Maxon MCB-30 User manual

MCB-30
Compact 40 Channel
Mobile CB Radio
OWNER'S MANUAL
English/Spanish

TABLE OF CONTENTS
Product Description 1
FCC Regulations 1
Performance Features 2
Package Contents 3
Controls and Functions 3
Installation Instructions 5
Mechanical Mounting 6
Power Supply Connection 7
Mobile Antenna Information 8
Antenna Tuning Information 9
Operating Instructions 9
External Speaker Operation 10
Radio Communication Codes 11
CB Channel Frequency Chart 12
Troubleshooting Chart 13
Specifications 14
Other Maxon Products 15
Warranty Service Instructions 16
Warranty Statement 17
Before operating your Maxon Citizens Band Radio,
read this Owner's Manual carefully. If you have a
problem, refer to the "Troubleshooting" section of
this manual before returning your radio for repairs.

TABLA DE CONTENIDO
Controles y Funciones 3
Descripción del Producto 18
Regulaciones de la FCC
(Comisión Federal de Comunicaciones) 18
Características de Funcionamiento 19
Contenido del Paquete 20
Instrucciones Para Instalación 21
Montaje Mecánico 22
Conexión del Suministro Energético 23
Información Sobre la Antena Móvil 24
Información Para la Sintonización de
la Antena 25
Instrucciones de Operación 25
Operación de los Altoparlantes Exteriores 26
Tabla de Frecuencia del Canal de CB
(Banda Ciudadana) 27
Tabla de Localización y Reparación
de Averías 28
Especificaciones 29
Otros Productos Maxon 30
Instrucciones Servicio de Garantía 31
Aclaración de la Garantía 32
Antes de hacer funcionar su radio de Banda
Ciudadana de Maxon lea detenidamente este Manual
del Propietario. Si tiene unproblema, refiérase a la
sección "Localización y Reparación de Averías" de este
manual antes de devolver su radio para la reparación.

1
PRODUCT DESCRIPTION
Thank you for choosing the
Maxon MCB-30 Mobile CB Radio.
This compact CB is designed to be simple to
operate, and will provide years of trouble-free
service and enjoyment.
Variable controls let you adjust radio volume and
squelch settings to your preference; push button
channel selectors allow you to easily scroll through
the 40 available CB channels.
A large scale display identifies your current channel
selection - even in dim lighting.
The radio's front-mounted microphone allows
installation of the MCB-30 almost anywhere in
your car, van, truck or RV.
Enjoy your new Maxon CB!
YOU DO NOT NEED AN FCC LICENSE TO
OPERATE THIS RADIO IN THE UNITED STATES.
However, you must know and be familiar with
Part 95 of the FCC Rules in regard to Subpart D
of the Citizens Band Radio Service. (A copy is
enclosed with the unit.)

2
PERFORMANCE FEATURES
•Maximum legal RF output power (4 W) with high
level modulation (in accordance with FCC Part
95 Rules)
•Solid-state components for years of trouble-free
operation
•LED Channel display and transmit indicator
•Channel up/down selector buttons
•Front-mounted microphone with 5-pin connector,
push-to-talk bar and coiled cord
•Last channel memory recalls last channel
displayed
•Phase Locked Loop synthesizer provides clear
voice transmission and reception on all CB
channels
•Built-in Automatic Noise Limiter (ANL) circuitry
reduces atmospheric static noise
•Automatic RF gain control adjusts the receiving
sensitivity of the radio
•Automatic modulation control eliminates peak
and valley transmission signals
•Dual-conversion superheterodyne receiver
•Rugged metal case material
•Jacks for mobile antenna and optional external
speaker (not included)
•One year warranty

3
PACKAGE CONTENTS
Main CB unit
Handheld microphone
CB Mounting bracket and hardware
Owner's manual
Copy of FCC Part 95, Subpart "D"
An external mobile antenna is required for use -
antenna is not included. Refer to Mobile Antenna
Information section for more information.
CONTROLS AND FUNCTIONS
CONTROLES Y FUNCIONES
A. Microphone and Cord • Micrófono y Cable
B. Push-To-Talk Bar -Permits radio transmissions
•Barra "Presione Para Hablar" (P-T-T) - Permite la
transmisión por radio
C. TX LED - Indicates the radio is transmitting
• TX LED - Indica que el radio está transmitiendo
D. LED Channel Display -Identifies CB channel
• LED Imagen de Canal - Identifica el canal CB
E. Microphone Jack • Conector del Micrófono
F. Channel Up/Down Buttons -Selects any one of
40 channels available •Botones de Subida y Bajada
de Canales - Selecciona cualquiera de los 40 canales
disponibles
G. Squelch Control •Control Para Amortiguar Ruidos
H. Off/On-Volume Control -Used to turn the radio on
or off and to adjust the listening volume •Control
de Volumen -Se usa para encender o apagar el radio
y para ajustar el volumen
Antenna Jack: Located on back panel, not shown
•Conector Para Antena: Situado en el panel
trasero, no se ve
External Speaker Jack: Located on back panel,
not shown •Conector Para Altoparlante
Externo: Situado en el panel trasero, no se ve

4
B
H G F E
C D
A

INSTALLATION INSTRUCTIONS
Your new MCB-30 is designed to be installed
under the dash or anywhere inside your vehicle.
It can be mounted horizontally or vertically. Safety
and convenience should be your primary consider-
ations in deciding exactly where to locate your
Maxon MCB-30 CB Radio.
CAUTION: Be sure the unit is located where
it will not interfere with the driver or impair
access to any controls necessary for the safe
driving of the vehicle. The radio's power or
antenna connecting cables must be routed and
secured in such a manner as not to interfere with
the operation of the brake, accelerator or other
controls. Interference from either the CB unit or
it's connecting cables may contribute to the loss
of control of the vehicle.
Installing the MCB-30:
5

Mechanical Mounting
1) Determine the mounting location of your
MCB-30.
2) Use the CB cabinet mounting bracket as a
template for marking the location of the screw
holes when mounting the CB under the dash,
or at another selected location.
3) Drill the necessary holes and secure the
mounting bracket with the self-tapping
screws provided.
CAUTION: EXTREME CARE SHOULD BE
EXERCISED WHEN DRILLING UP INTO
THE DASH to avoid any damage to in-dash
electronic ignition wiring, cruise control,
instruments or accessory wiring.
4) Position the CB unit between the mounting
bracket arms (in line with the retention knobs).
Set the CB unit angle for the best operating
comfort and control accessibility. Tighten the
two retention knobs to secure the CB unit in
place.
5) Install the microphone hanger bracket utilizing
the pre-drilled mounting holes in the MCB-30
cabinet, or attach the bracket to the vehicle
dash or another convenient location.
6) If you choose to mount the CB in a location
where self-tapping screws cannot be used,
determine the most secure method of fastening
the CB cabinet.
6

Power Supply Connection
The MCB-30 is designed for 12V DC operation in
vehicles with NEGATIVE (-) GROUND electrical
systems. Most domestic and foreign made cars and
trucks use a negative ground system. NOTE: If your
negative (-) battery terminal is connected to the
motor block of your vehicle, it is a negative ground
system.
CAUTION: Do not attempt to connect your
MCB-30 to a POSITIVE (+) ground vehicle
as damage may occur to the CB unit and/or
to your vehicle's electrical system.
NOTE: Check your vehicle's ground requirements
before you begin the installation!
Your MCB-30 should be connected using the
following steps:
1) Move the off/on-volume control to the "off"
position. CAUTION: If the off/on-volume
control is in the "on" position without an
antenna hook-up, it could result in damage
to the transmitter circuitry.
2) Disconnect the cable from your vehicle
battery's negative (-) terminal.
3) Connect the black GROUND wire to a metal
part of your vehicle's frame.
NOTE: Be sure the metal part is not insulated from
the vehicle's frame by a plastic part.
4) Connect the red (to switched accessory) wire
to a source of voltage that turns on and off with
7

the ignition switch, such as a spare accessory
terminal in your vehicle's fuse box.
5) Connect the orange (Batt +) wire to your
vehicle's battery positive (+) terminal or to
a point in the vehicle's fuse box that provides
a continuous source of 12 Volts even when
the ignition is turned off. This connection
provides last channel memory feature.
6) Reconnect the cable to the vehicle's battery
negative (-) terminal.
MOBILE ANTENNA INFORMATION
Your Maxon MCB-30 requires a vehicle mount CB
antenna for operation. An antenna is not included
with your MCB-30 because of varying vehicle
applications, individual needs, and owner cost
preferences.
You may use any standard 50 Ohm vehicle mount
CB/weather antenna system with a PL-259 connec-
tor. Maxon antenna model WTA-4WP may be
obtained from your local Maxon CB distributor/
retailer.
NOTE: When installing a mobile antenna, please
follow the antenna manufacturer's installation
instructions completely. Never operate your
CB radio without an antenna or with a broken
antenna cable. This can result in damage to your
CB transmitter circuitry.
•Connect the antenna securely to the unit's
antenna receptacle
8

9
•Mount the antenna as high on the vehicle
as possible - the more the antenna extends
above the roof, the better the reception
•If possible, mount the antenna in the center
of the surface you have chosen
•Keep the antenna cables away from noise
sources such as the ignition system, gauges,
etc.
•Make sure you have a solid, metal-to-metal
ground
ANTENNA TUNING INFORMATION
Most antennas are factory tuned, but performance
can usually be improved by slightly lengthening
or shortening the antenna using a Standing Wave
Ratio (SWR) meter (not included). Refer to the
antenna manufacturer's installation manual for
the exact procedure to tune the antenna. You
can purchase an SWR meter, or have your antenna
checked by your CB Dealer's service department.
OPERATING INSTRUCTIONS
Once you have properly wired your new CB and
connected the antenna, you are now ready to adjust
your radio for optimum reception and voice trans-
mission.
For proper operation, the radio's microphone must
be connected to the unit. Insert the microphone
plug into the microphone jack (MIC). The plug has
a spring loaded locking pin. When inserting the
plug into the jack, push inward until pin is locked
into place. When removing, hold pin in and
withdraw the plug.

10
1) Turn the off/on-volume control clockwise and
adjust to a comfortable volume level.
2) Select the desired CB channel by pressing the
!" button to scroll up or the #button to scroll
down.
3) Adjust the squelch control knob to reduce any
undesirable background noise when no signal
is being received. To do this, select a channel
where no signals are present, or wait until
signals cease on your channel. Then, rotate
the squelch control knob clockwise to a point
where the background noise ceases.
NOTE: When the squelch is set properly, the
speaker will remain quiet until a signal is received.
In order to receive weak signals, do not set the
squelch too high.
To Transmit: Press and hold the push-to-talk bar.
Speak slowly and clearly in a normal voice, two
to three inches from the microphone. When trans-
mitting, the TX LED will glow red.
To Receive: Release the push-to-talk bar.
External Speaker Operation
To connect an optional external speaker, locate
the external speaker jack on the rear of the unit
and insert the speaker plug into the jack. The
radio's internal speaker will be silenced when
an external speaker is engaged.

RADIO COMMUNICATION CODES
Citizens Band radio operators have universally adopted
the "10" Code for standard questions and answers. It
enables them to communicate faster, easier and more
understandably in noisy surroundings.
The following are some of the most common codes and
their descriptions.
When using the code 10-1, you would say, "Ten one",
not "One zero dash one".
Code Description
10-1
10-2
10-3
10-4
10-5
10-6
10-7
10-8
10-9
10-10
10-11
10-12
10-13
10-16
10-17
10-18
10-19
10-20
10-21
10-22
10-23
10-24
10-25
10-26
10-27
10-28
10-29
10-30
10-32
10-33
10-34
Receiving poorly.
Receiving well.
Stop transmitting.
OK, message received.
Relay message.
Busy, stand by.
Out of service; leaving
the air.
In service, subject to call.
Repeat message.
Transmission completed,
standing by.
Talking too fast.
Visitors present.
Advise weather/
road conditions.
Make pickup at_______.
Urgent business.
Anything for us?
Nothing for you;
return to base.
My location is_______.
Call by telephone.
Report in person to_____.
Stand by.
Completed last assignment.
Can you contact?
Disregard last information.
I am moving to channel_.
Identify your station.
Time is up for contact.
Does not conform
to FCC rules.
I will give you a radio check.
Emergency traffic.
Trouble at this station.
11
Code Description
10-35 Confidential information.
10-36 Correct time is________.
10-37 Wrecker needed at ____.
10-38 Ambulance needed at__.
10-39 Your message delivered.
10-41 Please turn to channel_.
10-42 Traffic accident at______.
10-43 Traffic tie-up at________.
10-44 I have a message for you.
10-45 All units within range
report.
10-50 Break channel.
10-60 What is next message
number?
10-62 Unable to copy; use phone.
10-63 Network directed to.
10-64 Network clear.
10-65 Awaiting your next
message/assignment.
10-67 All units comply.
10-70 Fire at _______________.
10-71 Proceed with transmission
in sequence.
10-77 Negative contact.
10-81 Reserve hotel room at___.
10-82 Reserve room for_______.
10-84 My telephone number is_.
10-85 My address is_________.
10-91 Talk closer to microphone.
10-93 Check my frequency on
this channel.
10-94 Please give me a long
count.
10-99 Mission completed; all
units secure.
10-200 Police needed at_______.

Channel:
12
CB CHANNEL FREQUENCY CHART
26.965 MHz
26.975 MHz
26.985 MHz
27.005 MHz
27.015 MHz
27.025 MHz
27.035 MHz
27.055 MHz
27.065 MHz Emergency Channel
27.075 MHz
27.085 MHz
27.105 MHz
27.115 MHz
27.125 MHz
27.135 MHz
27.155 MHz
27.165 MHz
27.175 MHz
27.185 MHz Highway Channel
27.205 MHz
27.215 MHz
27.225 MHz
27.255 MHz
27.235 MHz
27.245 MHz
27.265 MHz
27.275 MHz
27.285 MHz
27.295 MHz
27.305 MHz
27.315 MHz
27.325 MHz
27.335 MHz
27.345 MHz
27.355 MHz
27.365 MHz
27.375 MHz
27.385 MHz
27.395 MHz
27.405 MHz
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

No sound or LED lights
LED illuminated, but no sound
No voice reception
Poor reception
Unclear reception
Transmission problems
This mobile Citizens Band radio has been manufac-
tured in accordance with Maxon's exacting quality
control standards.
It should be handled
with reasonable care.
Avoid exposing it to
dirt or moisture.
If you experience
problems, please
refer to this
Troubleshooting
Chart.
TROUBLESHOOTING CHART
13
POSSIBLE PROBLEMS:
WARNING: DO NOT ATTEMPT TO MAKE ANY INTERNAL
ADJUSTMENTS. Internal adjustments and/or modifications can
lead to illegal operation as defined by FCC Rules and Regulations,
Part 95. They must be made only by qualified technical personnel.
Illegal operation can result in serious consequences.
CAUTION: The fuse included with this unit is an important safety
feature which must not be circumvented. Removal of this fuse
or the use of a fuse rated higher than supplied may result in
overheating and/or fire and consequential damage to the unit
or vehicle. If a replacement fuse burns out, have the unit inspected
and repaired by a qualified service technician.
Check power cable connection Check fuses (in-line and main junction block) Check squelch adjustment Check power off/on-volume control Change to active channel Check antenna connection Fully depress push-to-talk bar when speaking Check microphone connection
POSSIBLE SOLUTIONS:

SPECIFICATIONS
GENERAL
CB Channels: 40
Frequency Range: 26.965 to 27.405 MHz
Frequency Control: Phase Locked Loop (P-L-L)
synthesizer
Operating Temperature
Range: -22o F to +122o F
Channel Display: Light Emitting Diode (LED)
Input Voltage: 13.8V DC nominal,
negative ground
DC Input Power: 5 W
Dimensions: 4-1/2" W x 6-1/4" D x 1-1/4" H
Weight: 1-3/4 lbs.
External Speaker
(optional): 5 W input @8 Ohms with
3.5 mm plug
RECEIVER
Receiving System: AM Dual conversion
superheterodyne
Intermediate
Frequency: 1st IF: 10.695 MHz
2nd IF: 455 MHz
Audio Output Power: 4 W
TRANSMITTER
RF Output Power: 4 W (Maximum FCC allowable)
Specifications are subject to change without notice.
14

15
OTHER MAXON PRODUCTS
Maxon manufactures a full line of personal electronic
products, including handheld and mobile CB radios,
49 MHz personal communicators, Family Radio
Service radios, GMRS/DOT two-way radios, CDMA,
GSM and AMPS cellular handsets, weather monitors
and a variety of optional accessory items. Look for
Maxon brand products in quality retail stores nation-
wide.
WTA-4WP Magnetic mount mobile
CB/weather antenna
FRS-114 Palm sized two-way radio
operates on one of 14
license-free channels
49-FX Unique belt worn two-way
communicator offers ear
speaker/microphone for
hands-free conversations

FOR YOUR RECORDS
Purchase Date:
Purchased From:
Serial Number:
KEEP THIS INFORMATION
IN A SAFE PLACE.
WARRANTY SERVICE INSTRUCTIONS
1) Refer to the Operating Instructions section of
this Owner’s Manual for proper operation and
adjustments.
2) Refer to the basic Troubleshooting Chart for
possible solutions.
3) If the problem cannot be corrected by
reference to this Owner's Manual, return
the product with proof of purchase (a sales
receipt) to the place of purchase, or call
Maxon’s Customer Service Department for
assistance, 1-800-821-7848, Ext. 499.
16

LIMITED WARRANTY
The Consumer Products Division of Maxon America, Inc., (herein-
after referred to as "Maxon"), warrants that its Products and their
included accessories will be free from defects in workmanship or
materials under normal use for a period of one (1) year from date
of purchase by the original end user, provided that the buyer has
complied with the requirements stated herein.
If the Product fails to function under normal use because of man-
ufacturing defect(s) or workmanship during the one (1) year period
following the date of purchase, it will be replaced or repaired at
Maxon's option at no charge when returned to the place of pur-
chase. The defective unit must be accompanied by proof of the
date of purchase in the form of a sales receipt.
Maxon's sole obligation hereunder shall be to replace or repair
the product covered in this Warranty. Replacement, at Maxon's
option, may include a similar or higher-featured product. Repair
may include the replacement of parts or boards with functionally
equivalent reconditioned or new parts or boards. Replaced parts,
accessories, batteries or boards are warranted for the balance of
the original time period. All replaced parts, accessories, batteries
or boards become the property of Maxon America, Inc.
Maxon shall have no obligation to make repairs or to cause
replacement required which result from normal wear and tear
or is necessitated in whole or in part by catastrophe, the fault or
negligence of the user, improper or unauthorized alterations,
repairs to the Product, incorrect wiring, use of the Product in a
manner for which it was not designed, or by causes external to
the Product. This warranty is void if the serial number is altered,
defaced or removed.
The purchaser shall provide for removal of the defective Product
and installation of its replacement.
THE EXPRESS WARRANTIES CONTAINED HEREIN ARE IN LIEU
OF ALL OTHER WARRANTIES, EITHER EXPRESSED OR IMPLIED
OR STATUTORY, INCLUDING, WITHOUT LIMITATION, ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
FOR ANY PRODUCT WHICH DOES NOT COMPLY WITH THE
WARRANTY SPECIFIED, THE SOLE REMEDY WILL BE REPAIR
OR REPLACEMENT. IN NO EVENT WILL MAXON AMERICA,
INC. BE LIABLE TO THE BUYER OR ITS CUSTOMERS FOR ANY
DAMAGES, INCLUDING ANY SPECIAL, INCIDENTAL, INDIRECT
OR CONSEQUENTIAL DAMAGES, OR THE LOSS OF PROFIT,
REVENUE OR DATA ARISING OUT OF THE USE OF OR THE
INABILITY TO USE THE PRODUCT.
This warranty is void for sales and deliveries outside of the U.S.A.
17
