Matrix MAGNUM SERIES User manual

MATRIX FITNESS | 1600 LANDMARK DRIVE COTTAGE GROVE WI 53527 USA
Toll Free 866.693.4863 | matrixfitness.com | Fax [phone]
PART # 0000000000
REV. 2.1
MAGNUM SERIES
A680 BREAKER OLYMPIC DECLINE BENCH
PROPER USAGE
1. Do not exceed weight limits of the exercise device.
2. If applicable, set safety stops to appropriate height.
3. If applicable, adjust seat pads, leg pads, foot pads, range of motion
adjustment, or any other type of adjustment mechanisms to a
comfortable start position. Make certain that the adjusting mechanism is
fully engaged to prevent unintentional movement and to avoid injury.
4. Sit on bench (if applicable) and get into appropriate position for exercise.
5. Exercise using no more weight than you can safely lift and control.
6. In a controlled manner, perform exercise.
7. Return weight to its fully-supported start position.
MAINTENANCE CHECKLIST
ACTION FREQUENCY
Clean Upholstery * Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips * As Needed
Lubricate Guide Rods † As Needed
* Upholstery & Grips should be cleaned with a mild soap and water
or a non-ammonia based cleaner.
† Guide rods should be lubricated with Teon based lubricant. Apply the
lubricant to a cotton cloth and then apply up and down the guide rods.
PRODUCT SPECIFICATIONS
TECH SPECS
Maximum User Weight 182 kg / 400 lbs.
Maximum Training Weight 272 kg / 600 lbs.
Product Weight 186 kg / 410 lbs.
Overall Dimensions (L x W x H)* 71 x 257 x 114 cm /
28" x 101" x 45"
Weight Horn Diameter
(Weight Plate Storage) 47.63 mm / 1.875”
* Ensure a minimum clearance width of 0.6 meters (24”) for access to and pas-
sage around MATRIX strength equipment. Please note, 0.91 meters (36”) is
the ADA recommended clearance width for individuals in wheelchairs.
WARRANTY
Valid in North America only
Frame (not coatings) * 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specied 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
Accessories 6 months
* Frame is dened as the welded metal base of the unit and does not include
removable parts.
Product specications subject to change without notice.
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX products to instruct all individuals, whether
they are the end user or supervising personnel on proper usage of the equipment.
It is recommended that all users of MATRIX exercise equipment be informed of the following
information prior to its use.
Do not use any equipment in any way other than designed or intended by the manufacturer. It is
imperative that MATRIX equipment be used properly to avoid injury.
INSTALLATION
1. STABLE AND LEVEL SURFACE: MATRIX exercise equipment must be installed on a stable
base and properly leveled.
2. SECURING EQUIPMENT: Manufacturer recommends that all stationary MATRIX
strength equipment be secured to the oor to stabilize equipment and eliminate
rocking or tipping over. This must be performed by a licensed contractor.
3. Under no circumstances should you slide equipment across the oor due to risk of tipping.
Use proper materials handling techniques and equipment recommended by OSHA.
All anchor points must be able to withstand 750 lbs. (3.3 kN) pull-out force.
MAINTENANCE
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only
replacement parts supplied by your country’s local MATRIX dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They
contain important information. If unreadable or missing, contact your MATRIX dealer for a
replacement.
3. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating
equipment as well as keeping your liability to a minimum. Equipment needs to be inspected
at regular intervals.
4. Ensure that any person(s) making adjustments or performing maintenance or repair of any
kind is qualied to do so. MATRIX dealers will provide service and maintenance training at
our corporate facility upon request.
ADDITIONAL NOTES
This equipment should only be used in supervised areas where access and control is specically
regulated by the owner. It is up to the owner to determine who is allowed access to this training
equipment. The owner should consider a user’s: degree of reliability, age, experience, etc.
This training equipment meets industry standards for stability when used for its intended purpose
in accordance with the instructions provided by the manufacturer.
This training equipment is in compliance with EN 957-1 and the relevant portions of EN 957-2
and EN 957-4.
WARNING
Plate-loaded / Free Weight
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS
EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID
INJURY!
1. Keep children under the age of 14 away from this
strength training equipment. Teenagers must be
supervised at all times while using this
equipment.
2. This equipment is not intended for use by persons
with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the equipment by a
person responsible for their safety.
3. All warnings and instructions should be read and
proper instruction obtained prior to use. Use this
equipment for its intended purpose ONLY.
4. Inspect the machine before use. DO NOT use
machine if it appears damaged or inoperable.
5. Do not exceed weight capacity of this equipment.
6. ALWAYS use a spotter if using free weights.
7. Balance the weight applied to this equipment
and/or any barbell. Where applicable, use
retention devices to retain weight discs.
8. Injuries to health may result from incorrect or
excessive training. Cease exercise if you feel faint
or dizzy. Obtain a medical exam before beginning
an exercise program.
9. Keep body, clothing, hair, and fitness accessories
free and clear of all moving parts.
10. Adjustable stops, where provided, must be used
at all times.
11. When adjusting any adjustable mechanism (stop
position, seat position, pad location, range of
motion limiter, pulley carriage, or any other type),
make certain that the adjustable mechanism is fully
engaged prior to use to prevent unintended motion.
12. Manufacturer recommends that this equipment be
secured to the floor to stabilize and eliminate
rocking or tipping over. Use a licensed contractor.
13. If equipment is NOT secured to floor: NEVER allow
resistance straps, ropes or other means to be
attached to this equipment, as this may result in
serious injury. NEVER use this equipment for
support during stretching, as this may result in
serious injury.
14. DO NOT REMOVE THIS LABEL. REPLACE IF
DAMAGED OR ILLEGIBLE.
MX19_Magnum_A680_OM_r2_1.indd 1 7/15/19 1:17 PM

MAGNUM SERIES (A680) BREAKER OLYMPIC DECLINE BENCH
UNPACKING MAGNUM (A680) BREAKER OLYMPIC DECLINE BENCH
Thank you for purchasing a MATRIX Fitness product. Your MAGNUM SERIES (A680) BREAKER OLYMPIC DECLINE BENCH is inspected before it is packaged.
It is shipped in multiple pieces to facilitate the compact packaging of the machine. Prior to assembly, conrm all the components by matching them with the
exploded diagrams. Carefully unpack the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
To avoid injury to yourself and prevent damage to the frame components, be sure to have proper assistance removing the frame pieces from this box. Please be
sure to install the equipment on a stable base, properly level the machine and leave at least two feet of clearance to enter and exit the machine.
TOOLS REQUIRED FOR ASSEMBLY (not included)
3MM L-Shaped Allen Wrench 10MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench Phillips Screwdriver
5MM L-Shaped Allen Wrench 8MM Open-End Wrench
6MM L-Shaped Allen Wrench 17MM Open-End Wrench
8MM L-Shaped Allen Wrench Guide Rod Lubrication
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0mm 10 20 30 40 50 60 70 80 90 100 110 120 130
During each assembly step, ensure that ALL nuts and bolts are in place
and partially threaded. It is recommended you complete the full assembly
of your unit before completely tightening any ONE bolt.
IMPORTANT
H14x2
B50x2 C25x4
Z10x4
Z12x2
Z11
Z04
Z02x3
Z03x3
Z06x2
Z02x4
Z02x8
Z01x8
STEP 1
Frame Detail
Hardware
Description Qty
Z01
Z02
Z03
Z10
H14
B50
C25
Z11
Z04
Z06
Z12
Screw (M10x20L)
Flat Washer (M10)
Screw (M10x70L)
Screw (M10x1.5Px40L)
Screw (M8x1.25Px25L)
Flat Washer (M8)
Screw (M6x1.0Px4L)
Flat Washer (M10)
Screw (M10x25L)
Nut Nylon (M10)
Screw (M10x1.5Px125L)
8
15
3
4
2
2
4
1
1
2
2
8xZ01
8xZ02
STEP 3
Optional Parts Assembly
Hardware
Description Qty
Z01
Z02
Bolt (M10x20L)
Flat Washer (M10)
8
8
Z06x4
Z02x8
Z10x4
Z38
Z38
STEP 2
Frame Detail
Hardware
Description Qty
Z10
Z02
Z06
Z38
Flat Washer (M10)
Screw (M10x40L)
Nylon Nut (M10)
Adjustment Washer
4
8
4
3
* Use Z38 only when needed for leveling
breaker arms
