Makita 9045N Manual

Volt Current Frequency Continuous rating input
100V 5.5 A 50-60 Hz 520 W
Abrasive paper size 114 x 280 mm
Pad size 114 x 234 mm
No load speed (R.P.M.) 10000 rpm
Overall length 268 x 132 x 160 mm
Net weight 2.8 kg
Power supply cord 2.5 m
Abrasive paper --- #60, #100, #120, #150, #180 two pieces for each
Parts no Names Applications
7425019 Abrasive paper 114-60 For wood #60, 10 pieces contained
7425027 Abrasive paper 114-100 For wood #100, 10 pieces contained
7425035 Abrasive paper 114-120 For wood #120, 10 pieces contained
7425043 Abrasive paper 114-150 For wood #150, 10 pieces contained
7425051 Abrasive paper 114-180 For wood #180, 10 pieces contained
The standard equipment for the tools shown may differ form country to country
CONCEPT AND MAIN APPLICATIONS
The model 9045N has been developed as the new
model of the current type of 9045. Unlike the
conventional type, the dust collecting unit is
installed and the machine vibration has been
minimized to extremely improve the working efficiency.
Appearace layout
Models No.
Description
New Tool
TECHNICAL INFORMATION
9045N
MAKITA Finishing sander
Specifications
Standard equipment
Optional accessories

(1) Disassembling
(a) Remove the steel band(for holding the rubber sleeve)mounted on the base from between the base and the frame.
(b) Remove the push buttons(2 pieces at back/forth) protruded above the top of frame.
(c) Remove the bearing retainer at center on the base. To disconnect it, place the minus screw driver on the cracked
point on the bearing retainer and turn the bearing retainer in left.
(d) Remove the pan head screw M5x12 holding the balance weight on the bearing #6003ZZ. At this time insert the
minus screw driver into the rubber sleeve to protect the balance weight from turning for easy disconnection.
Repair
(2) Cautions in assembling
(a) Slightly grease the Grease(Albania No.2)on the needle bearing housed in the frame.
(b) When assembling the base, assemble it so that the face at base side can be parallel to the face at the frame side.
(e) Next disconnect the base. If hard to disconnect it due to the base tightly connected, insert the screw driver
between the frame and the base and disconnect while slightly twisting the driver.
