MasterChef RSH014348 User manual

HELPLINE 0844 809 4871
or visit www.masterchef-bbq.com and follow link.
THE OUTDOOR COLLECTION
INSTRUCTIONS FOR USE:
READ ALL WARNINGS AND INSTRUCTIONS BEFORE USE, AND RETAIN.
Tesco/RSH-014348/022012
USER GUIDE
Model No. RSH014348
3 BURNER COMPETITOR
STAINLESS STEEL GAS BBQ

Tesco/RSH014348/022012 1
1
COMPETITOR 3 Burner Gas BBQ with side burner
Model No: RSH-014348
MasterChef Helpline
For assistance, please call 0844 809 4871 or visit www.masterchef-bbq.com.
This website offers further advice including images to assist with the use of the
gas regulator and assembly of the side burner venturi pipe.
Warnings
Read before starting!
We recommend reading the relevant sections of these instructions prior to assembly and before each use. Follow the
steps in the order they are specified and please observe the safety warnings.
Failure to observe these instructions can affect or damage the barbecue and lead to personal injury.
These instructions should always be stored with the product and passed onto each subsequent user.
Propane LPG bottle is the only form of fuel to use with this barbecue (see ‘Gas System’ for full details).
The regulator supplied with this product is the new generation easy-use model. These are compatible with all current
gas cylinders eg: Calor, Flo-gas and other suppliers.
Always check for gas leaks regularly and when connecting or reconnecting the regulator and hose. See ‘Checking for
Leaks’.
Check all the parts are included before commencing assembly. If any parts are missing please call the MasterChef
Helpline number above or visit www.masterchef-bbq.com. If the barbecue is faulty or damaged ensure all the parts are
back in the box and return to the store with your receipt as proof of purchase.
It is recommended this barbecue is assembled by two people.
A medium sized Phillips screwdriver and a suitable spanner (flat spanner or box spanner) are required for assembly.

Tesco/RSH014348/022012 2
2
Specifications
Authorization
Intertek Testing Services Ltd. (ITS)
Notify Body Number CE –0359
Barbecue
Device category
I3+(28-30/37) according to EN498
Total weight:
36 kg approx.
Dimensions (L x H x W)
1220 x 575 x 1105mm approx.
Barbecue surface (L x W)
580 x 370 mm approx.
Gas system
Heat output
approx. 10.4 kW (743g/h) total rate
Type of gas
Propane at 37mbar
Injector size
0.82mm for the grill burners
0.70mm for the side burner
Preset and approved pressure reducer
Flow rate: 1.5 kg/h max.
Operating pressure: Propane at 37mbar
Gas cylinder
Standard gas cylinder with 5 to 13kg Liquid Petroleum
Gas (LPG) max.
Gas hose
CE-approved hose comply with EN1763-1
Ignition
Automatic ignition
Control valve
Adjustable 0 - max.
** Liquid Petroleum Gas = LPG throughout this document
Safety Instructions
Definition of terms used
The following pictograms and signal words are used in these instructions to point out hazards and important information:
PICTOGRAM AND SIGNAL WORD
Note on …
Danger
… a possible danger that can result in severe personal injury or damage to
property if the stated measures are not observed.
Caution
… a possible danger that can result in damage to property if the specified
measures are not observed.
For safety:
FOR OUTDOORS USE ONLY
(Outside any enclosure)

Tesco/RSH014348/022012 3
3
Warning
To avoid injury and damage to property, be sure
to follow all the warnings and instructions
carefully, before every use.
CAUTION!
ALWAYS KEEP THIS APPLIANCE CLEAN. To
help avoid fat flash fires/ flare ups and therefore
possible injury or damage to property, it is vital
that this appliance is clean before it is used.
Always follow the Care Instructions.
CAUTION!
KEEP OUT OF REACH OF CHILDREN and
PETS DURING and AFTER USE, as accessible
surfaces will be extremely hot during use and will
remain hot for sometime thereafter. KEEP
CHILDREN & PETS WELL AWAY!
CAUTION!
SIDE BURNER: For safety, when using the side
burner it is strongly recommended to use pots
less then 20cm diameter. Pots larger then 20cm
are not suitable for this appliance.
WARNING!
DO NOT USE INDOORS - FOR OUTDOOR
USE ONLY
NEVER LEAVE A BARBECUE UNATTENDED.
If ever in doubt, before use consult a qualified
gas engineer.
WHEN LIGHTING FOR THE FIRST TIME
ALWAYS take extra care. Keep your head and
arms from hanging over the barbecue cooking
surface.
ALWAYS make sure the barbecue is completely
cool before applying covers.
CAUTION!
This barbecue will become very hot during
operation - always wear suitably protective heat
proof gloves during use.
NOTE:
This is a gas appliance. DO NOT USE any other
type of fuel/accelerants or lava rock in this
barbecue.
Protect from the elements and damp.
Stand the barbecue on a safe, solid, level
surface, well away from flammable items such
as wooden fences or over-hanging tree
branches.
ALWAYS close and disconnect from the gas
bottle after use and for storage.
DO NOT MOVE DURING USE. ALWAYS allow
to cool before moving.
Please retain instructions for future use.
ONLY store away when the barbecue is
completely extinguished and cool.
In construction of this barbecue use all and only the
components provided. If parts are missing, do not use
and call MasterChef Helpline on 0844 809 4871.
Utilisation
Proper use
The barbecue is a gas barbecue for outdoor use. It is
designed to be used exclusively in accordance with
these instructions for preparing foods that are suitable for
barbecue cooking.
For private/domestic use only!
Improper use
Any other application or applications extending beyond
the stated purpose are not authorised. This applies in
particular to misuse involving the following possible
scenarios:
Do not operate the barbecue with coal or any
fuel other than LPG.
Apart from the side burner (see earlier Side
Burner Caution), do not operate the barbecue
as a stove using pots and pans.
Do not operate the barbecue as a heater.
Any modification of the appliance may be
dangerous.
Parts sealed by the manufacturer must not be
altered by the user.
Do not use the barbecue to heat materials and
substances other than foods that are suitable for
barbecuing.
The barbecue has been manufactured according to the
general engineering rules –that were valid at the time
manufacturing was started –and the requirement of the
CE- sign. It is certified and approved by INTERTEK
Testing Services Ltd. (ITS) (Test number CE-0359). The
barbecue left the factory in good order and condition in
terms of its function and safety.

Tesco/RSH014348/022012 4
4
Danger “Hot surface and parts”
During operation some parts of the barbecue can
become very hot, particularly those close to the fire bowl.
Possible consequences:
Severe burns from touching parts near the fire
bowl.
Fire, or smouldering fire, if flammable materials or
substances are near the barbecue.
Safety measures prior to using the barbecue:
Select a place to set up the barbecue so that:
There are not, and will not be, flammable material
or substances nearby or any overhead obstruction
above and at the sides. Allow a minimum of one
metre distance to highly flammable materials or
substances, e.g. walls and fences.
The barbecue is positioned firmly on a sufficiently
large, flat, solid surface area. It must not be moved
during operation.
Do not use the barbecue on a surface that may be
damaged by excessive heat.
Safety measures during barbecuing:
Wear heat-protective barbecue gloves.
Never leave the hot barbecue unattended.
TAKE PARTICULAR CARE TO ENSURE THAT
CHILDREN AND PETS ARE KEPT AWAY FROM
THE BARBECUE.
Never fit the gas bottle right next to the barbecue.
Always place the gas bottle at the rear of the
appliance sited as far away as possible without
straining the hose.
No part of the hose should touch any part of the
barbecue.
Danger “Gas is highly flammable”
Liquid gas is highly flammable and explosive.
Possible consequences:
Serious personal injury or damage to property if
escaping gas ignites in an environment in which it is
not controlled.
Safety measures when using gas:
Only use the barbecue outdoors and ensure that
the area is well ventilated.
Protect the gas bottle and gas hose from direct
sunlight and other heat sources (max. 50°C). Take
special care to ensure that the gas hose does not
touch any part of the hot barbecue.
DO NOT place the gas bottle on the lower shelf,
as it is too near the burner.
DO NOT lean over the barbecue when igniting the
gas flame.
Close the regulator attached to the gas bottle after
each use by turning the lever clockwise. Also turn
off the control knobs (fully clockwise to OFF).
Never leave the hot barbecue unattended. If the
flame extinguishes, relight immediately or cut off
the supply from the gas bottle.
When connecting the gas bottle, ensure that there
are no ignition sources within a 5m radius.
Take special care not to light near any naked
flames, do not smoke or switch on electric
appliances (devices, lights, door bells), etc. as
sparkover possible.
Before each use, check to ensure that all
connections through which the gas is supplied are
sealed and intact.
If necessary, ensure when replacing the hose it
meets with national requirements. Always use
hose-clips to secure the hose to the regulator and
barbecue.
If the connections for the gas supply are porous or
faulty, the barbecue must not be used. This also
applies, for example, to hoses or fittings blocked by
insects, as this can lead to a dangerous flashback.

Tesco/RSH014348/022012 5
5
Parts List
Ref
Description
Illustration
QTY
Ref
Description
Illustration
QTY
1.
Thermometer
1
11.
Trolley base board
1
2.
Body
1
12.
Universal wheel
4
3.
Side burner
grate
1
13.
Base cross bar
1
4.
Side burner with
venturi hole** in
pipe
1
14,
15.
door
2
5.
Side burner
shelf
1
16a
16b
Trolley legs (right
front), Trolley legs
(right back)
2
6.
Back board
1
17.
Upper decoration bar
1
7.
Warming rack
1
18.
Crossbeam
1
8.
Left side shelf
decoration bar
1
19.
Fixing sheet for door
2
9a,
9b.
Trolley legs (left
front), Trolley
legs (left back)
2
20.
Drip tray
1
10.
Trolley side
panel
2
21.
Handle for drip tray
1

Tesco/RSH014348/022012 6
6
22.
Right side shelf
decoration bar
1
25.
Cooking grill
1
23.
Right side shelf
1
26.
Griddle
1
24.
Flame tamer
2
** Part 4. Side burner. The venturi is a small hole in the side burner pipe which allows the intake of air as the gas is
sucked through the pipe. Adding the air to the intake of LP gas creates combustion –a flame. NB: the side burner
pipe will always be loose fitting to allow for expansion/movement during the intake of gas and air.
NB: Rotisserie equipment is not included. It is available from specialist garden centres and is adjustable.
Screws and Nuts
A.
M5x35
8pcs
B.
M5x12
36pcs
C.
M4x6
4pcs
D.
M5
2pcs
E.
M4x8
4pcs
F.
M5x20
4pcs
L.
Spare screws
1pcs
A+B+C+D+E+F
Assembly tools: A medium sized Phillips screwdriver and a suitable spanner (flat spanner or box spanner) are
required for assembly.
Regulator, Hose & Clips (supplied with the gas barbecue)
(1)
Regulator
1pc
(2)
Hose
1pc
(3)
Hose clips
2pcs
WARNING: It is recommended in the course of normal wear and tear to replace the hose every two years.

Tesco/RSH014348/022012 7
7
Getting to know the barbecue

Tesco/RSH014348/022012 8
8
Operational Elements
POSITION
DESCRIPTION
FUNCTION
A
Control knob- OFF position
Flame will go out/off
B
Control knob- MAX position
Flame will be at its highest after ignition.
Ignition will take place
C
Control knob- MIN position
Flame will be at its lowest after ignition
G1
Regulator
Reduces gas pressure
G2
Operating lever/ Release
A separate safety facility with 2 settings:
OFF: Turn the
lever clockwise
180° so the thin
rectangular line is
showing on top of
the horizontal lever.
RELEASE: To release the regulator from
the gas bottle, press in the lever only
when in the OFF position.
ON: Turn the lever
180° anti-clockwise
so the flame symbol
is showing on top of
the horizontal lever.
G3
Regulator valve
To connect the hose to the regulator
G4
Gas bottle with bottle valve
Fuel container
G5
Gas hose with hose clip
Directs gas to burner
G6
Coupling nut
Connects regulator to gas bottle valve
Function
With the gas bottle lever in the ON position (“FLAME” sign on G2 facing upward) and the control knob pointing
between position B and C, the gas flows through the gas hose (G5) and the setting device (behind the front panel) into
the burner.
While turning each control knob from position A to B, sparks will be emitted from the electrode on the burner which
then ignites the gas. The heat output can be adjusted for the burners by turning the control knob to positions (B) for
maximum and (C) for minimum heat.
For more details, please refer to “Operating the Barbecue”.

Tesco/RSH014348/022012 9
9
Assembly Instructions
Before starting:
Here are a few tips to help assemble the barbecue quickly
and successfully:
Check that no parts are missing by placing all of the
individual parts on an empty surface (we reserve the
right to make minor technical alterations, such as the
content of the small parts bag). If, despite careful
factory checks, a component is missing, please
contact the MasterChef Helpline. If the barbecue is
faulty or damaged ensure all the parts are back in the
box and return to the store with your receipt as proof
of purchase.
Carefully sort out the small parts, as some of the
screws and bolts, for example, are very similar and
can be easily confused.
A medium sized screwdriver and a suitable spanner
(flat spanner or box spanner) are required for
assembly.
Make sure all the protective packaging has been
removed before assembling.
Even if not experienced at DIY, it does not generally
take more than one hour when two people work
together on the assembly.
Please note:
Only use tools that are intact and suitable. Worn or
unsuitable tools will not allow sufficient tightening of
the screws and bolts, and will damage them to the
extent that they can no longer be turned.
Always fit all joining parts (screws, nuts, etc) as
shown in the following illustrations. If a joining part is
misplaced, replace with an appropriate part. Only by
doing this can the construction be strong and safe.
It is essential that the instructions are followed in the
order they are specified!
Read the text for each step before carrying it out, as
useful information is sometimes only provided at the
end of the section.
2.
01
02
2.

Tesco/RSH014348/022012 10
10
B
4pcs
.
A
8pcs
04
B
4pcs
03
B
4pcs
05
06

Tesco/RSH014348/022012 11
11
B
4pcs
07
11
11
B
4pcs
08
10.
E
4pcs
10
B
4pcs
09

Tesco/RSH014348/022012 12
12
B
1pc
D
1pc
B
1pc
D
1pc
11
12
13
14

Tesco/RSH014348/022012 13
13
F
2pcs
15
16
17
18
B
4pcs
C
2pcs
F
2pcs

Tesco/RSH014348/022012 14
14
B
3pcs
19
20
21
B
3pcs
C
2pcs
22

Tesco/RSH014348/022012 15
15
25
23
24
Attach the hose to the air- in vent on right
under side shelf. (refer to “Connecting and
Disconnecting the gas bottle).

Tesco/RSH014348/022012 16
16
Connecting and disconnecting
the gas bottle
Gas bottle - Standard LPG gas bottle with weight
between 5kg to 13kg LPG (e.g. propane). These are
available from most garden centres, DIY stores and
camping sites.
The following parts are included with the barbecue.
They correspond to the standards applicable in the
country to which they have been supplied.
Gas hose- CE approved hose of sufficient length,
allowing installation without any kinks (length shall
not exceed 1.5m).
Regulator –Preset and CE-approved pressure
Regulator, operating pressure suitable for the LPgas
bottle. This type of regulator is also available from
your local gas bottle stockist. It is the easy-use
clip-on model, compatible with current Calor,
Flo-Gas and other gas bottle suppliers.
Danger “Ignition of escaping gas”
LPG is highly flammable and explosive.
Possible consequences:
Serious personal injury or damage to property if
escaping gas ignites in an environment in which it is
not controlled.
Safety measures:
When connecting the gas bottle, ensure there are no
ignition sources within a 5m radius.
Do not light near any naked flames, do not smoke or
switch on electrical appliances (devices, lights,
door-bells), etc as sparkover possible.
Ensure the flexible hosing is routed so there are no
kinks and it is not subject to twisting.
Do not obstruct ventilation of the barbecue.
If necessary, ensure that a replacement hose meets
with BS3212 national requirements.

Tesco/RSH014348/022012 17
17
Connecting the gas bottle (fig 1 above)
1. Select a suitable position to set up the barbecue.
Ensure that:
There are not, and will not be, flammable material
or substances nearby, or any overhead
obstruction above and at the sides. Allow a
minimum of one metre distance to highly
flammable materials or substances, e.g. walls and
fences.
The barbecue is positioned firmly on a sufficiently
large, flat, solid surface area. It must not be moved
during operation.
Do not use the barbecue on a surface that may be
damaged by excessive heat.
Never place or fit the gas bottle right next to the
barbecue.
Always place the gas bottle at the rear of the
appliance sited as far away as possible without
straining the hose.
No part of the hose should touch any part of the
barbecue.
2. Never lay the gas bottle on its side or place on the
lower shelf. The gas hose must not be bent or
under tension.
3. Check the gas bottle and the regulator are in good
working order.
4. Turn the operating lever G2 clockwise to OFF, and
push the regulator (G1) down onto the gas bottle
valve (G4) until it clicks.
5. Check it is correctly connected by pulling the
regulator upwards. The regulator must not
disconnect from the bottle valve.
6. Check the connection between the regulator and
the gas hose G5, and the gas hose to the
regulator valve (G3) to ensure they are secured.
7. Open the gas bottle’s valve by turning the
operating lever G2 anti-clockwise to the ON
position.
Checking for Leaks
WARNING: Never check for leaks if there is an
open flame. Listening for leaks is not a reliable
method of detection.
ALWAYS test for leaks when fitting a new gas bottle,
or it has been removed, stored away or not used in the
last month.
Testing for Leaks
NEVER check for leaks with a naked flame.
With the regulator lever in the ON position:
Use a standard gas leak detector (available from DIY
stores and camping sites) to ensure all connections
are tight. Please observe the instructions for the leak
indicator. If there is a leak, tighten the connections and
test again.
An alternative option to check for leaks - brush a
solution of approximately 50:50 water to soap
(washing-up liquid can be used but make sure the
solution does not have too many bubbles before
applying) over the regulator and hose connections.
There is a leak if bubbles form over any of the
connections. Immediately turn off the gas supply and
retighten all connections. Repeat the soap/water test.
If there is still a leak replace the leaking part. Repeat
the leak test to ensure the leak has stopped before
using. If there is still a leak replace the leaking part.
Repeat the leak test to ensure the leak has stopped
before using.
8. If not using the barbecue immediately, close the gas
bottle valve by turning the operating lever G2
clockwise to OFF.
Disconnecting the gas bottle (Fig.2 above)
1. Close the bottle valve by turning the operating
lever G2 clockwise to OFF.
2. Press in the operating lever G2 and pull the
regulator G1 upwards.
3. Store the regulator G1 with the gas hose under the
barbecue. Ensure the hose is not kinked or twisted
4. Store the gas bottle correctly:
Fit the gas bottle valve with the safety cap
(supplied with the gas bottle).
Do not store the gas bottle in areas below
ground level, in or near stairways, hallways
or passages for pedestrians, in cars or
between buildings. Always store gas bottles
outside.
Always store gas bottles upright, even if they
are empty!

Tesco/RSH014348/022012 18
18
Operating the Barbecue
NB: When using the barbecue for the first time, follow
the instructions below and heat the barbecue for about
20minutes without food so that the food-safe coating
is hardened (as with any barbecue).
Have heat-proof gloves, appropriate meat
thermometer and long-handled barbecue utensils
(available from most DIY stores and garden centres)
to hand.
Starting up the barbecue
1. Check to ensure the barbecue is in a suitable
position.
There are not, and will not be, flammable
material or substances nearby or any
overhead obstruction above and at the sides.
Allow a minimum of one metre distance to
highly flammable materials or substances, e.g.
walls and fences.
The barbecue is positioned firmly on a
sufficiently large, flat, solid surface area. It
must not be moved during operation.
Do not use the barbecue on a surface that
may be damaged by excessive heat.
Check to ensure the barbecue is fully
assembled and has no apparent faults, the
grill has been inserted and that the fat-catcher
(drip) tray is clean and underneath the fire
bowl.
2. Turn the regulator lever (G2) anti-clockwise to
ON.
3. Check to ensure that the gas system is sealed (if
not, turn the operating lever (G2) clockwise to
OFF and follow the Checking For Leaks section
on previous page.
4. Open the lid of the fire bowl.
ALWAYS keep open while igniting the flame.
Caution: Do not lean over the barbecue during
step 6. 7 and 8. Keep a safe distance.
5. Press in and turn a control knob for a grill burner
to position (B) anti-clockwise.
6. When in position (B), the burner will ignite.
7. If necessary, repeat the above until the burner
ignites.
8. Wait for a few seconds and then release the
control knob. If the flame goes out, turn the
control knob to ‘OFF’ position (A), wait 3 minutes
and repeat the above for ignition. Repeat steps
6, 7, 8 and 9 to light the other burners.
9. Close the lid and allow the barbecue to heat up
at full power.
10. When the barbecue is heated up, turn the control
knob to the appropriate setting.
11. Place the food on the grill rack using
long-handled utensils. Wear barbecue gloves or
other heat-proof gloves to protect from the heat.
12. Use an appropriate cooking/meat thermometer
to
check the internal temperature of barbecued
meats have met the appropriate minimum
temperatures before serving. Meats not
cooked
through properly can lead to illness.
Switching on the side burner
Lift the lid and repeat the above from step 5, using the
control knob for the side burner.
Lighting with a taper/long match
If the control knob is not igniting the gas, light it with a
long match or taper through the small hole in the side
of the body of the barbecue directly underneath the
shelf. (The lighting hole can be seen in diagrams 19
and 20). It is the round hole nearest the control panel
(not the larger hole in the side panel). If the left hand
burner is alight the other burners will ignite when
switching on the control knobs.

Tesco/RSH014348/022012 19
19
Switching off the barbecue:
1. Close off the gas by turning the lever (G2)
clockwise.
2. Turn the control knobs to the OFF position (A).
3. Wait until all of the barbecue has cooled down
and then clean all soiled parts.
4. Close the lid.
5. If the barbecue is not to be used for some time:
Disconnect the gas bottle (see the section
“Disconnecting the gas bottle”).
Store the barbecue in a dry place.
Care Instructions
Checking
Please note to inspect the barbecue before every
use. The barbecue should be clean and in good
working order.
It is important to replace barbecue parts if they
show signs of fatigue, corrosion or damage.
Please note: Continuing to use an appliance which
is damaged could cause injury or damage to
property
Cleaning the barbecue
To remove food debris on the grill, keep the grill on for
a further 10-15 minutes after cooking to burn off the
debris.
To ensure the longevity of this barbecue for many
years to come, it should be cleaned after each use
with washing- up liquid, a brush and cloth –ensure
that all parts have cooled down first. It is much easier
than cleaning it at a later stage when the dirt has dried
hard.
If the inside surface of the barbecue lid has the
appearance of peeling paint, then baked-on grease
build-up has turned to carbon and is flaking off.
Clean thoroughly with a strong, hot soapy water
solution. Rinse with clean water and allow to
completely dry. NEVER USE OVEN CLEANER.
Cleaning the drip tray
The drip tray (for fat collection) must be cleaned after
every use, as fat is flammable and could cause a fire if
not kept clean, which could lead to injury or damage to
property.
Caution: “Electrode on burner can be bent”
The electrode on the burner can be bent or may snap
off during cleaning.
Possible consequences:
Burner no longer lights.
Safety measures:
Take special care when cleaning the area around
the burner.
Cleaning the gas system
If necessary, the gas outlet jet (under the right hand
side shelf) and the venturi hole can be cleaned with a
pipe cleaner, or use an opened up paper clip. All other
parts through which gas is passed may only be
cleaned by an expert.
Never dismantle the valve!
Maintenance
Perform maintenance checks at regular intervals. The
intervals will depend on how often the barbecue is
used and the environment to which it is exposed.
Maintaining the barbecue
Check to ensure that all parts of the barbecue
are present and assembled (visual check).
Check to ensure that all connections are present
and securely fastened; tighten if necessary.
Maintaining the gas system
The gas system needs to be checked every time a gas
bottle is connected (see section “Connecting and
disconnecting the gas bottle”).
If necessary, ensure to replace the hose to meet with
national requirements.
Environment information and disposal measures
To dispose of the barbecue, disassemble it into its
individual parts. Recycle the metal and plastic parts.
