18V LXT®LITHIUM-ION
CORDLESS 3-1/4" PLANER
18V PLANING.
18V LXT Li-Ion batteries charge
in 30 minutes,run longer and
deliver 3X more cycles
PERFORMANCE
Spring-loaded stand elevates
the base to protect the blades
and workpiece
CONVENIENCE
Precision machined aluminum
base for planing accuracy
PRECISION
Planes up to 3-1/4" wide and
5/64" deep in a single pass
CAPACITY
Models
LXPK01
LXPK01Z
PLANES UP TO 3-1/4" WIDE AND 5/64" DEEP IN A SINGLE PASS
• 2-BladeCutterHeadwithDoubleEdgeCarbideBladesforAdded
 PerformanceandSmoothFinish
• PrecisionMachinedAluminumBaseforPlaningAccuracy
• Spring-LoadedStandElevatestheBasetoProtecttheBladesandWorkpiece
• 14,000RPMMotorEngineeredforFastStockRemoval
• HighPower-to-WeightRatio;Weighsonly7.4lbs.
• ClickDepthAdjustmentKnobwithEasy-to-ReadScalewithSettingsfrom
 0"to5/64"forPreciseDepthAdjustment

18V LXT®LITHIUM-ION 3-1/4" PLANER
Models LXPK01/LXPK01Z
FEATURES&BENEFITS
nPlanes up to 3-1/4" wide and 5/64" deep in a single pass
n2-blade cutter head with double edge carbide blades for added performance
and smooth finish
nPrecision machined aluminum base for planing accuracy
nSpring-loaded stand elevates the base to protect the blades and workpiece
n14,000 RPM motor engineered for fast stock removal
nHigh power-to-weight ratio; weighs only 7.4 lbs.
nClick depth adjustment knob with easy-to-read scale with settings from 0" to 5/64"
for precise depth adjustment
nErgonomically centered balance with rubberized soft grip front and rear handles
for increased comfort on the job
nEasy blade setting system for fast blade installation
SPECIFICATIONS
Planing width 3-1/4"
Planing depth 5/64"
No load speed 14,000 RPM
Battery 18V LXT Lithium-Ion
Overall length 13-1/8"
Net weight 7.4 lbs.
Shipping weight LXPK01 17.5 lbs.
LXPK01Z 7.5 lbs.
Master carton quantity LXPK01 1
LXPK01Z 3
UPC code: LXPK01 088381-617499
LXPK01Z 088381-617505
OPTIONALACCESSORIES
nTungsten-carbide planer blades (D-17223)
nHigh-speed steel planer blades (D-17271)
nDouble edge tungsten-carbide planer blades* (D-16966)
nDouble edge tungsten-carbide planer blades with set plates (D-17239)
nBlade gauge assembly (123062-2)
nStraight guide rule (165581-2)
Makita U.S.A.,14930 Northam St.,La Mirada,CA 90638
Makita offers a wide variety of PLANER accessories. For a complete listing, please refer
to the Makita General Catalog or visit our website at makitatools.com, or call 1-800-4MAKITA.
All specifications subject to change without prior notice. All models and accessories subject to stock on hand.
NTF-1011-1 MA-0662-11 “The Makita Teal color is the registered trade dress of Makita Corporation.”
STANDARDEQUIPMENT
n2 ea. 18V LXT Lithium-Ion battery (BL1830)
n1 30-Minute Rapid Optimum Charger (DC18RA)
nContractor bag (821016-X)
nWrench (782209-3)*
nBlade set (D-16966)*
nBlade gauge assembly (123062-2)*
Model LXPK01Z (tool only) - battery, charger and tool bag not included
* Included as standard equipment for LXPK01Z
Model LXPK01 Model LXPK01Z
088381 61749 9088381 61750 5
nBevel guide (123060-6)
nNozzle assembly (451329-1)
nSharpening holding assembly (123004-6)
*Blades only
