7ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: DUR189
No load speed
(without cutting tool)
4,000/5,000/6,000 min-1
Overall length
(without cutting tool)
1,510 - 1,610 mm
Nylon cord diameter 2.0 - 2.4 mm
Applicable
cutting tool
and cutting
diameter
Nylon cutting head (P/N
198971-4 / 198972-2)
300 mm
Plastic blade (P/N
198383-1 / 198384-9)
255 mm
Rated voltage D.C. 18 V
Net weight 3.0 - 3.3 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydi󰀨erfromcountrytocountry.
• Theweightmaydi󰀨erdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-
estcombination,accordingtoEPTA-Procedure01/2014,areshowninthetable.
Applicable battery cartridge and charger
Battery cartridge BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 /
BL1840B / BL1850 / BL1850B / BL1860B
Charger DC18RC/DC18RD/DC18RE/DC18SD/DC18SE/DC18SF/
DC18SH
• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionof
residence.
WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges
andchargersmaycauseinjuryand/orre.
Symbols
Thefollowingsshowthesymbolswhichmaybeused
fortheequipment.Besurethatyouunderstandtheir
meaningbeforeuse.
Takeparticularcareandattention.
Read instruction manual.
Danger;beawareofthrownobjects.
Thedistancebetweenthetooland
bystanders must be at least 15 m.
360°
Keep bystanders away.
15m(50FT)Keep distance at least 15 m.
Wear a helmet, goggles and ear protection.
Wear protective gloves.
Wear sturdy boots with nonslip soles.
Steeltoedsafetybootsarerecommended.
Do not expose to moisture.
Never use metal blade.
Ni-MH
Li-ion
OnlyforEUcountries
Donotdisposeofelectricequipmentor
battery pack together with household
wastematerial!Inobservanceofthe
European Directives, on Waste Electric
andElectronicEquipmentandBatteries
and Accumulators and Waste Batteries and
Accumulators and their implementation
in accordance with national laws, electric
equipmentandbatteriesandbattery
pack(s)thathavereachedtheendof
theirlifemustbecollectedseparatelyand
returned to an environmentally compatible
recyclingfacility.

8ENGLISH
SAFETY WARNINGS
IMPORTANT SAFETY
INSTRUCTIONS
WARNING: Read all safety warnings and
all instructions. Failuretofollowthewarningsand
instructionsmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
1. Be familiar with the controls and proper use of
the equipment.
2. Cutting elements continue to rotate after the
motor is switched o󰀨.
3. Never allow children or people unfamiliar with
the instructions to use the machine. Local reg-
ulations may restrict the age of the operator.
4. Stop using the machine while people, espe-
cially children, or pets are nearby.
5. Only use the machine in daylight or good
articial light. Avoid using the machine in bad
weather conditions especially when there is a
risk of lightning.
6. Before using the machine and after any
impact, check for signs of wear or damage and
repair as necessary.
7. Take care against injury from any device
tted for trimming the lament line length.
After extending new cutter line always return
the machine to its normal operating position
before switching on.
8. Never t metal cutting elements.
9. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with
the appliance.
10. Use the tool with the utmost care and
attention.
11. Operate the tool only if you are in good phys-
ical condition. Perform all work calmly and
carefully. Use common sense and keep in mind
that the operator or user is responsible for
accidents or hazards occurring to other people
or their property.
12. Never operate the tool when tired, feeling ill or
under the inuence of alcohol or drugs.
13. The tool should be switched o󰀨 immediately if
it shows any signs of unusual operation.
14. Keep ngers away from switch trigger when
not operating the tool and when moving from
one operating position to another.
Intended use of the tool
1. Use right tool. The cordless grass trimmer is
only intended for cutting grass, light weeds. It
should not be used for any other purpose such
as hedge cutting as this may cause injury.
Personal protective equipment
►Fig.1
►Fig.2
1. Dress Properly. The clothing worn should be
functional and appropriate, i.e. it should be
tight-tting but not cause hindrance. Do not
wear either jewelry or clothing which could
become entangled with high grass. Wear pro-
tective hair covering to contain long hair.
2. When using the tool, always wear sturdy shoes
with a non-slip sole. This protects against
injuries and ensures a good footing.
3. Always wear protective goggles to protect
your eyes from injury when using power tools.
The goggles must comply with ANSI Z87.1 in
the USA, EN 166 in Europe, or AS/NZS 1336
in Australia/New Zealand. In Australia/New
Zealand, it is legally required to wear a face
shield to protect your face, too.
It is an employer's responsibility to enforce
the use of appropriate safety protective equip-
ments by the tool operators and by other per-
sons in the immediate working area.
Electrical and battery safety
1. Avoid dangerous environment. Don't use the
tool in damp or wet locations or expose it to
rain. Water entering the tool will increase the
risk of electric shock.
2. Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of
re when used with another battery pack.
3. Use power tools only with specically desig-
nated battery packs. Use of any other battery
packs may create a risk of injury and re.
4. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nals together may cause burns or a re.

9ENGLISH
5. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, seek medical help. Liquid
ejected from the battery may cause irritation or
burns.
6. Do not dispose of the battery(ies) in a re. The
cell may explode. Check with local codes for
possible special disposal instructions.
7. Do not open or mutilate the battery(ies).
Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be
toxic if swallowed.
8. Do not charge battery in rain, or in wet
locations.
Starting up the tool
►Fig.3
1. Make sure that there are no children or other
people within a working range of 15 meters
(50 ft), also pay attention to any animals in the
working vicinity. Otherwise stop using the tool.
2. Before use always check that the tool is safe
for operation. Check the security of the cutting
tool and the guard and the switch trigger/lever
for easy and proper action. Check for clean
and dry handles and test the on/o󰀨 function of
the switch.
3. Check damaged parts before further use of
the tool. A guard or other part that is damaged
should be carefully checked to determine
that it will operate properly and perform its
intended function. Check for alignment of
moving parts, binding of moving parts, break-
age of parts, mounting, and any other condi-
tion that may a󰀨ect its operation. A guard or
other part that is damaged should be properly
repaired or replaced by our authorized ser-
vice center unless indicated elsewhere in this
manual.
4. Switch on the motor only when hands and feet
are away from the cutting tool.
5. Before starting make sure that the cutting
tool has no contact with hard objects such as
branches, stones etc. as the cutting tool will
revolve when starting.
6. Make sure there are no electrical cables, water
pipes, gas pipes etc. that could cause a hazard
if damaged by use of the tool.
Method of operation
1. Never operate the machine with damaged
guards or without the guards in place.
2. Only use the tool in good light and visibility.
During the winter season beware of slippery
or wet areas, ice and snow (risk of slipping).
Always ensure a safe footing.
3. Take care against injury to feet and hands from
the cutting tool.
4. Keep hands and feet away from the cutting
means at all times and especially when switch-
ing on the motor.
5. Never cut above waist height.
6. Never stand on a ladder and run the tool.
7. Never work on unstable surfaces.
8. Don't overreach. Keep proper footing and
balance at all times.
9. Remove sand, stones, nails etc. found within
the working range. Foreign particles may
damage the cutting tool and can cause to be
thrown away, resulting in a serious injury.
10. Should the cutting tool hit stones or other hard
objects, immediately switch o󰀨 the motor and
inspect the cutting tool.
11. Before commencing cutting, the cutting tool
must have reached full working speed.
12. During operation always hold the tool with
both hands. Never hold the tool with one hand
during use. Always ensure a safe footing.
13. All protective equipment such as guards
supplied with the tool must be used during
operation.
14. Except in case of emergency, never drop
or cast the tool to the ground or this may
severely damage the tool.
15. Never drag the tool on the ground when mov-
ing from place to place, the tool may become
damaged if moved in this manner.
16. Always remove the battery cartridge from the
tool:
— whenever leaving the tool unattended;
— before clearing a blockage;
— before checking, cleaning or working on
the tool;
— before making any adjustments, chang-
ing accessories or storing;
— whenever the tool starts vibrating
unusually;
— whenever transporting the tool.
17. Don't force the tool. It will do the job better and
with less likelihood of a risk of injury at the
rate for which it was designed.
18. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
whichmayignitethedustorfumes.
19. Take a rest to prevent loss of control caused
by fatigue. We recommend to take a 10 to
20-minute rest every hour.
20. Do not use the tool on steep slopes.
21. The shoulder harness must be used during
operation, if supplied with the tool.
Maintenance instructions
1. The condition of the cutting tool, protec-
tive devices and shoulder harness must be
checked before commencing work.
2. Turn o󰀨 the motor and remove the battery
cartridge before carrying out maintenance,
replacing the cutting tool and cleaning the
tool.
3. After use, disconnect the battery cartridge
from the tool and check for damage.
4. Check for loose fasteners and damaged parts
such as nearly halfway cut-o󰀨 state in the
cutting tool.
5. When not in use store the equipment in a dry
location that is locked up or out of children's
reach.

10 ENGLISH
6. Use only the manufacturer's recommended
replacement parts and accessories.
7. Always ensure that ventilation openings are
kept clear of debris.
8. Inspect and maintain the tool regularly, espe-
cially before/after use. Have the tool repaired
only by our authorized service center.
9. Keep handles dry, clean and free from oil and
grease.
SAVE THESE INSTRUCTIONS.
WARNING: DO NOT let comfort or familiarity
with product (gained from repeated use) replace
strict adherence to safety rules for the subject
product. MISUSE or failure to follow the safety
rules stated in this instruction manual may cause
serious personal injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble or tamper with the battery
cartridge.Itmayresultinare,excessiveheat,
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store and use the tool and battery car-
tridge in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge.Suchconductmayresultina
re,excessiveheat,orexplosion.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
Forcommercialtransportse.g.bythirdparties,
forwardingagents,specialrequirementonpack-
aging and labeling must be observed.
Forpreparationoftheitembeingshipped,consult-
inganexpertforhazardousmaterialisrequired.
Please also observe possibly more detailed
national regulations.
Tapeormasko󰀨opencontactsandpackupthe
battery in such a manner that it cannot move
around in the packaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
specied by Makita. Installing the batteries to
non-compliantproductsmayresultinare,exces-
siveheat,explosion,orleakofelectrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.
14. During and after use, the battery cartridge may
take on heat which can cause burns or low
temperature burns. Pay attention to the han-
dling of hot battery cartridges.
15. Do not touch the terminal of the tool imme-
diately after use as it may get hot enough to
cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge.Itmayresultinpoorperformanceor
breakdownofthetoolorbatterycartridge.
17. Unless the tool supports the use near
high-voltage electrical power lines, do not use
the battery cartridge near high-voltage electri-
cal power lines.Itmayresultinamalfunctionor
breakdownofthetoolorbatterycartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Useofnon-genuineMakitabatteries,orbatteriesthat
have been altered, may result in the battery bursting
causingres,personalinjuryanddamage.Itwill
alsovoidtheMakitawarrantyfortheMakitatooland
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.

11 ENGLISH
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).
PARTS DESCRIPTION
►Fig.4
1Battery cartridge 2Lock-o󰀨lever 3Switchtrigger 4Speedindicator
5Auto speed control
indicator
6Power lamp 7Mainpowerbutton 8Reverse button
9Hanger 10 Lock sleeve 11 Handle 12 Protector (cutting tool
guard)
13 Shoulderharness - - - - - -
FUNCTIONAL
DESCRIPTION
WARNING: Always be sure that the tool is
switched o󰀨 and the battery cartridge is removed
before adjusting or checking function on the tool.
Failuretoswitcho󰀨andremovethebatterycartridge
mayresultinseriouspersonalinjuryfromaccidental
start-up.
Installing or removing battery
cartridge
CAUTION: Always switch o󰀨 the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge.Failuretoholdthetoolandthebattery
cartridgermlymaycausethemtoslipo󰀨yourhands
and result in damage to the tool and battery cartridge
andapersonalinjury.
►Fig.5: 1. Red indicator 2. Button 3. Battery cartridge
Toremovethebatterycartridge,slideitfromthetool
whileslidingthebuttononthefrontofthecartridge.
Toinstallthebatterycartridge,alignthetongueonthe
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
withalittleclick.Ifyoucanseetheredindicatoronthe
uppersideofthebutton,itisnotlockedcompletely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen.Ifnot,
itmayaccidentallyfalloutofthetool,causinginjuryto
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly.Ifthecartridgedoesnotslideineasily,itis
not being inserted correctly.
Tool / battery protection system
Thetoolisequippedwithatool/batteryprotectionsys-
tem.Thissystemautomaticallycutso󰀨powertothe
motortoextendtoolandbatterylife.Thetoolwillauto-
maticallystopduringoperationifthetoolorbatteryis
placedunderoneofthefollowingconditions:
Status Indicator lamps
On O󰀨 Blinking
Overload
Overheat
Over
discharge
Overload protection
Ifthetoolisoverloadedbyentangledweedsorother
debris, and the middle indicators start blinking and
the tool automatically stops.
Inthissituation,turnthetoolo󰀨andstoptheapplication
thatcausedthetooltobecomeoverloaded.Thenturn
the tool on to restart.
Overheat protection for tool or
battery
Therearetwotypesofoverheating;tooloverheating
and battery overheating. When the tool over heating
occurs, all speed indicators blink. When the battery over
heating occurs, indicator blinks.
Iftheoverheatingoccurs,thetoolstopsautomatically.
Letthetooland/orbatterycooldownbeforeturningthe
tool on again.

12 ENGLISH
Overdischarge protection
When the battery capacity becomes low, the tool stops
automatically and indicator blinks.
Ifthetooldoesnotoperateevenwhentheswitchesare
operated,removethebatteriesfromthetoolandcharge
the batteries.
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
►Fig.6: 1. Indicator lamps 2. Check button
Press the check button on the battery cartridge to indi-
catetheremainingbatterycapacity.Theindicatorlamps
lightupforafewseconds.
Indicator lamps Remaining
capacity
Lighted O󰀨 Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
Thebattery
may have
malfunctioned.
NOTE:Dependingontheconditionsofuseandthe
ambienttemperature,theindicationmaydi󰀨erslightly
fromtheactualcapacity.
NOTE:Therst(farleft)indicatorlampwillblinkwhen
the battery protection system works.
Power switch action
WARNING: Before installing the battery car-
tridge on the tool, always check to see that the
switch trigger actuates properly and returns to
the “OFF” position when released. Operating a tool
with a switch that does not actuate properly can lead
tolossofcontrolandseriouspersonalinjury.
CAUTION: Never put your nger on the
switch when carrying.Thetoolmaystartuninten-
tionallyandcauseinjury.
Pressandholdthemainpowerbuttonforsomesec-
onds to turn on the tool.
Toturno󰀨thetool,pressandholdthemainpower
button again.
►Fig.7: 1.Mainpowerbutton
Topreventtheswitchtriggerfrombeingaccidentally
pulled,alock-o󰀨leverisprovided.
Tostartthetool,graspthehandle(thelock-o󰀨leveris
released by the grasp) and then pull the switch trigger.
Tostopthetool,releasetheswitchtrigger.
►Fig.8: 1.Lock-o󰀨lever2.Switchtrigger
NOTE:Thetoolisautomaticallyturnedo󰀨afterthe
toolisleftoneminutewithoutanyoperations.
Speed adjusting
Youcanadjustthetoolspeedbytappingthemain
power button.
Eachtimeyoutapthemainpowerbutton,thelevelof
speed will change.
►Fig.9: 1.Mainpowerbutton
Indicator Mode Rotation speed
Auto 4,000 - 6,000 min-1
High 6,000 min-1
Medium 5,000 min-1
Low 4,000 min-1
Reverse button for debris removal
WARNING: Switch o󰀨 the tool and remove
the battery cartridge before you remove entan-
gled weeds or debris which the reverse rotation
function can not remove.Failuretoswitcho󰀨and
remove the battery cartridge may result in serious
personalinjuryfromaccidentalstart-up.
Thistoolhasareversebuttontochangethedirectionof
rotation.Itisonlyforremovingweedsanddebrisentan-
gled in the tool.
Toreversetherotation,tapthereversebuttonandpull
thetriggerwhenthetool’sheadisstopped.Thepower
lamp starts blinking, and the tool's head rotates in
reverse direction when you pull the switch trigger.
Toreturntoregularrotation,releasethetriggerandwait
until the tool's head stops.
►Fig.10: 1. Reverse button
NOTE: During the reverse rotation, the tool operates
onlyforashortperiodoftimeandthenautomatically
stops.
NOTE: Once the tool is stopped, the rotation returns
to regular direction when you start the tool again.
NOTE:Ifyoutapthereversebuttonwhilethetool's
head is still rotating, the tool comes to stop and to be
readyforreverserotation.

13 ENGLISH
Nylon cutting head
Optional accessory
NOTICE:Thebumpfeedwillnotoperateproperlyif
the head is not rotating.
►Fig.11: 1.Moste󰀨ectivecuttingarea
Thenyloncuttingheadisadualstringtrimmerhead
providedwithabump&feedmechanism.
Tofeedoutthenyloncord,tapthecuttingheadagainst
the ground while rotating.
NOTE:Ifthenyloncorddoesnotfeedoutwhile
tapping the head, rewind/replace the nylon cord
byfollowingtheproceduresdescribedunder
“Maintenance”.
Adjusting the shaft length
WARNING: Before adjusting the shaft length,
release the switch trigger and remove the battery
cartridge from the tool.Failuretoreleasethetrig-
ger and removing the battery cartridge may cause a
personalinjury.
CAUTION: Make sure to tighten the lock
sleeve before operation. Otherwise the tool may
losecontrolandresultinpersonalinjury.
Toadjustthelengthoftheshaft,turnthelocksleeve
counterclockwise until the arrow mark on the lock
sleeve indicates the unlock mark on the housing, and
pulloutorpushintheshafttothedesiredlength.
Afteradjustment,tightenthelocksleeveuntilthearrow
mark on the lock sleeve indicates the lock mark on the
housing.
►Fig.12: 1.Shaft2. Lock sleeve
ASSEMBLY
WARNING: Always be sure that the tool is
switched o󰀨 and battery cartridge is removed
before carrying out any work on the tool.Failureto
switcho󰀨andremovethebatterycartridgemayresult
inseriouspersonalinjuryfromaccidentalstart-up.
WARNING: Never start the tool unless it is
completely assembled.Operationofthetoolina
partially assembled state may result in serious per-
sonalinjuryfromaccidentalstart-up.
Installing the handle
Fitthehandleontotheshaftandsecureitwiththebolt
and the knob.
►Fig.13: 1.Handle2. Bolt 3. Knob 4. Cutting tool
side 5. Battery cartridge side
Makesurethatthehandleislocatedinthestraightarea
oftheshaftasshowninthegure.
►Fig.14
Installing the protector
WARNING: Never use the tool without the
protector illustrated in place.Failuretodosocan
causeseriouspersonalinjury.
CAUTION: Take care not to injure yourself on
the cutter for cutting the nylon cord.
1. Attach the protector and the protector holder to the
motorhousingasillustrated.Besuretottheprojec-
tions and grooves on them to their counter parts.
►Fig.15: 1. Protector 2. Groove 3.Projection
4. Protector holder
2. Tightenthehexsocketheadboltssecurelyto
fastentheprotectorandtheprotectorholder.
►Fig.16: 1.Hexsocketheadbolt2.Hexwrench
Installing the wire guard
CAUTION: Before adjusting the wire guard,
wait for the cutting head comes to standstill. Do
not adjust the wire guard with your foot.
►Fig.17
Toreducetheriskdamagingtheobjectsinfrontofthe
cutting head, insert the wire guard so that it controls the
cuttingrangeofthemowingline.
Slightlyexpandthewireguardoutwardandtheninsert
it into the holes on the protector.
►Fig.18: 1. Wire guard 2.Hole(onbothsides)
NOTICE: Do not expand the wire guard outward too
much. Otherwise it may break.
Whenwireguardisnotinuse,liftitfortheidleposition.
►Fig.19
Installing nylon cutting head
Optional accessory
CAUTION: If the nylon cutting head acciden-
tally impacts a rock or hard object during oper-
ation, stop the tool and inspect for any damage.
If the nylon cutting head is damaged, replace it
immediately.Useofadamagedcuttingtoolcould
resultinseriouspersonalinjury.
CAUTION: Be sure to remove the hex wrench
after installation.
NOTICE: Be sure to use genuine Makita nylon
cutting head.
►Fig.20: 1. Nylon cutting head 2.Metalguard
3.Spindle4.Hexwrench5.Tighten
6. Loosen
1. Turnthetoolupsidedownsothatyoucanreplace
the cutting tool easily.
2. Insert the hex wrench through the hole on the
motor housing and rotate the spindle until the spindle is
locked.

14 ENGLISH
3. Place the nylon cutting head onto the threaded
spindle directly and tighten it by turning in the tightening
directionasshowninthegure.
4. Remove the hex wrench.
Toremovethenyloncuttinghead,turnitintheopposite
direction while locking the spindle with the hex wrench.
Installing plastic blade
Optional accessory
CAUTION: If the plastic blade accidentally
impacts a rock or hard object during operation,
stop the tool and inspect for any damage. If the
plastic blade is damaged, replace it immediately.
Useofadamagedcuttingtoolcouldresultinserious
personalinjury.
CAUTION: Be sure to remove the hex wrench
after installation.
NOTICE: Be sure to use genuine Makita plastic
blade.
►Fig.21: 1. Plastic blade 2.Metalguard3.Hex
wrench 4.Tighten5. Loosen
1. Turnthetoolupsidedownsothatyoucanreplace
the cutting tool easily.
2. Insert the hex wrench through the hole on the
motor housing and rotate the spindle until the spindle is
locked.
3. Place the plastic blade onto the threaded spindle
directly and tighten it by turning in the tightening direc-
tionasshowninthegure.
4. Remove the hex wrench.
Toremovetheplasticblade,turnitintheoppositedirec-
tion while locking the spindle with the hex wrench.
Hex wrench storage
CAUTION: Be careful not to leave the hex
wrench inserted in the tool head. It may cause
injuryand/ordamagetothetool.
When not in use, store the hex wrench as shown in the
guretokeepitfrombeinglost.
►Fig.22: 1.Hexwrench
OPERATION
Correct handling of tool
WARNING: Always position the tool on your
right-hand side.Correctpositioningofthetoolallows
formaximumcontrolandwillreducetheriskofseri-
ouspersonalinjurycausedbykickback.
WARNING: Be extremely careful to maintain
control of the tool at all times. Do not allow the
tool to be deected toward you or anyone in the
work vicinity.Failuretokeepcontrolofthetool
couldresultinseriousinjurytothebystanderandthe
operator.
WARNING: To avoid accident, leave more
than 15m (50 ft) distance between operators when
two or more operators work in one area. Also,
arrange a person to observe the distance between
operators. If someone or an animal enter the
working area, immediately stop the operation.
►Fig.23
Attachment of shoulder harness
CAUTION: Always use the shoulder harness
attached. Before operation, adjust the shoulder
harness according to the user size to prevent
fatigue.
CAUTION: When you use the tool in combi-
nation of the backpack-type power supply such
as portable power pack, do not use the shoulder
harness included in the tool package, but use the
hanging band recommended by Makita.
Ifyouputontheshoulderharnessincludedinthe
toolpackageandtheshoulderharnessoftheback-
pack-type power supply at the same time, removing
thetoolorbackpack-typepowersupplyisdi󰀩cultin
caseofanemergency,anditmaycauseanaccident
orinjury.Fortherecommendedhangingband,ask
MakitaAuthorizedServiceCenters.
Connecttheclaspoftheshoulderharnesstothe
hangerpartofthehousing.Puttheshoulderharness
on. Be sure that the buckles are locked completely in
place.
►Fig.24: 1. Clasp 2.Hanger
Detachment
Thebuckleisprovidedwithameansofquickrelease.
Simplysqueezethesidesofthebuckletoreleasethe
tool.
►Fig.25: 1. Buckle

15 ENGLISH
MAINTENANCE
WARNING: Always be sure that the tool is
switched o󰀨 and battery cartridge is removed
before attempting to perform inspection or main-
tenance on the tool.Failuretoswitcho󰀨andremove
the battery cartridge may result in serious personal
injuryfromaccidentalstart-up.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Replacing the nylon cord
WARNING: Use nylon cord with diameter
specied in “SPECIFICATIONS” only. Never use
heavier line, metal wire, rope or the like. Use rec-
ommended nylon cord only, otherwise it may cause
damage to the tool and result in serious personal
injury.
WARNING: Make sure that the cover of the
nylon cutting head is secured to the housing
properly as described below.Failuretoproperly
secure the cover may cause the nylon cutting head to
yapartresultinginseriouspersonalinjury.
1. Pressonthehousinglatchesinwardtolifto󰀨the
cover, then remove the spool.
►Fig.26: 1. Latch 2. Cover
2. Prepareapproximately3m(9ft)ofnewnylon
cord.Foldthenewnyloncordwithoneendbecome
approximately80mm(3-1/8″)longerthantheother
end.Thenhookthenewnyloncordintothenotchinthe
centerofthespool.
Windbothendsrmlyaroundthespoolinthedirection
oftheheadrotation(right-handdirectionindicatedby
RHonthesideofthespool).
►Fig.27: 1.Spool
3. Windallbutabout100mm(3-15/16″)ofthe
cords, leaving the ends temporarily hooked through a
notchonthesideofthespool.
►Fig.28
4. Mountthespoolinthehousingsothatthegrooves
and protrusions on the spool match up with those in the
housing. Keep the side with letters on the spool visible
onthetop.Now,unhooktheendsofthecordfromtheir
temporarypositionandfeedthecordsthroughthe
eyeletstocomeoutofthehousing.
►Fig.29: 1.Spool2.Housing3. Eyelet
5. Aligntheprotrusionontheundersideofthecover
withtheslotsoftheeyelets.Thenpushthecoverrmly
onto the housing to secure it.
►Fig.30
Replacing the plastic blade
Replacetheplasticbladeifitiswornoutorbroken.
►Fig.31
Wheninstallingtheplasticblade,alignthedirectionof
thearrowonthebladewiththatoftheprotector.
►Fig.32: 1. Arrow on the protector 2. Arrow on the
blade
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.

16 ENGLISH
TROUBLESHOOTING
Beforeaskingforrepairs,conductyourowninspectionrst.Ifyoundaproblemthatisnotexplainedinthemanual,
donotattempttodismantlethetool.Instead,askMakitaAuthorizedServiceCenters,alwaysusingMakitareplace-
mentpartsforrepairs.
State of abnormality Probable cause (malfunction) Remedy
Motordoesnotrun. Battery cartridge is not installed. Install the battery cartridge.
Battery problem (under voltage) Rechargethebattery.Ifrechargingisnote󰀨ective,
replace battery.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Motorstopsrunningafteralittleuse. Battery's charge level is low. Rechargethebattery.Ifrechargingisnote󰀨ective,
replace battery.
Overheating. Stopusingoftooltoallowittocooldown.
ItdoesnotreachmaximumRPM. Battery is installed improperly. Install the battery cartridge as described in this
manual.
Battery power is dropping. Rechargethebattery.Ifrechargingisnote󰀨ective,
replace battery.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Cuttingtooldoesnotrotate:
stop the machine immediately!
Foreignobjectsuchasabranchis
jammedbetweentheprotectorandthe
cutting tool.
Removetheforeignobject.
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Abnormalvibration:
stop the machine immediately!
Oneendofthenyloncordhasbeen
broken.
Tapthenyloncuttingheadagainstthegroundwhile
itisrotatingtocausethecordtofeed.
Plastic blade(s) is broken. Replace broken plastic blade(s) with new one(s).
Thedrivesystemdoesnotwork
correctly.
Askyourlocalauthorizedservicecenterforrepair.
Cuttingtoolandmotorcannotstop:
Remove the battery immediately!
Electricorelectronicmalfunction. Removethebatteryandaskyourlocalauthorized
servicecenterforrepair.
OPTIONAL
ACCESSORIES
WARNING: Do not mount a metal blade on
this tool and only use the recommended accesso-
ries or attachments indicated in this manual.The
useofametalbladeoranyotheraccessoryorattach-
mentmayresultinseriouspersonalinjury.
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
specied in this manual.Theuseofanyother
accessoriesorattachmentsmightpresentariskof
injurytopersons.Onlyuseaccessoryorattachment
foritsstatedpurpose.
Ifyouneedanyassistanceformoredetailsregard-
ingtheseaccessories,askyourlocalMakitaService
Center.
• Nyloncuttinghead
• Nyloncord(cuttingline)
• Plasticblade
• Makitagenuinebatteryandcharger
NOTE:Someitemsinthelistmaybeincludedinthe
toolpackageasstandardaccessories.Theymay
di󰀨erfromcountrytocountry.

17
中文简体
中文简体 (原本)
规格
型号： DUR189
空载速度
（不含切割工具）
4,000/5,000/6,000 /min
总长度
（不含切割工具）
1,510 - 1,610 mm
尼龙线直径 2.0 - 2.4 mm
适用切割
工具和切
割直径
尼龙打草头
（P/N 198971-4 /
198972-2）
300 mm
塑料刀片
（P/N 198383-1 /
198384-9）
255 mm
额定电压 D.C. 18 V
净重 3.0 - 3.3 kg
•生产者保留变更规格不另行通知之权利。
•规格可能因销往国家之不同而异。
•重量因附件（包括电池组）而异。根据EPTA-Procedure01/2014，最重与最轻的组合
见表格。
适用电池组和充电器
电池组 BL1815N / BL1820 / BL1820B / BL1830 /
BL1830B / BL1840 / BL1840B / BL1850 /
BL1850B / BL1860B
充电器 DC18RC/DC18RD/DC18RE/DC18SD/
DC18SE/DC18SF/DC18SH
•部分以上所列电池组和充电器是否适用视用户所在地区而异。
警告： 请仅使用以上所列电池组和充电器。使用其他类型的电池组或充电器可能会导
致人身伤害和／或失火。
符号
以下显示本设备可能会使用的符号。在使用
工具之前，请务必理解其含义。
特别小心和注意。
阅读使用说明书。
危险；注意抛掷物体。
工具和旁观者的距离至少为
15 m。
360°
使旁观者远离。
15m(50FT)保持最少15 m的距离。
佩戴头盔、护目镜和耳罩。
佩戴防护手套。
穿戴具有防滑底的结实靴。
建议穿戴铁头安全靴。
勿暴露于潮湿环境。

18
中文简体
切勿使用金属刀片。
Ni-MH
Li-ion 仅限于欧盟国家
请勿将电气设备或电池组与家
庭普通废弃物一同丢弃！请务
必遵守欧洲关于废弃电子电气
设备、电池和蓄电池以及废弃
电池和蓄电池的指令并根据法
律法规执行。达到使用寿命的
电气设备和电池组必须分类回
收至符合环境保护规定的再循
环机构。
安全警告
重要安全注意事项
警告： 阅读所有警告和所有说明。不
遵照以下警告和说明会导致电击、着火
和／或严重伤害。
保存所有警告和说明书以备查
阅。
1. 熟悉控制和正确操作本设备的方法。
2. 电机关闭后切割部件还会继续旋转。
3. 勿允许儿童或不熟悉这些使用须知的人
员使用本机器。当地法规会限制操作人
员的年龄。
4. 切勿在附近有人（特别是儿童）或宠物
的情况下使用本机器。
5. 仅可在光线充足或良好照明的情况下使
用机器。请避免在恶劣天气尤其是雷电
天气条件下使用机器。
6. 在使用机器前或机器受到撞击后，检查
磨损或损坏情况，必要时进行维修。
7. 注意不要被割草线设备划伤。扩展新的
切割线之后，务必在开启设备前将其恢
复至正常操作位置。
8. 切勿安装金属切割部件。
9. 本设备不得由不熟悉操作说明的人员
（包括小孩）和体力、感觉及心智不健
全或缺乏经验和知识的人员使用，除非
由负责他们安全的人员在使用时对他们
进行监督和指导。应看管好儿童，勿让
其玩耍本工具。
10. 使用工具时务必特别小心谨慎。
11. 请仅在身体状态良好的情况下操作工
具。镇定且小心地进行所有操作。操作
时运用常识并时刻谨记，如果给他人及
其财产造成损失，操作者或用户要为此
负责。
12. 切勿在疲劳、身体不适或饮酒、服药的
情况下操作工具。
13. 如果工具有运行故障的迹象，应立即关
闭工具。
14. 不操作工具以及在操作位置之间移动
时，请使手指远离开关扳机。
工具用途
1. 使用正确的工具。充电式草坪修剪机仅
用于切割青草和草丛。不应将其用作其
他用途，如树篱切割，否则可能会造成
人身伤害。
个人防护设备
►图片1
►图片2
1. 注意衣装。着装应实用得体，如应穿着
紧身但不能妨碍操作的衣服。请勿佩戴
首饰或穿着可能会与草丛缠在一起的衣
服。佩带保护头盔来保护长发。
2. 使用工具时，务必穿戴具有防滑底的结
实靴。这可以避免受到伤害并确保立足
稳固。
3. 使用电动工具时请始终佩带护目镜以
免伤害眼睛。护目镜须符合美国ANSI
Z87.1、欧洲EN 166或者澳大利亚／新
西兰的AS/NZS 1336的规定。在澳大
利亚／新西兰，法律要求佩带面罩保护
脸部。
雇主有责任监督工具操作者和其他近工
作区域人员佩带合适的安全防护设备。

19
中文简体
电气和电池安全
1. 避免危险的环境。请勿在潮湿或淋雨环
境下使用工具。工具受潮将增加触电的
危险。
2. 请仅使用制造商指定的充电器进行充电。
将适用于某一种类型电池组的充电器用于
其他类型的电池组时，可能会导致起火。
3. 电动工具仅可使用专门指定的电池组。
使用其他类型的电池组可能会导致人身
伤害或起火。
4. 不使用电池组时请将其远离纸夹、硬币、
钥匙、钉子、螺丝或其他小型金属物体放
置。这些物体可能会使电池端子短路。这
些物体可能会使电池端子短路，引起燃烧
或起火。
5. 使用过度时，电池中可能溢出液体。请
避免接触。如果意外接触到电池漏液，
请用水冲洗。如果液体接触到眼睛，请
就医。电池漏液可能会导致过敏发炎或
灼伤。
6. 请勿将电池弃于火中。否则会引起电池
爆炸。请查阅当地法规了解适当的特殊
处理说明。
7. 请勿打开或拆解电池。溢出的电解质具
有腐蚀性，可能会对眼睛或皮肤造成损
伤。吞服则有致毒危险。
8. 请勿在雨中或潮湿的地方充电。
启动工具
►图片3
1. 确保无儿童或其他人员在15 m（50英
尺）的工作范围内，并确保工作区域没
有任何其他动物。否则请停止使用工具。
2. 使用前务必检查并确保可以安全操作工
具。检查切割工具、保护罩以及开关扳
机／杆的的安全性，并确保其可以正常
工作。确保把手清洁干燥并测试开关的
启动／停止功能。
3. 进一步使用工具前请检查受损部件。应
仔细检查保护罩或其他部件有无损坏，
以确定工具是否可以正常运转。检查运
动部件是否有偏差或粘连、部件是否破
损、安装是否妥当以及其他可能会影响
工具运行的情况。除非本手册另有声明，
否则应对受损保护罩或其他部件进行修复
或由授权维修中心进行更换。
4. 仅当手和脚离开切割工具时方可打开电
机。
5. 打开切割工具前确保其不与硬质物体如，
枝干、石头等接触，否则会导致工具起动
时打转。
6. 请确保不存在电缆、水管、煤气管道
等，如果其因使用本工具而受损，可能
会引起危险。
操作方法
1. 切勿在保护罩受损或未将保护罩安装到
位时运行工具。
2. 仅在光线及可视性良好的环境下使用工
具。在冬季，要注意打滑或潮湿区域以
及冰雪等（打滑危险）。务必确保立足
稳固。
3. 小心避免切割工具伤及脚和手。
4. 请始终将手、足远离切割部件，在开启
电机后尤其需要注意。
5. 切勿在腰部高度以上进行切割。
6. 切勿站立在梯子上操作工具。
7. 切勿在非稳固表面上进行作业。
8. 请勿伸得过远。操作时请双脚站稳，始
终保持平衡。
9. 除去工作范围内的砂石、砾石、钉子
等。这些异物可能会损坏切割工具，可
能会飞溅出去导致严重的人身伤害。
10. 如果切割工具打到石头或其他硬物，应
立即关闭电机并对切割工具进行检查。
11. 开始切割前，必须使切割工具达到全速。
12. 操作时务必用双手握住工具。切勿在使
用时仅用一只手握住工具。务必确保立
足稳固。
13. 操作期间，必须使用工具附带的所有防
护设备，例如，保护罩。
14. 除紧急情况外，切勿抛掷或弃扔工具到
地面上，否则可能会严重损坏工具。
15. 移动工具时切勿在地面上拖曳工具，否
则会使工具受损。
16. 出现以下情况时，务必从工具上拆下电
池组：
— 工具无人照看时；
— 清除堵塞物前；
— 检查、清洁或处理工具前；
— 在进行任何调节、更换附件或存放
工具之前；
— 工具开始异常振动时；
— 搬运工具时。
17. 请勿滥用工具。在设计的额定功率下使
用设备可更好地完成工作并能降低损伤
风险。
18. 请勿在易爆环境，如有可燃性液体、气
体或粉尘的环境下操作电动工具。电动
工具产生的火花可能会引燃粉尘或气体。

20
中文简体
19. 注意休息，以免疲劳操作导致失控。建
议每隔1小时休息10到20分钟。
20. 切勿在陡坡上使用该工具。
21. 操作期间务必使用随工具附带的肩带
（如果有）。
保养说明
1. 开始工作前，必须检查切割工具、防护
设备和肩带等的状态。
2. 执行保养、更换切割工具以及清洁工具
前必须关闭电机并拆下电池组。
3. 使用完毕后，取出电池组，检查工具是
否受损。
4. 检查是否有松散的紧固装置、损坏部件，
如切割工具上的裂痕等。
5. 不使用设备时，请将设备存放在加锁或
儿童无法触及的干燥位置。
6. 仅使用制造商建议的替换部件和附件。
7. 务必确保通风口无任何碎片。
8. 定期检查和保养工具，特别是在使用前
后。仅通过我们的授权维修中心来修复
工具。
9. 保持把手干燥、清洁，无油污和润滑脂。
请保留此说明书。
警告： 请勿为图方便或因对产品足够
熟悉（由于重复使用而获得的经验）而不
严格遵循相关产品安全规则。使用不当或
不遵循使用说明书中的安全规则会导致严
重的人身伤害。
电池组的重要安全注意事项
1. 在使用电池组之前，请仔细通读所有的
说明以及（1）电池充电器，（2）电
池，以及（3）使用电池的产品上的警
告标记。
2. 切勿拆卸或改装电池组。否则可能引起
火灾、过热或爆炸。
3. 如果机器运行时间变得过短，请立即停
止使用。否则可能会导致过热、起火甚
至爆炸。
4. 如果电解液进入您的眼睛，请用清水将
其冲洗干净并立即就医。否则可能会导
致视力受损。
5. 请勿使电池组短路：
(1) 请勿使任何导电材料碰触到端子。
(2) 避免将电池组与其他金属物品如钉
子、硬币等放置在同一容器内。
(3) 请勿将电池组置于水中或使其淋雨。
电池短路将产生大的电流，导致过热，
并可能导致起火甚至击穿。
6. 请勿在温度可能达到或超过50°C
（122°F）的场所存放以及使用工具和
电池组。
7. 即使电池组已经严重损坏或完全磨损，也
请勿焚烧电池组。电池组会在火中爆炸。
8. 请勿对电池组射钉，或者切削、挤压、抛
掷、掉落电池组，又或者用硬物撞击电池
组。否则可能引起火灾、过热或爆炸。
9. 请勿使用损坏的电池。
10. 本工具附带的锂离子电池需符合危险品
法规要求。
第三方或转运代理等进行商业运输时，
应遵循包装和标识方面的特殊要求。
有关运输项目的准备作业，咨询危险品
方面的专业人士。同时，请遵守可能更
为详尽的国家法规。
请使用胶带保护且勿遮掩表面的联络信
息，并牢固封装电池，使电池在包装内
不可动。
11. 丢弃电池组时，需将其从工具上卸下并
在安全地带进行处理。关于如何处理废
弃的电池，请遵循当地法规。
12. 仅将电池用于Makita（牧田）指定的产
品。将电池安装至不兼容的产品会导致
起火、过热、爆炸或电解液泄漏。
13. 如长时间未使用工具，必须将电池从工
具内取出。
14. 使用工具期间以及使用工具之后，电池组
温度可能较高易引起灼伤或低温烫伤。处
理高温电池组时请小心操作。
15. 在使用工具后请勿立即触碰工具的端子，
否则可能引起灼伤。
16. 避免锯屑、灰尘或泥土卡入电池组的端
子、孔口和凹槽内。否则可能导致工具
或电池组性能下降或故障。
17. 除非工具支持在高压电源线路附近使用，
否则请勿在高压电源线路附近使用电池
组。否则可能导致工具或电池组故障或
失常。
18. 确保电池远离儿童。
请保留此说明书。
