INSTRUCTION MANUAL
Straight Grinder
GS5000
GS6000
ENGLISH: Original instructions
DOUBLE INSULATION
Read before use.
2ENGLISH
SPECIFICATIONS
Model GS5000 GS6000
Maximum wheel capacity (diameter X thickness) 125 mm × 20 mm 150 mm × 20 mm
Spindle thread
No load speed (min-1)5,600
Overall length With support cover 590 mm 590 mm
Without support cover 588 mm 588 mm
Net weight With support cover 5.0 kg 5.2 kg
Without support cover 4.9 kg 5.0 kg
Safety class /II
-
out notice.
Symbols
The following show the symbols used for the equip-
ment. Be sure that you understand their meaning before
use.
Read instruction manual.
DOUBLE INSULATION
Wear safety glasses.
Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of the European Directive,
on Waste Electric and Electronic
Equipment and its implementation in
accordance with national law, electric
equipment that have reached the end of
their life must be collected separately and
returned to an environmentally compatible
recycling facility.
Intended use
The tool is intended for grinding ferrous materials or
deburring castings.
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated and can, therefore, also be used
from sockets without earth wire.
Noise
The typical A-weighted noise level determined accord-
ing to EN60745:
Sound pressure level (LpA
Sound power level (LWA) : 94 dB (A)
Wear ear protection
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to EN60745:
Work mode : surface grinding
Vibration emission (ah,SG) : 2.5 m/s2or less
Uncertainty (K) : 1.5 m/s2
NOTE:
The declared vibration emission value has been
measured in accordance with the standard test method
and may be used for comparing one tool with another.
NOTE:
The declared vibration emission value may
also be used in a preliminary assessment of exposure.
NOTE: The declared vibration emission value is used
for main applications of the power tool. However if the
power tool is used for other applications, the vibration
emission value may be different.
WARNING: The vibration emission during actual
use of the power tool can differ from the declared
emission value depending on the ways in which the
tool is used.
WARNING: Be sure to identify safety measures
to protect the operator that are based on an estima-
tion of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it is
running idle in addition to the trigger time).
For European countries only
EC Declaration of Conformity
Makita declares that the following Machine(s):
Designation of Machine:
Straight Grinder
Model No./ Type: GS5000, GS6000
Conforms to the following European Directives:
2006/42/EC
They are manufactured in accordance with the following
standard or standardized documents:
EN60745
available from:
3ENGLISH
1.2.2016
Yasushi Fukaya
Director
General Power Tool Safety Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and instruc-
Save all warnings and instruc-
tions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Do not operate power tools in explosive atmo-
liquids, gases or dust.
which may ignite the dust or fumes.
Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
Electrical safety
4. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
reduce risk of electric shock.
5. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
6. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
7. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
8. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
9. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
10. Use of power supply via a RCD with a rated
residual current of 30 mA or less is always
recommended.
Personal safety
11. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
-
ication. A moment of inattention while operating
12. Use personal protective equipment. Always
wear eye protection.
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools with
that have the switch on invites accidents.
14. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
15. Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
16. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing, and gloves
away from moving parts.-
lery or long hair can be caught in moving parts.
17. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
Power tool use and care
18. Do not force the power tool. Use the correct
power tool for your application. The correct
rate for which it was designed.
19. Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
20. Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such pre-
ventive safety measures reduce the risk of starting
the power tool accidentally.
21. Store idle power tools out of the reach of chil-
dren and do not allow persons unfamiliar with
the power tool or these instructions to operate
the power tool.
hands of untrained users.
22. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
Keep cutting tools sharp and clean.
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
4ENGLISH
24. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
Service
25.
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
26. Follow instruction for lubricating and chang-
ing accessories.
27. Keep handles dry, clean and free from oil and
grease.
STRAIGHT GRINDER SAFETY
WARNINGS
Safety Warnings Common for Grinding Operation:
1. This power tool is intended to function as a
grinder. Read all safety warnings, instructions,
this power tool. Failure to follow all instructions
2. Operations such as sanding, wire brush-
ing, polishing or cutting-off are not recom-
mended to be performed with this power tool.
Operations for which the power tool was not
designed may create a hazard and cause per-
-
cally designed and recommended by the tool
manufacturer. Just because the accessory can
be attached to your power tool, it does not assure
safe operation.
4. The rated speed of the accessory must be at
least equal to the maximum speed marked on
the power tool. Accessories running faster than
5. The outside diameter and the thickness of your
accessory must be within the capacity rating
of your power tool. Incorrectly sized accessories
cannot be adequately guarded or controlled.
6. Threaded mounting of accessories must
match the grinder spindle thread. For acces-
Accessories that do not match the
mounting hardware of the power tool will run out of
balance, vibrate excessively and may cause loss
of control.
7. Do not use a damaged accessory. Before each
use inspect the accessory such as abrasive
wheels for chips and cracks. If power tool or
accessory is dropped, inspect for damage or
install an undamaged accessory. After inspect-
ing and installing an accessory, position your-
self and bystanders away from the plane of
the rotating accessory and run the power tool
at maximum no-load speed for one minute.
Damaged accessories will normally break apart
during this test time.
8. Wear personal protective equipment.
Depending on application, use face shield,
safety goggles or safety glasses. As appro-
priate, wear dust mask, hearing protectors,
gloves and workshop apron capable of stop-
ping small abrasive or workpiece fragments.
The eye protection must be capable of stopping
The dust mask or respirator must be capable of
cause hearing loss.
9. Keep bystanders a safe distance away from
work area. Anyone entering the work area
must wear personal protective equipment.
Fragments of workpiece or of a broken accessory
area of operation.
10. Hold the power tool by insulated gripping
surfaces only, when performing an operation
where the cutting accessory may contact hid-
den wiring or its own cord. Cutting accessory
contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the
operator an electric shock.
11. Position the cord clear of the spinning acces-
sory. If you lose control, the cord may be cut or
snagged and your hand or arm may be pulled into
the spinning accessory.
12. Never lay the power tool down until the acces-
sory has come to a complete stop. The spinning
accessory may grab the surface and pull the
power tool out of your control.
Do not run the power tool while carrying it at
your side. Accidental contact with the spinning
accessory could snag your clothing, pulling the
accessory into your body.
14. Regularly clean the power tool’s air vents. The
motor’s fan will draw the dust inside the housing
and excessive accumulation of powdered metal
may cause electrical hazards.
15.
materials. Sparks could ignite these materials.
16. Do not use accessories that require liquid
coolants. Using water or other liquid coolants
may result in electrocution or shock.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged
rotating wheel, backing pad, brush or any other acces-
rotating accessory which in turn causes the uncon-
trolled power tool to be forced in the direction opposite
of the accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or
pinched by the workpiece, the edge of the wheel that is
entering into the pinch point can dig into the surface of
the material causing the wheel to climb out or kick out.
operator, depending on direction of the wheel’s move-
ment at the point of pinching. Abrasive wheels may also
break under these conditions.
Kickback is the result of power tool misuse and/or
incorrect operating procedures or conditions and can be
avoided by taking proper precautions as given below.
5ENGLISH
a)
position your body and arm to allow you to
resist kickback forces. Always use auxiliary
handle, if provided, for maximum control over
kickback or torque reaction during start-up.
The operator can control torque reactions or kick-
back forces, if proper precautions are taken.
b) Never place your hand near the rotating
accessory. Accessory may kickback over your
hand.
c) Do not position your body in the area where
power tool will move if kickback occurs.
Kickback will propel the tool in direction opposite
to the wheel’s movement at the point of snagging.
d) Use special care when working corners,
sharp edges etc. Avoid bouncing and snagging
the accessory. Corners, sharp edges or bouncing
have a tendency to snag the rotating accessory
and cause loss of control or kickback.
e) Do not attach a saw chain woodcarving
blade or toothed saw blade. Such blades create
frequent kickback and loss of control.
a) Use only wheel types that are recommended
designed for the selected wheel. Wheels for
which the power tool was not designed cannot be
adequately guarded and are unsafe.
b) The guard must be securely attached to the
power tool and positioned for maximum safety,
so the least amount of wheel is exposed
towards the operator. The guard helps to protect
the operator from broken wheel fragments, acci-
dental contact with wheel and sparks that could
ignite clothing.
c)
are of correct size and shape for your selected
wheel.
thus reducing the possibility of wheel breakage.
Flanges for cut-off wheels may be different from
d) Do not use worn down wheels from larger
power tools. Wheel intended for larger power tool
is not suitable for the higher speed of a smaller
tool and may burst.
Additional safety warnings:
17. Never use depressed center wheels or abra-
sive cut-off wheels.
18. Be careful not to damage the spindle, the
lock nut. Damage to these parts could result in
wheel breakage.
19. Make sure the wheel is not contacting the
workpiece before the switch is turned on.
20. Before using the tool on an actual workpiece,
let it run for a while. Watch for vibration or
wobbling that could indicate poor installation
or a poorly balanced wheel.
21. -
form the grinding.
22. Do not leave the tool running. Operate the tool
only when hand-held.
Do not touch the workpiece immediately after
operation; it may be extremely hot and could
burn your skin.
24. Observe the instructions of the manufacturer
for correct mounting and use of wheels.
Handle and store wheels with care.
25.
26. Check that the workpiece is properly
supported.
27. Pay attention that the wheel continues to
rotate after the tool is switched off.
28. If working place is extremely hot and humid,
or badly polluted by conductive dust, use a
short-circuit breaker (30 mA) to assure opera-
tor safety.
29. Do not use the tool on any materials contain-
ing asbestos.
sure no one is below when using the tool in
high locations.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or famil-
iarity with product (gained from repeated
use) replace strict adherence to safety
rules for the subject product. MISUSE or
failure to follow the safety rules stated in
this instruction manual may cause serious
personal injury.
6ENGLISH
FUNCTIONAL
DESCRIPTION
CAUTION:
on the tool.
Switch action
1
2
A
B
C
1. Switch trigger 2. Lock lever
CAUTION:
the switch trigger actuates properly and returns
to the "OFF" position when released.
For tool with the lock-on switch
CAUTION:
of operator comfort during extended use. Apply
caution when locking tool in "ON" position and
To start the tool, simply pull the switch trigger (in the B
direction). Release the switch trigger to stop. For con-
tinuous operation, pull the switch trigger (in the B direc-
tion) and then push in the lock lever (in the A direction).
To stop the tool from the locked position, pull the switch
trigger fully (in the B direction), then release it.
For tool with the lock-off switch
To prevent the switch trigger from accidentally pulled, a
lock lever is provided. To start the tool, push in the lock
lever (in the A direction) and then pull the switch trigger
(in the B direction). Release the switch trigger to stop.
For tool with the lock on and lock-off
switch
To prevent the switch trigger from accidentally pulled, a
lock lever is provided.
To start the tool, push in the lock lever (in the A direc-
tion) and then pull the switch trigger (in the B direction).
Release the switch trigger to stop.
For continuous operation, push in the lock lever (in the
A direction), pull the switch trigger (in the B direction)
and then pull the lock lever (in the C direction).
To stop the tool from the locked position, pull the switch
trigger fully (in the B direction), then release it.
ASSEMBLY
CAUTION:
unplugged before carrying out any work on the
tool.
1
2
4
5
3
1. Hex wrench 2. Hex bolt 3. Hex lock nut 4. Tighten
5. Loosen
CAUTION:
safety, tighten the two hex bolts by the strength
properly.
Installing or removing grinding
wheel
Optional accessory
CAUTION:
that a blotter part does not have any abnormali-
ties such as chips or cracks.
that has larger diameter than the lock nut or the
7ENGLISH
For tool with support cover only
1
2
1. Wing bolt 2. Support cover
Before installing or removing the grinding wheel, open
the support cover. Loosen the wing bolts on both sides
of the support cover and then open it.
After securing the wheel grinding, close the support
cover and then secure the wing bolts properly.
For all tools
Type A
1
23
1. Lock nut 2. Grinding wheel 3. Spindle
Securing method for type A
1
2
3
4
1. Screwdriver 2.3. Lock nut wrench
4. Lock nut
Grip the lock nut with the lock nut wrench, turning in
the direction of wheel rotation to loosen the lock nut.
Remove the lock nut. Then install the wheel and tighten
the lock nut in the direction of arrow as shown in the
Type B
12
34
1. Hex nut 2.3. Grinding
wheel 4. Spindle
Type C
12
34
1. Hex nut 2.3. Grinding
wheel 4. Spindle
Securing method for type B and C
1
2
3
4
1. Screwdriver 2. Hex wrench 3.4. Hex
nut
8ENGLISH
the hex nut with the wrench, turning in the direction
of wheel rotation to loosen the hex nut. Remove the
Tighten the hex nut in the direction of arrow as shown
OPERATION
CAUTION:
and overloading of the motor.
tool is switched off.
handle and the other hand on the front grip
when performing the tool.
Hanger (optional accessory)
Continuous operation of the grinder is made easy by
loop the cord over the head or shoulder, after threading
it through the eyelet on the top of the tool housing.
MAINTENANCE
CAUTION:
unplugged before attempting to perform inspec-
tion or maintenance.
Never use gasoline, benzine, thinner, alcohol or the
like. Discoloration, deformation or cracks may result.
1
2
1. Exhaust vent 2. Inhalation vent
The tool and its air vents have to be kept clean.
Regularly clean the tool's air vents or whenever the
vents start to become obstructed.
Installing or removing dust cover
(optional accessory)
CAUTION:
unplugged before installing or removing the dust
cover attachments.
of the air through the dust cover attachments
becomes obstructed with built up dust or foreign
matters. Continued operation in such a condi-
tion may damage the tool.
forcing it up without unhooking hook A or B may
break hooking part.
1
2
4
3
1. Handle R 2. Dust cover attachment R 3. Handle L
4. Dust cover attachment L
9ENGLISH
Dust cover attachment R/L are respectively installed
on the handles R/L with the sides shown above facing
toward the tool.
2
1
3
5
4
4
5
2
1
3
1. Hook B 2. Hook A 3. Rib A 4. Vent A 5. vent B
To install the attachments, insert hook A and rib A into
vent A lightly.
Insert hook B into vent B.
1
3
2
1. Dust cover attachment R 2. Dust cover attach-
ment L 3. Screwdriver
To remove, lift it up by using a slotted bit screwdriver
near the hook B.
Also lift it up near the hook A.
NOTE: Dust cover attachments installed on GS5000
and GS6000 do not cover the vents above and below
the brush holder which is designed dust-proof.
Replacing carbon brushes
1
2
3
1. Commutator 2. Insulating tip 3. Carbon brush
When the resin insulating tip inside the carbon brush
is exposed to contact the commutator, it will automati-
cally shut off the motor. When this occurs, both carbon
brushes should be replaced. Keep the carbon brushes
clean and free to slip in the holders. Both carbon
brushes should be replaced at the same time. Use only
identical carbon brushes.
1
2
1. Brush holder cap 2. Screwdriver
Use a screwdriver to remove the brush holder caps.
Take out the worn carbon brushes, insert the new ones
and secure the brush holder caps.
To maintain product SAFETY and RELIABILITY, repairs,
-
formed by Makita Authorized Service Centers, always
using Makita replacement parts.
10
OPTIONAL
ACCESSORIES
CAUTION:
-
in this manual. The use of any other accessories
persons. Only use accessory or attachment for
its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
NOTE:
tool package as standard accessories. They
may differ from country to country.
ENGLISH
11
www.makita.com
Mak i t a E ur ope N.V.
Mak i t a C or poration 3-11- 8, S um i y os hi - c ho,
Anjo, A i c hi 446-8502 Japan
Jan-Baptist Vi nk s t r aat 2,
3070 Kortenberg, B el gi um
885199C226
EN
Other manuals for GS5000
9
This manual suits for next models
1
Table of contents
Other Makita Power Tools manuals
Makita
Makita DHS660 User manual
Makita
Makita JN3201 User manual
Makita
Makita WR100D User manual
Makita
Makita 6016 User manual
Makita
Makita DCS553 User manual
Makita
Makita DTW181Z User manual
Makita
Makita JS3201 User manual
Makita
Makita DTM41 User manual
Makita
Makita UX01G User manual
Makita
Makita Makstar BVR450 User manual
Makita
Makita 4305 User manual
Makita
Makita DPP200 User manual
Makita
Makita DHR202 User manual
Makita
Makita TW100D Series User manual
Makita
Makita DTW250 User manual
Makita
Makita BTW151 User manual
Makita
Makita DUX18 User manual
Makita
Makita DJV140 User manual
Makita
Makita 1806B User manual
Makita
Makita 4304 User manual
