Mars QP10 Series User manual

Document No: QP-IOM
Date: 08/25/20
QuietPro 10 (QP10) COMMERCIAL SERIES
Installation, Operation and Maintenance Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate, or maintain
the product described. Protect yourself and others by observing all safety information. Failure to comply with these
instructions could result in personal injury and/or property damage. Retain these instructions for future reference.
OVERVIEW
Mars Air Curtains are
designed to cover door
openings, providing
both temperature
control/environmental
separation and flying
insect control, when the
building’s doors are
opened. Typical
installation heights are:
QuietPro 10 Series
(Environmental
Separation up to 12’,
Flying Insect Control up
to 10’). The units are
typically wall mounted
horizontally above the door opening. They can also be
suspended from the ceiling or vertically mounted
alongside the opening. The units are ETL Listed, Canada
and US, for either an inside or outside mount. Heated
units must be mounted on the inside or the protected side
of the opening. The motors used in the QuietPro 10
series are 1/2 HP.
QuietPro 10 come standard with an air intake screen(s).
They can also be configured with an aluminum mesh air
intake filter instead of the air intake grille or in conjunction
with it.
GENERAL SAFETY
INFORMATION
Use this product only in
the manner intended by
the manufacturer. Only
qualified personnel
should install this
product. Installing
personnel should have a
clear understanding of
these instructions and
should be aware of
general safety
precautions. Improper
installation can result in
electric shock, possible
injury due to coming in
contact with moving parts, as well as other potential
hazards.
WARNING
To reduce the risk of fire, electric shock, or injury to
persons, observe the following.
A. Always disconnect, lock and tag power source before
installing or servicing product.
B. Installation work or electrical wiring must be done by
qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction.
C. The combustion airflow needed for safe operation of
fuel burning equipment in the area may be affected by
the product’s operation. Follow the heating equipment
manufacturer’s guideline and safety standards, such
as those published by the National Fire Protection
Agency (NFPA), the American Society of Heating,
Refrigeration and Air Conditioning Engineers
(ASHRAE) and local code authorities.
D. When cutting or drilling into a wall or ceiling, be careful
not to damage electrical wiring and other hidden
utilities.
WARNING
When servicing the product, motor may be hot enough
to cause pain or injury. Allow motor to cool before
servicing.

RECEIVING AND INSPECTION
Upon receiving the product, check to make sure all items
are accounted for by referencing the Bill of Lading to
ensure all items were received. Inspect each carton for
shipping damage before accepting delivery. Notify the
freight carrier if any damage is noticed. The carrier will
make notification on the delivery receipt acknowledging
any damage to the product. All damage
should be noted on all copies of the Bill of Lading which
is countersigned by the delivering carrier. A Carrier
Inspection Report should be filled out by the carrier upon
arrival and a report given to the Traffic Department. If
damaged upon arrival, file a claim immediately with the
carrier. Any physical damage to the unit after acceptance
is not the responsibility of Mars Air Systems.
UNPACKING
Verify that all parts, components and accessories, and
the correct quantities of each have been received. If any
items are missing, report shortages to Mars Air Systems
directly to arrange for obtaining the missing items. Again,
verify quantities received against those on the Bill of
Lading only, as multiple shipments may be involved.
INSTALLATION
Typical Mounting – Wall or Ceiling Mounted
Horizontally Above the Door Opening
1. Gently remove all packaging materials, hardware, and
all other accessories from interior of unit prior to
operating. Severe unit damage will occur if these items
are not removed prior to operation.
2. Remove the air intake grille(s) and/or filter(s) from the
product and set aside.
3. Measure the housing and center it over the opening.
The air curtain shall be equal to or greater than the width
of the opening.
4. Wall mounting brackets with (3) ¼” mounting holes on
each bracket are provided for your convenience. These
holes must be utilized to secure the product to the wall
or ceiling. For ceiling mount, rotate the wall mounting
bracket 900to point upwards. Threaded rods to be
bolted to these ¼” holes. All hardware is field provided
by others.
5. Mount the product such that the discharge is 1” above
the opening and all obstacles. (FIG. 1)
Note: If the product is installed higher than the
recommended 1” above the opening, then it must be
moved 3/8” away from the wall for every 1” that it is
moved up. Any void between the wall and the product
must be sealed, by others, to optimize performance.
6. Use four (4) threaded rods for overhead installation or
four (6) threaded bolts for wall installation. All hardware
is field provided by others. (FIG. 1)
7. If applicable, additional wall mounting brackets are
available for attaching the unit to a wall.
(Reference Accessory Installation Supplement)
8. If applicable, for tandem installation or products
mounted side by side, allow no more than 6” between
the two products. For overhead installation using
threaded rods, the products may require a beam, by
others, to span the full distance of the mounting length.
(Reference Accessory Installation Supplement)
9. All wires must be connected internal of the unit and
some knockouts are provided. However, it may be
necessary to create your own knockout, as required.
10. The unit must be wired per NEC and local codes.
11. Service clearance of 18” required on top of the air
curtain.
FIG. 1
Motor Fan Assembly Installation and Electrical Field
Wiring
1. Once the mounting brackets or overhead support is
installed over the opening, the Air Curtain Unit (ACU)
must be re-placed and securely fastened to the
mounting support. For heated ACU installation,
reference Heated Products Supplement Sheet.
WARNING
Precaution should be taken in explosive atmospheres.

2. The unit and any optional accessories must be wired
with the proper voltage to the junction box per the wiring
diagram. (FIG. 3, unheated products only)
3. All 3 phase motors are bi-directional, which means they
can rotate in either direction. Follow directional arrows
4. on the blower wheel housings for proper rotation. If the
motor is rotating incorrectly, switch two of the 3 phase
power or motor leads and the motor will rotate the
5. opposite direction. Make sure all motors are
turning in the same and proper direction. (FIG. 2)
6. Replace the air intake grille(s) or filter(s) once the
product has been properly tested.
FIG. 2
FIG. 3
START-UP
This product has been assembled and tested at the
factory prior to shipping. The following procedures should
be performed to assure its performance. Before
continuing with the start-up, it is important to recognize
the safety controls furnished with the unit.
SCREWS PROVIDED TO
SECURE BLOWERS TO
HOUSING
WALL MOUNTING
HOLES
TOP MOUNTING
HOLES
SCREWS FOR INTAKE
SCREEN (RIGHT) AND
BOTTOM PANEL (LEFT)
STRAP PROVIDED TO
SECURE MOTOR TO
HOUSING
DOOR
OPENING
Typical Door Limit
Switch Installation for
Split Sliding Doors
Typical Door Limit
Switch Installation for
Commercial Swing Doors
Typical Door Limit
Switch Installation for
Industrial Roll Up or Lift Doors
CONTROL
PANEL
Field Conduit Wiring
TO
POWER
PANEL
MARS
Wheel Rotation
WARNING
The following items must all be completed by a qualified
installer and checked off when completed
A. Re-check that the product has been installed properly
and is level and secure.
B. Check all terminal screws are tight and field wiring is
connected in accordance to National Electrical Code
and wired per the enclosed wiring diagram. For
electric heated models, ensure that the coils are
secured and not touching each other on any metal
surface.
C. Verify proper voltage prior to powering the product.
(See product label for reference).
D. Check all field wired components “if supplied” are
wired correctly.
E. Check that the inlet air supply and the discharge air
supply are free of obstructions.
F. Check that all air filter(s) and/or air intake grille(s) are
in place and installed properly, as originally shipped.
G. Verify voltage to the product once more and turn
power on.
H. Regardless of whether the product is mounted on the
inside or outside of the door opening, set the air
directional vanes in the discharge nozzle slightly
outward to approximately 10-15° towards the outside,
or the wind load. (FIG. 4)
I. For products with control panels, turn the HOA (Hand-
On-Auto) selector switch to “On” position and open
the door to energize the product. For products without
a control panel or an On/Off switch, open the door to
energize the product.
J. If heated products are installed, reference Heated
Products Supplement.
K. For three phase units, verify direction of rotation of
blower wheels (note direction arrows on the blower
wheel housing). Correct if needed by changing
polarity of three phase power.
WARNING
Prevent hazard of electrical shock. More than one
disconnect switch may be required to de-energize
this product.
FIG. 4

MAINTENANCE
Routine maintenance is required to keep this product
operating at its peak performance and efficiency. Over
time, the housing, air intake grille, air intake filter, blower
wheels and motor(s) will accumulate a build up of dust,
debris, and other residue. It is imperative to keep these
components clean. Failure to do so will not only lower
operational efficiency and performance, but also reduce
the useful life of the product. The time between cleanings
depends on the application, location, and daily hours of
use. On average, under normal use conditions, the
product should require a thorough cleaning once every
six (6) months.
To clean the product, perform the following:
1. Verify the product has been disconnected from the
power source.
2. Use a damp cloth and either a warm mild soapy water
solution or bio-degradable degreaser, to wipe down the
exterior components of the housing.
3. To access the interior of the product, remove the air
intake grille and/or air intake filter. This is accomplished
by removing the screws on the face of each air intake
grille/filter.
4. Thoroughly clean the air intake grille/filter.
5. Thoroughly wipe down the motor, blower wheels and
blower wheel housings. Be careful not to spray the
motor with a water hose.
6. The motor(s) require no additional lubrication. They are
permanently lubricated and feature double sealed ball
bearings.
7. To re-install the product, reverse the procedures above.
8. Reconnect the power source to the product
9. If you have any questions regarding the maintenance of
the product, contact the manufacturer.
SPECIAL APPLICATIONS
Outdoor Installation
For outdoor unit special consideration may be required
for enclosure, motor, wheel, and other components to
minimize damage caused by exposure to the outdoor
elements. Contact factory for special construction and
costing.
Freezer and Cooler Installation
Air curtain must be mounted on the warm side for optimal
performance. Variable Frequency Drive (VFD) is
strongly recommended to control the air curtain air flow
velocity at the floor level.
High humid areas may require de-humidifier or additional
defrost cycle to minimize condensation and freezing for
freezer applications. We recommend the air curtain unit
to not replace doors but work in conjunction with door
opening sequence cycle.
Contact factory for details.
CAUTION
The appliance is not to be used by persons (including
children) with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction. Children
are not to play with the appliance.
DISCLAIMER
Mars reserves the right to change specifications and
product design without notice. Such revisions do not
entitle the buyer to corresponding changes,
improvements, additions, or replacements for previously
purchased equipment.
L. VERY IMPORTANT Using a clamp meter, measure
the amperage to each motor and ensure that they
do not exceed the amperage listed on the product
label.
M. If applicable, adjust the air intake grille(s) such that
the output air stream reaches the floor. For
temperature control and environmental separation
applications, the air stream should reach the floor
with sufficient strength to create an air seal around
the door opening without creating turbulent mixing
of the inside and outside air. For flying insect
control applications, the air stream should reach the
floor with maximum strength. If after proper
installation and adjustment, the product appears to
be producing too little or too much air for the
application, contact the manufacturer.
WARNING
To reduce the risk of fire, electrical shock, or injury to
persons, observe the following:
A. Maintenance is to be performed only by qualified
personnel who are familiar with local codes and
regulations and are experienced with this type of
product.
B. Before servicing or cleaning the product switch power
off at service panel and lock service panel to prevent
power from being switched “ON” accidentally.
NOTE
For accessory installation, reference Accessory
Installation Supplement.
For heated products, reference Heated Products
Supplement.
