Makita DVC261 User manual

DVC261
EN Cordless Backpack Vacuum
Cleaner INSTRUCTION MANUAL 9
FR  MANUEL D’INSTRUCTIONS 19
DE Akku-Rucksackstaubsauger BETRIEBSANLEITUNG 30
IT Aspirapolvere spalleggiato a
batteria ISTRUZIONI PER L’USO 41
NL Ruggedragen accustofzuiger GEBRUIKSAANWIJZING 52
ES Aspiradora de mochila a
batería
MANUAL DE
INSTRUCCIONES 63
PT Aspirador Costal a Bateria MANUAL DE INSTRUÇÕES 74
EL 
  85
TR  KULLANMA KILAVUZU 97

2
1
2
3
Fig.1
1
2
Fig.2
12
1
2
Fig.3
1
2
Fig.4
2
1
Fig.5
1
2
Fig.6
1
Fig.7

3
Fig.8
Fig.9
1
2
3
Fig.10
1 1
2
2
Fig.11
Fig.12
1
2
Fig.13
1
2
3
Fig.14
1
234
Fig.15

4
2
1
3
4
Fig.16
1
Fig.17
1
2
3
Fig.18
1
Fig.19
1
2
3
4
4
Fig.20
2
3
1
Fig.21

5
1
2
Fig.22
2
1
1
3
Fig.23
4
1
3
2
Fig.24
1
2
Fig.25
1
2
Fig.26
2
1
3
Fig.27

6
3
2
1
4
1
Fig.28
Fig.29
Fig.30
2
1
Fig.31
1
Fig.32
1
Fig.33
Fig.34

7
1
2
3 4
Fig.35
Fig.36
4
1
3
2
Fig.37
1
2
3
Fig.38
1
Fig.39
2
3
1
4
Fig.40
2
1
Fig.41

8
1
2
Fig.42
1
2
Fig.43
2
1
3
Fig.44

9ENGLISH
ENGLISH (Original instructions)
WARNING
• This machine is not intended for use by persons including children with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge.
• Children should be supervised to ensure that they do not play with the cleaner.
• See the chapter “SPECIFICATIONS” for the type reference of the battery.
• See the section “Installing or removing battery cartridge” for how to remove or install the battery.
• When disposing the battery cartridge, remove it from the tool and dispose of it in a safe place. Follow your local
regulations relating to disposal of battery.
• If the tool is not used for a long period of time, the battery must be removed from the tool.
• Do not short the battery cartridge.
• See the chapter “MAINTENANCE” for the appropriate details of precautions during user maintenance.
SPECIFICATIONS
Model: DVC261
Capacity Filter bag 2.0 L
Dust bag 1.5 L
Maximum air volume With hose ø28 mm x 1.0 m 2.0 m3/min
With hose ø32 mm x 1.0 m 2.2 m3/min
With hose ø38 mm x 1.5 m 2.3 m3/min
Vacuum 110 hPa
Dimensions (L x W x H)
(excluding the harness)
230 mm x 152 mm x 373 mm
Rated voltage D.C. 36 V
Net weight 3.9 - 4.5 kg
 
without notice.
 󰀨
• The weight does not include accessories but battery cartridge(s). The lightest and heaviest combination weight
of the appliance and battery cartridge(s) are shown in the table.
• The length of supplied hose varies depending on the countries.
Applicable battery cartridge and charger
Battery cartridge BL1815N / BL1820B / BL1830B / BL1840B / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /
DC18SH / DC18WC
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges

WARNING: Do not use a corded power supply such as battery adapter or portable power pack with
this tool.󰀩


10 ENGLISH
Symbols
The followings show the symbols which may be used
for the equipment. Be sure that you understand their
meaning before use.
Read instruction manual.
Take particular care and attention.
A representative battery applicable to this
product.
Ni-MH
Li-ion
Only for EU countries
Due to the presence of hazardous com-
ponents in the equipment, waste electrical
and electronic equipment, accumulators
and batteries may have a negative impact
on the environment and human health.
Do not dispose of electrical and electronic
appliances or batteries with household
waste!
In accordance with the European Directive
on waste electrical and electronic equip-
ment and on accumulators and batteries
and waste accumulators and batteries,
as well as their adaptation to national law,
waste electrical equipment, batteries and
accumulators should be stored separately
and delivered to a separate collection point
for municipal waste, operating in accor-
dance with the regulations on environmen-
tal protection.
This is indicated by the symbol of the
crossed-out wheeled bin placed on the
equipment.
Intended use
The tool is intended for collecting dry dust. The tool
is suitable for commercial use, for example in hotels,
󰀩
businesses.
Noise
The typical A-weighted noise level determined accord-
ing to IEC60335-2-69, IEC60704-2-1:
Sound pressure level (LpA) : 70 dB(A) or less
Uncertainty (K) : 2.5 dB (A)
The noise level under working may exceed 80 dB (A).
NOTE: The declared noise emission value(s) has
been measured in accordance with a standard test
method and may be used for comparing one tool with
another.
NOTE: The declared noise emission value(s)
may also be used in a preliminary assessment of
exposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual
󰀨
value(s) depending on the ways in which the
tool is used especially what kind of workpiece is
processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
󰀨
trigger time).
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to IEC60335-2-69:
Work mode: operation without load
Vibration emission (ah) : 2.5 m/s2or less
Uncertainty (K) : 1.5 m/s2
NOTE: The declared vibration total value(s) has been
measured in accordance with a standard test method
and may be used for comparing one tool with another.
NOTE: The declared vibration total value(s) may also
be used in a preliminary assessment of exposure.
WARNING: The vibration emission during
󰀨
declared value(s) depending on the ways in which
the tool is used especially what kind of workpiece
is processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
󰀨
trigger time).
Declarations of Conformity
For European countries only
The Declarations of conformity are included in Annex A
to this instruction manual.
SAFETY WARNINGS
Cordless vacuum cleaner safety
warnings
WARNING: IMPORTANT! READ CAREFULLY
all safety warnings and all instructions BEFORE
USE. Failure to follow the warnings and instructions

1. Before use, make sure that this cleaner must
be used by people who have been adequately
instructed on the use of this cleaner.

11 ENGLISH
2. 

3. 

metal chips, sharp materials such as razors,
needles, broken glass or the like.
4.
NEVER USE THE CLEANER IN THE VICINITY
OF GASOLINE, GAS, PAINT, ADHESIVES OR
OTHER HIGHLY EXPLOSIVE SUBSTANCES.
The switch emits sparks when turned ON and
OFF. And so does the motor commutator during
operation. A dangerous explosion may result.
5. This cleaner is not suitable for picking up
hazardous dust.
6. Never vacuum up toxic, carcinogenic, com-
bustible or other hazardous materials such
as asbestos, arsenic, barium, beryllium,
lead, pesticides, or other health endangering
materials.
7. Never use the cleaner outdoors in the rain.
8. For Finland, this machine is not to be used
outdoors at low temperature.
9. Do not use close to heat sources (stoves, etc.).
10. Do not block cooling vents. These vents per-
mit cooling of the motor. Blockage should be
carefully avoided otherwise the motor will burn
out from lack of ventilation.
11. Keep proper footing and balance at all times.
12. Do not fold, tug or step on the hose.
13. Stop the cleaner immediately if you notice
poor performance or anything abnormal
during operation.
14. DISCONNECT THE BATTERIES. When not in
use, before servicing, and when changing
accessories.
15. Clean and service the cleaner immediately
after each use to keep it in tiptop operating
condition.
16. MAINTAIN THE CLEANER WITH CARE. Keep
the cleaner clean for better and safer per-
formance. Follow instructions for changing
accessories. Keep handles dry, clean, and free
from oil and grease.
17. CHECK DAMAGED PARTS. Before further use
of the cleaner, a guard or other part that is
damaged should be carefully checked to deter-
mine that it will operate properly and perform
its intended function. Check for alignment of
moving parts, binding of moving parts, break-
age of parts, mounting, and any other condi-
󰀨
other part that is damaged should be properly
repaired or replaced by an authorized service
center unless otherwise indicated elsewhere
in this instruction manual. Have defective
switches replaced by authorized service cen-
ter. Don’t use the cleaner if switch does not
󰀨
18. REPLACEMENT PARTS. When servicing, use
only identical replacement parts.
19.
When not in use, always store the cleaner indoors.
20. Be kind to your cleaner. Rough handling can
cause breakage of even the most sturdily built
cleaner.
21. Do not attempt to clean the exterior or interior
with benzine, thinner or cleaning chemicals.
Cracks and discoloration may be caused.
22. Do not use cleaner in an enclosed space where

󰀨


23. Do not operate the cleaner while under the

24. As a basic rule of safety, use safety goggles or
safety glasses with side shields.
25. Use a dust mask in dusty work conditions.
26. This machine is not intended for use by per-
sons including children with reduced physical,
sensory or mental capabilities, or lack of expe-
rience and knowledge.
27. Children should be supervised to ensure that
they do not play with the cleaner.
28. Never handle battery(ies) and cleaner with wet
hands.
29. Use extreme caution when cleaning on stairs.
30. Do not use the cleaner as a stool or work
bench. The machine may fall down and may
result in personal injury.
Battery tool use and care
1. 
the manufacturer. A charger that is suitable for

when used with another battery pack.
2. -
nated battery packs. Use of any other battery

3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-

4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-

liquid contacts eyes, additionally seek medical
help.
irritation or burns.
5. Do not use a battery pack or tool that is dam-

may exhibit unpredictable behaviour resulting in

6. 
excessive temperature.-
perature above 130 °C may cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
-
tions. Charging improperly or at temperatures


8. Do not use a corded power supply such as bat-
tery adapter or portable power pack with this
tool. The cable of such power supply may hinder


12 ENGLISH
Service
1. 
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
2. Follow instruction for lubricating and chang-
ing accessories.
3. Keep handles dry, clean and free from oil and
grease.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble or tamper with the battery
cartridge.
or explosion.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current

breakdown.
6. Do not store and use the tool and battery car-
tridge in locations where the temperature may
reach or exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn

8. Do not nail, cut, crush, throw, drop the battery
cartridge, or hit against a hard object to the
battery cartridge. Such conduct may result in a

9. Do not use a damaged battery.
10. The contained lithium-ion batteries are subject
to the Dangerous Goods Legislation require-
ments.
For commercial transports e.g. by third parties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
ing an expert for hazardous material is required.
Please also observe possibly more detailed
national regulations.
󰀨
battery in such a manner that it cannot move
around in the packaging.
11. When disposing the battery cartridge, remove
it from the tool and dispose of it in a safe
place. Follow your local regulations relating to
disposal of battery.
12. Use the batteries only with the products
 Installing the batteries to
-
sive heat, explosion, or leak of electrolyte.
13. If the tool is not used for a long period of time,
the battery must be removed from the tool.
14. During and after use, the battery cartridge may
take on heat which can cause burns or low
temperature burns. Pay attention to the han-
dling of hot battery cartridges.
15. Do not touch the terminal of the tool imme-
diately after use as it may get hot enough to
cause burns.
16. Do not allow chips, dust, or soil stuck into the
terminals, holes, and grooves of the battery
cartridge.
burst and malfunction of the tool or battery car-

17. Unless the tool supports the use near
high-voltage electrical power lines, do not use
the battery cartridge near high-voltage electri-
cal power lines. It may result in a malfunction or
breakdown of the tool or battery cartridge.
18. Keep the battery away from children.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery bursting

also void the Makita warranty for the Makita tool and
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room tem-
perature at 10 °C - 40 °C (50 °F - 104 °F). Let
a hot battery cartridge cool down before
charging it.
4. When not using the battery cartridge, remove
it from the tool or the charger.
5. Charge the battery cartridge if you do not use
it for a long period (more than six months).

13 ENGLISH
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
󰀨
before adjusting or checking function on the tool.
Installing or removing battery
cartridge
CAUTION: 󰀨
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-

cartridge. Failure to hold the tool and the battery
󰀨
and result in damage to the tool and battery cartridge

Fig.1: 1. Red indicator 2. Button 3. Battery cartridge
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator as

CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,

you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
Tool / battery protection system
The tool is equipped with a tool/battery protection sys-
󰀨
motor to extend tool and battery life. The tool will auto-
matically stop during operation if the tool or battery is
placed under one of the following conditions.
Overload protection
When the tool is operated in a manner that causes it to
draw an abnormally high current, the tool automatically
stops without any indication. In this situation, turn the
󰀨
become overloaded. Then turn the tool on to restart.
Overheat protection
When the tool is overheated, the tool stops automatically.
Let the tool cool down before turning the tool on again.
Overdischarge protection
When the battery capacity becomes low, the tool stops
automatically. If the product does not operate even
when the switches are operated, remove the batteries
from the tool and charge the batteries.
Indicating the remaining battery
capacity
Only for battery cartridges with the indicator
Fig.2: 1. Indicator lamps 2. Check button
Press the check button on the battery cartridge to indi-
cate the remaining battery capacity. The indicator lamps
light up for a few seconds.
Indicator lamps Remaining
capacity
Lighted 󰀨 Blinking
75% to 100%
50% to 75%
25% to 50%
0% to 25%
Charge the
battery.
The battery
may have
malfunctioned.
NOTE: Depending on the conditions of use and the
󰀨
from the actual capacity.
NOTE:
the battery protection system works.
Switch box position
The switch box can be hooked on either side of the
lower belt. Arrange the cord so that the switch box
comes to your desired side. To prevent the cord from
being damaged, pass the cord through the hook as
illustrated.
Fig.3: 1. Hook 2. Cord
Adjusting belts
The tightness of the shoulder belts, upper and lower
-

To tighten, pull the end of the strap as illustrated. To
loosen, pull up the end of the fastener.
Lower belt
Fig.4: 1. Strap 2. Fastener
Shoulder belts
Fig.5: 1. Strap 2. Fastener
Upper belt
Fig.6: 1. Strap 2. Fastener

14 ENGLISH
Carrying hook
Always grab the carrying hook when handling the vac-
uum cleaner body.
Fig.7: 1. Carrying hook
Switch action
You can change the suction power in three steps: nor-
mal (1), high (2), and max (3).
To start vacuuming, press button once. When you
change the suction power, press the button while the
vacuum cleaner is running. The suction power switches
in order normal (1) , high (2) , and max (3).
󰀨 button.
Fig.8
NOTE: When you start the vacuum cleaner again, it
will start in the same suction power as the previous
setting.
LED light
LED light is installed in the head of the switch box to
ease the operations in dark places. Press button to
󰀨 button again.
Fig.9
CAUTION: Do not look in the light or see the
source of light directly. Never aim the light to
other people's eyes.
NOTE:󰀨
the vacuum cleaner is not operated for more than 10
minutes.
NOTE: The vacuum cleaner will automatically
󰀨-


or other reasons.
Hose band
Hose band can be used for holding the hose or free
nozzle.
To secure the hose to the vacuum cleaner body, pass
the hose band through the slot on the body. You can
attach the hose band on either side.
Fig.10: 1. Hose band 2. Slot 3. Hose
The loop on the lower belt can be used for carrying
nozzles as illustrated.
Fig.11: 1. Loop 2. Nozzles
Hose hook
When you suspend the operation, the hook on the bent
pipe assembly can be used for hanging the wand on the
lower belt.
Fig.12
ASSEMBLY
CAUTION: Always be sure that the tool is
󰀨
before carrying out any work on the tool.
Assembling hose
󰀨
turn it clockwise.
Fig.13: 1.󰀨2. Vacuum cleaner body
Using as a cleaner
Attaching bent pipe assembly
Optional accessory
NOTE: You don't need to perform this procedure
if your model comes with the bent pipe assembly
attached to the hose.
NOTE: There are two types of bent pipe assembly;
the one for slide-type extension wand and the one for
ring-type extension wand. If you prepare the bent pipe
assembly, choose the one for your desired extension
wand type.
The bent pipe assembly is used for connecting the
extension wand or nozzle for vacuum cleaning to this
product.
If you want to use this product as the vacuum cleaner,
attach the bent pipe assembly to the hose.
󰀨
fasten the sleeve of bent pipe assembly onto the hose.
To remove, loosen the sleeve of bent pipe assembly
from the hose.
Fig.14: 1. Hose 2. Bent pipe assembly 3. Sleeve
Assembling nozzle and wand
Optional accessory
NOTE: The type of the nozzle and wand included in
the product varies depending on countries. In some
countries, the nozzle and wand are not included.
1. Twist and insert the nozzle to the extension wand.
Fig.15: 1. Extension wand 2. Free nozzle
3. T-shape nozzle 4. T-shape nozzle (slim)
NOTE: By twisting the nozzle while inserting, the noz-
zle can be attached to the extension wand securely.
NOTE: For the model with ø38 mm hose and front
󰀨
bending pipe / aluminum straight pipe.

15 ENGLISH
2. Follow the procedures below, depending on the
type of the extension wand :
NOTE: The slide-type extension wand and the ring-
type extension wand are not compatible with each
other. If you want to change the slide-type extension
wand to the ring-type extension wand or vice versa,
change the bent pipe assembly also.
NOTE: The free nozzle can be attached to the bent
pipe assembly directly.
For the slide-type extension wand
Shoulder the vacuum cleaner body then insert the
extension wand into the bent pipe assembly until it
clicks. To disconnect, extract the extension wand with
pressing the button.
Fig.16: 1. Bent pipe assembly 2. Button 3. Slide-
type extension wand 4. Free nozzle


The length is locked when releasing the slide button.
Fig.17: 1. Slide button
For the ring-type extension wand
Shoulder the vacuum cleaner body then twist and insert
the extension wand into the bent pipe assembly. To
disconnect, twist and extract it.
Fig.18: 1. Bent pipe assembly 2. Ring-type exten-
sion wand 3. Free nozzle


length. Tighten the ring at your desired length.
Fig.19: 1. Ring
For the aluminum bending pipe / aluminum straight
pipe
󰀨
Shoulder the vacuum cleaner body then twist and insert
󰀨
extract it.
Fig.20: 1.󰀨2. Aluminum bending pipe
3. Aluminum straight pipe 4. Nozzle
For the two aluminum straight pipes
Shoulder the vacuum cleaner body then twist and insert
the pipes. To disconnect, twist and extract it.
Fig.21: 1. Bent pipe assembly 2. Aluminum straight
pipe 1 3. Aluminum straight pipe 2
Connecting the tool
NOTE: If the bent pipe assembly is attached to the
hose, remove it beforehand.
To connect a tool to the cleaner, the dedicated hose
and/or additional parts are required. Depending on your
cleaner model, you need to replace the hose and/or
prepare additional parts.
Refer to the following table for details.
Supplied
hose
diameter
Hose end type Action
ø28 mm
without part
󰀨
with snap-on part
Replace the hose end
(snap-on part) with the front
󰀨
The hose end can be removed
by turning it counterclockwise.
ø32 mm
with snap-on part
Replace the hose with the one
for dust extraction (ø28 mm,
󰀨
ø38 mm
with snap-on part
Replace the hose with the one
for dust extraction (ø28 mm,
󰀨
󰀨

󰀨
NOTE:󰀨
󰀨󰀨
connected to the hose.
Fig.22: 1.󰀨2.󰀨

16 ENGLISH
When using ø28 mm dust extraction
hose
1. 󰀨
󰀨
securely screwed on the hose.
2. 󰀨
outlet.
Fig.23: 1.󰀨2. Extraction outlet 3. Hose
󰀨-
clockwise while holding the hose.
When using ø38 mm hose with front
󰀨
1. 󰀨
inlet part on the hose, depending on the tool that you
are going to connect.
2. 󰀨
outlet.
Fig.24: 1. Joint 2.󰀨3. Extraction outlet
4. Hose
󰀨-
tion procedures in reverse.

Optional accessory
CAUTION: 

properly installed. Otherwise the vacuumed dust
or particles may be exhausted from the cleaner
and they may cause respiratory disease to the
operator.
NOTICE:
with new one. When the dust bag is already full,

full results in reduced suction power.
1. Unlock the latch by lifting the bottom side. Push
the grooved area to lift the front latching side. Pull the
latch to open the lid.
Fig.25: 1. Hook 2. Lid
2. 
the room as illustrated.
Fig.26: 1. Slit 2. Filter bag
When using the dust bag, insert the brim of the dust bag
into the slit.
Fig.27: 1. Slit 2. Brim 3. Dust bag
3. 󰀨
and push the cardboard portion to the end. Make sure

󰀨
Fig.28: 1.2. Rim on
󰀨3. Cardboard portion of the
4.󰀨
OPERATION
WARNING: Operators shall be adequately
instructed on the use of the vacuum cleaner.
WARNING: This vacuum cleaner is not suit-
able for picking up hazardous dust.
CAUTION: This cleaner is for dry use only.
CAUTION: This cleaner is for indoor use only.
CAUTION: Always insert the battery cartridge
all the way until it locks in place. If you can see the
red indicator on the upper side of the button, it is not
locked completely. Insert it fully until the red indicator
cannot be seen. If not, it may accidentally fall out of

you.
CAUTION: During operation, be conscious
of the vacuum cleaner on your back. You may
lose your balance if the vacuum cleaner body bumps
against a wall or the hose is hooked by an obstacle.
1. Shoulder the vacuum cleaner body and fas-

necessary.
Fig.29
2. Press
button to start vacuuming. If you want
to change the suction power, press button until the
desired suction power is selected. Press button to
stop.
Fig.30
During the operation, hook the switch box on the D-ring
or the lower belt. The hook can be slanted for lighting
forward when hooked on the lower belt.
Fig.31: 1. D-ring 2. Lower belt
NOTE: The vacuum cleaner will automatically
󰀨-
uum cleaner is overheated due to the reduced air-


of the problem and cool the vacuum cleaner before
restarting.
3. 



Fig.32: 1. Strip
When using a dust bag, take out the dust bag and dis-
pose of the dust by releasing the latch.
Fig.33: 1. Latch
NOTICE: 
full.
reduced suction power.
NOTICE: 
-

damage to the cleaner. If you want to use the bag
repeatedly, use a dust bag.

17 ENGLISH
MAINTENANCE
CAUTION: Always be sure that the tool is
󰀨
before attempting to perform inspection or
maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
To maintain product SAFETY and RELIABILITY,

be performed by Makita Authorized or Factory Service
Centers, always using Makita replacement parts.

CAUTION: Do not use the vacuum cleaner
-

exhausted from the cleaner and they may cause
respiratory disease to the operator.
NOTICE: To keep optimum suction power and

enough suction power is not obtained even after

NOTICE: -
aged, do not use following tools and similar items
for cleaning :
— Air duster
— High pressure washer
— Tools made of hard materials such as a
metallic brush
1. 

cleaner body.
Fig.34
2. 󰀨
washed with water. Rinse away the dust and particles

completely in a shaded and well-ventilated place to
prevent unpleasant odor or malfunctions.
3. 


Fig.35: 1. Holder 2.3. Rib 4. Flap
Cleaning the dust bag
Regularly clean the dust bag with soap and water. Turn
the dust bag inside out and remove the sticky dust.
Wash lightly by hand and rinse well with water. Dry
completely before installing to the vacuum cleaner.
Fig.36
NOTICE: Wet dust bag lowers the vacuuming per-
formance as well as the life of the motor.
Clearing the clog
When clearing the clog, remove the hose or the exten-
sion wand, or the bent pipe assembly to check inside.
Removing/attaching the snap-on type bent pipe
assembly
To remove, pull the bent pipe assembly while pressing
both of the tab on the hose end.
To attach, insert the hose end into the bent pipe assem-
bly. Make sure that the tabs on the hose end snap into
the holes on the bent pipe assembly.
Fig.37: 1. Hose end 2. Tab 3. Hole 4. Bent pipe
assembly
Removing/attaching the screw-in type bent pipe
assembly
To remove, loosen the sleeve of bent pipe assembly
from the hose.
To attach, fasten the sleeve of bent pipe assembly onto
the hose.
Fig.38: 1. Hose 2. Bent pipe assembly 3. Sleeve
OPTIONAL
ACCESSORIES
CAUTION: These accessories or attachments
are recommended for use with your Makita tool
 The use of any other
accessories or attachments might present a risk of

for its stated purpose.
If you need any assistance for more details regard-
ing these accessories, ask your local Makita Service
Center.
• Hose (for vacuum cleaner type)
• Hose (for dust extraction type)
• Extension wand
• Free nozzle
• T-shape nozzle
• Seat nozzle
• Corner nozzle
• Shelf brush
• Round brush
• Bent pipe assembly
• Filter bag
• Dust bag
 󰀨
 
• Pipe
• Cyclone attachment
• Harness cover
• Protection cover
• Makita genuine battery and charger
NOTE: Some items in the list may be included in the
tool package as standard accessories. They may
󰀨

18 ENGLISH
Cyclone attachment
Optional accessory
NOTE: When using the cyclone attachment with this
appliance, the bent pipe is also required.
Fig.39: 1. Cyclone attachment
About the cyclone attachment
Using the cleaner with the cyclone attachment installed
reduces the amount of dust that enters the dust bag,
which helps to prevent the suction force from weaken-
ing. In addition, cleaning after use is also simple.
CAUTION: Always be sure that the tool is
󰀨
before carrying out any work on the tool. If the
battery cartridge is left inserted, the cleaner may start

CAUTION: 
cyclone attachment and the dust bag of the
cleaner unit when they become clogged.
Continued use in the clogged condition may result in
heating or smoke.
NOTICE: When the cyclone attachment is
attached, do not use the cyclone attachment in
the horizontal or upward facing condition. Doing

NOTICE: Always use the cleaner with the dust
bag installed, even when using the cyclone
attachment. Using the cleaner without the dust bag
installed may result in a motor malfunction.
NOTE: Check that the cyclone attachment, cleaner,
and straight pipe are locked properly before use.
NOTE: Empty the dust case of the cyclone attach-
ment and the dust bag of the cleaner when dust has
accumulated. Continued use will result in weakened
suction force.
NOTE: You can use the cyclone attachment with or
without lock function.
NOTE: To install or remove the cyclone attachment,
refer to the section "Using as a cleaner".
Disposing of dust
When dust has accumulated up to the full line of the
dust case, follow the procedure below and dispose of
the dust.
1. 
buttons, and remove the dust case.
Fig.40: 1. Full line 2. Dust case 3. Button (two
locations) 4.
2. Dispose of the dust inside the dust case and
remove any dust and powder adhered to the surface of

3. Insert the dust case all the way until the two but-
tons lock with a click.
Fig.41: 1. Dust case 2. Button (two locations)
NOTE: Check that the cyclone attachment, cleaner,
and straight pipe are locked properly before restarting
operation.
NOTE: If the suction force does not recover even
after disposing of the dust and cleaning the mesh

bag of the cleaner or clogging has occurred.
Cleaning

clogged, remove and wash them with water. (Refer to
“Disposing of dust” for the removal procedure.)
Dry the parts thoroughly before reinstallation and use.
Fig.42: 1. Dust case 2.

following procedures.
1. 
it while the hooks are unlocked.
Fig.43: 1.2. Hook
2. 
it with water. After that, dry it thoroughly.
3. 

until the hooks are locked with a click. Make sure that

Fig.44: 1.2. Hook 3. Port

19 FRANÇAIS
FRANÇAIS (Instructions originales)
AVERTISSEMENT
• Cette machine n’est pas destinée à être utilisée par des personnes (y compris les enfants) aux facultés phy-
siques, sensorielles ou mentales diminuées ou sans expérience ni expertise.
 
• Voir le chapitre « SPÉCIFICATIONS » pour la désignation de la batterie.
• Voir la section « Insertion ou retrait de la batterie » pour la méthode de retrait ou d’insertion de la batterie.
 -
tion locale en matière de mise au rebut des batteries.
• Lorsque vous n’utilisez pas l’outil pendant une période prolongée, la batterie doit être retirée de l’outil.
• Ne court-circuitez pas la batterie.
• Voir le chapitre « ENTRETIEN » pour des précautions détaillées pendant l’entretien à la charge de l’utilisateur.
SPÉCIFICATIONS
Modèle : DVC261
Capacité  2,0 L
Sac à poussière 1,5 L
Volume d’air maximum
Avec un tuyau de ø28 mm x 1,0 m 2,0 m3/min
Avec un tuyau de ø32 mm x 1,0 m 2,2 m3/min
Avec un tuyau de ø38 mm x 1,5 m 2,3 m3/min
Vide 110 hPa
Dimensions (L x P x H)
(sans le harnais)
230 mm x 152 mm x 373 mm
Tension nominale 36 V CC
Poids net 3,9 - 4,5 kg
 

 
• Le poids ne comprend pas les accessoires, mais la ou les batteries. Le poids combiné le plus léger et le plus
lourd de l’appareil et de la ou des batteries est indiqué dans le tableau.
 󰀨
Batterie et chargeur applicables
Batterie BL1815N / BL1820B / BL1830B / BL1840B / BL1850B / BL1860B
Chargeur DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /
DC18SH / DC18WC
• Certains chargeurs et batteries répertoriés ci-dessus peuvent ne pas être disponibles selon la région où vous
résidez.
AVERTISSEMENT : N’utilisez que les batteries et les chargeurs répertoriés ci-dessus. L’utilisation
d’autres batteries et chargeurs peut provoquer des blessures et/ou un incendie.
AVERTISSEMENT : N’utilisez pas de source d’alimentation câblée comme un adaptateur de batterie
ou un support d’alimentation portable avec cet outil. Le port de plus d’un harnais à la fois complique l’utilisa-
tion et le dégagement de l’outil, et peut provoquer des blessures.

20 FRANÇAIS
Symboles
Vous trouverez ci-dessous les symboles susceptibles
d’être utilisés pour l’appareil. Veillez à comprendre leur

Lire le mode d’emploi.
Veuillez être prudent et rester attentif.
Représentation d’une batterie utilisable
avec ce produit.
Ni-MH
Li-ion
Pour les pays de l’Union européenne
uniquement
En raison de la présence de composants
dangereux dans l’équipement, les déchets
d’équipements électriques et électro-
niques, les accumulateurs et les batteries
peuvent avoir un impact négatif sur l’envi-
ronnement et la santé humaine.

électroniques ou les batteries avec les
ordures ménagères !
Conformément à la directive européenne
relative aux déchets d’équipements élec-
triques et électroniques et aux déchets
d’accumulateurs et de batteries, ainsi qu’à
son adaptation à la législation nationale,
les déchets d’équipements électriques,
les batteries et les accumulateurs doivent
être collectés séparément et déposés
dans un point de collecte distinct pour
déchets urbains, conformément aux régle-
mentations en matière de protection de
l’environnement.
Cela est indiqué par le symbole de la pou-
belle à roulettes barrée sur l’équipement.
Utilisations
L’outil est conçu pour la collecte des poussières
sèches. L’outil est prévu pour un usage commercial,
par exemple, dans les hôtels, écoles, hôpitaux, usines,
magasins, bureaux et agences de location.
Bruit
Niveau de bruit pondéré A typique, déterminé selon
IEC60335-2-69, IEC60704-2-1 :
Niveau de pression sonore (LpA) : 70 dB (A) ou moins
Incertitude (K) : 2,5 dB (A)
Le niveau de bruit en fonctionnement peut dépasser 80 dB (A).
NOTE : La ou les valeurs d’émission de bruit décla-
rées ont été mesurées conformément à la méthode
de test standard et peuvent être utilisées pour com-
parer les outils entre eux.
NOTE : La ou les valeurs d’émission de bruit décla-
rées peuvent aussi être utilisées pour l’évaluation
préliminaire de l’exposition.
AVERTISSEMENT : Portez un serre-tête
antibruit.
AVERTISSEMENT : L’émission de bruit
lors de l’usage réel de l’outil électrique peut être
󰀨
la façon dont l’outil est utilisé, particulièrement
selon le type de pièce usinée.
AVERTISSEMENT : Les mesures de sécurité
à prendre pour protéger l’utilisateur doivent être
basées sur une estimation de l’exposition dans
des conditions réelles d’utilisation (en tenant
compte de toutes les composantes du cycle
d’utilisation, comme par exemple le moment de
sa mise hors tension, lorsqu’il tourne à vide et le
moment de son déclenchement).
Vibrations
Valeur totale de vibrations (somme de vecteur triaxial)
déterminée selon IEC60335-2-69 :
Mode de travail : coupe de planches
Émission de vibrations (ah) : 2,5 m/s2ou moins
Incertitude (K) : 1,5 m/s2
NOTE : La ou les valeurs de vibration totales décla-
rées ont été mesurées conformément à la méthode
de test standard et peuvent être utilisées pour com-
parer les outils entre eux.
NOTE : La ou les valeurs de vibration totales décla-
rées peuvent aussi être utilisées pour l’évaluation
préliminaire de l’exposition.
AVERTISSEMENT : L’émission de vibrations
lors de l’usage réel de l’outil électrique peut être
󰀨
la façon dont l’outil est utilisé, particulièrement
selon le type de pièce usinée.
AVERTISSEMENT : Les mesures de sécurité
à prendre pour protéger l’utilisateur doivent être
basées sur une estimation de l’exposition dans
des conditions réelles d’utilisation (en tenant
compte de toutes les composantes du cycle
d’utilisation, comme par exemple le moment de
sa mise hors tension, lorsqu’il tourne à vide et le
moment de son déclenchement).
Déclarations de conformité
Pour les pays européens uniquement
Les déclarations de conformité sont fournies en Annexe
A à ce mode d’emploi.
