Maxxhaul 70468 User manual

Read and understand this entire manual before assembling,
installing, operating, or servicing this product.
SAVE THIS MANUAL
Copyrightc2016 by MAXXHAUL. All rights reserved. No portion of this manual or any artwork contained
herein may be reproduced in any shape or form without the express written consent of MAXXHAUL. Due
to continuing improvements, actual product may di󰀨er slightly from the product described herein. Tools
required for assembly and maintenance may not be included.
Instruction Manual
&
Parts List
LED
Trailer Lights
Model 70468

IMPORTANT SAFETY
INFORMATION
This is a SAFETY ALERT symbol.
It is used to alert you to
potential personal
injury hazards. Obey all
safety messages that follow
this symbol to avoid possible injury or death.
DANGER indicates a
hazardous situation which, if not avoided,
will result in death or injury.
WARNING indicates a
hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a
hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE indicates
important information which, if not followed,
may cause damage to equipment.
SAVE THIS MANUAL
Keep this manual for the safety warnings
and precautions. The manual o󰀨ers impor-
tant information on how to assemble, use
and maintain this product.
Write the product’s model number and
purchase date on the cover page of this
manual.
Keep this manual (and your purchase re-
ceipt) in a safe place.
UNPACKING
The shipment should be thoroughly inspected as
soon as it is received. The signed “bill of lad-
ing” is acknowledgement by the carrier of receipt
in good condition or shipment covered by our
invoice. For your own protection, if any of the
goods called for on the bill of lading are shorted
or damaged, do not accept them until the carrier
makes a notation on the freight bill of the shorted
or damaged goods.
Notify MAXXHAUL immediately if any hidden
loss or damage is discovered after receipt.
DANGER
WARNING
CAUTION
NOTICE
INSTRUCTION
MANUAL
WARNING concerning Risk of Eye
Injury. Wear ANSI approved eye
protection.
WARNING concerning Risk of
Hearing Loss. Wear hearing pro-
tection.
Denition of Symbols
IMPORTANT SAFETY
INSTRUCTIONS
1. Read and understand all
safety warnings and in-
structions. Failure to follow the warnings
and instructions may result in serious injury
or death. Save all warnings and instructions
for future reference.
2. Personal and Work Area Safety
A. Always wear ANSI approved
safety goggles.
B. Always wear hearing protec-
tection when working in
noisy environments. Prolonged exposure
to high intensity noise can cause hearing
loss.
C. Use safety equipment. Safe-
ty shoes, hard hat and work
gloves must be used for applicable condi-
tions.
Model 70468 Page 2
D. Dress appropriately. Never wear loose
tting clothing or jewelry when working.
Contain long hair, and keep hair, clothing
and gloves away from moving parts.
E. Use common sense when working.
Stay alert and concentrate when setting up
and using the Trailer Lights. Never work
while under the inuence of alcohol, drugs or
medications.

Model 70468 Page 3
Personal and Work Area Safety (continued)
F. While assembling and setting up the
Trailer Lights keep work area clean and
well lighted. Keep spectators and chil-
dren out of the work area.
3. Use of the Trailer Lights
A. Do not modify the Trailer Lights and do
not use this product for purposes that it was
not designed for.
B. This 12V LED Trailer Light kit is designed
for trailers less than 80 inches in width. Only
install these lights on a 12V negative ground
circuit. Adhere to all Department of Trans-
portation (DOT) standards and regulations
regarding light kits.
C. As pertaining to lights on trailers, read
and adhere to all safety guidelines and
instructions provided by the manufacturer of
the trailer.
D. If you are not experienced in assembling
and setting up 12V electrical products such
as this one, the work should be done by a
qualied service technician.
E. Keep children and spectators clear of the
area when setting up this product and when
maneuvering a towed vehicle.
F. Note: If the trailer is wider than 80 inch-
es, DOT standards require the installation of
3 additional red marker lights (not included in
this kit) to the rear of the trailer.
If the trailer has turn signals that are wired
separately from the stop lights, di󰀨erent
installation methods than described in this
manual will be required. Contact a qualied
service technician for assistance.
G. The vehicle/trailer must be in a safe,
level location away from moving tra󰀩c when
the Trailer Lights are installed. Vehicle’s en-
gine must be OFF and parking brake set.
H. To verify that the correct wire has been
located on the tow vehicle’s wiring harness,
it is recommended that a circuit tester (not
included) be used.
I. Only set up lights with red lights facing
backward (towards tra󰀩c behind). Test
the operation of the lights before driving in
tra󰀩c. Once Trailer Lights are in operation,
periodically pull over and check the position
and operation of the lights. Wind, vibration
and road conditions can a󰀨ect the position of
the lights. Make sure that the lights remain
securely in position.
J. Save packaging information and name-
plates on the Trailer Lights. They contain
important information and must always
remain readable. Contact MAXXHAUL for
replacements.
Keep in mind that the warnings previous-
ly discussed cannot cover all possible
conditions or situations that could occur.
It is important that the person setting up
and using this product understand that
common sense and caution are factors
which cannot be built into this product,
and must be supplied by the person(s)
using this product.
Limited Warranty
MAXXHAUL warrants to the original retail
purchaser that the product is free of defects
in material and workmanship at the time of
shipment. This Trailer Light set is warran-
teed for 90 days from the date of purchase.
This warranty is expressly in lieu of all other
warranties, express or implied.
Proof of purchase is required for warranty
transactions; a copy of the original invoice
or sales receipt is required.

Assembling and Setting Up
the Trailer Lights
Always wear ANSI approved
safety goggles.
1. Refer to the photos and Wiring Illustration
below to identify components of the Trailer
Light kit.
Left Hand Tail Light
(with the clear window on bottom
to illuminate license plate holder)
Right Hand
Tail Light
License Plate Holder
Frame Clips
Wire
Connectors
Splice
Connectors
License Plate
Hardware
Wiring package includes
Trunk Harness (4 wires)
and
Y-Harness (5 wires)
Trunk Harness
Y-Harness
2. Towing Vehicle Wire Installation
Use Splice Connectors to make the follow-
ing wire connections:
A. Using Trunk Harness, connect Brown
wire to the towing vehicle’s “Running
Lights” wire.
B. Using Trunk Harness, connect Yellow
wire to the vehicle’s “Left Stop and Turn
Light” wire.
C. Using Trunk Harness, connect Green
wire to the vehicle’s “Right Stop and Turn
Light” wire.
D. Using Trunk Harness, attach the White
Ground wire to the towing vehicle’s frame
(clean, bare metal surface).
3. Trailer Wire Installation
A. Mount the Left Hand Tail Light (with the
clear window on bottom) to the left rear of
the trailer. Make sure red reector on the
side of light faces outward so it can be seen
from side of trailer.
B. Mount the License Plate underneath the
Left hand Tail Light, using enclosed hard-
ware (bolts, washers, nuts).
C. Mount the Right Hand Tail Light to the
right rear of the trailer (side reector facing
outward).
D. Position the Y-Harness wires down each
Tow Vehicle’s
Running Lights
Y-Harness
Trunk Harness
Model 70468 Page 4
Vehicle

Model 70468 Page 5
side of the trailer. The connected Yellow and
Brown wires are placed down left side of
trailer and the connected Green and Brown
wires are placed down the right side of the
trailer. Use included Frame Clips to attach
the wires to the sides of the trailer frame.
E. Use Wire Connector to connect Yellow
wire of Y-Harness to Yellow wire on Left
Hand Tail Light.
Use another Wire Connector to attach Brown
wire to Brown wire.
F. Attach the White Ground wire to the trailer
frame (must be a clean, bare metal surface).
G. On right side of trailer, use Wire Con-
nector to connect Green wire of Y-Harness
to Green wire on Right Hand Tail Light. Use
another Wire Connector to attach Brown
wire to Brown wire.
H. Attach White Ground wire of Right Hand
Tail Light to a clean, bare metal surface of
the trailer frame.
Testing and Using the Trailer Lights
1. With wiring complete, connect the Trunk
Harness plug to the Y-Harness plug.
2. With a second person as a spotter, turn
on headlights of towing vehicle. The two
trailer tail lights should turn on.
3. When the vehicle’s brake pedal is de-
pressed, the brighter Stop Lights should ap-
pear. When the turn signal is activated, the
brighter blinking lights should appear. Note:
the ignition key must be in the ON position
when testing the lights.
Test all lights be-
fore each use. Make sure trailer light
operation always matches vehicle light
operation. Periodically check all wiring for
proper connections and to make sure that
no wire deterioration has occured.
WARNING
When servicing or testing lights, make sure
vehicle is in a safe location away from tra󰀩c
with parking brake activated.
4. Problem solving: Some ideas when
lights are not working properly.
A. If trailer light operation is not consis-
tent with vehicle light operation, the Trunk
Harness may not be wired properly to the
vehicle’s electical system. Also check that
Y-Harness is properly wired to each trailer
light.
B. One or more of the LED lights ickers or
fails to light up: Wiring may be disconnected
or loose. Ground wire may not have a prop-
er connection. LED light may be burned out
- the Trailer Light will have to be replaced.
C. If Trailer Lights do not turn on: Running
lights of vehicle may be turned o󰀨. Ground
wire may be loose or disconnected. Trailer’s
wiring harness may be disconnected.
D. Blown fuse in vehicle: Diagnose for short
circuit in lights or wiring. Make sure routed
wires are not pinched.
SPECIFICATIONS
Power 12 VDC Only (Negative
Ground Only)
Light Source LED (Light Emitting
Diode) - not serviceable
Kit Includes 2 Submersible Trailer
Lights (Stop, Tail, Turn
Signals) - Class A,
License Plate Bracket, Y-
Harness, Trunk Harness
Safety Requirements DOT (Department of
Transportation) approved
(when installed properly).
Note: Some parts are listed and shown for illustration pur-
poses only, and are not available as replacement parts. All
repairs to this tool (including replacing parts) should only be
done by a qualied service technician.
Manufactured and Distributed by:
Maxx Group, LLC, 1500 E. Wooley Rd., Unit C, Oxnard, CA
USA 93030
Telephone: [phone]
