Marantz TT-15S1 User manual

TT-15S1
Printed in Japan
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.
Service
Manual
Printed on 100% Recycled Paper
TT-15S1
Turntable
TT-15S1 /F W
Part no. 90M31BW855010
First Issue 2004.12
MJI
TABLE OF CONTENTS
SECTION PAGE
1. TECHNICAL SPECIFICATIONS ........................................................................................... 1
2. EXPLODED VIEW AND PARTS LIST................................................................................... 2
3. USER GUIDE........................................................................................................................ 5

MARANTZ DESIGN AND SERVICE
Using superior design and selected high grade components, MARANTZ company has created the ultimate in stereo sound.
Only original MARANTZ parts can insure that your MARANTZ product will continue to perform to the specifications for which
it is famous.
Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent.
ORDERING PARTS :
Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
The following information must be supplied to eliminate delays in processing your order :
1. Complete address
2. Complete part numbers and quantities required
3. Description of parts
4. Model number for which part is required
5. Way of shipment
6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.
SHOCK, FIRE HAZARD SERVICE TEST :
CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary AC
cord connector pins ( with unit NOT connected to AC mains and its Power switch ON ), and the face or Front Panel of product and
controls and chassis bottom.
Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied, and
verified before it is return to the user/customer.
In case of difficulties, do not hesitate to contact the Technical
Department at above mentioned address.
041015MJI
USA
MARANTZ AMERICA, INC
1100 MAPLEWOOD DRIVE
ITASCA, IL. 60143
USA
PHONE : 630 - 741 - 0300
FAX : 630 - 741 - 0301
JAPAN Technical
MARANTZ JAPAN, INC.
35- 1, 7- CHOME, SAGAMIONO
SAGAMIHARA - SHI, KANAGAWA
JAPAN 228-8505
PHONE : [phone]
FAX : [phone]
EUROPE / TRADING
MARANTZ EUROPE B.V.
P. O. BOX 8744, BUILDING SILVERPOINT
BEEMDSTRAAT 11, 5653 MA EINDHOVEN
THE NETHERLANDS
PHONE : +31 - 40 - 2507844
FAX : +31 - 40 - 2507860
AUSTRALIA
QualiFi Pty Ltd,
24 LIONEL ROAD,
MT. WAVERLEY VIC 3149
AUSTRALIA
PHONE : +61 - (0)3 - 9543 - 1522
FAX : +61 - (0)3 - 9543 - 3677
NEW ZEALAND
WILDASH AUDIO SYSTEMS NZ
14 MALVERN ROAD MT ALBERT
AUCKLAND NEW ZEALAND
PHONE : +64 - 9 - 8451958
FAX : +64 - 9 - 8463554
THAILAND
MRZ STANDARD CO., LTD
746 - 754 MAHACHAI ROAD.,
WANGBURAPAPIROM, PHRANAKORN,
BANGKOK, 10200 THAILAND
PHONE : +66 - 2 - 222 9181
FAX : +66 - 2 - 224 6795
TAIWAN
PAI- YUING CO., LTD.
6 TH FL NO, 148 SUNG KIANG ROAD,
TAIPEI, 10429, TAIWAN R.O.C.
PHONE : +886 - 2 - 25221304
FAX : +886 - 2 - 25630415
MALAYSIA
WO KEE HONG ELECTRONICS SDN. BHD.
2ND FLOOR BANGUNAN INFINITE CENTRE
LOT 1, JALAN 13/6, 46200 PETALING JAYA
SELANGOR DARUL EHSAN, MALAYSIA
PHONE : +60 - 3 - 7954 8088
FAX : +60 - 3 - 7954 7088
KOREA
MK ENTERPRISES LTD.
ROOM 604/605, ELECTRO-OFFICETEL, 16-58,
3GA, HANGANG-RO, YONGSAN-KU, SEOUL
KOREA
PHONE : +822 - 3232 - 155
FAX : +822 - 3232 - 154
SINGAPORE
WO KEE HONG DISTRIBUTION PTE LTD
No.1 JALAN KILANG TIMOR
#08-03 PACIFIC TECH CENTRE
SINGAPORE 159303
PHONE : [phone]
FAX : [phone]
CANADA
MARANTZ CANADA INC.
5-505 APPLE CREEK BLVD.
MARKHAM, ONTARIO L3R 5B1
CANADA
PHONE : 905 - 415 - 9292
FAX : 905 - 475 - 4159

1
440
350
350
110
ǫȸȈȪȃǸ
ųᢿԼဪӭᲴ90M-PC000030R
1.TECHNICAL SPECIFICATIONS

2
2. EXPLODED VIEW AND PARTS LIST

3
41

4
POS. NO. VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI) PART NAME DESCRIPTION
90M-PC000030R PHONO
CARTRIDGE VIRTUOSO MM NEW ELEMENT MM New
1 90M-PA000030R TONE ARM TONE ARM ASSY SS-TT15/001
2 nsp SCREW ANTI-SKATING SCREW SS-TT15/002
3 nsp NUT LOCK NUT, NOTCHED F28 SS-TT15/003
4 90M31BW160010 BRACKET BRACKET FOR REST POSITION
OF ARM SS-TT15/004
5 90M31BW010010 SCREW SCREW FOR REST BRACKET M
3 X 16 SS-TT15/005
6 90M31BW154010 KNOB GRIP FOR TONE ARM LIFT SS-TT15/006
7 90M31BW371010 HOLDER HEADSHELL UNIT SS-TT15/007
8 nsp HOLDER HEADSHELL PLATE UNIT SS-TT15/008
9 nsp ARM TONE ARM REST HANDLE SS-TT15/009
10 nsp STICKER ANTI-SLIDE STICKER SS-TT15/010
11 nsp SCREW M2X5 HEXAGON SOCKET
SCREW SS-TT15/011
13 nsp SCREW M3X6 HEXAGON SOCKET
SCREW SS-TT15/012
14 90M31BW008010 WEIGHT CONTRA WEIGHT SS-TT15/014
15 90M31BW353010 RING O-RING FOR TONE ARM
CONTRA WEIGHT SS-TT15/015
16 nsp STICKER STICKER WITH SCALE SS-TT15/016
17 90M31BW107010 SHEET TONE ARM HIGHT ADJUSTMENT
FELT SHEET SS-TT15/017
18 90M31BW105010 CHASSIS MAIN CHASSIS SS-TT15/018
19 90M31BW165010 TURNTABLE TURNTABLE 28MM SS-TT15/019
20 90M31BW160020 BRACKET BEARING BRACKET UPPER
PART SS-TT15/020
21 90M31BW107020 SHEET SLIP MAT, SS-TT15/021
22 90M31BW010020 SCREW M10X30 SCREW SS-TT15/022
23 90M31BW057010 LEG ALMINUME FOOT SS-TT15/023
24 90M31BW056010 BUFFER BUFFER FOR FOOT SS-TT15/024
25 90M31BW106010 SUSTAINER CERAMIC BALL D=5 SS-TT15/025
26 nsp SCREW M6X8 HEXAGON SOCKET
SCREW SS-TT15/026
28 /F W 90M-PM100020R PHONO MOTOR
UNIT MOTOR ASSY WITH AC ADAPTER 100V 50/60HZ SS-TT15/028
29 90M31BW353020 RING O-RING FOR MOTOR SS-TT15/029
30 90M31BW264010 BELT BELT SILICON, TRANSPARENT SS-TT15/030
32 /F W 90M31BW262010 PULLEY PULLY FOR JAPAN 100V 50HZ SS-TT15/032
33 /F W 90M31BW262020 PULLEY PULLY FOR JAPAN 100V 60HZ SS-TT15/033
36 90M31BW005010 CLAMPER RECORD CLAMP (CLEVER
CLAMP) SS-TT15/036
41 90M-ZD000430R CORD GROUNDING CABLE SP-TT15/41
PACKING
00M31BW851110 USER GUIDE TT-15S1 F
NOT STANDARD SPARE PARTS
90M31BW801010 PACKING CASE PACKING TT-15S1 TT15S1/KART
90M31BW809010 CUSHION CHASSIS,TURNTABLE,TONE
ARM TT15S1/F0AM
35 90M-SSTT15035 OIL OIL FOR CENTER SHAFT HOLE SS-TT15/035
37 nsp TOOL SCREWDRIVER SS-TT15/037
38 nsp TOOL HEXAGON WRENCH 1.5 MM SS-TT15/038
39 nsp TOOL HEXAGON WRENCH 2.5 MM SS-TT15/039
40 nsp TOOL HEXAGON WRENCH 3.0 MM SS-TT15/040
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.

5
Model TT-15S1 Turntable
1
3. USER GUIDE

6
2
源プ グ
3
源プ グ
源プ グ

7
5
源プ グ
4
源プ グ
源プ グ

8
前面
20cm
20cm
20cm 20cm
20cm
20cm
側面
6
7
50Hz地域用 60Hz地域用

9
8

ターンテーブルシートなし
アームリフター
カウンターウェイト
ターンテーブルシートあり
アームリフター
カウンターウェイト
トーンアーム 高さ調 整シート
トーンアーム
phonoケーブル
ターンテーブルシャーシ
ターンテーブル 
センターシャフト
センターシャフト
ターンテーブルシャーシ
ターンテーブル軸底部
アースワイヤー
9

10
ネジ 
ヘッドシェル 
カートリッジ
六角レンチ（中）
トーンアーム 
ヘッドシェル 
六角レンチ（大）
外す
平行になる
トーンアーム  ターンテーブル 
ベース側面
10
カートリッジカバー
カウンターウェイト
トーンアーム 
アンチスケーティング
調整ネジ
赤 緑
白
青
付属カートリッジの場合
32mm
ネジ 
カートリッジ
トーンア ーム 
ヘッドシェル 
11

11
アンチスケーティング
調整ネジ
ネジの半分の位置
0
0.4
0.1
カウンターウェイト 基準ポイントから
4回転と2目盛回す
↓
針圧2.2g
0
0.4
0.3
0.2
0.1

0.4
0.1
カウンターウェイト
基準ポイント
アンチスケーティング
調整ネジ
トーンアーム
リフターレバ ー
カウンター 
ウェイト
バランス
をとる
12
33回転 45回転
下側にかける 上側にかける
中央の溝
接触しない
3mm
付属調整用
ドライバー 
13

12
15
電源
スイッチ 
TT-15S1
アンプ
赤
白
14
q w e r t y u i o !0 !1
w
!0 o i u y
e r t
q
!1

13
16
17

14
18
440
350
350
110
Printed in Japan 11/2004 00M31BW851110 mzh-g
