Matrix G3S22 User manual

G3 STRENGTH
G3-S22 REAR DELT / FLY
MATRIX FITNESS | 1600 LANDMARK DRIVE COTTAGE GROVE WI 53527 USA
To l l Free 866.693.4863 matrixfitness.com Fax [phone]
PART # 0000000000
REV. 1.1
ACTION FREQUENCY
Clean Upholstery Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips As Needed
Lubricate Guide Rods As Needed
Upholstery & Grips should be cleaned with a non-ammonia based cleaner (like Simple Green) or a mild soap and water.
Guide rods should be lubricated with Teflon based lubricant. Apply the lubricant to a cotton cloth and then apply up and
down the guide rods.
MAINTENANCE CHECKLIST
PRODUCT SPECIFICATIONS
TECH SPECS
Overall dimensions 54”L X 37”W x 68”H (137 cm x 94 cm x 173 cm)
Weight 647.5 lbs (294 kg)
Shipping weight 687 lbs (312 kg)
WARRANTY (Valid in USA only)
Frame (not coatings) 10 years
Structural parts 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specified 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX Fitness Systems products to instruct all individuals, whether they
are the end user or supervising personnel on proper usage of the equipment.
It is recommended that all users of MATRIX Fitness Systems exercise equipment be informed of the following information
prior to its use.
PROPER USAGE
Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative that MATRIX
Fitness Systems equipment be used properly to avoid injury.
Keep hands and feet clear at all times from moving parts to avoid injury.
CHECK FOR DAMAGED PARTS
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts supplied by
your country’s local MATRIX Fitness Systems dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important information.
If unreadable or missing, contact your MATRIX Fitness Systems dealer for a replacement.
3. SECURING EQUIPMENT: All equipment MUST be secured to the floor to stabilize and eliminate rocking or tipping over.
This must be performed by a licensed contractor.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping
your liability to a minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
MATRIX Fitness Systems dealers will provide service and maintenance training at our corporate facility upon request.
WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO
AVOID INJURY!
1. Never allow children on freeweight or bench equipment. Teenagers must be supervised at all times while using
this equipment.
2. All warnings and instructions should be read and proper instruction obtained prior to use.
3. Cease exercise if you feel faint or dizzy. Obtain a medical exam before beginning an exercise program
4. Keep body, hair, clothing and fitness accessories free and clear of all moving parts.
5. Inspect the machine before use. DO NOT use machine if it appears damaged or inoperable.
6. This equipment should only be used in supervised areas where access and control are regulated by the owner.
S22_reardeltfly_r1.1.indd 1 12/13/10 9:37 AM

G3-S22 REAR DELT / FLY
UNPACKING G3-S22 REAR DELT / FLY
Thank you for purchasing a MATRIX Fitness product. This machine is an EN957-1 and EN957-2 complaint Class S product. Your
MATRIX G3-S22 REAR DELT / FLY is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact
packaging of the machine. Prior to assembly, confirm all the components by matching them with the exploded diagrams. Carefully
unpack the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
The weight of the G3-S22 REAR DELT / FLY is 647.5 lbs. (294 kg). To avoid injury to yourself and prevent damage to the frame
components, be sure to have proper assistance removing the frame pieces from this box. Please be sure to install the equipment
on a stable base, properly level the machine and leave at least two feet of clearence to enter and exit the machine. Maximum user
weight for this machine is 350 lbs. (159 kg).
INCLUDED TOOLS REQUIRED FOR ASSEMBLY
17MM Open-End Wrench
3MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench
5MM L-Shaped Allen Wrench
6MM L-Shaped Allen Wrench
8MM L-Shaped Allen Wrench
10MM L-Shaped Allen Wrench
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0mm 10 20 30 40 50 60 70 80 90 100 1
10 120 130 140 150 160
Step 1
Frame Detail
Item QtyDescription
C33
12
Washer (M10)
C20
Arc-at Washer
Lock Washer (M10)
Allen Head Cap Screw (M10x25L)
6
12
18
C31
C32
C33
C32
C33
C33
C31
C31
C31
C33
C32
C32
C33
C20
C20
C20
C33
AC1
AB1
Step 2
Input Detail
DescriptionItem Qty
axle
Allen Head Cap Screw (M10x85L)
Lock Washer (M10)
nylon nut (M10)
D22
F30
F19
C31
2
2
2
Washer (M10) 2C20
Z20 Wavy Washer 2
2
F19
F30
C31
F19
D22
D22
C20
AD4
AD3
Z20
Z20
Step 3
C29 Screw (M10 X 25L)
Item Description Qty
7
C29
C29
Step 4
DescriptionItem Qty
10
K13
25
40
K07
280
295
250
265
205
235
220
175
190
100
160
145
130
115
70
85
55
Selector Pin
Top Weight
10
Guide Sleeve
Rubber Stack Cushions
E-Clipper (E-15)K13
K07
4
2
Step 5
Belt Fixer
Screw (M5x35L)
Item
F18
F21
F20
F13
Description
Lock Washer (M5)
4
8
8
8
Qty
Flat Washer (M5)
1
F08 Belt
F18
F21
F20 F13
F21
F18
F13
F20
F08
Step 6
Accessory Detail
AB1
B18
Q05
Q06
Q05
Q06
Front Shield
Q06 Q05
Rear Shield
B43
Q02
B43
B43
Upper Cover
B33
B33
Towel / Water
Bottle Holder
Z10
Description Panel
國際線
Item
B18 2
B33
6B43 Screw (M4 X12L)
6Washer (M4)
Upper coverQ02 2
Screw (M8 X30L)
12
Description Qty
Q06 12
Z10 2
Q06
Q05 6
Rubber Tip Weight Shield Bolt
Rubber Shield Spacer
Rubber Tip Weight Shield Bolt
Small Cap Head Bolt(M8x18L)
6
Q05 Rubber Shield Spacer
