Makita VC3211H User manual

1
ENGLISH (Original instructions)
INSTRUCTION MANUAL
IMPORTANT: Read Before Using.
V
acuum Cleaner
VC3211H
013368

2
ENGLISH (Original instructions)
SPECIFICATIONS
Model VC3211H
Countries EU Switzerland UK
Voltage Volt 230-240 230-240 110 230-240
Power consumption Watt 1050 1050 1050 1050
Watt at symbol mode 2400 1100 600 1900
Connected load for appliance
socket Watt at symbol mode 2600 1400 850 2100
Total connected load Watt 3450 2150 1650 2950
Model VC3211H
With φ28 mm X 3.5 m hose 2.0 m3/min
Volume flow (air) With φ38 mm X 2.5 m hose 3.5 m3/min
Vacuum 22 kPa
Type of protection IP X4 (splash-proof)
Dust 32 L
Recoverable capacity Water 27 L
Dimensions (L x W x H) 552 mm x 398 mm x 685 mm
Net weight 17.0 kg
Safety class Class I
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
END114-2
Symbols
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
･Read instruction manual.
･Take particular care and attention.
･Warning! The cleaner may contain
hazardous dust.
･Never stand on the cleaner.
･The cleaners are capable of picking up
dust class L,M and H. Follow your
county's regulations relating to dusts
and to occupational health and safety.
Warning! This machine contains dust
hazardous to health. Emptying and
maintenance operations, including
removal of the dust collection means,
must only be carried out by authorised
personnel wearing suitable personal
protection. Do not operate without the
full filtration system fitted.
･Only for EU countries
Do not dispose of electric equipment
together with household waste material!
In observance of the European
Directive, on Waste Electric and
Electronic Equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
ENE084-1
Intended use
The tool is intended for collecting both wet and dry dust.
The tool is suitable for commercial use, for example in
hotels, schools, hospitals, factories, shops, offices and
rental businesses.
ENF001-1
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. This tool
should be grounded while in use to protect the operator
from electric shock. Use only three-wire extension cords
which have three-prong grounding-type plugs and three-
pole receptacles which accept the tool's plug.

3
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN/IEC60704:
Sound pressure level (LpA) : 72.5 dB (A)
Uncertainty (K) : 2.5 dB (A)
The noise level under working may exceed 80 dB (A).
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN/IEC60335:
The vibration emission value is below 2.5 m/s2.
ENH038-3
For European countries only
EC Declaration of Conformity
Makita declares that the following Machine(s):
Designation of Machine:
Vacuum Cleaner
Model No./ Type: VC3211H
Conforms to the following European Directives:
2006/42/EC
They are manufactured in accordance with the following
standard or standardized documents:
EN60335
The technical file in accordance with 2006/42/EC is
available from:
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
31.7.2014
000331
Yasushi Fukaya
Director
Makita, Jan-Baptist Vinkstraat 2, 3070, Belgium
ENB121-1
VACUUM CLEANER SAFETY
WARNINGS
WARNING! IMPORTANT READ CAREFULLY all
safety warnings and all instructions BEFORE USE.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
1. Before use, make sure that this cleaner must
be used by people who have been adequately
instructed on the use of this cleaner.
2. Only use the socket outlet on the cleaner for
purposes specified in the instructions.
3. If foam/liquid comes out, switch off
immediately.
4. Clean the water level limiting device regularly
and examine it for signs of damage.
5. Do not use the cleaner without the filter.
Replace a damaged filter immediately.
6. USE OF EXTENSION CORD. When using an
extension cord because of the great distance
to your power source, try to employ a cord
that is sufficiently thick but not too long, or
cleaner performance will be adversely
affected. For outdoor applications use an
extension cord suitable for outdoor use.
7.
VOLTAGE WARNING: Before connecting the
cleaner to a power source (receptacle, outlet, etc.)
be sure the voltage supplied is the same as that
specified on the nameplate of the cleaner. A power
source with voltage greater than that specified for
the cleaner can result in SERIOUS INJURY to the
operator as well as damage to the cleaner. If in
doubt, DO NOT PLUG IN THE CLEANER. Using a
power source with voltage less than the nameplate
rating is harmful to the motor.
8. AVOID UNINTENTIONAL STARTING. Be sure
switch is OFF when plugging in.
9. Do not attempt to pick up flammable materials,
fire works, lighted cigarettes, hot ashes, hot
metal chips, sharp materials such as razors,
needles, broken glass or the like.
10.
NEVER USE THE CLEANER IN THE VICINITY OF
GASOLINE, GAS, PAINT, ADHESIVES OR OTHER
HIGHLY EXPLOSIVE SUBSTANCES. The switch
emits sparks when turned ON and OFF. And so
does the motor commutator during operation. A
dangerous explosion may result.
11. After vacuuming up toxic, carcinogenic or
pathogenic, or other hazardous materials such as
asbestos, arsenic, barium, beryllium, lead,
pesticides, or other health endangering materials,
bring the machine to authorised institution for
cleaning and disposal of those hazardous dusts
in accordance with your country’s regulation.
12. Never vacuum up combustible dusts or materials.
13. Never use the cleaner outdoors in the rain.
14. Do not use close to heat sources (stoves, etc.).
15. GUARD AGAINST ELECTRIC SHOCK. Prevent
body contact with grounded surfaces. For
example; pipes, radiators, ranges, refrigerator
enclosures.
16. Do not block cooling vents. These vents
permit cooling of the motor. Blockage should
be carefully avoided otherwise the motor will
burn out from lack of ventilation.
17. Keep proper footing and balance at all times.
18. DO NOT ABUSE CORD. Never carry the

4
cleaner by cord or yank it to disconnect from
receptacle. Keep cord away from heat, oil, and
sharp edges. Inspect cleaner cords
periodically and if damaged, have repaired by
authorized service facility. Inspect extension
cords periodically and replace if damaged.
19. Do not fold, tug or step on the hose.
20. Stop the cleaner immediately if you notice
poor performance or anything abnormal
during operation.
21.
DISCONNECT THE CLEANER. When not in use,
before servicing, and when changing accessories.
22. Clean and service the cleaner immediately
after each use to keep it in tiptop operating
condition.
23. MAINTAIN THE CLEANER WITH CARE. Keep
the cleaner clean for better and safer
performance. Follow instructions for
changing accessories. Keep handles dry,
clean, and free from oil and grease.
24.
CHECK DAMAGED PARTS. Before further use of
the cleaner, a guard or other part that is damaged
should be carefully checked to determine that it
will operate properly and perform its intended
function. Check for alignment of moving parts,
binding of moving parts, breakage of parts,
mounting, and any other conditions that may
affect its operation. A guard or other part that is
damaged should be properly repaired or replaced
by an authorized service center unless otherwise
indicated elsewhere in this instruction manual.
Have defective switches replaced by authorized
service center. Don’t use the cleaner if switch
does not turn it on and off.
25. REPLACEMENT PARTS. When servicing, use
only identical replacement parts.
26. STORE IDLE CLEANER. When not in use, the
cleaner should be stored indoors.
27.
Be kind to your cleaner. Rough handling can cause
breakage of even the most sturdily built cleaner.
28. Do not attempt to clean the exterior or interior
with benzine, thinner or cleaning chemicals.
Cracks and discoloration may be caused.
29. Do not use cleaner in an enclosed space
where flammable, explosive or toxic vapors
are given off by oil-base paint, paint-thinner,
gasoline, some mothproofing substances, etc.,
or in areas where flammable dust is present.
30. Do not leave the cleaner cord lying on the
floor after you have finished a cleaning job. It
can become a tripping hazard or may cause
damage to the cleaner.
31. Do not operate this or any tool while under
the influence of drugs or alcohol.
32. As a basic rule of safety, use safety goggles
or safety glasses with side shields.
33. Use a dust mask in dusty work conditions.
34. This machine is not intended for use by
persons including children with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge.
35. Young children should be supervised to
ensure that they do not play with the cleaner.
36. Never handle plug cord or cleaner with wet
hands.
37. Use extreme caution when cleaning on stairs.
38. Do not use the cleaner as a stool or work
bench. The machine may fall down and may
result in personal injury.
KEEP FOR FUTURE
REFERENCE
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product. MISUSE or
failure to follow the safety rules stated in this
instruction manual may cause serious personal
injury.

5
FUNCTIONAL DESCRIPTION
WARNING:
• Before plugging the cleaner, always make sure
that the cleaner is switched off. Plugging the
cleaner with the switch on may cause an
unexpected start resulting in serious personal
injury.
Switch action
1
2
3
013369
To start the cleaner, rotate the switch lever to the "I" side.
To stop it, rotate the switch lever to the "O" side.
1
23
013478
The suction force can be adjusted according to your
work need.
Suction force can be increased by turning the suction force
adjusting knob from the symbol to the symbol.
Also, set the hose diameter selection dial to the hose's
diameter that you are going to use.
Hose diameter selection dial
Turn the dial direction in accordance with the hose you
use.
NOTE:
Do not set the dial at the middle. Always turn either side
according to the hose diameter.
Warning beep
There are two types of beeping sound. One is short
beeps, and the other is long beep.
When the air flow speed falls under 20 m/s, the cleaner
emits short warning beeps for safety reasons. When it
sounds, check the hose diameter selection dial or if the
suction force is not too low. If the beeps keep sounding,
perform maintenance or ask your local service center.
When the tank is filled with liquid, the cleaner emits long
warning beep.
When the tank is full and the beep sounds, switch off
the cleaner and empty the tank.
Connecting electric power tools
WARNING:
• Make sure that both the cleaner and the electric
power tool are switched off before connecting or
disconnecting. Connecting the power tool to the
cleaner with both of them being switched on may
cause unexpected and sudden start resulting
serious personal injury.
• Never connect an electric power tool with an input
power exceeding that specified in the
"SPECIFICATIONS" to the socket of the cleaner
by turning the suction force adjusting knob.
Connecting the electric power tool exceeding the
specified input power may cause overheat and
damage to the cleaner.
• When connecting a grounded tool, insert a plug
with a grounding plate to the socket of the cleaner.
The cleaner can be connected to an electric power tool
up to input power shown in the "SPECIFICATIONS".
1
2
3
4
5
013371
1
23
013478
1. To connect an electric power tool, open the outlet
cap and insert the power tool plug into the socket
of the cleaner.
1. Suction force
adjusting knob
2. Hose diameter
selection dial
3. Switch lever
1. Outlet cap
2. Power supply
cord
3. Hose diameter
selection dial
4. Suction force
adjusting knob
5. Switch lever
1. Suction force
adjusting knob
2. Hose diameter
selection dial
3. Switch lever
1. Suction force
adjusting knob
2. Hose diameter
selection dial
3. Switch lever
