Parts Breakdown 6826N
Page 1 of 2 2/8/2008

Parts Breakdown 6826N
Fig # Part ID Part Name Quantity
1 152822-5 LOCATOR CPL. 5/16, 6826 1
2 421775-2 DUST SEAL RING, 6826 1
3 213373-4 O RING 22, GEO600 1
4 416994-3 LOCK RING., 6823 1
5 232154-7 LEAF SPRING, 6823 1
6 266050-7 P.T. SCREW 4X30, 4304 3
7 153497-3 GEAR HOUSING CPL. 1
8 421766-3 RING 20, 6827 1
9 232050-9 LEAF SPRING, 6820V 1
10 216001-0 STEEL BALL 3.5, 6800DBV 1
11 324328-5 SPINDLE, 6826N 1
12 233126-5 COMP. SPRING 6, 6832 1
13 268099-3 COLLARED PIN 8, 6824N 1
14 227090-0 SPUR GEAR 36, 6826N 1
15 211014-6 B. BEARING 606, 6826 1
16 226133-5 GEAR CPL.17-35, 6823/23TP 1
17 267017-8 F. WASHER, HK1800L 1
19 216213-5 WASHER 824, 6824 1
20 216415-3 THRUST NEEDLE GAUGE 821, 6824 1
21 216212-7 WASHER 821, 6824 1
22 153499-9 GEAR HOUSING COVER CPL. 1
23 210005-4 BALL BEARING 608DDW, 9031 1
24 510053-6 ARMATURE ASS'Y 115V, 6826N 1
25 681636-0 INSULATION WASHER, 4304 1
26 211021-9 BALL BEARING 607LLB, LS1013 1
27 421479-6 RUBBER RING 19, JN1601 1
28 416993-5 BAFFLE PLATE, 6823 1
29 266147-2 TAPPING SCREW 4X55, 6824 2
30 633441-1 FIELD, 6823 1
31 417625-7 HOOK, 6827 1
32 183285-4 MOTOR HOUSING SET, 6827 1
33 819063-3 MAKITA LABEL, 6992DWDE 1
34 850433-7 NAME PLATE 1
35 643952-8 BRUSH HOLDER, 6823/6823TP 1
36 191927-6 CARBON BRUSH SET CB-407, 6821 1
37 664891-9 CORD 1
38 682559-5 CORD GUARD 8, 6824 1
39 687063-9 STRAIN RELIEF, 4323K 1
40 265995-6 TAPPING SCREW 4X18, 4323K 2
41 651978-6 SWITCH, 6823 1
42 151961-8 HANDLE COVER COMPLETE, JS1300 1
43 265999-8 TAPPING SCREW M4X25, HM1800 1
44 253139-0 F. WASHER 8, 6510LVR 1
45 643953-6 BRUSH HOLDER, 6823/6823TP 1
47 265999-8 TAPPING SCREW M4X25, HM1800 2
48 240022-0 FAN 52, JS1300 1
49 442136-3 GASKET , 6827 1
50 256157-7 PIN 3, 6222DWE 1
1,001 784804-5 5/16 NUT SETTER, 6802BV 1
5,001 810134-9 N/A 1
Page 2 of 2 2/8/2008
