999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No. 135 On Boom No. 82 or 22EL
Manitowoc Cranes, Inc. 8248-A, 2011-10-19
Manitowoc, Wisconsin 54220 U.S.A. 1/10
Recommended boom and luffing jib raising and lowering procedure:
999 SERIES 1 must be equipped with 149,000 lb (67 860 kg) crane counterweight, 999 SERIES 2 must be
equipped with 184,600 lb (83 730 kg) crane counterweight and 44,000 lb (19 960 kg) carbody counterweight and
999 SERIES 3 must be equipped with 219,600 lb (99 610 kg) crane counterweight and 80,000 lb (36 290 kg)
carbody counterweight for raising and lowering various boom and luffing jib combinations. Refer to luffing jib
rigging assembly No. 196199 (Boom No. 22EL) or No. 196200 (Boom No. 82) without intermediate fall or
No. A09286 (Boom No. 22EL) or No. A09287 (Boom No. 82) with intermediate fall for boom and luffing jib make-
up of inserts, pendants and miscellaneous parts, etc.
Three methods may be used to raise and lower boom and luffing jib combinations, depending on length.
A. Layout In-Line Method
Boom and luffing jib are assembled in layout, end-to-end, position. Slowly raise boom until luffing jib stop strut
is just clear of ground. Attach luffing jib stop pendants and unpin luffing jib stop inner strut from retracted
position. Slowly raise boom until luffing jib stop strut is fully extended and pins engaged (approximately 168
degree boom-to-luffing jib angle). Tighten luffing jib suspension with luffing jib hoist. Boom and luffing jib can
then be raised simultaneously using only the boom hoist. Luffing jib radius must be within capacity chart before
swinging over side of machine when raising over end of blocked crawlers. Reverse this procedure when
lowering boom and luffing jib.
Boom and luffing jib combinations in following tables may be raised and lowered using layout in-line method.
For jib lengths shown with (c), machine must be equipped with lowerworks jacking cylinders when boom
catwalks are attached.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 1
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method
Without Intermediate Fall
Boom
Length
Over End of
Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
70 21,3 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
80 24,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
90 27,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
100 30,5 70 - 170 21,3 - 51,8 70 - 150 21,3 - 45,7
110 33,5 70 - 170 21,3 - 51,8 70 - 120 21,3 - 36,6
120 36,6 70 - 140 21,3 - 42,7 70 - 90 21,3 - 27,4
130 39,6 70 - 120 21,3 - 36,6 70 21,3
140 42,7 70 - 90 21,3 - 27,4 — —
150 45,7 70(c) 21,3 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
Intermediate fall must be completely removed for 999 SERIES 1 application.
REFERENCE
ONLY!

8248-A, 2011-10-19 Manitowoc Cranes, Inc.
2/10 Manitowoc, Wisconsin 54220 U.S.A.
999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No.135 On Boom No. 82 or 22EL
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 2
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method
Without Intermediate Fall
Boom
Length
Over End of
Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
70 21,3 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
80 24,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
90 27,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
100 30,5 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
110 33,5 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
120 36,6 70 - 170 21,3 - 51,8 70 - 160 21,3 - 48,8
130 39,6 70 - 160 21,3 - 48,8 70 - 140 21,3 - 42,7
140 42,7 70 - 150 21,3 - 45,7 70 - 120 21,3 - 36,6
150 45,7 70 - 120 21,3 - 36,6 70 - 90 21,3 - 27,4
160 48,8 70 - 100 21,3 - 30,5 — —
170 51,8 70 - 80 21,3 - 24,4 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 3
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method
Without Intermediate Fall
Boom
Length
Over End of
Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
70 21,3 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
80 24,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
90 27,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
100 30,5 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
110 33,5 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
120 36,6 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8
130 39,6 70 - 160 21,3 - 48,8 70 - 160 21,3 - 48,8
140 42,7 70 - 150 21,3 - 45,7 70 - 150 21,3 - 45,7
150 45,7 70 - 120 21,3 - 36,6 70 - 120 21,3 - 36,6
160 48,8 70 - 100 21,3 - 30,5 70 - 100 21,3 - 30,5
170 51,8 70 - 80 21,3 - 24,4 70 - 80 21,3 - 24,4
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
REFERENCE
ONLY!

999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No. 135 On Boom No. 82 or 22EL
Manitowoc Cranes, Inc. 8248-A, 2011-10-19
Manitowoc, Wisconsin 54220 U.S.A. 3/10
Boom and luffing jib combinations with intermediate fall in following tables may be raised and lowered using
in-line method.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 2
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method
With Intermediate Fall
Boom
Length
Over End of
Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
70 21,3 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
80 24,4 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
90 27,4 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
100 30,5 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
110 33,5 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
120 36,6 110 - 160 33,5 - 48,8 110 - 150 33,5 - 45,7
130 39,6 110 - 150 33,5 - 45,7 110 - 120 33,5 - 36,6
140 42,7 110 - 130 33,5 - 39,6 — —
150 45,7 110 33,5 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 3
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method
With Intermediate Fall
Boom
Length
Over End of
Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
70 21,3 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
80 24,4 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
90 27,4 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
100 30,5 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
110 33,5 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8
120 36,6 110 - 160 33,5 - 48,8 110 -160 33,5 - 48,8
130 39,6 110 - 150 33,5 - 45,7 110 -150 33,5 - 45,7
140 42,7 110 - 130 33,5 - 39,6 110 - 130 33,5 - 39,6
150 45,7 110 33,5 110 33,5
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
REFERENCE
ONLY!

8248-A, 2011-10-19 Manitowoc Cranes, Inc.
4/10 Manitowoc, Wisconsin 54220 U.S.A.
999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No.135 On Boom No. 82 or 22EL
B. Layout Jack-Knife Method:
(Longer boom and luffing jib combinations must be raised and lowered using this method)
Raising:
Boom and luffing jib are assembled in layout, end-to-end, position. Slowly raise boom until luffing jib stop strut
is just clear of ground. Attach luffing jib stop pendants and unpin luffing jib stop inner strut from retracted
position. Slowly raise boom until luffing jib stop strut is fully extended and pins engaged (approximately 168
degree boom-to-luffing jib angle). Boom is then raised while luffing jib point wheels are allowed to roll on
ground. Tension should be applied to luffing jib hoist to keep luffing jib strut off luffing jib during boom raising.
Boom up until boom-to-luffing jib angle reaches value specified in table below or vertical, whichever occurs first.
Tighten luffing jib suspension with luffing jib hoist. Boom and luffing jib are then raised together using boom
hoist until boom reaches desired boom operating angle. Luffing jib radius must be within capacity chart before
swinging over side of machine when raising over end of blocked crawlers.
Lowering:
Position boom at 75 degrees prior to lowering luffing jib. Lower luffing jib until boom-to-luffing jib angle reaches
value specified in table below. Lower boom until luffing jib point wheels contact ground. If luffing jib is hanging
vertical, raise luffing jib a few degrees forward of vertical. Continue to lower boom while luffing jib rolls along
ground. Keep enough tension on luffing jib hoist to keep luffing jib strut off luffing jib. Stop lowering boom when
luffing jib stop pendants start to go into tension (approximately 168 degree boom-to-luffing jib angle).
Disengage luffing jib stop strut pins and lower boom to retract luffing jib stop inner strut. Pin strut in retracted
position and unpin luffing jib stop pendants. Rotate luffing jib stop struts forward and lower boom and luffing jib
to ground.
REFERENCE
ONLY!

999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No. 135 On Boom No. 82 or 22EL
Manitowoc Cranes, Inc. 8248-A, 2011-10-19
Manitowoc, Wisconsin 54220 U.S.A. 5/10
Boom and luffing jib combinations in following tables require layout jack-knifing to a specified boom-to-luffing jib
angle for raising and lowering. Boom lengths shown with (a) require only the middle two sheaves in lower boom
point. All other sheaves must be removed from lower boom point. Boom lengths shown with (b) require lower
boom point to be removed. For jib lengths shown with (c), machine must be equipped with lowerworks jacking
cylinders when boom catwalks are attached.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 1
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
Without Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135
Boom to
Luffing Jib
Angle Luffing Jib No. 135
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
100 30,5 —— — 160 - 170 48,8 - 51,8 90
110 33,5 —— — 130 - 170 39,6 - 51,8 90
120 36,6 150 - 170 45,7 - 51,8 90 100 - 170 30,5 - 51,8 90
130 39,6 130 - 170 39,6 - 51,8 90 80 - 170 24,4 - 51,8 90
140 42,7 100 - 170 30,5 - 51,8 90 70 - 150 21,3 - 45,7 90
—— — 160 - 170 48,8 - 51,8 60
150 45,7 80 - 170 24,4 - 51,8 90 (c) 80 - 90 24,4 - 27,4 60
160 48,8 70 - 170(c) 21,3 - 51,8 60 — — —
(b) 170 51,8 80 - 150(c) 24,4 - 45,7 60 — — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected. Intermediate fall must be
completely removed for 999 SERIES 1 application.
REFERENCE
ONLY!

8248-A, 2011-10-19 Manitowoc Cranes, Inc.
6/10 Manitowoc, Wisconsin 54220 U.S.A.
999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No.135 On Boom No. 82 or 22EL
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 2
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
Without Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135
Boom to
Luffing Jib
Angle Luffing Jib No. 135
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
120 36,6 — — — 170 51,8 90
130 39,6 170 51,8 90 150 - 170 45,7 - 51,8 90
140 42,7 160 - 170 48,8 - 51,8 90 130 - 170 39,6 - 51,8 90
150 45,7 130 - 170 39,6 - 51,8 90 100 - 170 30,5 - 51,8 90
160 48,8 110 - 170 33,5 - 51,8 90 70 - 170 21,3 - 51,8 90
170 51,8 90 - 170 27,4 - 51,8 90 70 - 170(c) 21,3 - 51,8 60
180 54,9 70 - 170 21,3 - 51,8 90 — ——
(a) 190 57,9 70 - 170 21,3 - 51,8 60 — ——
(b) 200 61,0 100 - 170(c) 30,5 - 51,8 60 — ——
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 3
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
Without Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135
Boom to
Luffing Jib
Angle Luffing Jib No. 135
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
130 39,6 170 51,8 90 170 51,8 90
140 42,7 160 - 170 48,8 - 51,8 90 160 - 170 48,8 - 51,8 90
150 45,7 130 - 170 39,6 - 51,8 90 130 - 170 39,6 - 51,8 90
160 48,8 110 - 170 33,5 - 51,8 90 110 - 170 33,5 - 51,8 90
170 51,8 90 - 170 27,4 - 51,8 90 90 - 170 27,4 - 51,8 90
180 54,9 70 - 170 21,3 - 51,8 90 70 - 170 21,3 - 51,8 90
(a) 190 57,9 70 - 170 21,3 - 51,8 90 70 - 150 21,3 - 45,7 60
(b) 200 61,0 70 - 170 21,3 - 51,8 90 — ——
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
REFERENCE
ONLY!

999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No. 135 On Boom No. 82 or 22EL
Manitowoc Cranes, Inc. 8248-A, 2011-10-19
Manitowoc, Wisconsin 54220 U.S.A. 7/10
Boom and luffing jib combinations with intermediate fall in following tables may be raised and lowered using
jack-knife method.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 2
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
With Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135
Boom to
Luffing Jib
Angle Luffing Jib No. 135
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
120 36,6 170 51,8 90 160 - 170 48,8 - 51,8 90
130 39,6 160 - 170 48,8 - 51,8 90 130 - 170 39,6 - 51,8 90
140 42,7 140 - 170 42,7 - 51,8 90 110 - 170 33,5 - 51,8 90
150 45,7 120 - 170 36,6 - 51,8 90 110 - 170 33,5 - 51,8 90
160 48,8 110 - 170 33,5 - 51,8 90 110 - 170 33,5 - 51,8 60
170 51,8 110 - 170 33,5 - 51,8 90 110 - 140(c) 33,5 - 42,7 60
180 54,9 110 - 170 33,5 - 51,8 60 — ——
(b) 190 57,9 110 - 170 33,5 - 51,8 60 — ——
(b) 200 61,0 110 - 150(c) 33,5 - 45,7 60 — ——
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 3
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method
With Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135
Boom to
Luffing Jib
Angle Luffing Jib No. 135
Boom to
Luffing Jib
Angle
Feet Meters Feet Meters Degrees Feet Meters Degrees
120 36,6 170 51,8 90 170 51,8 90
130 39,6 160 - 170 48,8 - 51,8 90 160 - 170 48,8 - 51,8 90
140 42,7 140 - 170 42,7 - 51,8 90 140 - 170 42,7 - 51,8 90
150 45,7 120 - 170 36,6 - 51,8 90 120 - 170 36,6 - 51,8 90
160 48,8 110 - 170 33,5 - 51,8 90 110 - 170 33,5 - 51,8 90
170 51,8 110 - 170 33,5 - 51,8 90 110 - 170 33,5 - 51,8 90
180 54,9 110 - 170 33,5 - 51,8 60 110 - 170 33,5 - 51,8 90
(b) 190 57,9 110 - 170 33,5 - 51,8 60 110 - 130 33,5 - 51,8 60
(b) 200 61,0 110 - 150 33,5 - 45,7 60 — ——
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
REFERENCE
ONLY!

8248-A, 2011-10-19 Manitowoc Cranes, Inc.
8/10 Manitowoc, Wisconsin 54220 U.S.A.
999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No.135 On Boom No. 82 or 22EL
C. Fold Under Jack-Knife Method:
Raising:
Boom and luffing jib are assembled in fold under position. Slowly raise boom; luffing jib point wheels will roll along
ground. When luffing jib hinge pin is 30 ft (9,1m) off ground, connect luffing jib pendants. Move luffing jib top wire rope
guide to working position. Tighten luffing jib suspension with luffing jib hoist. Slowly raise boom until luffing jib is vertical
and luffing jib point wheels are clear of ground. Tighten luffing jib suspension with luffing jib hoist. Boom and luffing jib
are then raised together using boom hoist until boom reaches desired boom operating range. Luffing jib radius must be
within capacity chart before swinging over side of machine when raising over end of blocked crawlers.
Lowering:
Position boom at 75 degrees prior to lowering luffing jib. Slowly lower luffing jib to vertical. Lower boom until luffing jib
point wheels are just clear of ground. Slowly boom down and assist luffing jib point wheels in fold under direction. Boom
down until luffing jib hinge pin is 30 ft (9,1m) off ground. Disconnect luffing jib pendants. Move luffing jib top wire rope
guide to stowed position. Raise luffing jib strut with luffing jib hoist until luffing jib strut is inline with luffing jib. Lower
boom and luffing jib to ground.
Boom and luffing jib combinations in following tables may be raised and lowered using fold under jack-knife method.
Boom length shown with (a) requires only the middle two sheaves in lower boom point. All other sheaves must be
removed from lower boom point. Boom lengths shown with a (b) require lower boom point to be removed. For jib
lengths shown with(c), machine must be equipped with lowerworks jacking cylinders when boom catwalks are attached.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 1
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method
Without Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
90 27,4 70 21,3 70 21,3
100 30,5 70 - 80 21,3 - 24,4 70 - 80 21,3 - 24,4
110 33,5 70 - 90 21,3 - 27,4 70 - 90 21,3 - 27,4
120 36,6 70 - 100 21,3 - 30,5 70 - 100 21,3 - 30,5
130 39,6 70 - 110 21,3 - 33,5 70 - 110 21,3 - 33,5
140 42,7 70 - 120 21,3 - 36,6 70 - 120 21,3 - 36,6
150 45,7 70 - 130 21,3 - 39,6 (c) 80 - 90 24,4 - 27,4
160 48,8 70 - 140 21,3 - 42,7 — —
(b) 170 51,8 80 -150(c) 24,4 - 45.7 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected. Intermediate fall must
be completely removed for 999 SERIES 1 application.
REFERENCE
ONLY!

999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No. 135 On Boom No. 82 or 22EL
Manitowoc Cranes, Inc. 8248-A, 2011-10-19
Manitowoc, Wisconsin 54220 U.S.A. 9/10
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 2
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method
Without Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
90 27,4 70 21,3 70 21,3
100 30,5 70 - 80 21,3 - 24,4 70 - 80 21,3 - 24,4
110 33,5 70 - 90 21,3 - 27,4 70 - 90 21,3 - 27,4
120 36,6 70 - 100 21,3 - 30,5 70 - 100 21,3 - 30,5
130 39,6 70 - 110 21,3 - 33,5 70 - 110 21,3 - 33,5
140 42,7 70 - 120 21,3 - 36,6 70 - 120 21,3 - 36,6
150 45,7 70 - 130 21,3 - 39,6 70 - 130 21,3 - 39,6
160 48,8 70 - 140 21,3 - 42,7 70 - 140 21,3 - 42.7
170 51,8 70 - 150 21,3 - 45.7 70 - 150 21,3 - 45.7
180 54,9 70 - 160 21,3 - 48.8 ——
(a) 190 57,9 70 - 170 21,3 - 51,8 — —
(b) 200 61,0 100 - 170(c) 30.5 - 51,8 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 3
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method
Without Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
90 27,4 70 21,3 70 21,3
100 30,5 70 - 80 21,3 - 24,4 70 - 80 21,3 - 24,4
110 33,5 70 - 90 21,3 - 27,4 70 - 90 21,3 - 27,4
120 36,6 70 - 100 21,3 - 30,5 70 - 100 21,3 - 30,5
130 39,6 70 - 110 21,3 - 33,5 70 - 110 21,3 - 33,5
140 42,7 70 - 120 21,3 - 36,6 70 - 120 21,3 - 36,6
150 45,7 70 - 130 21,3 - 39,6 70 - 130 21,3 - 39,6
160 48,8 70 - 140 21,3 - 42,7 70 - 140 21,3 - 42.7
170 51,8 70 - 150 21,3 - 45.7 70 - 150 21,3 - 45.7
180 54,9 70 - 160 21,3 - 48.8 70 - 160 21,3 - 48.8
(a) 190 57,9 70 - 170 21,3 - 51,8 70 - 150 21,3 - 45.7
(b) 200 61,0 70 - 170 21,3 - 51,8 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
REFERENCE
ONLY!

8248-A, 2011-10-19 Manitowoc Cranes, Inc.
10/10 Manitowoc, Wisconsin 54220 U.S.A.
999 SERIES 1, 2, 3
Luffing Jib Raising Procedure
Luffing Jib No.135 On Boom No. 82 or 22EL
Boom and luffing jib combinations with intermediate fall in following tables may be raised and lowered using fold under
jack-knife method.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 2
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method
With Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
130 39,6 110 33,5 110 33,5
140 42,7 110 - 120 33,5 - 36,6 110 - 120 33,5 - 36,6
150 45,7 110 - 130 33,5 - 39,6 110 - 130 33,5 - 39,6
160 48,8 110 - 140 33,5 - 42,7 110 - 140 33,5 - 42.7
170 51,8 110 - 150 33,5 - 45.7 110 - 140(c) 33,5 - 42.7
180 54,9 110 - 160 33,5 - 48.8 ——
(b) 190 57,9 110 - 170 33,5 - 51,8 ——
(b) 200 61,0 100 - 150(c) 33,5 - 45.7 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
WITH OR WITHOUT BOOM CATWALKS
999 SERIES 3
Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method
With Intermediate Fall
Boom
Length
Over End of Blocked Crawlers Over Side of Crawlers
Luffing Jib No. 135 Luffing Jib No. 135
Feet Meters Feet Meters Feet Meters
130 39,6 110 33,5 110 33,5
140 42,7 110 - 120 33,5 - 36,6 110 - 120 33,5 - 36,6
150 45,7 110 - 130 33,5 - 39,6 110 - 130 33,5 - 39,6
160 48,8 110 - 140 33,5 - 42,7 110 - 140 33,5 - 42.7
170 51,8 110 - 150 33,5 - 45.7 110 - 150 33,5 - 45.7
180 54,9 110 - 160 33,5 - 48.8 110 - 160 33,5 - 48.8
(b) 190 57,9 110 - 170 33,5 - 51,8 110 - 130 33,5 - 39,6
(b) 200 61,0 110 - 150 33,5 - 45.7 — —
Load blocks, hook and weight ball on ground until boom and luffing jib are erected.
REFERENCE
ONLY!
