matson Workshop MW15 User manual

8
Matson Automotive Industries Pty Ltd
100 Links Road
StMary’s NSW 2760
+ 61 2 98333 444
www.matson.com.au
[email protected]
Warranty Card
Name:
Company Name:
Address:
Ph: Fax:
E-mail:
Purchased From:
Date Purchased:
Product Purchased: (Model No.)
Return Authority Number:
Please Note: Proof of purchase will be required for all warranty
claims.
**Refer to the full warranty statement at www.matson.com.au
1

2
• Explosive gases may escape from the battery during charging. Prevent
flames and sparks. Ensure area is well ventilated.
• Before charging ensure you have read the instruction manual in full.
• This appliance is for USE INDOORS. Do not expose to rain or excessive
dust.
• For charging 12 volt batteries only.
• Disconnect from 240Volt supply before making or disconnecting
connections to the battery.
• This appliance requires an earthed 240Volt mains supply.
• This appliance is not for use with non-rechargeable batteries.
• Never charge a frozen battery.
• In the event of the AC cord becoming damaged it must be replaced by a
qualified electrician.
• Corrosive gasses may escape during the charging process, ensure charger
is placed well away from battery.
• This appliance is intended for use by responsible persons and should not
be operated by children.
• Always check battery manufacturers specifications on charge rates and
voltage prior to charging.
7
LED INDICATORS:
Power indicator ON Charger connected to power source
Faulty indicator ON Battery is faulty, have checked by authorised
technician
Lead Acid Indicator ON Charger is set to Lead Acid type
Gel / AGM Indicator ON Charger is set to Gel/AGM type
Calcium Indicator ON Charger is set to Calcium type
Charging LED is ON Charger is operating normally in charge mode
Fully Charged Led is ON Battery is fully charged and charger is in float
mode
5A LED is ON Charger is set to 5Amp output
10A LED is ON Charger is set to 10Amp output
15A LED is ON Charger is set to 15Amp output

6 3
FEATURES:
7 Stage Automatic Charging
The Matson WORKSHOP MW15 is fully automatic 7 stage pulse battery
charger.
Automatic chargers prevent your battery from being overcharged and
consequently becoming damaged. The WORKSHOP MW15 can be
connected to the battery indefinitely.
The WORKSHOP MW15 charger can be programmed for different battery
types including GEL, AGM, Deep Cycle, Sealed Lead Acid and Calcium
Batteries and has three Amperage settings, 5/10and 15Amp..
The WORKSHOP MW15 has a unique inbuilt diagnosis program. On con-
nection to the battery the charger will automatically diagnose the batteries
condition and change its charge rate and charge stages accordingly. This
function will optimise charging conditions and extend battery life.
• Solid aluminium housing
• Micro-chip monitoring and control
• Electronic touch-button controls
• Chemistry selection: Sealed lead acid / GEL / Deep Cycle / Calcium
• Cell equalisation technology
• Temperature variable output
• High frequency charging for efficiency
• Polarity protection. Prevents output leads from sparking due to reverse
connection or short circuit.
• Over temperature protection. Fan cooled internals with set cut off point for
additional safety.
• Over current protection. Charger will automatically reduce current for
optimum battery condition.

Model No: MW15
Type 7 stage
Input 240VAC 50Hz
Output Voltage 12Volt DC
Output current 5/10/15Amp
Selectable / Variable
Minimum Start Volt 1.5Volt
CHARGE CONTROL
Desulphation High Frequency Pulse Charge
(DEPENDENT ON DIAGNOSIS)
Soft Start Yes
Bulk Charge 14.1V (Gel)
14.7V (SLA)
15.1V (Calcium)
Absorption Constant voltage with automatic amperage control
Equalization Automatic
Analysis Automatically detects faulty batteries. Led warning and
audible alarm
Recondition Constant current automatically varied
14.5v (Gel), 15.2V (SLA), 15.6V (Calcium)
Float 13.7V (SLA), 13.7V (Calcium), 13.3V (Gel)
BATTERY RANGE
Deep Cycle 17 ~300Ah
Automotive 150 ~950CCA
4 5
CHARGING INSTRUCTIONS:
• Check liquid level in battery.
Before attempting to charge the battery remove vent caps and check liquid level (not re-
quired for sealed lead acid and maintenance free batteries). Top up with Matson
distilled water if need and replace vent caps
• Charging a battery not in a vehicle:
Ensure 240Volt power supply is OFF.
Connect black (negative) charging clamp to negative battery post.
Connect red (positive) charging clamp to positive battery post.
Turn on 240Volt power source.
Set battery type. (Chemistry selection)
Select charge rate. (Amperage output)
• Charging a battery in a vehicle:
Ensure 240Volt power supply is OFF.
Position input cable and output cable away from risk ie: fans, bonnet or door
Most vehicles in Australia are negative earth (black cable to chassis of vehicle)
In this case connect red (positive) charge clamp to positive terminal of battery
Connect black (negative) charge clamp to chassis of vehicle away from any moving
parts
Turn on 240Volt power source
Set battery type. (Chemistry selection)
Select charge rate. (Amperage output)
• Disconnecting the charger:
Ensure 240Volt mains supply is turned off and removed from power socket
Remove black (negative) charger clamp from battery post or vehicle chassis first
Remove red (positive ) charger clamp from battery post next.
