MasterChef TF2201804-MC User manual

Outdoor 3-In-1 Cooker
Product no. 085-3250-4 (TF2201804-MC)
USER MANUAL
TM
Toll-free: 1-855-803-9313
Read this manual thoroughly before using and save it for future reference.

2
Table of Contents
Warnings 2
Product Diagram 6
Component List 7
Hardware List 8
Assembly Instructions 9
LP Tank 15
18
Lighting Instructions 19
Warnings
•To the installer or person assembling this appliance: Leave this manual with this appliance for future reference.
•This instruction manual contains important information necessary for the proper assembly and safe use
of the appliance.
•Read and follow all warnings and instructions before assembling and using the appliance.
•Follow all warnings and instructions when using the appliance.
•Keep this manual for further reference.
SAFETY SYMBOLS:
The symbols and boxes shown below explain what each heading means.
Read and follow all of the messages found throughout the manual.
DANGER: Indicates an imminent hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
Leak Testing
Cleaning and Maintenance 21
Operation 24
Cooking Guide 26
Troubleshooting 30
32
Limited Warranty

3
TM
DANGER:
If you smell gas:
1. Shut o gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odour continues, keep away from the appliance and immediately call your gas supplier or fire
department.
Failure to follow these instructions could result in fire or explosion which could cause property
damage, personal injury or death.
Warnings
DANGER:
1. Never operate this appliance unattended.
2. Never operate this appliance within 10’ (3.0 m) of any structure, combustible material or other
gas cylinder.
3. Never operate this appliance within 25’ (7.5 m) of any flammable liquid.
4. If a fire should occur, keep away from the appliance and immediately call your fire department.
Do not attempt to extinguish an oil or grease fire with water.
Failure to follow these instructions could result in fire or explosion which could cause property
damage, personal injury or death.
WARNING:
This appliance is not intended for commercial use.
WARNING:
1. Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other
appliance.
2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
3. Do not attempt to repair or alter the hose/valve/regulator for any “assumed” defect. Any
modification to this assembly will void your warranty and create the risk of a gas leak and fire. Use
only authorized replacement parts supplied by manufacturer.
DANGER:
•The safety relief valve on the LP tank could activate releasing gas and cause an intense fire with
risk of death or serious injury. Therefore, follow instructions bulleted below exactly.
(a) Do not store a spare LP-gas cylinder under or near this appliance.
(b) Never fill the cylinder beyond 80 percent full.
•If the instructions in (a) and (b) are not followed exactly, a fire causing death or serious injury
may occur.

4
Warnings
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
WARNING:
•This appliance is for OUTDOOR USE ONLY. DO NOT use in building, garage, shed, breezeway, or
any other enclosed area.
•This appliance is not intended to be installed in or on a boat. This appliance is not intended to be
installed in or on recreational vehicles.
•This appliance must not be used on or under any apartment or condominium balcony or deck.
•If stored indoors, detach and leave cylinder outdoors.
•DO NOT leave appliance unattended. Keep children and pets away from the appliance at all times.
•The use of alcohol, prescription or non-prescription drugs may impair the user’s ability to properly
assemble or safely operate the appliance.
•Never move the appliance when in use. Allow the cooking vessel to cool before moving or storing.
•Always keep the fuel supply hose away from any heated surface.
•It is for household use only. DO NOT use this appliance for anything other than its intended purpose.
•This appliance is not intended for and should never be used as a heater.
•Never use natural gas in a unit designed for liquid propane gas.
•Leak tests must be conducted prior to each use.
•Appliance is hot when in use.
To avoid burns:
DO NOT attempt to move the appliance.
Wear protective gloves or oven mitts.
DO NOT touch any hot surfaces.
DO NOT wear loose clothing or allow hair to come in contact with appliance.
•This appliance will be hot during and after use. Use insulated oven mitts or gloves for protection
from hot surfaces or splatter from cooking liquids.
•When cooking with oil or grease, have a type BC or ABC fire extinguisher readily available. In the
event of an oil or grease fire do not attempt to extinguish with water. Immediately call the FIRE
DEPARTMENT. A type BC or ABC fire extinguisher may, in some circumstances contain fire.
•When cooking, the appliance must be on a level, stable noncombustible surface in an area clear of
combustible material. An asphalt surface is not acceptable for this purpose.

5
TM
Warnings
WARNING:
•Use your appliance OUTDOORS in a well-ventilated
space away from dwellings or other buildings to
prevent dangers associated with gas accumulation
and toxic vapors. The appliance should be situated
at least 10 feet (3.05 m) from buildings. Not
adhering to these clearances will prevent proper
ventilation and may increase the risk of a fire and/or
property damage, which could also result in personal
injury.
•Maintain a minimum clearance of 10 feet (3.05 m)
between all sides of the appliance, deck railings,
walls or other combustible material. The outdoor cooking gas appliance must not be used under
overhead combustible constructions. DO NOT obstruct the flow of combustion/ventilation air.
WARNING:
•Never move the appliance when in use.
•Never operate appliance with LP cylinder out of correct
position specified in assembly instructions.
•Always close LP cylinder valve and remove coupling nut
before moving LP cylinder from specified operating
position.
•Avoid bumping of or impact with the appliance to prevent
spillage or splashing of hot grease.
•Grease collected in grease tray is hot. Do not remove the
grease tray from the appliance until it is cool to touch.
•Keep appliance area clear and free from combustible
materials, gasoline and other flammable vapors and liquids.
•Keep LP cylinder at a minimum distance of 24 inches (61 cm) away from appliance at all times.
WARNING: Hose is a trip hazard
24” (61 cm)
Keep the fuel supply hose away
from any heated surface
10’ (3 m)
10’ (3 m)
CAUTION:
•Open lid while lighting.
•It is not possible to put out grease fires by closing the lid, as the appliance is well ventilated for
safety reasons.
•Do not use water on a grease fire. Personal injury may result. If a grease fire develops, turn knob
and LP cylinder o.
•Do not leave appliance unattended while burning o food residue. If appliance has not been
regularly cleaned, a grease fire can occur that may damage the product.

6
Product Diagram
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
1
19
2
15
3
16
4
5
8
9
10
13
7
12
11
6
14
18
17
15
3

7
TM
Component List
Key No. Description Qty.
1 1
2 Body Assembly 1
3 4
4 Lid Handle, Silver 1
5 2
6 Basket 1
7 1
8 Front Left Leg 1
9 1
10 Control Panel And Regulator Assembly 1
11 3
Lid Assembly
Match Hole Cover
Rear Legs
Grease Tray
Front Right Leg
Flame Tamer
12 Grease Collector 1
13 1
Meat Thermometer
14 Lifting Hook 1
15 2
16 Wood Chips Box 1
17 1
Fryer Handle, Black
Hanger
18 Rack 1
19 1
Thermometer

8
Hardware List
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
Part No. Description Diagram Qty.
A M6 x 12 mm Bolt 24
Tools required (not included):
Cross-head screwdriver / Adjustable wrench
BM6 Step Bolt 4
C Hinge Pin 2
DCotter Pin 2
E Heat Insulation Washer 4

9
TM
Assembly Instructions
Step 1
Step 2
Attach the Rear Legs (5), Front Left
Leg (8) and Front Right Leg (9) to
the Body Assembly (2) by using
12 pcs M6 x 12 mm Bolt (A).
5
A
8
2
9
10
A
Attach the Control Panel And
Regulator Assembly (10) to the
front legs by using 4 pcs
M6 x 12 mm Bolt (A) as shown.

10
Assembly Instructions
Step 3
Step 4
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
Attach the Orifice Bracket to the
bottom of the body assembly by
using 2 pcs M6 x 12 mm Bolt (A)
as shown.
Make sure that the valve outlet
(orifice) is inserted UPRIGHT
into the burner port.
A
Correct Position Incorrect Position
Insert the terminal of the ignition
wire into the connector of the
burner valve.

11
TM
Assembly Instructions
Step 5
Step 6
Attach the Match Hole Covers (3)
to the body assembly by using
4 pcs M6 Step Bolt (B).
Make sure that the covers can
swing smoothly.
Attach the Fryer Handle, Black (15)
to the body assembly by using
4 pcs M6 x 12 mm Bolt (A).
B
3
15
A

12
Assembly Instructions
Step 7
Step 8
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
Attach the Lid Assembly (1) to
the body assembly by using
2 pcs Hinge Pin (C) and 2 pcs
Cotter Pin (D).
1
DC
Attach the Lid Handle, Silver (4)
to the lid by using 2 pcs
M6 x 12 mm Bolt (A) and 4 pcs
Heat Insulation Washer (E).
Then unscrew the nut and washer
from the Thermometer (19) and
fix it to the lid with the washer and
nut again.
19
A
E
4

13
TM
Assembly Instructions
Step 9
Step 10
Position the Grease Collector (12)
into the fryer body and make sure
that it is fixed by 4 guiding pins in
the fryer body as shown.
Then put the Wood Chips Box (16)
in the opening at the front of the
fryer body.
Insert the Grease Tray (7) into the
sliding slots at the bottom of the
body assembly as shown.
We suggest using a disposable
aluminum tray as a liner.
7
12
12
16

14
Assembly Instructions
Step 11
Step 12
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
Place the Flame Tamer (11)
into the guiding pins on the
grease collector as shown.
Place the Basket (6) into the
fryer body (on the grease
collector) as shown.
11
11
12
12
6
6

15
TM
Assembly Instructions
Step 13
Your unit is fully assembled!
Make sure to read and follow the User
Manual before using this appliance.
When transporting or storing the
appliance without the tank attached,
hook the regulator onto the handle to
prevent damage to regulator.
LP Tank
USE AND INSTALLATION OF LP GAS CYLINDER (PROPANE TANK)
BEFORE INSTALLING:
The installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and
Handling Code, B149.2, or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV
Series, Recreational Vehicle Code, as applicable.
BEFORE EVERY USE:
Make sure to inspect the hose for leaks, cuts, wear, abrasion, or damage of any sort before using this appliance. If any
damage is apparent, the hose must be replaced with a new hose specified by the manufacturer before further use.
LP GAS CYLINDER
The LP (liquid propane) cylinder specifically designed to be used with this unit MUST have a 20 lb. (9.1 kg) capacity
with a Q.C.C. Type 1 cylinder valve and an overfilling protection device (OPD). Only use LP cylinders with this type
of valve.

16
LP Tank
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
LP CYLINDER VALVE REQUIREMENT:
•Purchase LP cylinders only with these required measurements: 12” (30.5 cm)
(diameter) x 18” (45.7 cm) (tall) with 20 lb. (9.1 kg) capacity maximum.
•Q.C.C. Type 1 outlet compatible with regulator or appliance.
•Safety relief valve.
•UL-listed Overfill Protection Device (OPD). This OPD safety feature is identified
by a unique triangular hand wheel. Use only tanks equipped with this type of valve.
•LP cylinder must be arranged for vapor withdrawal. The LP cylinder must
be constructed and marked in accordance with the Specifications for
LP-Gas Cylinders of the U.S. Department of Transportation (D.O.T.) or
the National Standard of Canada CAN/CSA – B339, Cylinder, Spheres
and Tubes for Transportation of Dangerous Goods; and Commission of
Dangerous Goods; as applicable.
•The LP cylinder must include a collar to protect the cylinder valve.
•If the outdoor cooking gas appliance is not in use, the gas must be
turned o at the supply cylinder(s).
•The LP cylinder must be stored outdoors out of the reach of children
and MUST NOT be stored in a building, garage, shed, breezeway, or any
other enclosed space.
•Storage of an outdoor cooking gas appliance indoors is permissible
ONLY if the cylinder is disconnected and removed from the outdoor
cooking gas appliance.
•The cylinder should ALWAYS be put in an upright position.
OPD Hand Wheel
LP Tank Valve
Safety Cap
Retainer Strap
DANGER:
•DO NOT connect this appliance to an existing #510 POL cylinder valve with left-hand threads.
The Type 1 valve can be identified with the large external threads on the valve outlet.
•DO NOT connect to a propane cylinder exceeding its capacity.
•DO NOT connect to a cylinder that uses any other type of valve connection device.
•Never store a spare LP gas cylinder under or near your grill. This could cause pressure to be expelled
through the vapor relief valve resulting in fire, explosion, or severe personal injury, including death.
•Keep the ventilation opening(s) of the LP gas cylinder enclosure free and clear from obstructions
and debris.
•DO NOT insert any foreign objects into the valve outlet. Damage to the valve outlet could result.
A damaged valve outlet can cause a leak, possibly resulting in explosions, fire, severe bodily harm,
or death.

17
TM
LP Tank
WARNING:
FILLING THE LP GAS CYLINDER
•Allow only qualified LP gas dealers to properly fill or repair your LP cylinder.
•DO NOT allow the cylinder to be filled beyond 80% capacity. Over-filled tanks can create a
dangerous condition. Over-filled tanks can build up pressure and cause the relief valve to expel
propane gas vapors. The vapor is combustible and if it comes in contact with a spark source or
flame an explosion causing severe burns, bodily harm, or death could occur.
•Always use a safety cap when the grill is not connected to a cylinder.
•If you exchange a cylinder with a qualified exchange program, be sure the cylinder has a Type 1
valve and an over-fill prevention device (OPD).
Cylinder Valve / Knob
External Male Threads
Regulator Assembly
Coupling Nut
CONNECTION PROCEDURES
1. Make sure the cylinder valve is closed (turn valve clockwise until tight).
2. Check the cylinder valve to ensure it has the proper external male threads.
3. Make sure all burner valves are turned OFF.
4. Inspect valve connections, port, and regulator assembly. Look for any
damage or debris. Remove any debris. Inspect the hose for damage. Never
attempt to use damaged or obstructed equipment. Contact your local LP
gas dealer for repair.
5. When connecting the regulator assembly to the valve, hand tighten the
quick coupling nut clockwise to a complete stop. Do not use a wrench to
tighten. Use of a wrench may damage the quick coupling nut and result in
a hazardous condition.
6. Open the cylinder valve fully (counterclockwise). Use a soapy water
solution to check all connections for leaks (a Leak Test) before
attempting to light the appliance (see P.18). If a leak is found, turn
the cylinder valve o and do not use the appliance until your LP gas dealer
can make repairs.
TO DISCONNECT THE LP CYLINDER:
1. Turn the burner valve o.
2. Turn the cylinder valve o fully (turn clockwise to stop).
3. Detach the regulator assembly from the cylinder valve by turning the quick coupling nut counterclockwise.
CAUTION:
•When installing LP cylinders, the pressure regulator and hose supplied by the manufacturer MUST
be used with the appropriate cylinder. Replacement regulators and hoses need to be specified by
the manufacturer of this appliance.
•Place the dust cap on the cylinder valve outlet whenever the cylinder is not in use. Only install the
type of dust cap on the cylinder valve outlet that is provided with the cylinder. Other types of caps
or plugs may result in leakage of propane.

18
Leak Testing
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
GENERAL
Although all gas connections on the appliance are leak tested at the factory prior to shipment, a complete gas tightness check
must be performed at the installation site due to possible mishandling in shipment, or excessive pressure unknowingly being
applied to the unit.
Periodically check the entire system for leaks following the procedures listed below. Before using your appliance you must
check for leaks.
BEFORE TESTING
Make sure that all packing material is removed from the appliance.
Make a soap solution of one part liquid detergent and one part water. You will need a spray bottle, brush, or rag to apply the
solution to the fittings. For the initial leak test, make sure the LP cylinder is full.
WARNING:
•DO NOT SMOKE WHILE CONDUCTING LEAK TEST.
•NEVER PERFORM LEAK TEST WITH AN OPEN FLAME.
•If it is evident that there is excessive abrasion, wear or the hose is cut, it must be replaced prior to
the appliance being put into operation. The replacement hose must be specified by the
manufacturer.
TO TEST
1. Make sure the control valve is in the OFF position then turn
on the gas supply.
2. Check all connections from the gas cylinder, LP gas regulator
and supply valve up to and including all connections to the
pipe that go to the burner. The following are the points where
the soap-water mixture is to be applied. Soap bubbles will
appear if a leak is present.
A. Supply tank (cylinder) weld.
B. Tank valve to cylinder.
C. Tank valve knob.
D. Regulator coupling nut to tank valve.
E. Regulator to regulator coupling nut.
F. Regulator connections to gas supply hoses.
G. The full length of gas supply hose.
H. Burner valve stem cap.
I. Hose connection to burner valve.
J. The full length of corrugated tube.
3. If a leak is present, immediately turn o the gas supply and tighten the leaky fittings.
4. Turn the gas back on and recheck.
5. Should gas continue to leak from any of the fittings, turn o the gas supply and contact the customer service department.
Watch For Bubbles
C
D
E
A
H
B
F
G
I
J

19
TM
Lighting Instructions
Step Procedure Illustration
LIGHTING INSTRUCTIONS
Push and turn the control knob slowly all the
way to “ON” until a clicking sound is heard.
Burner should light immediately.
Fully open the LP tank valve.
4
1
2
3
5
6
Read all instructions before lighting.
Make sure the control knob is in the “OFF”
position.
If ignition does NOT occur in 5 seconds, turn
the control knob o, wait 5 minutes to allow
gas to dissipate. Repeat the lighting procedure.
Open the lid before lighting.
ON
OFF
WARNING:
•Inspect the gas supply hose prior to turning the gas ON.
•If there is evidence of cuts, wear, or abrasion, the hose must be replaced prior to use.
•Do not use the appliance if the odor of gas is present.
•Only the pressure regulator and hose assembly supplied with the unit should be used.
•Perform the “LEAK TEST” according to the instructions before operating the appliance.
•ALWAYS keep your face and body away from the top opening of main body while lighting.
SEASONING YOUR UNIT
We suggest seasoning the unit prior to first use. Apply a light coating of vegetable oil with a paper towel to the
interior walls and turn on high for 1 hour with the lid closed.
ON
OFF

20
Lighting Instructions
Product no. 085-3250-4 (TF2201804-MC) |
Contact us: 1-855-803-9313
Step Procedure Illustration
DANGER:
Do not lean over appliance while lighting.
CAUTION:
If burner does not light OR if burner flame is accidentally extinguished, turn knob to “OFF”, wait 5
minutes, and try again. If the burner does not ignite with valve open OR if burner flame is accidentally
extinguished after lighting, gas will continue to flow out of the burner and could accidentally ignite
with risk of injury.
7To turn burner o, turn the control knob
clockwise until it locks in the “OFF” position.
ON
OFF
8
MATCH-LIGHTING
Swing the match hole cover to expose the match
lighting hole. Place lit match into the match lighting
hole of the appliance as shown below. Make sure lit
match is placed inside the hole and near the burner.
Push in and turn the control knob slowly all the way
to “ON”. Make sure that the burner lights and stays
lit. Once lit, swing the match hole cover back to its
original position. Caution: Cover may be hot.
Holes in Burner
Good Bad
Yellow
Blue
Blue
Yellow
BURNER FLAME CHECK
Light burner then rotate regulator knob from HIGH to LOW. You should see a
smaller flame in the LOW position than in HIGH. Always check flame prior to
each use. The air damper mounted on the back of your burner helps to control
the amount of primary air that mixes with the LP gas. A blue flame with little
or no yellow flame provides the best heat. Adjust the air damper by turning it
clockwise or counter-clockwise until the desired flame is achieved.
