MasterChef G32008 User manual

PRIME 3-BURNER
PROPANE BARBECUE
Assembly Manual
085-3135-0 / G32008
1 YEAR LIMITED WARRANTY
ANSI Z21.58-2015 / CSA 1.6-2015
ANSI Z21.58-2015 / CSA 1.6-2015 ANSI Z21.58-2015 / CSA 1.6-2015
ANSI Z21.58-2015 / CSA 1.6-2015
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
Assemble your grill immediately.
Missing or damaged parts claims must be submitted within 30 days of purchase date.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-855-453-2150.

DANGER
1. If you smell Gas:
a. Shut o gas to the appliance.
b. Extinguish any open ame.
c. Open lid.
d. If odor continues, keep away from
the appliance and immediately
call your gas supplier or your
re department.
2. Requires two people to complete the
assembly process.
3. Beware of sharp edges.
WARNING
Failure to follow all of the Manufacturer’s
instructions could result in hazardous res,
explosions, property damage, or serious
personal injury or even death.
Follow all leak check procedures carefully
prior to operation of barbecue, even if grill
was dealer assembled. Do not try to light
this barbecue without reading the Lighting
Instructions section of this manual.
THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES
CAUTION
Read and follow all safety statements,
assembly instructions, use and care
directions before attempting to assemble
and cook.
WARNING
1. Do not store or use gasoline or other
ammable liquids or vapours in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
WARNING
IN DIRECT SUNLIGHT, AND IN
OPERATION, YOUR BBQ’S STAINLESS
STEEL AND PAINTED STEEL PARTS CAN
BECOME VERY HOT.
CAUTION
Sharp edges. Wear gloves when assembling
your grill.
THIS BARBECUE IS FOR OUTDOOR USE ONLY.
CONTACT CALL CENTRE IF ANY PARTS ARE MISSING.
1-855-453-2150
INSTALLER OR ASSEMBLER/CONSUMER
This manual should be kept with the BBQ at
all times.
HEAVY ARTICLE NEEDS 2 TO LIFT
To ORDER non-warranty replacement parts or accessories, or to register your warranty,
please visit us on the web at
www.masterchefbbqs.com

3
HARDWARE PACK
1/4” - 20 UNC x 30 Screw
X 4
No. 10 - 24 UNC x 13 Screw
X 24
No. 10 - 24 UNC x 13 Screw Set
X 4
1/4” - 20 UNC Nut
X 10
1/4” - 20 UNC Wing Nut
X 2
Wheel Spacer
X 2
Stopper, Warming Rack
X 2
1/4” - 20 UNC x 13 Screw
X 16
No. 8 - 32 UNC x 10 Screw
X 6
Aluminum Washer
X 5
Hitch Pin, Burner
X 3
Hitch Pin, Wheel
X 1
ST4.2 x 8 Tapping Screw
X 6
Washer, Burner Box
X 4
φ6 Washer
X 1
Wheel Washer
X 1
1 3
4
7
10
13
16
5
8
11
14
6
9
12
15
KEY # DESCRIPTION PART NUMBER QUANTITY
1 1/4” - 20 UNC x 30 Screw 20120-13030-036 4
2 1/4” - 20 UNC x 13 Screw 20120-13013-036 16
3 No. 10 - 24 UNC x 13 20124-10013-036 24
4 No. 10 - 24 UNC x 13 Screw Set G432-U400-9091 4
5 No. 8 - 32 UNC x 10 Screw 20132-08010-250 6
6 ST4.2 x 8 Tapping Screw 24200-42008-136 6
7 1/4” - 20 UNC Nut 31220-13000-036 10
8 Aluminum Washer G466-0042-9000 5
9 Washer, Burner Box G437-0050-9000 4
10 1/4” - 20 UNC Wing Nut 33300-13000-036 2
11 Hitch Pin, Burner G515-0013-9000 3
12 φ6 Washer 40100-06000-036 1
13 Wheel Spacer G305-0024-9088 2
14 Hitch Pin, Wheel G306-0005-9088 1
15 Wheel Washer 40300-08000-036 1
16 Stopper, Warming Rack G320-3004-9191 2
TOOLS NEEDED FOR ASSEMBLY
• #2 Star-head screwdriver (long and short)
• ¼” Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
For correct hardware assembly, always position
the lock washer between the screw and the at
washer.
Caution:
Sheet metal can cause injury. Wear gloves when installing the grill.
Lock Washer
Flat Washer
Screw
BEFORE ASSEMBLING THIS BARBECUE, READ THE INSTRUCTIONS CAREFULLY.
Assemble the barbecue on a flat, clean surface. The grill is heavy, two people are
recommended to complete assembly.
2

4
PARTS LIST (PROPANE) FOR 085-3135-0 / G32008
KEY # QUANTITY DESCRIPTION PART NO.
AA 1 Top Lid Assembly G320-5200-01
AB 1 Thermometer G312-B201-02
AC 1 Top Lid Handle G320-5102-01
AD 2 Lid Hinge G320-5101-01
BA 1 Burner Box Assembly G320-5400-01
BB 3 Main Burner G320-0200-01
BC 1 Electrode Set, Main Burner G311-0005-02
BD 2 Carryover Assembly G413-0004-02
BE 3 Flame Tamer G320-3002-01
BF 1 Cooking Grate G305-0006-01
BG 1 Warming Rack G320-5301-01
CA 1 Control Panel G320-6000-01
CB 1 Manifold Assembly G320-6100-01
CC 1 Regulator G320-0702-01
CD 3 Control Knob G320-5302-01
CE 1 Ignitor G206-0701-01
CF 1 Grease Cup Hook G305-0043-01
CG 1 Grease Cup G430-0033-02
CH 1 Heat Shield G320-3003-01
DA 1 Left cart frame, G320-5601-01
DB 1 Left front cart leg (1) G320-5602-01
DC 1 Left rear cart leg (2) G320-5603-01
DD 1 Right cart frame G320-5701-01
DE 1 Right front cart leg (3) G320-5702-01
DF 1 Right Rear Cart Leg (4) G320-5703-01
DG 2 Lower Cart Brace G320-5604-01
DH 1 Upper Back Brace G320-5800-01
DI 1 Lower Back Brace G320-5900-01
DJ 1 Front Panel G320-5501-01
DK 2 End Caps G320-5504-01
DL 2 Wheel G320-5506-01
DM 1 Wheel Axle G320-5507-01
DN 1 Match Holder G401-0079-01
DO 2 Tank Exclusion Wire G320-5502-01
DP 1 Gas Tank Support G320-5503-01
EA 2 Side Shelf G320-0051-01
F1 1 Hardware Pack G320-B008-01
F2 1 Assembly Instructions G320-M008-01
F3 1 Safe Use and Care Manual G320-M008-02

5
EXPLODED DIAGRAM (PROPANE) FOR 085-3135-0 / G32008
AA
AC
AB
AD
BA
DP
DH
DI
EA
DB
DJ
CB
DG
BC
DN
CC
CE
CH
DO
CA
BD
BB
EA
BE
BF
BG
CD
CF
CG
DA
DD
DC DE
DF
DG
DK
DL
DM
HARDWARE
PACK
F1
F2 F3
ASSEMBLY
MANUAL
SAFETY
AND CARE
MANUAL

6
1
ASSEMBLY INSTRUCTIONS
DB
DC
DG
DG
DB
DC
DA
YOU WILL NEED:
3
X 2
YOU WILL NEED:
76
1
X 2
7
X 2

7
2
ASSEMBLY INSTRUCTIONS
DE
DF
DE
DG
DF
DG
DD
YOU WILL NEED:
3
X 2
YOU WILL NEED:
76
1
X 2
7
X 2

8
ASSEMBLY INSTRUCTIONS
3
YOU WILL NEED:
3
X 6
DJ
DA
DD

9
ASSEMBLY INSTRUCTIONS
4
YOU WILL NEED:
3
X 8
DH
DI
DD DA

10
ASSEMBLY INSTRUCTIONS
5
DM
14
14
13 15
DL
15
13
DL
13
DK
YOU WILL NEED:
76
13
X 2
14 15
X 1 X 1

11
ASSEMBLY INSTRUCTIONS
6
DI
DI
DO
DO
DJ
DJ
YOU WILL NEED:
6
X 2

12
ASSEMBLY INSTRUCTIONS
7
CE
CE
CA
A

13
ASSEMBLY INSTRUCTIONS
7
CA
CA
CB
CB
YOU WILL NEED:
5
X 6
B

14
ASSEMBLY INSTRUCTIONS
8
YOU WILL NEED:
11
X 3
BB
11
BC
BA
BB
1
2
3
BB
11
A
Assemble burner with electrode
in the middle.

15
ASSEMBLY INSTRUCTIONS
8
YOU WILL NEED:
6
X 3
BD
BC
BB
BA
B
BA
BA
BD

16
ASSEMBLY INSTRUCTIONS
9
CA
BA
YOU WILL NEED:
76
3
X 4
9
X 4
A
BB
CA
BB
Make sure the burners (BB)
engage the burners valves (CA).

17
ASSEMBLY INSTRUCTIONS
9B
BC
CE
BC
CE
Attach the main burner
electrode wire (BC) to
the ignitor (CE). Make sure
that the electrode wire (BD)
is pushed in rmly.

18
ASSEMBLY INSTRUCTIONS
10
CD
CB
CA

19
ASSEMBLY INSTRUCTIONS
11 YOU WILL NEED:
4
X 4
BA
BA
A
B

20
ASSEMBLY INSTRUCTIONS
11
YOU WILL NEED:
3
X 2
CH
BA
CH
BA
C
