Makeblock Mars Exploration Base Instruction Manual

Building Instructions
Mars Exploration Base

Take out the wood boards.
12
Pro tips
Use the sandpaper included to sand
a smooth finish on the wood board
before you start installing it.
Install the power module.
0
1
3
2
0
1
3
2
Front (with marks) Back (without)
Make sure you correctly identify the
front and back sides. The front side
has marks while the back side has no
marks.
Ensure this front
side faces up.

5
4Insert a 10cm connection cable to the right
port of the servo driver.
Add the servo driver. 6Connect the servo driver to the power
module.
20 cm
10 cm
Add the motor driver.
3

8Join the wood boards. Bind them using rubber bands as shown.Attach an M4 adapter to the board.
7
Attach the rubber band.
Rotate
Attach the
rubber band.

9Adjust the servo hub. Add the wood board to the servo hub.
10
Turn the servo hub clockwise
all the way to the bottom.
Turn the servo hub's
opening to the side of the
servo with a ring mark.
Ensure the
swallow-tailed side
faces this way.

11 Install the servo. 12 Combine the wood boards. Bind them using a rubber band as shown.
Tighten the stud.
M3 *14mm
M3 *30mm
1:1
Attach the rubber
band.
Rotate

Attach it to the board. Push
the rivets all the way down to
the bottom.
13 Add the side board. Bind them using rubber bands. Combine the cardboard and the wood board with rivets.
14
Attach the rubber band.
Attach the rubber band.
Attach the rubber band.
Align the holes on the
cardboard and wood board.
Push the rivets through the
holes all the way down to
the bottom.
Take out the
cardboard piece.

Attach Halocode to the board.
1615 Insert the servo cable into the servo driver.
M3 *14mm
M3 *30mm
1:1
Ensure the Micro USB
port faces this way. Put
down Halocode.
Back side
Tighten the stud.
Follow the same steps to install
the rest screws and studs.
Front (with marks) Back (without)
Make sure you correctly identify the
front and back sides. The front side
has numbers marks.
0
1
3
2

Assemble the motor.
18
Combine the wood boards. Bind them using rubber bands as shown.
17
M3 *14mm
M3 *30mm
1:1
3
2
Tighten the studs.
Ensure the motor cable
faces downward.
Attach the rubber band.
Attach the rubber band.

Insert the motor cable into the motor
driver.
20 Join the wood boards. Bind them
using a rubber band as shown.
21
Combine the wood boards. Bind them using rubber bands as shown.
19
Attach the rubber band.
Flip
Attach the
rubber band.
Attach the
rubber band.

Insert the board into the motor bearing.
22 Use a 10cm cable to connect the power module to the motor driver. 23
Pro tips
Check the video tutorials in the
software to view building guides.
20 cm
10 cm

Use a 10cm cable to connect Halocode to the servo driver. Excellent! You completed the Mars Exploration Base.
24 25
20 cm
10 cm

Now, return to mBlock on your PC or iPad and program your project.
mBlock
https://hezi.makeblock.com
26
