MakerBot Replicator User manual

REFERENCE GUIDE

VERSION 1
Legal Notices................................................................................................................................. 5
Safety and Compliance............................................................................................................. 7
Diagrams.........................................................................................................................................9
About MakerBot Desktop......................................................................................................... 11
Printing with MakerBot Desktop.......................................................................................... 15
MakerBot PrintShop.................................................................................................................22
MakerBot Mobile........................................................................................................................22
Updating Firmware ...................................................................................................................23
Troubleshooting........................................................................................................................ 24
Specifications .............................................................................................................................27
Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Contact Us .................................................................................................................................. 30
TABLE OF CONTENTS
The product may dier slightly from the images and instructions in this guide as we continue to improve the MakerBot
Replicator Mini. Please see www.makerbot.com/um_rep_mini for the latest version of the guide.

REFERENCE REFERENCE 45
PRODUCT WARRANTY
The MakerBot®Replicator®Mini Compact3D Printer is covered by a limited warranty.
For terms and conditions, see makerbot.com/legal.
OVERALL PROVISIONS
All information in this reference guide (“Guide”) is subject to change at any time without
notice and is provided for convenience purposes only. MakerBot Industries, LLC and our
respective aliates and suppliers (“MakerBot”) reserves the right to modify or revise this
Guide in its sole discretion and at any time and makes no commitment to provide any such
changes, updates, enhancements, or other additions to this Guide in a timely manner or
at all. You agree to be bound by any modifications and/or revisions. Contact the MakerBot
Support Team for up-to-date information.
In order to protect MakerBot proprietary and confidential information and/or trade secrets,
this document may describe some aspects of MakerBot technology in generalized terms.
INTELLECTUAL PROPERTY
The design of this Guide and all text, graphics, information, content, and other material are
protected by copyright and other laws. The contents are copyright 2009, 2010, 2011, 2012,
2013, 2014 MakerBot. All rights reserved. Certain trademarks, trade names, service marks,
and logos (the “Marks”) used in this Guide are registered and unregistered trademarks,
trade names, and service marks of MakerBot and its aliates. Nothing contained in this
Guide grants or should be construed as granting, by implication, estoppel, or otherwise,
any license or right to use any Marks without the written permission of MakerBot. Any
unauthorized use of any information, materials, or Marks may violate copyright laws,
trademark laws, laws of privacy and publicity, and/or other laws and regulations.
DISCLAIMERS
MakerBot does not warrant the accuracy or completeness of the information, products,
or services provided by or through this Guide and assumes no responsibility for any
typographical, technical, or other inaccuracies in this Guide, which is provided “as is”
and without any express or implied warranties of any kind, including warranties of
merchantability, fitness for a particular purpose, or non-infringement of intellectual
property. In connection with your use of this Guide, MakerBot shall not be liable to
you for any damages whatsoever, be they direct, economic, commercial, special,
consequential, incidental, exemplary, or indirect damages, even if MakerBot has been
advised of the possibility of such damages, including without limitation, loss of business
revenue or earnings, lost data, or lost profits. MakerBot assumes no responsibility,
nor will be liable, for any damages to, or any viruses or malware that may infect, your
computer, telecommunication equipment, or other property caused by or arising from
your downloading of any information or materials related to this Guide. The foregoing
exclusions do not apply to the extent prohibited by law; please refer to your local laws for
any such prohibitions.
LEGAL NOTICESLEGAL NOTICES

REFERENCE 7
SAFETY AND COMPLIANCE
Safety alert symbols precede each safety message in this manual. These symbols indicate
potential safety hazards that could harm you or others or cause product or property damage.
Warning: The MakerBot Replicator Mini Compact 3D Printer generates high temperatures.
Always allow the MakerBot Replicator Mini to cool down before you reach inside.
Warning: The MakerBot Replicator Mini includes moving parts that can cause injury.
Never reach inside the MakerBot Replicator Mini while it is in operation.
Warning: There is a risk of shock. This product is not user serviceable.
Warning: Do not leave the MakerBot Replicator Mini unattended during operation.
Caution: Do not print using materials that have not been approved by MakerBot for
use with the MakerBot Replicator Mini. Refer to the Specifications section on page 27
for more information.
Caution: The socket outlet must be located near the equipment and must be
easily accessible.
Caution: In case of emergency disconnect the MakerBot Replicator Mini from the
wall socket.
Caution: The MakerBot Replicator Mini melts plastic during printing. Plastic odors
are emitted during this operation. Make sure to set up the MakerBot Replicator Mini in
a well-ventilated area.
Caution: Do not look directly at any operating LED component.
WELCOME TO THE
REFERENCE MANUAL FOR
THE MAKERBOT REPLICATOR
MINI COMPACT 3D PRINTER.
The MakerBot®Replicator®Mini is super easy to use,
but it’s also packed with brand-new features. Use
this reference guide to familiarize yourself with
the capabilities of your new MakerBot Replicator
Mini and the MakerBot Desktop App.

REFERENCE REFERENCE 89
SAFETY AND COMPLIANCE
RADIO AND TELEVISION INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• • Reorient or relocate the receiving antenna.
• • Increase the separation between the equipment and the receiver.
• • Connect the equipment to an outlet on a circuit dierent from that to which the
receiver is connected.
• • Consult the dealer or an experienced radio/TV technician for help.
You may also find helpful the following booklet, prepared by the FCC: “How to Identify and
Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government
Printing Oce, Washington, DC 20402.
Changes and modifications not expressly approved by the manufacturer or registrant of this
equipment can void your authority to operate this equipment under FCC rules.
MANUFACTURER
MakerBot Industries, LLC
One MetroTech Center, 21st Floor
Brooklyn, NY 11201
347.334.6800
DIAGRAMS
MAKERBOT REPLICATOR MINI FRONT VIEW
1. Filament Spool Pocket
2. Gantry
4. Build Plate
5. Action Button
1
2
4
5
3
3. Filament Guide Tube

REFERENCE REFERENCE 10 11
MakerBot Desktop is a free app for preparing 3D prints and managing your 3D content.
It consist of four sections: Explore, Library, Prepare, and Store.
1. Explore gives you access to MakerBot Thingiverse®and the hundreds of thousands of
3D printable objects designed by the Thingiverse community. Use Explore to search
Thingiverse for inspiration or for new things to print, then save them to your collections or
prepare them for printing.
2. Library gives you access to your MakerBot Cloud Library and helps you organize your
3D model files. Use it to access things you’ve collected on Thingiverse or bought from the
MakerBot Digital Store as well as your own models.
3. Prepare is where you will turn 3D models into print files. Bring 3D models into the
Prepare screen to manipulate them on a virtual build plate. Then specify print options
and send print files to your MakerBot Replicator Mini.
4. Store lets you buy print files for premium 3D models. The MakerBot Digital Store
sells original, fun, and collectible digital content specifically designed for MakerBot
Replicator Desktop 3D Printers. When you buy a model from the MakerBot Digital Store,
a print file for your MakerBot Replicator Mini will be added to your MakerBot Cloud Library.
Use Store and Explore to find 3D models, Library to keep them organized, and Prepare
to send them to your MakerBot Replicator Mini for printing.
ABOUT MAKERBOT DESKTOP
1 2 3 4
MAKERBOT REPLICATOR MINI SIDE VIEW
7. Power Input Port 9. Extruder Assembly
6. Power Switch 8. USB Port
DIAGRAMS
9
6
7
8

REFERENCE REFERENCE 12 13
1. +/–
• • Click the Plus and Minus buttons to zoom in and out.
• • You can also zoom using a track pad or the scroll wheel on your mouse.
•
2. Home View
• • Click the Home View button to return to the default view of the build plate.
•
3. View
• • Click the View button or press the V key to go into View mode.
• • In View mode, click and drag with your mouse to rotate the build plate.
• • In View mode, hold the Shi key and click and drag with your mouse to pan.
• • Click the View button again to open the Change View submenu and access preset views.
ABOUT MAKERBOT DESKTOP ABOUT MAKERBOT DESKTOP
THE PREPARE SCREEN 4. Move
• • Click the Move button or press the M key to go into Move mode.
• • In Move mode, click and drag with your mouse to move your model around
on the build plate.
• • In Move mode, hold the Shi key and click and drag with your mouse to move your
model up and down along the z-axis.
• • Click the Move button again to open the Change Position submenu and move your
object by a specific distance along the x-, y-, or z-axis.
•
5. Turn
• • Click the Turn button or press the T key to go into Turn mode.
• • In Turn mode, click and drag with your mouse to rotate your model around the z-axis.
• • Click the Turn button again to open the Change Rotation submenu and rotate your
object by a specific number of degrees around the x-, y-, or z-axis.
6. Scale
• • Click the Scale button or press the S key to go into Scale mode.
• • In Scale mode, click and drag with your mouse to shrink or enlarge your model.
• • Click the Scale button again to open the Change Dimensions submenu and scale
your object by a specific amount along the x-, y-, or z-axis.
•
7. File Name
• • The file name bar displays the name of the file or layout currently open. Thing files
can include multiple layouts, or arrangements of models on the plate.
8. Settings
• • Click Settings to open the settings dialog.
• • Use the dialog to change print settings for the current model or layout.
9. Add File
• • Click Add File to open an Open File dialog.
• • Navigate to the location of any STL, OBJ, or Thing file and select the file to add
• a model to the build plate.
• • Add as many models to the plate as you like.
• • Duplicate models already on the plate using the Copy and Paste options in the Edit
menu or the keyboard shortcuts Ctrl/Command+C and Ctrl/Command+V.
12
3
1
2
4
5
6
8 9 10 117

REFERENCE REFERENCE 14 15
ABOUT MAKERBOT DESKTOP PRINTING WITH MAKERBOT DESKTOP
10. Save
• • Click Save to open a Save dialog.
• • If you are logged into your MakerBot account, you can choose to save to your Library
or to your local computer. See makerbot.com/support for more information on
your MakerBot Cloud Library.
• • If you are not logged into your MakerBot account or if you are working oine, you
will be able to save your file only to your local computer.
• • If you are working in an existing Thing file, you can rearrange the models on the
plate and save this new layout to the Thing file without overwriting earlier layouts.
•
11. Print
• • Click Print to slice the model and send the print file to your MakerBot Replicator Mini.
• • Within the Print dialog, click Print Preview to open a preview of the sliced model.
•
12. Status
• • The status bar displays the connection status of any connected MakerBot
Desktop 3D Printer.
• • The status bar displays the progress of the current print.
• • Click the menu icon at the right side of the status bar to open a print monitor panel,
which will display more detailed information about your MakerBot Replicator Mini
and any print in progress, including a feed of images from the onboard camera.
• • Open the print monitor panel to pause or cancel a print, change filament, or change
Smart Extruder.
1 CHOOSING YOUR MODEL
You can download a model from Thingiverse or the MakerBot Digital Store, open a 3D
printable STL file from any source, or access objects that are already saved in your MakerBot
Cloud Library.
FINDING A MODEL ON THINGIVERSE
1. In MakerBot Desktop, click on the Explore tab. Click Explore at the right to browse
available models, or use the search bar to look for something specific.
2. Click the thumbnail or name of any Thing to go to the Thing page.
3. On the Thing page, scroll down and click on Thing Files to see available files.
4. Choose which part or version you want to print and click the Prepare button next
to the file name.
5. MakerBot Desktop will open the file and take you to the Prepare tab. The file you selected
will appear on the build plate.
6. To add an additional model from the same Thing to your layout, return to the Explore tab and
click Prepare next to the name of the additional file. The new model will be added to the plate.
Aer you’ve made your first print with the help of the Setup Assistant, you can continue
printing with your MakerBot Replicator Mini by following these simple steps:
1. Choose a Model
2. Prepare to Print
3. Print Your Model
4. Post Print Steps

REFERENCE REFERENCE 16 17
PRINTING WITH MAKERBOT DESKTOP PRINTING WITH MAKERBOT DESKTOP
CHOOSING A MODEL FROM YOUR MAKERBOT CLOUD LIBRARY
1. In MakerBot Desktop, click on the Library tab.
2. Click one of the folders at the le side of the screen to see items available in your Library.
3. Click on a list item and then click Prepare. MakerBot Desktop will open the file and take
you to the Prepare tab. The file you selected will appear on the build plate.
1.
FINDING A MODEL IN THE MAKERBOT DIGITAL STORE
1. In MakerBot Desktop, click on the Store tab.
2. Browse the Digital Store collections or use the search bar to find a model by name.
3. Once you’ve found a model or series you’d like to purchase, click BUY NOW.
4. If you haven’t already, set up your billing information.
5. Confirm your purchase. A print file for your purchased model will appear in your
MakerBot Cloud Library.
IMPORTING A MODEL FROM YOUR LOCAL COMPUTER
You can open any 3D-printable STL or OBJ file in MakerBot Desktop.
1. In MakerBot Desktop, click on the Prepare tab.
2. Click Add File.
3. Navigate to the location of your file and click Open. The model will appear on the build plate.
2 PREPARING YOUR MODEL
Use the Prepare Screen to manipulate your model, such as changing its orientation or
scaling it to a new size. You can also add more models to the layout. Then, to change
any print settings before you print, click the Settings button.
SETTINGS
The Settings dialog allows you to select options that will aect the quality of your printed object.
1. Supports. Select this checkbox to have
your object printed with support structures.
MakerBot Desktop will automatically
generate supports for any overhanging
sections of your object. Supports will be
easily removable once you remove your
finished object from the build plate.
2. Advanced Settings. Some options have
been grayed out to make your printing
experience with the MakerBot Replicator
Mini as simple and as easy as possible.
You can still access additional options
by clicking on Advanced Options. For
information on what the advanced
settings are and how to use them, go to
makerbot.com/support/makerbot-desktop.

REFERENCE REFERENCE 18 19
SENDING THE FILE TO THE MAKERBOT REPLICATOR MINI
If Connected via Wi-Fi
1. Click the Print button to slice your model
and send it to your MakerBot Replicator Mini.
2. When the print file is sent to the MakerBot
Replicator Mini, the Action Button will blink
blue. Press the Action Button to confirm
the print. The Action Button will then glow
red, indicating it is heating the MakerBot
Replicator Smart Extruder. When the Smart
Extruder is fully heated, the MakerBot
Replicator Mini will start to print your model.
3. Click OK to exit the print dialog, or, to
cancel the print, click Cancel Print.
If Connected via USB Cable
1. Click the Print button to slice your model. To
send the file to your MakerBot Replicator Mini
and exit the Print dialog, click Start Print.
If you decide not to send the file to the MakerBot Replicator Mini, click Cancel Print.
2. When the print file is sent to the MakerBot Replicator Mini, the Action Button will blink
blue. Press the Action Button to confirm the print. The Action Button will then glow red,
indicating it is heating the MakerBot Replicator Smart Extruder. When the Smart Extruder is
fully heated, the MakerBotReplicator Mini will start to print your model.
In the Print dialog, click Print Preview to see:
• • estimated print time
• • estimated amount of filament your print will use
• a rendering of what your print will look like
•
PRINTING WITH MAKERBOT DESKTOP PRINTING WITH MAKERBOT DESKTOP
3 PRINTING YOUR MODEL HOW TO PAUSE OR CANCEL A PRINT
To Pause: While the MakerBot Replicator Mini is printing, press the Action Button once to
pause. The Action Button color will turn from red to blue. Press the Action Button again to
resume printing, or press and hold the Action Button to cancel the print. You can also pause
by opening the print monitor panel in MakerBot Desktop and then clicking Pause.
To Cancel: While the MakerBot Replicator Mini is heating or printing, press and hold the
Action Button to cancel the print. You can also cancel by opening the print monitor panel in
MakerBot Desktop and then clicking Cancel.
If you are printing a file from Thingiverse, you will be prompted to share a photo once your
print is finished. Photos shared to Thingiverse will appear on the Thing page in the I Made
One! section. Sharing a photo is a nice thing to do – other Thingiverse users will love to see
how your prints of their designs come out.
To share a photo, click Share to Thingiverse. If you do not wish to share a photo of your
print to Thingiverse, click Back to Menu.
When your print finishes, wait for the Smart Extruder to cool, then remove the build plate
from the MakerBot Replicator Mini. Remove the print from the build plate, and peel o the
ra from the bottom of the print. Every object printed on your MakerBot Replicator Mini will
be built on a ra. The ra acts as a base for your object and any support structures, and
ensures that everything adheres well to the build plate. The ra will be easily removable
once you remove your finished object from the build plate.
Caution: Never turn o the MakerBot Replicator Mini during or immediately aer printing,
or when the Action Button is red. Wait a few minutes before powering down.
4 POST PRINT STEPS

REFERENCE REFERENCE 20 21
PRINTING WITH MAKERBOT DESKTOP PRINTING WITH MAKERBOT DESKTOP
HOW TO CHANGE FILAMENT
You can change filament at any time when the MakerBot Replicator Mini is not heating up
or printing.
• • When the MakerBot Replicator Mini is in an idle state and the Action Button is white,
press and hold the Action Button to initiate a filament change. Alternatively, you can
click the status bar in MakerBot Desktop, and then click Change Filament in the
print monitor panel.
• • If the MakerBot Replicator Mini senses loaded filament, the motor will turn
backward to unload it. Wait while the Smart Extruder unloads your filament. When
the filament stops backing out of the Smart Extruder, squeeze the tabs on the side
of the Smart Extruder and gently pull the filament free. If the MakerBot Replicator
Mini senses no loaded filament, the motor will turn forward to load new filament. Push
the filament until you feel the Smart Extruder pulling it in.
• • Before removing the current filament spool, unclip the filament guide tube from the
spool pocket.
• • Clip the filament guide tube back into place aer inserting the new filament spool.
• • During a filament change, pressing the Action Button will cancel the filament change.
• • During a filament change, pressing and holding the Action Button will change the
motor’s direction.
HOW TO CHANGE THE SMART EXTRUDER
If you need to remove the Smart Extruder from your MakerBot Replicator Mini, first unload
any filament.
Wait for the Smart Extruder to cool, then pull it away from the extruder carriage. MakerBot Desktop
will detect that the Smart Extruder is no longer attached and will open a dialog box guiding you
through the process of reattaching the extruder or attaching a new one. Click Attach Extruder. When
MakerBot Desktop directs you to, press your extruder against the back of the extruder carriage, with
the connector pins facing the extruder carriage. Magnets will lock the Smart Extruder into place.
Warning: Always use caution when handling the Smart Extruder. Never remove the
Smart Extruder during or immediately aer printing, or when the Action Button is red.
Wait a few minutes before handling the Smart Extruder.
HOW TO TAKE A PHOTO
You can take a photo of your print at any time using the built-in camera in the MakerBot
Replicator Mini. Click the print monitor panel in MakerBot Desktop, mouse over the current
displayed photo, and click Take a Picture. MakerBot Desktop will take a picture and let you
save it to your local computer. You must be connected to a Wi-Fi network to use the camera.
HOW TO FOCUS THE CAMERA
When you connect your new MakerBot Replicator Mini to MakerBot Desktop for the first time, the
camera image may be blurry. You will need to focus it manually to get the best image possible.
To focus the camera:
1. Connect the MakerBot Replicator Mini
to MakerBot Desktop via a Wi-Fi network
and open the print monitor panel.
2. Locate the camera. It is mounted inside the
le front corner of the MakerBot Replicator Mini.
3. Grasp the plastic ring around the lens
and twist it slightly. Avoid touching the
camera lens itself.
4. Check the camera feed and wait for the image to refresh. If the image is clearer than it
was before, continue twisting the lens in the same direction. If the image is less clear, start
twisting the lens in the opposite direction.
5. Twist in small increments and check the camera feed frequently. When the image is clear
and twisting in either direction makes it more blurry, stop making adjustments. You have
successfully focused the onboard camera.

REFERENCE REFERENCE 22 23
MAKERBOT PRINTSHOP™
MAKERBOT MOBILE
MakerBot PrintShop is a free app that allows you to design and customize prints, explore
and print from Thingiverse, and monitor and control your MakerBot Replicator Mini, all from
your tablet.
MakerBot Printshop has three features: Makers,Explore, and My Stu.
With the Maker tools, you can customize designs such as signs and bracelets using base
models provided by the app.
In Explore, you can browse a selection of ready-to-print items from Thingiverse.
In My Stu, you can access all recent prints initiated from MakerBot Printshop, as well as
your saved customized designs.
Once you initiate a print with MakerBot PrintShop, you can monitor that print as it’s
happening. The onboard camera on your MakerBot Replicator Mini will periodically take
photos of the build area, viewable right on your tablet. You can also pause and cancel prints
directly from MakerBot PrintShop.
To learn more about MakerBot Printshop, go to makerbot.com/printshop
MakerBot Mobile is a free app that allows you to monitor and control your MakerBot
Replicator Mini on your smartphone. You can start, pause, and cancel prints directly from
MakerBot Mobile, as well as receive notifications about your print, such as print completion
and any errors that may occur.
MakerBot Mobile gives you access to your MakerBot Cloud Library and Thingiverse. You can
print any sliced file via MakerBot Mobile and then monitor the print as it’s happening.
To learn more about MakerBot Mobile, go to makerbot.com/mobile
Firmware is the soware that runs on your MakerBot Replicator Mini. Keeping your firmware
up to date will help ensure that your MakerBot Replicator Mini is in the best possible working
order. Firmware updates allow MakerBot to add new features to your MakerBot Replicator
Mini and improve old ones.
MakerBot Desktop will let you know if there’s a firmware update available. To upgrade to the
new version, just select Update Firmware from the Devices menu. The soware will walk
you through the steps to bring your MakerBot Replicator Mini up to date.
UPDATING FIRMWARE

REFERENCE REFERENCE 24 25
TROUBLESHOOTING
PROBLEM SOLUTION
Can’t unload filament from
the MakerBot Replicator
Smart Extruder.
In the print monitor panel of MakerBot Desktop,
click change filament, and then select load
filament. Let the filament extrude for a few
seconds. Then try unloading again.
Can’t remove filament from
the MakerBot Replicator
Smart Extruder.
Try unloading the filament while squeezing the
tabs on the side of the Smart Extruder and pulling
on the filament.
Filament breaks between the
spool and the MakerBot Replicator
Smart Extruder.
Ensure that the filament unwinds counterclockwise
from the spool. Always unload any filament le
in the Smart Extruder before reloading. Make
sure the filament guide tube is secured to the
filament spool pocket.
Filament won’t extrude from
the Smart Extruder.
Try unloading and reloading the filament.
Hold and press the Action Button to initiate
a filament change. When the filament is free
from the extruder, the motor will reverse
direction, allowing you to reload the filament.
You may be able to avoid jams in the future
by allowing the Smart Extruder to cool before
turning o your MakerBot Replicator Mini.
TROUBLESHOOTING
PROBLEM SOLUTION
Printed object is stuck
to the build plate.
Remove the build plate from your MakerBot
Replicator Mini and wait for the object to cool
down. Objects will detach more easily aer they
have cooled.
If the object is still stuck, take a thin metal cra
spatula and carefully work the blade under the
edge of the object. When the blade is most of the
way under the object, twist the handle slightly.
The object should come free.
Object peels o the build plate
during printing.
Ensure that the build plate is clean. Dust and oil
from your hands or tears and wrinkles in any tape
covering the plate surface can prevent objects
from sticking to the plate. Wipe down the build
plate with a clean, lint-free cloth.
Object isn’t sticking to
the build plate.
Make sure that build plate tape is not covering
the metal disks at the back of the build plate.
Covering the metal disks may interfere with the
automated leveling process.
My front door popped o.
What do I do?
The front door is designed to pop o without
being damaged. Simply snap it back onto its
hinges.
PRINTING PROBLEMS PRINTING PROBLEMS

REFERENCE REFERENCE 26 27
PROBLEM SOLUTION
Can’t access the Library,
Explore, and Store sections
of MakerBot Desktop.
You may not be logged into your MakerBot
account. These features are accessible only when
you are logged in. If you are logged into your
MakerBot account but are still unable to access
the Library, Store, and Explore sections, your
computer may not be connected to the internet.
MakerBot Desktop does
not recognize the MakerBot
Replicator Mini.
Make sure you have selected the MakerBot
Replicator Mini as the printer you want to
connect to in MakerBot Desktop. Go to Devices
> Connect to a New Device, and select the
MakerBot Replicator Mini from the list of
available networked printers.
The MakerBot Replicator
Smart Extruder is installed,
but MakerBot Desktop
displays a message
stating it is not installed.
Remove the Smart Extruder. Follow
the instructions in MakerBot Desktop
for reattaching it.
I don’t see a camera feed in the
print monitor panel.
Make sure your MakerBot Replicator Mini is
connected to a Wi-Fi network. The camera will
not work if connected only via USB cable.
SPECIFICATIONS
PRINTING
Print Technology: Fused deposition modeling
Build Volume: 10.0 W x 10.0 D x 12.5 H cm [3.9 W x 3.9 D x 4.9 H in]
Layer Resolution: 200 microns
Filament: 1.75 mm [0.069 in] MakerBot PLA Filament
Nozzle Diameter: 0.4 mm [0.015 in]
Print File Type: .makerbot
SOFTWARE
Soware Bundle: MakerBot Desktop
3D Model File Types: .stl, .obj, .thing
Supported OS: Windows (7+), Mac OS X (10.7+), Linux (Ubuntu 12.04+, Fedora 19+)
PHYSICAL DIMENSIONS
Printer: 29.5 W x 31.0 D x 38.1 H cm [11.6 W x 12.2 D x 15.0 H in]
Shipping Box: 38.7 W x 39.7 D x 52.7 H cm [15.3 W x 15.6 D x 20.8 H in]
Printer Weight: 8 kg [18 lbs]
Shipping Weight: 10 kg [22 lbs]
TEMPERATURE
Ambient Operating
Temperature: 15-26°C [60-78°F]
Storage Temperature: 0-38° C [32-100° F]
ELECTRICAL
Power Requirements: 100-240 V, 50/60Hz, 0.75-0.41 A, 100 W
Connectivity: USB, Wi-Fi
MECHANICAL
Construction: PC ABS with powder-coated steel reinforcement
Build Surface: Injection molded acrylic
Stepper Motors: 1.8° step angle with 1/16 micro-stepping
XY Positioning Precision: 11 microns [0.0004 in]
Z Positioning Precision: 2.5 microns [0.0001 in]
CAMERA
Camera Resolution: 320 x 240
TROUBLESHOOTING
CONNECTIVITY PROBLEMS

REFERENCE REFERENCE 28 29
GLOSSARY
BUILD PLATE: The acrylic surface on which
the MakerBot Replicator Mini builds an object.
BUILD PLATE TAPE: Masking tape used
as a build surface for objects printed with
MakerBot PLA Filament. You can find build
plate tape sized for the MakerBot Replicator
Mini at http://store.makerbot.com
EXTRUDER ASSEMBLY: The MakerBot
Replicator Smart Extruder installed in the
extruder carriage.
EXTRUDER CARRIAGE: The part of the
extruder assembly that sits on the gantry
and moves back and forth. When the Smart
Extruder is installed in the extruder carriage,
the extruder assembly is complete.
EXTRUDER NOZZLE: The opening on
the end of the Smart Extruder from which
heated MakerBot PLA Filament emerges
to be spread onto the build plate.
FIRMWARE: The soware that runs on your
MakerBot Replicator Mini.
GANTRY: The apparatus that allows the
extruder assembly to move around.
LAYOUT: An arrangement of 3D models on
the build plate.
.MAKERBOT: The format of print files for
your MakerBot Replicator Mini. Print files
contain instructions for your MakerBot
Desktop 3D printer.
MAKERBOT ACCOUNT: The username
and password you will use to sign in to the
MakerBot Desktop app and to log on to
Thingiverse and other MakerBot sites.
MAKERBOT CLOUD LIBRARY: The part of
MakerBot Desktop where you can store and
organize your own design files as well as any
files you have downloaded from or collected
on Thingiverse.
MAKERBOT DESKTOP: Free soware
for use with your MakerBot Replicator
Desktop 3D Printer. MakerBot Desktop
will help you discover, manage, share,
and print 3D models.
MAKERBOT DIGITAL STORE: A digital
store where you can download premium
3D content.
MAKERBOT PLA FILAMENT: Polylactic
acid filament. PLA is a corn-based
thermoplastic. MakerBot PLA Filament is
the material from which you make objects
on the MakerBot Replicator Mini.
MAKERBOT REPLICATOR MINI:
The MakerBot Replicator Mini Compact
3D Printer.
GLOSSARY
.OBJ: A file format used for 3D models.
PRINT PREVIEW: The feature in the Print
dialog that provides an estimated print time,
estimated amount of filament your print will
use, and a rendering of what your print will
look like.
RAFT: A plastic base printed on the build
plate and used as a printing surface for your
printed object. All models printed on the
MakerBot Replicator Mini will be printed
with a ra.
SETTINGS DIALOG: The dialog that allows
you to select options that will aect the
quality of your printed object.
SLICING: The process of turning a 3D model
into a print file containing instructions for
your MakerBot 3D printer. The MakerBot
Replicator Mini uses print files with the
extension .makerbot.
SMART EXTRUDER: The MakerBot
Replicator Smart Extruder draws the
filament from the spool, melts it, and pushes
it through a nozzle onto the build plate.
.STL: A widely used file format for
3D models.
SUPPORTS: Automatically generated
support structures used to prop up any
sections of a print that will not stand alone.
.THING: A file format used by MakerBot
Desktop that stores additional information
about your 3D model files, such as
orientation and location on the build plate.
THINGIVERSE: MakerBot Thingiverse, an
online community for sharing 3D design files.
USB CABLE: A cable that allows your
computer to communicate with your
MakerBot Replicator Mini.

REFERENCE REFERENCE 30 31
CONTACT US
Support makerbot.com/support
Our website has extensive documentation and
troubleshooting information about your
MakerBot Replicator Mini. It’s a great resource
when you want to try to solve issues quickly on
your own.
makerbot.com/support/submit-a-case/
At MakerBot, we take pride in oering expert,
responsive, friendly customer support to all of
our customers around the world. If you need
help resolving an issue with your MakerBot
Replicator Mini, open a case with the MakerBot
Support Team at the web address above.
Sales sal[email protected]om
To learn about other MakerBot products,
including MakerBot PLA Filament, please email
the address above, or call our Sales Team at
347. 334.6800.
Feedback [e-mail]
For general questions, or to tell us what’s on
your mind, send an email to the address above.
We love to hear from you, and using this email
address helps keep our Sales and Support lines
free for customers in need.
NOTES

MakerBot One MetroTech Center, 21st Floor, Brooklyn, NY [e-mail] makerbot.com
WE CAN’T WAIT TO SEE WHAT YOU MAKE!
