Mainstays D2118.0001-MP User manual

MAINSTAYS 29" METAL 3 PIECE
DINING SET WITH STORAGE STOCK # D2118.0001-MP
STOCK # D2118.0002-MP
STOCK # D2118.0003-MP
WARNING:
ADULT ASSEMBLY REQUIRED
RECOMMENDED NUMBER OF PEOPLE FOR ASSEMBLY: 2
ESTIMATED ASSEMBLY TIME: 30 MIN
●CALL OUR TOLL FREE NUMBER 1-877-637-3590 FOR ASSISTANCE.WE ARE AVAILABLE TO ASSIST YOU
MONDAY-FRIDAY FROM 9am-5pm EASTERN STANDARD TIME OR SEND US YOUR QUESTIONS TO
[email protected].
●ADDITIONAL PARTS ARE AVAILABLE FOR A FEE.
●THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
●DO NOT ALLOW CHILDREN TO CLIMB OR PLAY ON THE UNIT.
●CLEAN THE PRODUCT WITH YOUR FAVORITE FURNITURE POLISH AND A SOFT CLOTH.
●DO NOT USE HARSH CHEMICALS OR ABRASIVE CLEANERS.
●MOVE YOUR NEW FURNITURE CAREFULLY WITH TWO PEOPLE. NEVER PUSH OR DRAG THE UNIT.
Manufactured By: Saigon Furniture Co.,Ltd.
zhangZhou, China
We are available to assist you Monday - Friday
from 9:00 am - 5:00 pm Eastern Standard Time.
1-877-637-3590
MAXIMUM LOAD 110 LBS (50KG)
MAXIMUM LOAD
242 LBS (110KG)
TEL: [phone] EMAIL: [email protected]
FOR MISSING OR DAMAGED PARTS,PLEASE CALL
1-877-637-3590 BEFORE RETURNING THE PRODUCT
TO STORE. PARTS WILL BE SHIPPED FREE OF
CHARGE WITHIN 90DAYS OF PURCHASE WITH
PROOF OF PURCHASE.PLEASE CALL OUR TOLL
FREE NUMBER OR E-MAIL TO
[email protected]
FOR PROMPT, RELIABLE SERVICE, PLEASE
HAVE YOUR ASSEMBLY MANUAL READY.
LOT NUMBER
DATE OF PURCHASE ⁄ ⁄

●Read and understand all the steps carefully before starting. Please
follow the steps in the correct orders to avoid difficulties or damages
to the parts during assembly.If each step is not followed in the
correct order the assembly will be difficult and may result in
damages.
●Work in a spacious area, preferably on a carpeted surface, near
where the unit will be used.
●Make sure all the parts are included. Most boards are labeled with a
removable sticker.
DO NOT USE POWER TOOLS TO ASSEMBLE
YOUR FURNITURE. POWER TOOLS MAY
DAMAGE THE PARTS AND RESULT IN
DAMAGE.
BEFORE STARTING
Manufactured By: Saigon Furniture Co.,Ltd.
zhangZhou, China
We are available to assist you Monday - Friday
from 9:00 am - 5:00 pm Eastern Standard Time.
1-877-637-3590
MAINSTAYS 29" METAL 3 PIECE
DINING SET WITH STORAGE
STOCK # D2118.0001-MP
STOCK # D2118.0002-MP
STOCK # D2118.0003-MP
Bolt M6x12mm
Qty: 10 (2 for spare)
Bolt M6x30mm
Qty: 20 (2 for spare)
Bolt M6x35mm
Qty: 18 (2 for spare)
Nut
Qty: 6 (2 for spare)
Allen Wrench
Qty: 1
Wrench
Qty: 1
2
1 2 3
4 5 6
TEL: [phone] EMAIL: [email protected]

VERIFY THAT ALL PARTS ARE
LISTED BEFORE BEGINNING
MAINSTAYS 29" METAL 3 PIECE
DINING SET WITH STORAGE
STOCK # D2118.0001-MP
STOCK # D2118.0002-MP
STOCK # D2118.0003-MP
Table Legs
(Qty: 2)
Chair Leg
(Qty: 2)
Chair Leg
(Qty: 2)
Chair back frame
(Qty: 2)
Chair Seat
(Qty: 2)
Chair Upper Support Rail
(Qty: 2)
Upper Support Frame
(Qty: 1)
Bottom Support Frame
(Qty: 2)
Table Top
(Qty: 1)
3
A
BCD
EF
G
H
I

x 8
Attach bottom support frame C to the table legs A with bots .
1
4
2
3
Bolt M6x35mm
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
A
A
C
C
x 4
3
Bolt M6x35mm
B
Attach top support frame B to the table legs A with bolts .
5
3
5

5
x 4
Attach table top D to the table legs A with bolts , tighten all
bolts with allen wrench .
3
Bolt M6x35mm
x 1
5
Allen Wrench
x 4
2
Bolt M6x30mm
x 2
4
Nut x2
Attach chair leg E and chair F to the chair back frame G with
bolts and nut .
3
3
3
3
3 5
3
D
2
2
4
4
4
2
2
G
EF
3 4
46
5

6
x 4
Attach chair upper support rail I to the chair back frame G with bolts .
1
Bolt M6x12mm
x 1
6
Wrench
x 1
5
Allen Wrench
x 5
2
Bolt M6x30mm
1.Attach chair seat H to the chair leg E and F with bolts ,
tighten all bolts with allen wrench and wrench .
2. Repeat the procedure to assemble the other chairs.
1
5
1
1
1
1
2
2
2
2
2
2
1
I
G
H
5 6
56
2
5
F
E

7
If you need to order parts please use the list below.
Please email defect photo and proof of purchase to [email protected]
Parts will be shipped free of charge within 90 days of purchase with proof of purchase.
Spare parts and services only support the purchase made from Walmart store or Walmart.com
Parts
Hardware
1
456
2 3
A
A
C
C
D
B
I
G
H
F
E
7

STOCK # D2118.0001-MP
STOCK # D2118.0002-MP
STOCK # D2118.0003-MP
NÚMERO DE PERSONAS RECOMENDADO PARA EL ENSAMBLAJE: 2
TIEMPO ESTIMADO DE ENSAMBLAJE: 30 MIN
● LLAME A NUESTRO NÚMERO GRATUITO 1-877-637-3590 PARA OBTENER MÁS AYUDA.
● PIEZAS ADICIONALES ESTÁN DISPONIBLES POR UNA TARIFA.
● ESTE MANUAL DE INSTRUCCIÓN CONTIENE INFORMACIÓN IMPORTANTE DE SEGURIDAD.
POR FAVOR DE LEER Y GUARDAR PARA FUTURAS REFERENCIAS.
● NO DEJAR A LOS NIÑOS SUBIR O JUGAR SOBRE LA UNIDAD.
● LIMPIAR EL PRODUCTO CON TU PULIDOR FAVORITE DE MUEBLE Y UN TRAPO BLANDO.
● NO USAR QUÍMICOS FUERTES O PRODUCTO DE LIMPIEZA ABRASIVO.
● MUEVA SUS NUEVOS MUEBLES CUIDADOSAMENTE CON DOS PERSONAS, NUNCA EMPUJE O
ARRASTRE LA UNIDAD.
NO DEVOLVER EL PRODUCTO A LA TIENDA.
TIENDAS INDIVIDUALES NO RESERVAN PIEZAS.
PARA PIEZAS PERDIDAS O DAÑADAS LLAME AL
PARTES SERÁN ENVIADOS DE FORMA RATUITA.
PARA UN SERVICIO RÁPIDO Y CONFIABLE, POR
FAVOR DE TENER A MANO EL MANUAL DE
ENSAMBLAJE.
Fabricante: Saigon Furniture Co.,Ltd.
zhangZhou, China
Estamos disponibles para ayudarlo de Lunes -
Voermes de 9:00 am - 5:00 pm Hora de la Zona Este.
1-877-637-3590
NUMERO DE PARTIDA
FECHA DE COMPRA ⁄ ⁄
MAXIMA CARGA 110 LBS (50KG)
MAXIMA CARGA
242 LBS (110KG)
MAINSTAYS 29" JUEGO DE COMEDOR
DE METAL DE 3 PIEZAS COM
ALMACENAMIENTO
ADVERTENCIA:
ASAMBLEA DE ADULTO REQUERIDO
TEL: [phone] EMAIL: [email protected]
1-877-637-3590 O EMAIL A [email protected]

●Leer y entender todos los pasos cuidadosamente antes de comenzar.
si no se sigue cada paso en el orden correcto, el montaie será difícil y
puede ocasionar daños.
●Trabaiar en una zona amplia, meior sobre la alfombra, cerca del sitio
donde la unidad se utiliza.
●Asegurarse de que todas las piezas estén incluidos. La mayoría de
los tableros están etiquetados con una pegatina removible.
NO UTILICE HERRAMIENTAS ELÉCTRICAS
PARA MONTAR SUS MUEBLES.
HERRAMIENTAS ELÉCTRICAS PUEDEN
DAÑAR LAS PIEZAS Y PROVOCAR DAÑOS.
ANTES DE COMENZAR
Fabricante: Saigon Furniture Co.,Ltd.
zhangZhou, China
Estamos disponibles para ayudarlo de Lunes -
Voermes de 9:00 am - 5:00 pm Hora de la Zona Este.
1-877-637-3590
MAINSTAYS 29" JUEGO DE COMEDOR DE
METAL DE 3 PIEZAS COM ALMACENAMIENTO
STOCK # D2118.0001-MP
STOCK # D2118.0002-MP
STOCK # D2118.0003-MP
Tornillo De M6x12mm
Cantidad: 10 (2 de repuesto)
Tornillo De M6x30mm
Cantidad: 20 (2 de repuesto)
Tornillo De M6x35mm
Cantidad: 18 (2 de repuesto)
Tuerca
Cantidad: 6 (2 de repuesto)
Llave Allen
Cantidad: 1
Llave Inglesa
Cantidad: 1
2
1 2 3
4 5 6
TEL: [phone] EMAIL: [email protected]

VERIFY THAT ALL PARTS ARE
LISTED BEFORE BEGINNING
MAINSTAYS 29" JUEGO DE COMEDOR DE
METAL DE 3 PIEZAS COM ALMACENAMIENTO
STOCK # D2118.0001-MP
STOCK # D2118.0002-MP
STOCK # D2118.0003-MP
Patas de mesa
(Cantidad: 2)
Patas de la
(Cantidad: 2)
Patas de la silla
(Cantidad: 2)
Marco de la silla
(Cantidad: 2)
Asiento de la silla
(Cantidad: 2)
Carril de soporte
(Qty: 2)
Bastidor de soporte superior
(Cantidad: 1)
Marco de soporte inferior
(Cantidad: 2)
Mesa
(Qty: 1)
3
A
BCD
EF
G
H
I
