOLOGY
The PULSAR Model R86 radar transmitter is based on
pulse burst radar technology combined with equivalent
time sampling circuitry. Short bursts of 26 G z
microwave energy are emitted and subsequently reflect-
ed from the liquid level surface. Distance is first meas-
ured by the equation:
D = Transit time (round-trip)/2.
Liquid level is then calculated based on transmitter
configuration.
APPLICATIONS
MEDIA: Liquids and slurries; hydrocarbons to water-
based media (dielectric 1.7–100, 1.4 in stillwell)
VESSELS: Most process or storage vessels up to rated
temperature and pressure. Pits and sumps as well as
glass-lined tanks.
CONDITIONS: Virtually all level measurement and con-
trol applications including process conditions exhibiting
varying specific gravity and dielectric, visible vapors,
high fill/empty rates, turbulence, low to moderate foam
and buildup.




TECHNOLOGY
PULSE BURST RADAR
The PULSAR R86 is a top-mounted, downward-facing pulse
burst radar operating at 26 G z. Unlike true pulse devices
(e.g., ECLIPSE Guided Wave Radar) which transmit a sin-
gle, sharp (fast rise-time) waveform of wide-band energy
(Figure 1), PULSAR emits short bursts of 26 G z energy
(Figure 2) and measures the transit time of the signal
reflected off the liquid surface.
Distance is measured utilizing the equation:
Distance equals the Speed of light multiplied by the transit
time divided by two (Distance = C ×Transit Ti e/2). Level
is then calculated by factoring in tank height and other
configuration information (Figure 3). The reference point
for distance and level calculations is the sensor reference
point (bottom of an NPT thread, top of a BSP thread, or
face of the flange).
The exact level measurement is extracted from false target
reflections and other background noise via the use of
sophisticated signal processing. The new PULSAR Model
R86 circuitry is extremely energy efficient so no duty
cycling is necessary to accomplish effective measurement.
1ns
500 ns




Distance = c ×(time ÷2)

2

Since larger horns yield stronger signals and smaller beam
angles, the 4" (100 mm) horn antenna should ideally be
used to ensure the best possible performance in all opera-
tional conditions. owever, as that is often impractical,
other antenna sizes are available.
The chart below (Figure 5) shows the maximum measuring
range of each antenna based on dielectric and turbulence.
Obstructions, noise and media buildup can drastically
decrease reliable measurement. Although it is theoretically
possible to measure a liquid level on the antenna, liquid
should not be allowed closer than 2 inches (50 mm) from
the bottom of the antenna or 12" (300mm) from the sensor
reference point (whichever is greater). Refer to Figure 6.
Sensor
Reference
Point
(Flange)
2" (50 mm)
12" (300 mm)

3

 
 1.7 –3 3 – 10 10 – 100 1.7 –3 3 – 10 10 – 100


11⁄2" Horn 30 (9) 40 (12) 60 (18) 10 (3) 16 (5) 26 (8)
2" Horn 33 (10) 49 (15) 66 (20) 10 (3) 20 (6) 33 (10)
3" Horn 50 (15) 66 (20) 98 (30) 13 (4) 30 (9) 40 (12)
4" Horn 66 (20) 98 (30) 130 (40) 23 (7) 40 (12) 50 (15)

OPERATIONAL CONSIDERATIONS
Tank
Height
Sensor Reference Point
Safety
Zone
Bottom Blocking Distance
Measurement
Region
Sensor
Level
Distance
Level = Tank Height – Distance
Top Blocking
Distance

Radar applications are characterized by
three basic conditions:
•Dielectric (process medium)
•Distance (measuring range)
•Disturbances (turbulence, foam,
false targets, multiple reflections)
The PULSAR R86 Radar transmitter is
offered with several horn antenna sizes
and configurations:
•11⁄2" (38 mm)
•2" (50 mm)
•3" (75mm)
•4" (100 mm)
Maximum measuring range (distance) is
measured from the sensor reference point
(bottom of NPT thread, gasket face of BSP
thread, or gasket face of flange) to the
bottom of the tank. Refer to Figure 4.
12"
(300 mm)
Sensor
Reference
Point
(Encapsulated
Horn)

The PULSAR Model R86 Radar transmitter can be mounted
on a vessel using a variety of process connections.
Generally either a threaded or flanged connection is used.
LOCATION
Ideally, the Radar transmitter should be mounted 1⁄2radius
from center of the tank providing an unobstructed signal
path to the liquid surface where it can illuminate (with
microwave energy) the largest possible surface area. A
conservative recommendation is to not install in center of
tank top or within 18 inches (45 cm) of tank wall. Tank
walls may produce reflections that must be minimized
during field configuration. Refer to Figure 7.
BEAM ANGLE
The various antenna sizes exhibit different beam patterns.
Figure 9 shows the beam spread for all PULSAR Model R86
antennas. Ideally the beam pattern should illuminate the
maximum liquid surface with minimum striking of other
objects in the vessel including the tank wall. Use these
drawings to determine the optimum installation location.
OBSTRUCTIONS
Almost any object that falls within the beam pattern will
cause reflections that may be misinterpreted as a false liq-
uid level. Although the PULSAR Model R86 has a power-
ful Echo Rejection routine, all possible precautions should
be taken to minimize false target reflections with proper
installation location. Refer to Figures 8 & 9.
1/2
Radius
>18"
(>45 cm)
D
W
∝
Beam Sprea , W @-3 B; ft (m)
Antenna
Beam Angle
(∝)
11⁄2" Horn
20°
2" Horn
18°
3" Horn
11°
4" Horn
9°
Distance, D
10 (3) 3.5 (1.1) 3.2 (1.0) 1.9 (0.6) 1.6 (0.5)
20 (6) 7.1 (2.1) 6.3 (1.9) 3.9 (1.2) 3.1 (0.9)
30 (9) 10.6 (3.2) 9.5 (2.9) 5.8 (1.7) 4.7 (1.4)
40 (12) 14.1 (4.2) 12.7 (3.8) 7.7 (2.3) 6.3 (1.9)
50 (15) 17.6 (5.3) 15.8 (4.8) 9.6 (2.9) 7.9 (2.4)
60 (18) 21.2 (6.3) 19.0 (5.7) 11.6 (3.5) 9.4 (2.8)
65 (20) 20.6 (6.3) 12.5 (3.9) 10.2 (3.1)
98 (30) 18.9 (5.8) 15.4 (4.7)
130 (40) 20.5 (6.3)

MOUNTING
 
4
feet (meters)

NOZZLES
Improper installation in a nozzle creates “ringing” (unde-
sired signals) which can adversely affect measurement. The
antenna should always be mounted such that the active
section of the antenna is a minimum of 0.5" (13 mm)
below the nozzle. Be sure to include any nozzle dimension
that may extend down inside the vessel. Refer to Figure 10.
Antenna extensions are offered to allow the PULSAR Model
R86 transmitter to work reliably in nozzles with an “L”
dimension up to 72" (1.8 m).
ORIENTATION
The PULSAR Model R86 transmitter utilizes circular
polarization. This means that the microwave beam does
not need to be manually adjusted (rotated) during
commissioning as is necessary with other radar transmitters.
The result is a much simpler start-up process.
MOUNTING
5
0.50" (13 mm)
Minimum
2" (50 mm)
" L " Dimension (Nozzle Height)

To limit the temperature exposure to the transmitter in high
temperature applications, a heat extension (032-6922-001) is
required between the antenna and transmitter. Refer to
“Operating Temperature Range” chart on page 6.
TEMPERATURE EXTENSION
HEAT EXTENSION FOR USE WITH HIGH
TEMPERATURE/HIGH PRESSURE ANTENNAS
The PULSAR Model R86 can be mounted in a standpipe
or stillwell but certain items must be considered:
•Metal stillwells only:
Inside diameter 13⁄4–8 inches (45–200 mm).
•Diameter must be consistent throughout length; no
reducers or gaps.
•Use only horn antennas sized to pipe ID; 11⁄2"–4"
(44–100mm); 8-inch pipe can use 4-inch horn.
•Stillwell length must cover complete range of
measurement (i.e., liquid must be in stillwell).
•Welds should be smooth.
•Vents: holes <0.125" (3 mm) diameter,
slots <0.125" (3 mm) width.
•If an isolation valve is used, it must be a full port
ball valve with an I.D. equal to the pipe diameter.
•Configuration must include a non-zero entry for
PIPE I.D parameter.
STANDPIPES AND STILLWELLS

6
TEMPERATURE/PRESSURE
OPERATING TEMPERATURE RANGE
0
500
250
43
-40 70 750
750
1000
1500
1250
2000
2250
1750
2500
-100 0 100 200 300 400 500 600 700 800
Pressure (psig)
0
20
40
60
80
100
120
140
160
-50 0 50 100 150 200 250 300 350 400
Pressure (bar)
Temperature (°F)
Temperature (°C)
Antenna Pressure Ratings
PTFE
POLYPROPYLENE
QUARTZ
Ambient Temperature °F (°C)
-40
(-40)
-20
(-29)
0
(-18)
20
(-7)
40
(4)
60
(16)
80
(27)
100
(38)
120
(49)
140
(60)
160
(71)
180
(82)
700 (371)
750 (400)
600 (315)
500 (260)
400 (204)
300 (149)
200 (93)
100 (38)
0 (-18)
-100 (-73)
Process Temperature °F (°C)
D
B, D
B, C
D
A, B, C, D
Safe Operating Regions
A: Standard PTFE Seal
B: Standard PTFE Seal with
Extension (P/N 032-6922-001)
C: HTHP Quartz Seal
D: HTHP Quartz Seal with
Extension (P/N 032-6922-001)
 
From 0 to 130 °C T4
From 130 to 195 °C T3
From 195 to 295 °C T2
From 295 to 400 °C T1

APPLICATIONS
PULSE BURST RADAR
R E A C T O R S


ENCLOSED SUMPS
 
7
MIXING AND
B L E N D I N G V E S S E L S
 
C H A M B E R S
AND BYPASS
STORAGE AND INTERMEDIATE
HOLDING TANKS

E N C L O S E D F L U M E S
A N D W E I R S
 



With a total of 35 flume and weir curves stored in
the electronics, it would be hard to find an open
channel flow application that cannot be handled
by the R86 transmitter. Unusual flow applications
can readily be accomplished through the use of
either the 20-point Custom Table or the Generic
Discharge Flow Equation which allows a direct
entry of unique flow equations.

Two 7-digit flow totalizers are provided for
recording flow in cubic feet, gallons, million
gallons, liters, million liters, or cubic meters.
One totalizer is resettable and the other is non-
resettable. Several multipliers are selectable to
allow for proper scaling. Totalizer time is also
recorded to show how long each totalizer has
been recording flow.

OPEN CHANNEL FLOW APPLICATIONS
NOTE: For optimal accuracy, mount the transmitter a
minimum of 30" (75 cm) above the flow element
(this is epen ent on type an size of the flow
element). Consult factory for assistance on this
imension.

PROBLEMATIC APPLICATIONS
GUIDED WAVE RADAR ALTERNATIVE
Some applications can be problematic for Non-Contact
Radar. The following are examples of when Guided
Wave Radar is recommended.
•Extremely low dielectric media (εr<1.7)
•Very weak reflections from the liquid surface
(particularly during turbulence) can cause poor
performance.
•Tanks heavily cluttered with false targets (mixers,
pumps, ladders, pipes, etc.)
•During times of very low liquid levels of low dielec-
tric media, the metal tank bottom may be detected,
which can deteriorate performance.
•Foam can either absorb or reflect the microwave
energy depending upon the depth, dielectric, density
and wall thickness of the bubbles. Due to typical
variations in the amount (depth) of foam, it is
impossible to quantify performance. It may be
possible to receive most, some or none of the
transmitted energy.
•Extremely high liquid level (Overflow) conditions
when liquid very near the antenna can cause
erroneous readings and measurement failure.
•Interface applications
Refer to ECLIPSE Model 706 Guided Wave Radar
bulletin 57-106.
8
 










Viton®GFLT 0 +400 °F @ 232 psi
(+200 °C @ 16 bar)
750 psi @ +70 °F
(51.7 bar @ +20 °C)
-40 °F
(-40 °C) General purpose, ethylene
Ketones (MEK, acetone),
sky rol flui s, amines, anhy-
rous ammonia, low molecular
weight esters an ethers, hot
hy rofluoric or chlorosulfuric
aci s, sour HCs
Kalrez®4079 2 +400 °F @ 232 psi
+(200 °C @ 16 bar)
750 psi @ +70 °F
(51.7 bar @ +20 °C)
-40 °F
(-40 °C)
Inorganic an organic aci s
(inclu ing HF an nitric),
al ehy es, ethylene, glycols,
organic oils, silicone oils, vinegar,
sour HCs
Black liquor, hot water/steam,
hot aliphatic amines, ethylene
oxi e,propylene oxi e, molten
so ium, molten potassium
➀
Simriz SZ485
(formerly
Aegis PF128)
8+400 °F @ 232 psi
+(200 °C @ 16 bar)
750 psi @ +70 °F
(51.7 bar @ +20 °C)
-4 °F
(-20 °C)
Inorganic an organic aci s
(inclu ing HF an nitric),
al ehy es, ethylene, glycols,
organic oils, silicone oils, vinegar,
sour HCs, steam, amines, ethyl-
ene oxi e, propylene oxi e,
NACE applications
Black liquor, Freon 43, Freon 75,
Gal en, KEL-F liqui , molten
so ium, molten potassium
Kalrez®6375 A 400 °F @ 232 psi
(200 °C @ 16 bar)
750 psi 70 °F
(51.7 bar @ 20 °C)
-40 °F
(-40 °C)
Inorganic an organic aci s
(inclu ing hy ro flui s an nitric),
al ehy es, ethylene, organic oils,
glycols, silicone oils, vinegar,
sour HCs
Hot water/steam, hot aliphatic
amines, ethylene oxi e, propylene
oxi e
Quartz N +750 °F @ 1375 psi
(+400 °C @ 94.8 bar)
2320 psi @ 70 °F
(160 bar @ +20 °C)
-100 °F
(-70 °C)
General high temperature/high
pressure applications,
hy rocarbons, full vacuum
(hermetic), ammonia, chlorine
Hot alkaline solutions HF aci ,
me ia with ph>12, irect exposure
to saturate steam
➀Maximum +300 °F (+150 °C) for use on steam.
O-RING (SEAL) SELECTION CHART

9
AGENCY APPROVALS
These evices are in compliance with the RED- irective 2014/53/EU, the EMC irective 2014/30/EU,
the PED- irective 2014/68/EU, the ATEX irective 2014/34/EU an RoHS irective 2011/65/EU.


FM17US0108X / FM17CA0055X
Class I, Div 1, Group B, C, D, T4…T1
Zone 1 A Ex b ia IIB+H2 T4…T1
Zone 1 Ex ia IIB+H2 T4…T1
Ta = -40 ºC to +70 ºC
Type 4X, IP67


II 1/2 G Ex b ia IIB + H2 T4…T1 Ga/Gb
Ta = -40 ºC to +70 ºC
IP67

Ex b ia IIB + H2 T4…T1 Ga/Gb
Ta = -40 ºC to +70 ºC
IP67


FM17US0108X / FM17CA0055X
Class I, II, III, Div 2, Group A, B, C, D, E, F, G, T4…T1
Class 1, Zone 2 AEx nA ia IIC T4…T1
Class 1, Zone 2 Ex nA ia IIC T4…T1
Ta = -15 ºC to +70 ºC
Type 4X, IP67

II 3 G Ex nA IIC Gc T4…T1
Ta = -15 ºC to +70 ºC
IP67

Ex nA IIC Gc T4…T1
Ta = -15 ºC to + 70 ºC
IP67


FM17US0108X / FM17CA0055X
Class I, II, III, Div 1, Group A, B, C, D, E, F, G, T4…T1
Class I, Zone 0 AEx ia IIC T4…T1
Class I, Zone 0 Ex ia IIC T4…T1 Ga
Ta =-40 ºC to +70 ºC
Type 4X, IP67

II 1 G Ex ia IIC T4…T1 Ga
Ta = -40 ºC to +70 ºC
IP67

Ex ia IIC T4…T1 Ga
Ta = -40 ºC to +70 ºC
IP67


FM17US0108X / FM17CA0055X
Class II, III, Div 1, Group E, F, an G, T4…T1
Ta = -15º C to +70º C
Type 4X, IP67

II 2 D Ex ia tb IIIC T100º C Db
Ta = -15º C to +70º C
IP67

Ex ia tb IIIC T100º C Db
Ta = -15º C to +70º C
IP67
FM3600:2011, FM3610:2010, FM3611:2004, FM3615:2006, FM3616:2011, FM3810:2005, ANSI/ISA60079-0:2013,
ANSI/ISA 60079-1:2015, ANSI/ISA 60079-11:2013, ANSI/ISA 60079-15:2012, ANSI/ISA 60079-26:2011, NEMA 250:2003,
ANSI/IEC 60529:2004, C22.2 No. 0.4:2009, C22.2 No. 0.5:2008, C22.2 No. 30:2007, C22.2 No. 94:2001, C22.2 No. 213:2012,
C22.2 No. 1010.1:2009, CAN/CSA 60079-0:2011, CAN/CSA 60079-1:2011, CAN/CSA 60079-11:2014, CAN/CSA 60079-
15:2012, C22.2 No. 60529:2005, EN60079-0:2012, EN60079-1:2014, EN60079-11:2012, EN60079-15:2010, EN60079-26:2007,
EN60079-31:2009, EN60529+A1:1991-2000, IEC60079-0:2011, IEC60079-1:2014, IEC60079-11:2011, IEC60079-15:2010,
IEC60079-26:2006, IEC60079-31:2008
“This equipment with chargeable non-con uctive parts, e.g. enclosure’s paint an antenna use PTFE, Co-polymer
Polypropylene or Noryl En265, is provi e with a warning label referring to the safety measures that must be taken if there is
electrostatic charging uring operation. For use in hazar ous area, the equipment an si e to be installe , e.g. tank, must be
connecte to earth an be attention to not only the measuring object, e.g. liqui s, gases, pow ers an etc., but also the relate
con itions, e.g. tank container, vessel an etc. (Accor ing to IEC 60079- 32-1).”

This equipment has been teste an foun to comply with the limits for a Class B igital evice, pursuant to part 15 of the FCC
Rules. These limits are esigne to provi e reasonable protection against harmful interference in a resi ential installation. This
equipment generates, uses an can ra iate ra io frequency energy an , if not installe an use in accor ance with the instruc-
tions, may cause harmful interference to ra io communications.

  
 47 CFR, Part 15, Subpart C, Section 15.209
Unintentional Ra iators 47 CFR, Part 15, Subpart C, Section 15.256
 RSS-211 RSS-211
 EN 302 372 V2.1.1 (2016-12) EN 302 729 V2.1.1 (2016-12)

TRANSMITTER SPECIFICATIONS
FUNCTIONAL/PHYSICAL
10

Measurement Principle Pulse Burst Ra ar 26 GHz

Measure Variable Level, etermine by the time-of-flight of ra ar pulse reflections
Span 0.5 to 130 feet (0.2 to 40 meters)

Type 4 to 20 mA with HART: 3.8 mA to 20.5 mA useable (per NAMUR NE43)
FOUNDATION fiel bus™: H1 (ITK Ver. 6.2.0)
Resolution Analog: .003 mA
Digital Display: 1 mm
Loop Resistance GP/IS: 591 ohms @ 24 VDC an 22 mA
XP/Flameproof: 500 ohms @ 24 VDC an 22 mA
Diagnostic Alarm Selectable: 3.6 mA, 22 mA (meets requirements of NAMUR NE 43), or HOLD last output
Diagnostic In ication Meets requirements of NAMUR NE107
Damping A justable 0-10

Keypa 4-button menu- riven ata entry
Display Graphic Liqui Crystal Display
Digital Communication HART Version 7–with Fiel Communicator, FOUNDATION fiel bus™, AMS, or FDT
DTM (PACTware™), EDDL
Menu Languages Transmitter LCD: English, French, German, Spanish, Russian
HART DD: English, French, German, Spanish, Russian, Chinese, Portuguese
FOUNDATION fiel bus Host System: English
Measure at instrument terminals) HART: General Purpose (Weather proof)/Intrinsically Safe/Explosion-proof:
11 VDC minimum at terminals un er certain con itions (refer to Manual 58-603)
FISCO, FNICO, Explosion Proof, General Purpose an Weather Proof
FOUNDATION fiel bus™: 9 to 17.5 VDC

Material IP67/ ie-cast aluminum A413 (<0.6% copper); optional stainless steel
Net/Gross Weight Aluminum: 4.5 lbs. (2.0 kg)
Stainless Steel: 10.0 lbs. (4.50 kg)
Overall Dimensions Refer to page 12
Cable Entry 1⁄2" NPT or M20
SIL 2 Har ware (Safety Integrity Level) Safe Failure Fraction = 93.2% (HART only)
Functional Safety to SIL 2 as 1oo1 in accor ance with IEC 61508
(Full FMEDA report available upon request)
Ambient Operating Temperature -40 to +175 °F (-40 to +80 °C); LCD viewable -5 to +160 °F (-20 to +70 °C)
Storage Temperature -50 to +185 °F (-45 to +85 °C)
Humi ity 0–99%, non-con ensing
Electromagnetic Compatibility Meets CE requirement (EN 61326) an NAMUR NE 21
Surge Protection Meets CE EN 61326 (1000V)
Shock/Vibration ANSI/ISA-S71.03 Class SA1 (Shock); ANSI/ISA-S71.03 Class VC2 (Vibration)
ENVIRONMENT

Reference Con itions Reflection from i eal reflector at +70 °F (+20 °C)
Linearity ±0.1 inch (3 mm) or 0.1% of tank height (whichever is greater)
Measure Error ±0.1 inch (3 mm) or 0.1% of tank height (whichever is greater)
(Performance will egra e slightly within 60" (1.5 m) of antenna)
Resolution 0.1 inch or 1mm
Repeatability ±0.1 inch (3 mm) or 0.05% of tank height (whichever is greater)
Response Time <2 secon s (configuration epen ent)
Initialization Time < 30 secon s
Ambient Temperature Effect Digital Average 0.12 inch (3 mm) / 10 K, max of ±0.4 inch (10 mm) over the entire
temperature range -40 to +175 °F (-40 to +80 °C)
Analog Current Output (a itional error with reference to 16 mA span)
Average 0.03% / 10 K. max 0.45% over entire temperature range
-40 to +175 °F (-40 to +80 °C)
Maximum Rate of Change 180 inches (450 cm)/minute
FOUNDATION fiel bus™: ITK Version 6.2.0
H1 Device Class Link Master (LAS) —selectable ON/OFF
H1 Profile Class 31PS, 32L
Function Blocks (8) Al, (3) Trans ucer, (1) Resource, (2) PID (1) Arithmetic,
(1) Signal Characterizer, (1) Input Selector, (1) Integrator
Quiescent Current 17 mA
Execution Time 10 ms (15 ms PID Block)
Device Revision 01
DD Version 0x01
PERFORMANCE
ANTENNA SPECIFICATIONS
FUNCTIONAL/PHYSICAL
11
Antenna Material 316 SS, Hastelloy C or Polypropylene
Process Seal Material PTFE with O-rings or Quartz
Maximum Process Temperature +750 °F @ 1375 psi (+400 °C @ 94.8 bar)
Maximum Process Pressure -14.7 to 2320 psi @ +70 °F (-1.0 to 160 bar @ +20 °C)
Vacuum Service Hermeticity to <5 ×10-7 cc/sec helium
Minimum Dielectric (application epen ent) 1.7 (1.4 with stillwells)

1/8" NPT
Flushing Port Option
1/8" NPT
Flushing Port Option
1/8" NPT
Flushing Port Option
1/8" NPT
Flushing Port Option
1/8" NPT
Flushing Port Option
D D D
D D D
2.81
(71)
H
1/8" NPT
Flushing Port Option
2.81
(71)
L
1.00
(25)
1.81
(46)
H
1.00
(25)
1.81
(46)
L
4.56
(116)
H
4.79
(122)
1.72
(44)
1.57
(40)
4.56
(116)
L
DIMENSIONAL SPECIFICATIONS
INCHES (MM)
12

 
  (11⁄2") (2") (3") (4")
  (None) 3.2 (81) 4.5 (114) 8.5 (216) 11.5 (292)

(4") 6 (152) ———
(8") 8 (203) 8.3 (211) — —
(12") 12 (305) 12 (305) 12.4 (315) 14.4 (366)
(24") 24 (610) 24 (610) 24 (610) 24 (610)
(48") 48 (1219) 48 (1219) 48 (1219) 48 (1219)
(72") 72 (1829) 72 (1829) 72 (1829) 72 (1829)
 1.56 (40) 1.89 (48) 2.95 (75) 3.74 (95)


 
3.96
(101)
4.51
(115)
7.77
(197)
3.22
(82)
" NPT
or M20
3.98
(101)
1.46
(37)
8.34
(212)

TRANSMITTER MODEL NUMBER
Mo els available for quick shipment, usually within one
week after factory receipt of a complete purchase
or er, through the Expe ite Ship Plan (ESP).
13
 
10 |
01⁄2" NPT
1 M20
21⁄2" NPT with sunsha e
3 M20 with sunsha e
| 
R 8 6 Through-Air Ra ar Level Transmitter - 26 GHz Pulse Burst Ra ar
| 
5 24 VDC, Two Wire
| 
1 4-20 mA with HART
2 FOUNDATION fiel bus™H1
| 
0 None (FOUNDATION fiel bus only, 5th igit = 2)
1 SIL 2 Har ware - HART only (5th igit = 1)
ANone (FOUNDATION fiel bus only, 5th igit = 2) – ETSI ➀
BSIL 2 Har ware - HART only (5th igit = 1) – ETSI ➀
7|
0 No Digital Display an Keypa - Integral
A Digital Display an Keypa - Integral
| 
1 Die-cast Aluminum, Dual Compartment, 20- egree
2 Investment Cast, 316ss, Dual Compartment, 20- egree
| 
0 General Purpose, Weatherproof (IP 67)
1 Intrinsically Safe or Non-incen ive (FM & CSA)
3 Explosion-proof (FM & CSA)
A Intrinsically Safe (ATEX/IEC)
BFlame-proof (ATEX/IEC)
(Available only when Antenna 10th Digit = N)
C Non-sparking (ATEX)
D Dust Ignition-proof
➀ Must be use with 3-inch or 4-inch horn

ANTENNA MODEL NUMBER
14
3|CONFIGURATION/STyLE
1 11⁄2" Horn
2 2" Horn
3 3" Horn
44" Horn
4–5 |PROCESS CONNECTION - SIZE/TyPE
RB 0
12 3 4 56 7 8 910 11 12 13 14 15
ASME Flanges EN (DIN) Flanges
1–2 | TEChNOLOGy
R B PULSAR Radar Antennas - 26 GHz
31 11⁄2" NPT thread 41 2" NPT Thread
32 11⁄2" BSP (G 11⁄2") thread 42 2" BSP (G2") Thread
43 2" 150# ASME ra sed face flange DA DN 50, PN 16 EN 1092-1 Type A
44 2" 300# ASME ra sed face flange DB DN 50, PN 25/40 EN 1092-1 Type A
45 2" 600# ASME ra sed face flange DD DN 50, PN 63 EN 1092-1 Type B2
53 3" 150# ASME ra sed face flange EA DN 80, PN 16 EN 1092-1 Type A
54 3" 300# ASME ra sed face flange EB DN 80, PN 25/40 EN 1092-1 Type A
55 3" 600# ASME ra sed face flange ED DN 80, PN 63 EN 1092-1 Type B2
63 4" 150# ASME ra sed face flange FA DN 100, PN 16 EN 1092-1 Type A
64 4" 300# ASME rased face flange FB DN 100, PN 25/40 EN 1092-1 Type A
65 4" 600# ASME ra sed face flange FD DN 100, PN 63 EN 1092-1 Type B2
73 6" 150# ASME ra sed face flange GA DN 150, PN 16 EN 1092-1 Type A
74 6" 300# ASME ra sed face flange GB DN 150, PN 25/40 EN 1092-1 Type A
75 6" 600# ASME ra sed face flange GD DN 150, PN 63 EN 1092-1 Type B2
6 | CONSTRUCTION CODES
0Industral
K ASME B31.1
LASME B31.3
MASME B31.3 & NACE MR0175 / MR0103
NNACE MR0175 / MR0103
7 | FLANGE OPTIONS
0 None

ANTENNA MODEL NUMBER
15
 
           
A 316SS/316L SS
B Hastelloy C
R316SS/316L SS with Carbon Steel Flange
S Hastelloy C with Carbon Steel Flange
E Polypropylene (available only when 3r igit = 1, 4th & 5th igits = 31, an 6th, 7th & 9th through 12th igits = 0)
| 
| 
0 None
| 
0 Viton GFLT
2Kalrez 4079
8Simriz SZ485 (formerly Aegis PF128) — NACE
AKalrez 6375
NNone - Quartz seal (man atory for flame proof (ATEX/IEC) approval) ➀
0 None
1 For nozzle height ≤ 4" (100 mm) (available only when Antenna 3r Digit = 1)
2 For nozzle height ≤ 8" (200 mm) (not available when Antenna 3r Digit = 3 or 4)
3 For nozzle height ≤ 12" (300 mm)
4 For nozzle height ≤ 24" (600 mm)
5 For nozzle height ≤ 48" (1200 mm)
6 For nozzle height ≤ 72" (1800 mm)
|  
| 
0 None
11⁄8" NPT Flushing Connection
➀ Refer to pages 5 an 6 for temperature extension information

The quality assurance system in place at
MAGNETROL guarantees the highest level
of quality throughout the company.
MAGNETROL is committed to providing full
customer satisfaction both in quality products
and quality service.
The MAGNETROL quality assurance system
is registered to ISO 9001 affirming its com-
mitment to known international quality
standards providing the strongest assurance
of product/service quality available.
Several PULSAR Through-Air Radar Level
Transmitters are available for quick shipment,
usually within one week after factory
receipt of a complete purchase order,
through the Expedite Ship Plan (ESP).
Models covered by ESP service are color
coded in the selection data charts.
To take advantage of ESP, simply match the
color coded model number codes (standard
dimensions apply).
ESP service may not apply to orders of ten
units or more. Contact your local represen-
tative for lead times on larger volume orders,
as well as other products and options.
Expe ite
Ship
Plan
All MAGNETROL electronic level and flow
controls are warranted free of defects in
materials or workmanship for eighteen
months from the date of original factory
shipment.
If returned within the warranty period; and,
upon factory inspection of the control, the
cause of the claim is determined to be cov-
ered under the warranty; then, MAGNETROL
will repair or replace the control at no cost
to the purchaser (or owner) other than
transportation.
MAGNETROL shall not be liable for misap-
plication, labor claims, direct or consequential
damage or expense arising from the instal-
lation or use of equipment. There are no
other warranties expressed or implied,
except special written warranties covering
some MAGNETROL products.



705 Enterprise Street • Aurora, Illinois 60504-8149 • 630-969-4000
[email protected] • www.magnetrol.com
Copyright © 2018 Magnetrol International, Incorporated.
Performance specifications are effective with date of issue and are subject to change without notice.
For a itional information, see Instruction Manual 58-603.
PULSAR Pulse Burst Ra ar transmitters may be protecte by one or more of the following U.S. Patent Nos.:
US 6,062,095; US 6,980,174; US 7,102,584; US 7,106,248
QUALITY
ESP
WARRANTY
Magnetrol & Magnetrol logotype, Eclipse an Pulsar are registere tra emarks of Magnetrol International, Incorporate .
Viton® an Kalrez® are registere tra emarks of DuPont Performance Elastomers.
HART® is a registere tra emark of the HART Communication Foun ation
PACTware is tra emark of PACTware Consortium
CSA logotype is a registere tra emark of Cana ian Stan ar s Association
Hastelloy® is a registere tra emark of Haynes International, Inc.
Tri-Clamp® is a registere tra emark of Alfa Laval, Inc.
