Installation in ventilation ducts
■The illustration shows the installation of an ERM fan within a duct system.
■Use the FUM foot to mount the fan on the wall or the ceiling.The mounting foot can be secured at any position on the fan
circumference with the screws supplied.
1Ventilation duct, to be supplied by the customer
2ELM flexible cuffs
3REM reducer
4Terminal box
5Ceiling, wall, girder
6FUM mounting foot
7ERM fan
Installation at end of duct, fan with free inlet
■The illustration shows the installation of an ERM fan at the end of a duct system.
■Use the FUM foot to mount the fan on the wall or the ceiling.The mounting foot can be secured at any position on the fan
circumference with the screws supplied.
■Use SGM protective grille for free outlet.
1Ceiling, wall, girder
2Ventilation duct, to be supplied by the customer
3ELM flexible cuffs
4REM reducer
5ERM fan
6FUM mounting foot
7SGM protective grille
8Terminal box

INSTALLATION INSTRUCTIONS
ERM 28
Version: 2019-05-22 - MAICO VENTILATOREN, www.maico-fans.com - We are not responsible for mistakes or printing errors and retain the
right to make technical modifications without giving prior notice Page 2
Rooms with bar equipment
■The illustration shows the construction of a duct system for extracting CO2or Nemissions in rooms with bar equipment.
■Use SGM protective grille for free inlet
1Ventilation duct, to be supplied by the customer
2ELM fixing cuff
3ERM fan
4SGM protective grille
