Fig.1
Fig.2
12
Fig.3
1
Fig.4
1
2
3
4
5
Fig.5
1
2
3
3
4
5
2
1
Fig.6
1
2
Fig.7
2

Fig.8
1
Fig.9
1
2
Fig.10
Fig.11
1
Fig.12
1
2
Fig.13
3

4ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: 4100KB
Wheel diameter 125 mm
Max. wheel thickness 2.2 mm
Max. cutting capacities 40 mm
Rated speed (n) 12,200 min-1
Overall length 231 mm
Net weight 3.0 kg
Safety class /II
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
withoutnotice.
• Specicationsmaydifferfromcountrytocountry.
• WeightaccordingtoEPTA-Procedure01/2014
Intended use
Thetoolisintendedforcuttinginbrickandconcrete
withouttheuseofwater.
Power supply
Thetoolshouldbeconnectedonlytoapowersupplyof
thesamevoltageasindicatedonthenameplate,and
canonlybeoperatedonsingle-phaseACsupply.They
aredouble-insulatedandcan,therefore,alsobeused
fromsocketswithoutearthwire.
For public low-voltage distribution
systems of between 220 V and 250 V
Switchingoperationsofelectricapparatuscausevolt-
ageuctuations.Theoperationofthisdeviceunder
unfavorablemainsconditionscanhaveadverseeffects
totheoperationofotherequipment.Withamains
impedanceequalorlessthan0.37Ohmsitcanbepre-
sumedthattherewillbenonegativeeffects.Themains
socketusedforthisdevicemustbeprotectedwitha
fuseorprotectivecircuitbreakerhavingslowtripping
characteristics.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ingtoEN60745:
Soundpressurelevel(LpA):96dB(A)
Soundpowerlevel(LWA):107dB(A)
Uncertainty(K):3dB(A)
WARNING: Wear ear protection.
Vibration
Thevibrationtotalvalue(tri-axialvectorsum)deter-
minedaccordingtoEN60745:
Workmode:concretecutting
Vibrationemission(ah):6.0m/s2
Uncertainty(K):1.5m/s2
NOTE: Thedeclaredvibrationemissionvaluehasbeen
measuredinaccordancewiththestandardtestmethod
andmaybeusedforcomparingonetoolwithanother.
NOTE: Thedeclaredvibrationemissionvaluemay
alsobeusedinapreliminaryassessmentofexposure.
WARNING:Thevibrationemissionduringactual
useofthepowertoolcandifferfromthedeclared
emissionvaluedependingonthewaysinwhichthe
toolisused.
WARNING:Besuretoidentifysafetymeasures
toprotecttheoperatorthatarebasedonanestima-
tionofexposureintheactualconditionsofuse(taking
accountofallpartsoftheoperatingcyclesuchas
thetimeswhenthetoolisswitchedoffandwhenitis
runningidleinadditiontothetriggertime).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
tothisinstructionmanual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool.Failuretofollowallinstructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless)powertool.

5ENGLISH
Cutter safety warnings
1. The guard provided with the tool must be
securely attached to the power tool and
positioned for maximum safety, so the least
amount of wheel is exposed towards the oper-
ator. Position yourself and bystanders away
from the plane of the rotating wheel.Theguard
helpstoprotectoperatorfrombrokenwheelfrag-
mentsandaccidentalcontactwithwheel.
2. Use only diamond cut-off wheels for your
power tool.Justbecauseanaccessorycanbe
attachedtoyourpowertool,itdoesnotassure
safeoperation.
3. The rated speed of the accessory must be at
least equal to the maximum speed marked on
the power tool. Accessoriesrunningfasterthan
theirratedspeedcanbreakandyapart.
4. Wheels must be used only for recommended
applications. For example: do not grind with
the side of cut-off wheel. Abrasivecut-offwheels
areintendedforperipheralgrinding,sideforces
appliedtothesewheelsmaycausethemto
shatter.
5. Always use undamaged wheel anges that are
of correct diameter for your selected wheel.
Properwheelangessupportthewheelthus
reducingthepossibilityofwheelbreakage.
6. The outside diameter and the thickness of your
accessory must be within the capacity rating
of your power tool. Incorrectlysizedaccessories
cannotbeadequatelyguardedorcontrolled.
7. The arbour size of wheels and anges must
properly t the spindle of the power tool.
Wheelsandangeswitharbourholesthatdonot
matchthemountinghardwareofthepowertool
willrunoutofbalance,vibrateexcessivelyand
maycauselossofcontrol.
8. Do not use damaged wheels. Before each
use, inspect the wheels for chips and cracks.
If power tool or wheel is dropped, inspect for
damage or install an undamaged wheel. After
inspecting and installing the wheel, position
yourself and bystanders away from the plane
of the rotating wheel and run the power tool
at maximum no load speed for one minute.
Damagedwheelswillnormallybreakapartduring
this test time.
9.
Wear personal protective equipment.
Depending on application, use face shield,
safety goggles or safety glasses. As appropri-
ate, wear dust mask, hearing protectors, gloves
and shop apron capable of stopping small
abrasive or workpiece fragments.Theeyepro-
tectionmustbecapableofstoppingyingdebris
generatedbyvariousoperations.Thedustmask
orrespiratormustbecapableofltratingparticles
generatedbyyouroperation.Prolongedexposure
tohighintensitynoisemaycausehearingloss.
10. Keep bystanders a safe distance away from
work area. Anyone entering the work area
must wear personal protective equipment.
Fragmentsofworkpieceorofabrokenwheelmay
yawayandcauseinjurybeyondimmediatearea
ofoperation.
11. Hold the power tool by insulated gripping
surfaces only, when performing an operation
where the cutting accessory may contact hid-
den wiring or its own cord.Cuttingaccessory
contactinga“live”wiremaymakeexposedmetal
partsofthepowertool“live”andcouldgivethe
operatoranelectricshock.
12. Position the cord clear of the spinning acces-
sory.Ifyoulosecontrol,thecordmaybecutor
snaggedandyourhandorarmmaybepulledinto
the spinning wheel.
13. Never lay the power tool down until the acces-
sory has come to a complete stop.Thespinning
wheelmaygrabthesurfaceandpullthepower
tooloutofyourcontrol.
14. Do not run the power tool while carrying it at
your side.Accidentalcontactwiththespinning
accessorycouldsnagyourclothing,pullingthe
accessoryintoyourbody.
15. Regularly clean the power tool’s air vents.The
motorʼsfanwilldrawthedustinsidethehousing
andexcessiveaccumulationofpowderedmetal
maycauseelectricalhazards.
16. Do not operate the power tool near ammable
materials.Sparkscouldignitethesematerials.
17. Do not use accessories that require liquid
coolants.Usingwaterorotherliquidcoolants
mayresultinelectrocutionorshock.
Kickback and related warnings
Kickbackisasuddenreactiontoapinchedorsnagged
rotatingwheel.Pinchingorsnaggingcausesrapid
stallingoftherotatingwheelwhichinturncausesthe
uncontrolledpowertooltobeforcedinthedirection
oppositeofthewheel’srotationatthepointofthe
binding.
Forexample,ifanabrasivewheelissnaggedor
pinchedbytheworkpiece,theedgeofthewheelthatis
enteringintothepinchpointcandigintothesurfaceof
thematerialcausingthewheeltoclimboutorkickout.
Thewheelmayeitherjumptowardorawayfromthe
operator,dependingondirectionofthewheel’smove-
mentatthepointofpinching.Abrasivewheelsmayalso
breakundertheseconditions.
Kickbackistheresultofpowertoolmisuseand/or
incorrectoperatingproceduresorconditionsandcanbe
avoidedbytakingproperprecautionsasgivenbelow.
1. Maintain a rm grip on the power tool and
position your body and arm to allow you to
resist kickback forces. Always use auxiliary
handle, if provided, for maximum control over
kickback or torque reaction during start-up.
Theoperatorcancontroltorquereactionsorkick-
backforces,ifproperprecautionsaretaken.
2. Never place your hand near the rotating acces-
sory.Accessorymaykickbackoveryourhand.
3. Do not position your body in line with the
rotating wheel.Kickbackwillpropelthetoolin
directionoppositetothewheel’smovementatthe
pointofsnagging.
4. Use special care when working corners, sharp
edges etc. Avoid bouncing and snagging the
accessory.Corners,sharpedgesorbouncing
haveatendencytosnagtherotatingaccessory
andcauselossofcontrolorkickback.

6ENGLISH
5. Do not attach a saw chain, woodcarving blade,
segmented diamond wheel with a peripheral
gap greater than 10 mm or toothed saw blade.
Suchbladescreatefrequentkickbackandlossof
control.
6. Do not “jam” the wheel or apply excessive
pressure. Do not attempt to make an excessive
depth of cut. Overstressing the wheel increases
theloadingandsusceptibilitytotwistingorbinding
ofthewheelinthecutandthepossibilityofkick-
backorwheelbreakage.
7. When wheel is binding or when interrupting
a cut for any reason, switch off the power
tool and hold the power tool motionless until
the wheel comes to a complete stop. Never
attempt to remove the wheel from the cut while
the wheel is in motion otherwise kickback may
occur.Investigateandtakecorrectiveactionto
eliminatethecauseofwheelbinding.
8. Do not restart the cutting operation in the
workpiece. Let the wheel reach full speed and
carefully re-enter the cut.Thewheelmaybind,
walkuporkickbackifthepowertoolisrestartedin
theworkpiece.
9. Support panels or any oversized workpiece to
minimize the risk of wheel pinching and kick-
back.Largeworkpiecestendtosagundertheir
ownweight.Supportsmustbeplacedunderthe
workpiecenearthelineofcutandneartheedge
oftheworkpieceonbothsidesofthewheel.
10. Use extra caution when making a “pocket cut”
into existing walls or other blind areas.The
protrudingwheelmaycutgasorwaterpipes,elec-
tricalwiringorobjectsthatcancausekickback.
11. Before using a segmented diamond wheel,
make sure that the diamond wheel has the
peripheral gap between segments of 10 mm or
less, only with a negative rake angle.
Additional Safety Warnings:
1. Never attempt to cut with the tool held upside
down in a vise.Thiscanleadtoseriousacci-
dents,becauseitisextremelydangerous.
2. Some material contains chemicals which may
be toxic. Take caution to prevent dust inhala-
tion and skin contact. Follow material supplier
safety data.
3. Store wheels as per manufacturer recom-
mendations.Improperstoragemaydamagethe
wheels.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched off and unplugged before adjusting or
checking function on the tool.
Adjusting depth of cut
CAUTION: After adjusting the depth of cut,
always tighten the lever securely.
Loosentheleveronthedepthguideandmovethebase
upordown.Atthedesireddepthofcut,securethebase
bytighteningthelever.
Forcleaner,safercuts,setcutdepthsothatthedia-
mondwheelprojects2mmorlessbelowworkpiece.
Usingpropercutdepthhelpstoreducepotentialfor
dangerousKICKBACKSwhichcancausepersonal
injury.
►Fig.1: 1.Lever
Sighting
Aligntheedgeofthefrontofthebasewithyourcutting
lineontheworkpiece.
►Fig.2
Switch action
CAUTION: Before plugging in the tool, always
check to see that the switch trigger actuates
properly and returns to the "OFF" position when
released.
►Fig.3: 1. Switch trigger 2.Lockbutton/Lock-off
button
For tool with lock button
CAUTION: Switch can be locked in "ON" posi-
tion for ease of operator comfort during extended
use. Apply caution when locking tool in "ON"
position and maintain rm grasp on tool.
Tostartthetool,simplypulltheswitchtrigger.Release
theswitchtriggertostop.Forcontinuousoperation,
pulltheswitchtrigger,pushinthelockbuttonandthen
releasetheswitchtrigger.Tostopthetoolfromthe
lockedposition,pullthetriggerfully,thenreleaseit.
For tool with lock-off button
Topreventtheswitchtriggerfrombeingaccidentally
pulled,alock-offbuttonisprovided.Tostartthetool,
pressthelock-offbuttonandpulltheswitchtrigger.
Releasetheswitchtriggertostop.

7ENGLISH
WARNING: NEVER use the tool if it runs when
you simply pull the switch trigger without press-
ing the lock-off button.Aswitchinneedofrepair
mayresultinunintentionaloperationandserious
personalinjury.ReturntooltoaMakitaservicecenter
forproperrepairsBEFOREfurtherusage.
WARNING: NEVER defeat the lock-off button
by taping down or some other means.Aswitchwith
anegatedlock-offbuttonmayresultinunintentional
operationandseriouspersonalinjury.
CAUTION: Do not pull the switch trigger hard
without pressing in the lock-off button. This can
cause switch breakage.
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and unplugged before carrying out
any work on the tool.
Hex wrench storage
Whennotinuse,storethehexwrenchasshowninthe
guretokeepitfrombeinglost.
►Fig.4: 1. Hex wrench
Removing or installing diamond
wheel
CAUTION: BE SURE TO TIGHTEN THE HEX
BOLT SECURELY. Also be careful not to tighten
the bolt forcibly. Slippingyourhandfromthehex
wrenchcancauseapersonalinjury.
CAUTION: Use only the Makita wrench and
hex wrench to install or remove the wheel.
Holdtheouterangewiththewrenchandloosenthe
hexboltwiththehexwrench.Thenremovethehexbolt,
outerangeanddiamondwheel.
►Fig.5: 1. Hex wrench 2.Hexbolt3. Wrench 22
4.Loosen5.Tighten
Toinstallthediamondwheel,followtheremovalpro-
cedureinreverse.Alwaysinstallthewheelsothatthe
arrowonthediamondwheelpointsinthesamedirec-
tionasthearrowonthegearhousing.
►Fig.6: 1.Hexbolt2.Outerange3.Diamondwheel
4.Innerange5.Cupwasher
Dust bag
Theuseofthedustbagmakescuttingoperationsclean
anddustcollectioneasy.Toattachthedustbag,tit
ontothedustspout.
►Fig.7: 1.Dustbag2.Dustspout
Theneckofthedustspoutrotatesfreely.Positionthe
dustbagsothatyoucanoperatethetoolcomfortably.
►Fig.8
Whenthedustbagisaboutone-thirdfull,removethe
dustbagfromthetoolandpullthefastenerout.Empty
thedustbagofitscontents,tappingitlightlysoasto
removeparticlesadheringtotheinsideswhichmight
hampercollection.
►Fig.9: 1. Fastener
Connecting the vacuum cleaner
Whenyouwishtoperformcleancuttingoperation,
connectaMakitavacuumcleanertoyourtool.
►Fig.10: 1.Hoseofthevacuumcleaner2.Dust
spout
OPERATION
CAUTION: THIS TOOL SHOULD ONLY BE
USED ON HORIZONTAL SURFACES.
CAUTION: Be sure to move the tool forward
in a straight line and gently.Forcingandexerting
excessivepressureorallowingthewheeltobend,
pinchortwistinthecutcancauseoverheatingofthe
motoranddangerouskickbackofthetool.
Holdthetoolrmly.Setthebaseplateontheworkpiece
tobecutwithoutthediamondwheelmakinganycon-
tact.Thenturnthetoolonandwaituntilthediamond
wheelattainsfullspeed.Nowsimplymovethetool
forwardovertheworkpiecesurface,keepingitatand
advancingsmoothlyuntilthecuttingiscompleted.Keep
yourcuttinglinestraightandyourspeedofadvance
uniform.
►Fig.11
MAINTENANCE
CAUTION: Always be sure that the tool is
switched off and unplugged before attempting to
perform inspection or maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Dressing diamond wheel
Ifthecuttingactionofthediamondwheelbeginsto
diminish,useanolddiscardedcoarsegritbenchgrinder
wheelorconcreteblocktodressthediamondwheel.To
dothis,tightlysecurethebenchgrinderwheelorcon-
creteblockandcutinit.
After use
Cleanthedustinsideofthetoolbyrunningthetoolat
anidleforawhile.Brushoffaccumulationofdustonthe
base.Accumulationofdustinthemotororonthebase
maycauseamalfunctionofthetool.

8ENGLISH
Replacing carbon brushes
Checkthecarbonbrushesregularly.
Replacethemwhentheyweardowntothelimitmark.
Keepthecarbonbrushescleanandfreetoslipinthe
holders.Bothcarbonbrushesshouldbereplacedatthe
sametime.Useonlyidenticalcarbonbrushes.
►Fig.12: 1.Limitmark
Useascrewdrivertoremovethebrushholdercaps.
Takeouttheworncarbonbrushes,insertthenewones
andsecurethebrushholdercaps.
►Fig.13: 1. Screwdriver 2.Brushholdercap
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessoriesorattachmentsmightpresentariskof
injurytopersons.Onlyuseaccessoryorattachment
foritsstatedpurpose.
Ifyouneedanyassistanceformoredetailsregard-
ingtheseaccessories,askyourlocalMakitaService
Center.
• Diamondwheels(Drytype)
• Wrench22
• Hexwrench
• Guiderail
• Guiderailadapter
• Safetygoggles
NOTE:Someitemsinthelistmaybeincludedinthe
toolpackageasstandardaccessories.Theymay
differfromcountrytocountry.

9SLOVENŠČINA
SLOVENŠČINA (Originalna navodila)
TEHNIČNI PODATKI
Model: 4100KB
Premerrezalneplošče 125 mm
Največjadebelinaplošče 2,2 mm
Največjezmogljivostirezanja 40 mm
Nazivnahitrost(n) 12.200 min-1
Celotnadolžina 231 mm
Netoteža 3,0 kg
Razredzaščite /II
• Kernenehnoopravljamoraziskaveinrazvijamosvojeizdelke,selahkotehničnipodatkivtemdokumentu
spremenijobrezobvestila.
• Tehničnipodatkiselahkorazlikujejooddržavedodržave.
• TežavskladuspostopkomEPTA01/2014
Predvidena uporaba
Orodjejenamenjenozarezanjeopekeinbetonabrez
uporabevode.
Priključitev na električno omrežje
Napetostelektričnegaomrežjasemoraujematis
podatkinatipskiploščici.Strojdelujesamozenofazno
izmeničnonapetostjo.Strojjepoevropskihsmernicah
dvojnozaščitnoizoliran,zatosegalahkopriključitudiv
vtičnicebrezozemljitvenegavoda.
Za javna nizkonapetostna električna
omrežja z napetostjo med 220 V in
250 V
Vklopiinizklopielektričnihaparatovpovzročajonihanje
električnenapetosti.Delovanjetenapravevneugodnih
omrežnihpogojihimalahkoneželeneučinkenadelova-
njedrugihpriključenihnaprav.Priimpedanciomrežja,ki
jeenakaalimanjšaod0,37ohma,jemožnopredposta-
viti,danebonegativnihučinkov.Omrežnavtičnica,na
katerobopriključenatanaprava,morabitizaščitenaz
varovalkoalistokovnimzaščitnimstikalomspočasno
karakteristikoproženja.
Hrup
ObičajnaA-ovrednotenaravenhrupavskladuzEN60745:
Ravenzvočnegatlaka(LpA):96dB(A)
Ravenzvočnemoči(LWA):107dB(A)
Odstopanje(K):3dB(A)
OPOZORILO: Uporabljajte zaščito za sluh.
Vibracije
Skupnevrednostivibracij(vektorskavsotatrehosi)v
skladuzEN60745:
Delovninačin:rezanjebetona
Emisijevibracij(ah):6,0m/s2
Odstopanje(K):1,5m/s2
OPOMBA:Navedenavrednostoddajanjavibracij
jebilaizmerjenavskladusstandardnimimetodami
testiranjainselahkouporabljazaprimerjavoorodij.
OPOMBA:
Navedenavrednostoddajanjavibracijse
lahkouporabljatudipripredhodnioceniizpostavljenosti.
OPOZORILO: Oddajanjevibracijmeddejansko
uporaboelektričnegaorodjaselahkorazlikujeodnavedene
vrednostioddajanja,odvisnoodnačinauporabeorodja.
OPOZORILO:Upravljavecmorazalastnozaš-
čitopoznativarnostneukrepe,kitemeljijonaoceni
izpostavljenostivdejanskihpogojihuporabe(poleg
časaproženjajetrebaupoštevaticelotendelovni
cikel,vključnosčasom,kojeorodjeizklopljeno,in
časom,kodelujevprostemteku).
Izjava o skladnosti ES
Samo za evropske države
IzjavaESoskladnostijevključenavdodatkuA,kije
priložentemnavodilomzauporabo.
VARNOSTNA OPOZORILA
Splošna varnostna opozorila za
električno orodje
OPOZORILO: Preberite vsa varnostna opozo-
rila in navodila s slikami in tehničnimi podatki, ki so
dobavljeni skupaj z električnim orodjem.Obneupo-
števanjuspodajnavedenihnavodilobstajanevarnost
električnegaudara,požarain/alihudihtelesnihpoškodb.
Shranite vsa opozorila in navo-
dila za poznejšo uporabo.
Izraz„električnoorodje“vopozorilihsenanašanavaše
električnoorodje(skablom)alibaterijskoelektrično
orodje(brezkabla).

10 SLOVENŠČINA
Varnostna opozorila v zvezi z
rezalnikom
1. Ščitnik, ki je priložen orodju, mora biti varno
pritrjen na električno orodje in nastavljen tako,
da zagotavlja najvišjo stopnjo zaščite in je proti
upravljavcu izpostavljen čim manjši delež rezalne
plošče. Vi in osebe v bližini se ne smejo približe-
vati ravnini vrteče se rezalne plošče.Ščitnikvaruje
upravljavcapredzlomljenimidelcirezalneploščein
nenamernimstikomzrezalnoploščo.
2. Uporabljajte le diamantne rezalne plošče, ki
ustrezajo vašemu električnemu orodju.Čeje
pribormogočepritrditinaelektričnoorodje,toše
nepomeni,dajeuporabategapriboravarna.
3.
Nazivno število vrtljajev nastavka mora ustrezati
vsaj največjemu številu vrtljajev, ki je označeno
na električnem orodju. Nastavek,kisevrtihitrejeod
nazivnegaštevilavrtljajev,selahkozlomiinrazleti.
4. Rezalne plošče se lahko uporabljajo le za
priporočene naprave. Primer: ne uporabljajte
jih za brušenje s stransko ploskvijo rezalne
plošče. Namenjenesobrušenjuzrobomrezila.
Priizvajanjubočnesilenateploščelahkopočijo.
5.
Uporabljajte samo nepoškodovane vpenjalne pri-
robnice, ki po dimenziji in obliki ustrezajo upora-
bljeni rezalni plošči.Ustrezneprirobnicepodpirajo
ploščoinzmanjšujejonevarnostzlomaplošče.
6. Zunanji premer in debelina nastavka morata
ustrezati nazivni moči električnega orodja.
Nastavkaneustreznevelikostinimogočepravilno
zavarovatisščitnikialigapovsemnadzorovati.
7. Mere rezalnih plošč, prirobnic in ostalih sesta-
vih delov se morajo natančno prilegati meram
vretena na električnem orodju.Česetemere
neujemajo,lahkopriuporabielektričnegaorodja
nastopiopletanjezvibracijamiinuporabnikizgubi
nadzornadelektričnimorodjem.
8.
Ne uporabljajte poškodovanih rezalnih plošč. Pred
vsako uporabo preverite, da rezalne plošče niso
počene ali kako drugače poškodovane. Če pade
električno orodje ali rezalna plošča na tla, preverite,
ali so nastale poškodbe, in po potrebi namestite
nepoškodovano rezalno ploščo. Po pregledu in
namestitvi rezalne plošče se postavite izven ravnine
vrtenja rezalne plošče, opozorite osebe v bližini, da
se oddaljijo, ter vključite orodje in ga pustite delo-
vati eno minuto brez obremenitve.Medtempreizku-
sompoškodovanerezalneploščeobičajnopočijo.
9. Uporabljajte osebna zaščitna sredstva. Odvisno
od dela, ki ga opravljate, uporabljajte zaščitno
masko za obraz in oči ali zaščitna očala. Če je
potrebno, uporabljajte zaščitno masko proti
prahu, glušnike, rokavice ali predpasnik za zaš-
čito pred drobci materiala.Zaščitazaočimora
zadržatiletečedrobce,kisoprisotniprirazličnih
načinihdela.Protiprašnamaskaalimaskazazaš-
čitodihalmorazadržatiprah,kinastajameddelom.
Izpostavljanjehrupulahkopovzročiizgubosluha.
10. Pri delu poskrbite, da bodo druge osebe varno
oddaljene od delovnega območja. V delovno
območje lahko vstopajo samo osebe z ustrezno
osebno zaščitno opremo.Letečidrobcimateriala
obdelovancaalipočenegapriborasonevarniinlahko
povzročijopoškodbetudiizvendelovnegaobmočja.
11. Če obstaja nevarnost, da bi z rezalnim orodjem
prerezali skrito električno napeljavo ali lasten kabel,
držite električno orodje samo na izoliranih držalnih
površinah.Obstikuzvodnikipodnapetostjodobijo
napetostvsineizoliranikovinskidelielektričnegaorodja,
zaradičesarlahkouporabnikutrpielektričniudar.
12. Pazite, da z vrtečimi se deli orodja ne poško-
dujete električnega kabla.Vprimeruizgube
nadzoranadelektričnimorodjemlahkopridedo
poškodbeelektričnegakabla,zaradičesarvam
lahkotoelektričnoorodjepoškodujeprstealiroke.
13.
Ne odlagajte električnega orodja iz rok, dokler se
nameščeni nastavek ne neha vrteti.Plošča,kise
ševednovrti,lahkopridevstikzodlagalnopovršino
inpovzročiizgubonadzoranadelektričnimorodjem.
14. Ne puščajte električnega orodja vključenega
brez nadzora.Vrtečisenastavekselahkonepri-
čakovanozapletevvašooblekoinvaspoškoduje.
15. Redno čistite hladilne reže električnega orodja.
Ventilatormotorjavsesavavohišjeprah,ki
povzročaškodljivokopičenjeprahuinstemnevar-
nostelektričneokvare.
16.
Ne uporabljajte električnega orodja v bližini gorljivih
snovi.Gorljivesnoviselahkovnamejozaradiiskrenja.
17. Ne uporabljajte nastavkov, ki so predvideni
za uporabo s tekočim hladilnim sredstvom.
Uporabavodealidrugihtekočinzahlajenjelahko
povzročielektričniudar.
Povratni udarec in s tem povezana opozorila
Povratniudarecjenenadnareakcijapristisnjenjualizagozde-
njuvrtečeseplošče.Zaradizagozdenjaalistisnjenjasepribor
nenadomazaustavi,električnoorodjepasunkovitoodskočiv
nasprotnismerivrtenjarezalneploščevtočkizagozdenja.
Čepridenaprimerdoblokadeabrazivneploščev
obdelovancu,lahkorobvtočkizagozdenjazarežev
površino,pritempanastalasilarezalnoploščoodbije
odmateriala.Rezalnaploščalahkoodskočibodisiproti
vamalivnasprotnismeri,karjeodvisnoodsmerivode-
njarezalneploščevtočkizagozdenja.Abrazivnaplošča
selahkopodtemipogojitudizlomi.
Povratniudarecjeposledicanestrokovnegaravnanjaz
električnimorodjemalineugodnihokoliščin.Preprečite
galahkozupoštevanjemspodajnavedenihopozoril.
1.
Električno orodje držite s trdnim prijemom in
se postavite v takšen položaj, da lahko prestre-
žete sile povratnega udarca. Če je na električno
orodje mogoče namestiti dodatni ročaj, ga
tudi uporabljajte, saj vam omogoča najboljši
nadzor nad povratnimi udarci ali reakcijskim
vrtilnim momentom.Reakcijskevrtilnemomente
alipovratneudarcejemogočeučinkovitopreprečiti
zupoštevanjemprevidnostnihukrepov.
2. Ne približujte rok vrtečim se delom električ-
nega orodja.Nameščenipriborlahkoudarinazaj
prekvašeroke.
3.
Ne postavljajte se v linijo z vrtečo se rezalno ploščo.
Povratniudarecsunkovitopotisneorodjevnasprotni
smerivrtenjarezalneploščevtočkizagozdenja.
4. Pri obdelavi vogalov, ostrih robov ipd. je
potrebna večja previdnost. Izogibajte se polo-
žajem, v katerih lahko orodje odskoči iz obde-
lovanca ali se zagozdi.Vvogalihinnaostrih
robovihobstajapovečananevarnostpovratnega
sunkaalizagozdenjapribora.Posledicategaje
lahkoizgubanadzoraalipovratniudarec.
