Maiwe MIGE2210 Series User manual

MIGE2210 Series
Gigabit Din-rail Switch
User Manual
(Edition: V1.1)
Wuhan Maiwe Communication Co., Ltd.

MIGE2210 Series Gigabit Din-rail Switch
I
Trademark
This trademark is owned by Wuhan Maiwe
Communication Co., Ltd.
Mwring is the trademark used for link redundancy and self-recovery
technology, owned by Wuhan Maiwe Communication Co., Ltd.
Microsoft and Windows is registered trademark owned by Microsoft.
Copyright
Copyright © Wuhan Maiwe Communication Co., Ltd.
Clarification
The user manual is applicable to MIGE2210 series gigabit din-rail switch.
Please read the following license agreement carefully before using this manual.
The products described in this manual can be used only if you agree on the
following license agreement.
Important Statement
Any information provided by our company in this manual does not represent for
corresponding authorization on these information.
Our company attempts to ensure the accuracy and applicability for the
information provided in this manual, however our company does not assume
any responsibility for the use of these information, and does not assume any
joint responsibility for the use of these information. There may be a few
technical or typographical errors in the product and manual. The company
reserves the right to change all or part of this manual without prior notice.
Statement
Due to continuous update and improvement of products and
technology, the contents of this document may not be completely
consistent with the actual products, appreciate for your understanding.
If necessary to inquiry the updates of the product, please check our
official website or contact our representative directly.
Revision history:
Version
Date
Reason
V1.0
2015.10.27
Create document
V1.1
2018.08.14
Model modification

MIGE2210 Series Gigabit Din-rail Switch
II
Safe Use Instruction
This product performance is excellent and reliable in the designed range of use,
but it’s necessary to avoid man-made damage or destroy for the
equipment.
Read the manual carefully and keep this manual for reference if need
afterwards.
Do not put the device close to the water sources or damp places.
Do not put anything on the power cable, it should be placed out of reach.
To avoid causing fire, do not knot or wrap the cable.
Power connector and other device connectors should be firmly
connected with each other, frequently inspection is needed.
Please keep the fiber socket and plug clean. Do not look directly at the
fiber section when the equipment is working.
Please keep the equipment clean and wipe it with a soft cotton cloth if
necessary.
Please do not repair the equipment by yourself, unless there is clear
instructions in the manual.
Under the following circumstances, please cut off power immediately and
contact us.
Equipment water damage.
The equipment is broken or the casing is broken.
The equipment works abnormally or the performance has completely
changed.
The equipment produces odor, smoke or noise.
Statement: Information requiring explanation in use of the managed software.
Attention: Matters requiring specific attention in the use of the managed
software.

MIGE2210 Series Gigabit Din-rail Switch
III
Catalogue
1. Product Introduction.................................................- 1 -
1.1. Product Description..................................................................... - 1 -
1.2. Features......................................................................................... - 1 -
1.2.1. High-performance Ethernet Switch Interface................................. - 1 -
1.2.2. Industrial Power Supply Design....................................................... - 1 -
1.2.3. Shell Design........................................................................................- 1 -
1.2.4. Dual Power Backup and Power Failure Alarm............................... - 2 -
1.2.5. Main Performance..............................................................................- 2 -
1.3. Industry Standard.........................................................................- 2 -
1.4. Product Selection Table..............................................................- 2 -
1.5. Packing List................................................................................... - 3 -
2. Performance Indicators............................................- 4 -
3. Hardware Structure................................................... - 6 -
3.1. Chassis...........................................................................................- 6 -
3.2. MIGE2210-2GT Appearance.....................................................- 6 -
3.3. MIGE2210-2GF Appearance.....................................................- 6 -
3.4. MIGE2210-2GF-4F Appearance.............................................. - 7 -
3.5. LED Indicator Light...................................................................... - 7 -
3.6. Power Input Terminal.................................................................. - 8 -
3.7. Fiber Optic Connection...............................................................- 8 -
4. Hardware Installation..............................................- 11 -
4.1. Din-rail Installation..................................................................... - 11 -
4.2. Cable Connection...................................................................... - 11 -
5. Test Methods.............................................................- 13 -
5.1. Self-test Process........................................................................- 13 -
5.2. Gigabit Tx Port Test...................................................................- 13 -
5.3. 100M Tx Port Test..................................................................... - 13 -
5.4. Gigabit Fx Port Test...................................................................- 14 -
5.5. 100M Fx Test.............................................................................. - 14 -
5.6. Network Connection..................................................................- 15 -
6. Maintenance and Service...................................... - 16 -
6.1. Internet Service..........................................................................- 16 -
6.2. Product Repair or Replacement.............................................- 16 -

MIGE2210 Series Gigabit Din-rail Switch
- 1 -
1. Product Introduction
1.1. Product Description
The MIGE2210 series switches are high-performance unmanaged
industrial Ethernet switches with 10 Ethernet interfaces. The product includes 2
Gigabit Ethernet interfaces and 8 100M Ethernet interfaces, which are suitable
for applications with large bandwidth requirements.
This series of products has a power failure alarm output function, which is
convenient for field engineers to find and handle faults in time. The standard
35mm pitch DIN rail mounting method is ideal for industrial field installation
applications.
1.2. Features
1.2.1. High-performance Ethernet Switch Interface
Data processing type is storage and forwarding switching
Rich communication interface, providing multiple forms of Ethernet
interface
Provides two 1000Base-FX Gigabit Fx ports or
10Base-T/100Base-TX/1000Base-T adaptive Gigabit Tx ports (supports
automatic MDI/MDI-X connection)
100Base-FX 100M Fx port interface
10Base-T/100Base-TX adaptive 100M Tx port interface (supports
automatic MDI/MDI-X connection)
Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
standard
1.2.2. Industrial Power Supply Design
Power supply range: DC12V-48V, AD220V (optional)
Double redundant backup power input
Power supply with reliable over current, reverse connection and EMC
protection
Using environmentally friendly materials 5.08mm pitch easy to access
power terminals
1.2.3. Shell Design
Single ribbed aluminum chassis cooling surface design, no fan efficient
cooling, the system can work reliably in the environment of -40 ° C ~ +85 ° C
High-strength enclosed aluminum housing allows the system to work
reliably in harsh and dangerous industrial environments
Standard products are DIN rail mounted, and can also provide other
accessories required for installation.

MIGE2210 Series Gigabit Din-rail Switch
- 2 -
1.2.4. Dual Power Backup and Power Failure Alarm
MIGE2210 series products support dual power supply redundant input
function
The product has 1 relay alarm output function. When the switch is
powered off, the relay is closed, and other sound and light alarm devices can
be connected. Relay contact rated current is 1A@24VDC
1.2.5. Main Performance
Supports adaptive MDI/MDI-X, connecting straight and cross lines can
work normally
Supports a maximum frame size of 1518bytes
Support storm suppression
Support MAC address fast learning and aging
1.3. Industry Standard
EMI: FCC CFR47 Part 15，EN55022/CISPR22，Class A
EMS: IEC61000-4-2(ESD)±8KV(contact), ±15KV(air)
IEC61000-4-3(RS)10V/m(80MHz～2GHz)
IEC61000-4-4(EFT) Power port: ±4KV; Signal port: ±2KV
IEC61000-4-5(Surge) Power port: ±2KV/DM，±4kV/CM; Signal port: ±2KV
IEC61000-4-6(CS) 3V (10kHz~150kHz): 10V(150kHz~80MHz)
IEC61000-4-16(Common mode conduction) 30V(Continuous harassment):
300V(Short-term resident harassment)
Mechanical: IEC68-2-6 (vibration)
IEC68-2-27 (impact)
IEC68-2-32 (free fall)
Industry: IEC61000-6-2
Railway: EN50155, EN50121
1.4. Product Selection Table
Table 1- 1 Optional model of MIGE2210 series switches
Model
Gigabit
Fx port
Gigabit
Tx port
100M
Fx
port
100M
Tx
port
Power
supply
MIGE2210
-2GT
/
2
/
8
DC12-48V
MIGE2210
-2GT-AD2
/
2
/
8
DC110~37
0V/

MIGE2210 Series Gigabit Din-rail Switch
- 3 -
20
AC85~264
MIGE2210
-2GF
2
/
/
8
DC12-48V
MIGE2210
-2GF-AD2
20
2
/
/
8
DC110~37
0V/
AC85~264
MIGE2210
-2GF-4F(S
/M)
2
/
4
4
DC12-48V
MIGE2210
-2GF-4F(S
/M)-AD220
2
/
4
4
DC110~37
0V/
AC85~264
1.5. Packing List
The package of MIGE2210 series contains the following items. If any of
the following items are lost or destroyed, please contact the agent or Wuhan
Maiwe Communication Co., Ltd. Customer Service Center to assist you to
replace or make up.
Table 1-2 Industrial Ethernet switch product packaging list
Product name
Quantity
MIGE2210 series host
1
User manual
1

MIGE2210 Series Gigabit Din-rail Switch
- 4 -
2. Performance Indicators
System indicator
MIGE2210 Series Industrial Ethernet Switches
Number of ports
2 Gigabit Ethernet ports + 8 100M Ethernet
ports
System parameters
Supported standards: IEEE802.3 (10Base-T),
IEEE802.3u (100Base-TX), IEEE802.3x (flow
control)
MAC address table: 8K
Exchange mode: store and forward
Fx port parameter
Gigabit optical port: 1000Base-FX
Wavelength: 850nm (multimode); 1310nm
(single mode), 1550nm (single mode)
Transmission distance: 550m (multimode);
10-80km optional (single mode)
Connector Type: Shielded SFP Base
Transmission rate: 1.25Gbps
100M Fx port: 100Base-FX, interface
(SC/FC/ST) optional
Wavelength: 1310nm (single mode) 1550nm
(single mode) 1310 nm (multimode)
Transmission distance: 5Km (multimode); 20 to
80km (single mode)
Connector Type: SC/FC/ST
Transmission rate: 125Mbps
Tx port parameter
Physical interface: RJ-45 with shielding
RJ-45 port: 10Base-T/100Base-TX supports
auto-negotiation;
10Base-T/100Base-TX/1000Base-T supports
auto-negotiation
Transmission distance: 100 meters (using
standard CAT5, CAT5e network cable)
Power parameter
Input voltage: DC12V, DC24V, DC48V, AD220V
(optional)
Power consumption: MIGE2210-2GT;
2.9W@24VDC (no load); 6.4W@24VDC (full

MIGE2210 Series Gigabit Din-rail Switch
- 5 -
load)
MIGE2210-2GF: 2.4W@24VDC (no load);
3.8W@24VDC (full load)
MIGE2210-2GF-4F: 2.3W@24VDC (no load);
4.5W@24VDC (full load)
Over-current protection: built-in
Mechanical
parameter
Housing: metal, no fan
Physical size (length, width and height):
144*110.4*54mm (excluding DIN rail assembly
size)
Protection level: IP40
Installation method: DIN rail type
Working
environment
Working temperature: -40°C~+85°C
Storage temperature: -40°C~+85°C
Humidity: 5 to 95%(no condensation)

MIGE2210 Series Gigabit Din-rail Switch
- 6 -
3. Hardware Structure
3.1. Chassis
The chassis of the MIGE2210 series industrial Ethernet switches is a small
DIN rail structure. The whole machine adopts a six-sided fully enclosed
structure.
3.2. MIGE2210-2GT Appearance
The front panel of the MIGE2210-2GT integrates 2
10Base-T/100Base-TX/1000Base-T adaptive Tx ports and 8
10Base-T/100Base-TX adaptive Tx ports. See Figure 3-1 below.
Figure 3-1 Front panel of the MIGE2210-2GT
3.3. MIGE2210-2GF Appearance
The front panel of the MIGE2210-2GF integrates two 1000Base-FX optical
ports and eight 10Base-T/100Base-TX adaptive electrical ports. See Figure
3-2 below.
Figure 3-2 Front panel of the MIGE2210-2GF

MIGE2210 Series Gigabit Din-rail Switch
- 7 -
3.4. MIGE2210-2GF-4F Appearance
The front panel of the MIGE2210-2GF-4F integrates two 1000Base-FX
optical ports, four 100Base-FX optical ports, and four 10Base-T/100Base-TX
adaptive electrical ports. See Figure 3-3 below.
Figure 3-2 Front panel of the MIGE2210-2GF
3.5. LED Indicator Light
The LED indicators on the front panel of the MIGE2210 Series Industrial
Ethernet Switches show the status of the system operation and ports, making it
easy to detect and resolve faults. The specific meaning is shown in the table
3-1 LED indicator status list.
Table 3-1 LED indicator status list
RUN
Flicker
The system is running normally
On/ off
The system is not working properly.
PWR1/PWR2
(Red light)
On
Power connection
Off
Power is not connected
Gigabit RJ45 port status LED
10M/100M/100M
(Yellow light)
On
1000M/10M working status
Off
100M working status
LINK/ACT (Green
light)
On
The port has established an active
network connection
Flicker
Port has network activity
Off
The port does not have a valid network
connection
100M RJ45 port status LED
10M/100M
(Yellow light)
On
100M working status
Off
100M working status
LINK/ACT (Green
light)
On
The port has established an active
network connection
Flicker
Port has network activity
Off
The port does not have a valid network

MIGE2210 Series Gigabit Din-rail Switch
- 8 -
connection
Gigabit Fx port status LED
1000M (Green
light light)
On
The port has established an active
network connection
Off
The port does not have a valid network
connection
100M Fx port status LED
100M (Green
light)
On
The port has established an active
network connection
Off
The port does not have a valid network
connection
3.6. Power Input Terminal
The schematic diagram of the power input terminals of MIGE2210 series
switches is shown in the figure. As shown in Figure 3-4.
Figure 3-4 Power supply input terminals of the MIGE2210 series switches
Power input
The MIGE2210 Industrial Ethernet Switch can be configured for DC12V-
DC48V, and AD220V inputs. It uses a 5.08mm pitch with a locking terminal to
connect two power inputs. When the input is AD220V, only the PWR1 power
port is valid.
Power failure alarm output
The MIGE2210 series switches support the power-down alarm function.
When the switch is powered normally, the relay normally closes the contact
open circuit. When the switch has no power input or the input power is
abnormal, the relay contact is closed.
The user can use the relay contact to output other external sound and light
alarm devices.
3.7. Fiber Optic Connection
Among the MIGE2210 series, MIGE2210-2GF and MIGE2210-2GF-4F

MIGE2210 Series Gigabit Din-rail Switch
- 9 -
have two 1000Base-X full-duplex single-mode/multimode Fx interfaces, SFP
hot-swap devices, and LC interfaces. The fiber interface needs to be used in
pairs (TX and RX are a pair), the TX port is the optical transmitter, and the
optical transceiver RX of the optical interface of another remote switch is
connected; the RX port is the optical transceiver, and the same optical
interface is connected to the same remote switch. The light ends TX. Two
redundant 1000Base-X fiber interfaces can be used to connect to the optical
interfaces of two remote switches at the same time.
Figure 3-5 shows the optical module of an SFP.
Figure 3-5 Optical module of the SFP
The hot plugging procedure of the SFP module is as follows. The
schematic diagram is shown in Figure 3-6.
Hot plugging steps:
During the SFP period, observe the end of the PCB gold finger.
Insert the gold finger end into the metal shield cage of the SFP. When
you hear the sound of the cymbal, the device has been inserted into the
position, and then the SFP is inserted and removed, and placed in the normal
position parallel to the interface.
Hot extraction step:
Put the SFP plug and pull handle down perpendicular to the interface. At
this time, the optical device should be disconnected from the hook of the SPF
shielding cage.
Pull out the SFP modules in parallel.
Figure 3-6 Hot swap of an SFP module

MIGE2210 Series Gigabit Din-rail Switch
- 10 -
Attention
This switch uses a laser to transmit signals over fiber optic cables. The
laser meets the requirements of Class 1 laser products, and normal
operation is harmless to the eyes. However, when powering up the unit, do
not look directly at the optical transmission port and the fiber optic terminator
end face.

MIGE2210 Series Gigabit Din-rail Switch
- 11 -
4. Hardware Installation
4.1. Din-rail Installation
For most industrial applications, the 35mm standard DIN rail mounting is
very convenient. When you remove the device from the box, the DIN rail
connector is fixed to the rear panel of the MIGE2210 series switch. If you need
to mount the card on the DIN rail, you should check the DIN rail installation
before installation. It mainly includes the following two items:
Whether the DIN rail is fixed or not, and whether the DIN rail has enough
space for installing the switch.
Is there a power supply on the DIN rail suitable for the operation of this
switch?
After selecting the installation location of the switch, install the switch to
the DIN rail as follows:
Insert the upper part of the DIN rail into the card slot of the circlip on the
upper part of the DIN rail connector. Rotate the device slightly on the upper
panel of the switch and turn the device as shown in A in Figure 4-1.
Insert the DIN rail into the DIN rail connector as shown by B in Figure 4-1.
Make sure that the MIGE2210 series switch devices are securely mounted to
the DIN rail.
Figure 4-1 DIN rail installation of the MIGE2210 series switches
4.2. Cable Connection
After the MIGE2210 series switches are properly installed, the cable can
be installed and connected, including the cable connections of the following
interfaces.
Business interface:
The terminal devices provided by this series of products are Gigabit, 100M
Ethernet RJ45 interfaces and Gigabit and 100M Fx ports, so they can be
connected to terminal devices or network devices using direct-connected
network cables and fiber-optic cables.

MIGE2210 Series Gigabit Din-rail Switch
- 12 -
Connect power supply:
The MIGE2210 series switch devices use the power supply as indicated
on the product label. When all other cables are connected, you can connect to
the power supply.

MIGE2210 Series Gigabit Din-rail Switch
- 13 -
5. Test Methods
5.1. Self-test Process
The power-on self-test phenomenon of the device under no load is:
At the moment of power-on, all the 100 Mbps Tx port indicators on the
front panel will flash once, and the two Gigabit Tx port indicators will only
illuminate yellow before the RUN indicator starts flashing, and the two yellow
lights will be off after the RUN indicator flashes. Gigabit Fx ports and 100M Fx
indicators will only be lit when an effective network connection is established,
and will normally go out.
5.2. Gigabit Tx Port Test
As shown in Figure 5-1, the switch powers up and connects two
MIGE2210-2GT devices into a chain network. Each device is connected to a
Gigabit electrical port through a direct connection cable and connected to the
test computer. Ping packets, both sides can correctly ping to the other party
without losing packets. At this time, if the computer network card is 100M, the
network port speed light (yellow light) connected to the computer should be off;
if the computer network card is gigabit, then the switch is connected to the
computer with the network port speed light (yellow light) ) should be in the
steady state, so the green light (link/ack light) on the port should be flashing. If
you see the above phenomenon, the two Gigabit electrical ports tested are
working properly.
Figure 5-1 Gigabit Tx port test connection diagram
5.3. 100M Tx Port Test
As shown in Figure 5-2, the switch is powered on, and any two 100 Mbps
Tx ports are connected to the network ports of the two test computers through
the direct connection network cable. The ping command is sent to each other.
The yellow light on the corresponding port should be always on (the computer
network card works in the 100M state) or the normal off (the computer network

MIGE2210 Series Gigabit Din-rail Switch
- 14 -
card works in the 10M state). The green light should flash. If you see the above
phenomenon, it means that the two hundred megabytes of the tested hardware
are working properly.
Figure 5-2 Schematic diagram of the test connection of the 100M Tx port
5.4. Gigabit Fx Port Test
As shown in Figure 5-3, the switch powers on and connects the Gigabit Fx
ports of the two MIGE2210-2GF devices to each other through fiber-optic
cables. Each device can be connected to a test computer through a
direct-connected network cable. In the computer console, the ping packets are
sent to each other, and both parties can correctly ping each other without
losing packets. At this time, if the computer network card is ten megabytes,
then the network port speed light (yellow light) connected to the computer
should be off; if the computer network card is 100 megabytes, then the switch
is connected to the computer with the network port speed light (yellow light) )
should be always on, so the green light (link/ack light) on the port should be
flashing. If you see the above phenomenon, the two Gigabit optical ports tested
are working properly.
Figure 5-3 Gigabit Fx port test connection diagram
5.5. 100M Fx Test
As shown in Figure 5-4, the switch is powered on, and the 100M Fx ports

MIGE2210 Series Gigabit Din-rail Switch
- 15 -
of the two MIGE2210-2GF-4S/M devices are connected by fiber cables. Each
device is connected to a 100-Mbps Tx port through a direct-connected network
cable and tested. The computers are connected, and the ping packets are sent
to each other in the computer console, and both parties can correctly ping each
other without losing packets. At this time, if the computer network card is 10M,
then the network port speed light (yellow light) connected to the computer
should be off; if the computer network card is 100M, then the switch is
connected to the computer with the network port speed light (yellow light) )
should be always on, so the green light (link/ack light) on the port should be
flashing. If you see the above phenomenon, the two 100M Fx port of the tested
hardware are working properly.
Figure 5-4 Schematic diagram of the 100M Fx port test connection
5.6. Network Connection
MIEN2210 series industrial Ethernet switches are equipped with 8 100M
Ethernet ports and 2 Gigabit Ethernet ports. Each RJ45 port can be directly
connected to the terminal device, or it can be connected to another industrial
Ethernet switch/hub in front of the terminal device. Used as a shared
connection. As shown below.
Figure 5-5 Network connection diagram

MIGE2210 Series Gigabit Din-rail Switch
- 16 -
6. Maintenance and Service
Wuhan Maiwe Communication Co., Ltd. provides a five-year product
warranty from the date of shipment. According to the product specifications
during the warranty period, if there is any malfunction or functional failure of the
product, we will repair or replace the product for the user without charge.
However, the above commitments do not cover damage caused by improper
use, accidents, natural disasters, improper operation or improper installation.
In order to ensure that consumers benefit from the series of products of
Wuhan Maiwe Communication Co., Ltd., help and problem solving can be
obtained by the following methods:
Internet service
Call the technical support office
Product is repaired or replaced.
6.1. Internet Service
Through the technical support section of Wuhan Maiwe Communication
Co., Ltd., you can get more useful information and tips.
6.2. Product Repair or Replacement
Product repair, replacement or return, in accordance with the processing
procedures of Wuhan Maiwe Communication Co., Ltd., should contact our
sales staff to complete Repair, replacement or return of the product.
