FC101 FlowCom Register
Installation, Operation and
Maintenance Manual

30119-50 Rev. 2.2 | 23JUL2020
Page ii
Contents
SAFETY WARNINGS .........................................................................1
1.0 INTRODUCTION ......................................................................2
1.1 Description ......................................................................2
1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.3 Model Number Identication .....................................................2
2.0 INSTALLATION........................................................................3
2.1 Mechanical-to-FlowCom Conversion Kit Installation - Meter Mount ...................3
2.2 Mechanical-to-FlowCom Conversion Kit Installation - Remote Mount ................9
3.0 OUTPUT WIRING CONNECTION.......................................................13
3.1 Wiring Diagrams ................................................................13
3.2 4-20mA Connection To Water Specialties Instrumentation .........................16
3.3 LCD Output Symbol Clarications ................................................17
4.0 PROGRAMMING .....................................................................18
4.1 Accessing The Conguration Menu ...............................................18
4.2 Document Changes .............................................................18
4.3 Menu Table Of Contents .........................................................19
4.4 Menu Navigation................................................................20
4.5 Conguration Examples .........................................................30
5.0 PRODUCT SPECIFICATIONS ..........................................................33
5.1 Specications ...................................................................33
5.2 Dimensions .....................................................................34
5.3 Housing ........................................................................34
5.4 Parts List .......................................................................35
6.0 PRODUCT MAINTENANCE ............................................................36
6.1 Battery Replacement ............................................................36
7.0 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
7.1 Circuit Board Connections .......................................................38
WARRANTY STATEMENT ...................................................................39

30119-50 Rev. 2.2 | 23JUL2020
Page 1
SAFETY WARNINGS
SAFETY WARNINGS
When installing, operating, and maintaining McCrometer equipment where hazards may be present, you must protect
yourself by wearing Personal Protective Equipment (PPE) and be trained to enter conned spaces. Examples of conned
spaces are manholes, pumping stations, pipelines, pits, septic tanks, sewage digesters, vaults, degreasers, storage tanks,
boilers, and furnaces.
You must follow all state and local laws, as well as Occupational Health and Safety Administration (OSHA) regulations
concerning Personal Protective Equipment, conned-space entry, and exposure to bloodborne pathogens. Specic
requirements can be found in the OSHA section of the Code of Federal Regulations: 29 CFR, 1910.132 - 1910.140, Personal
Protective Equipment; CFR Title 29, Part 1910.146, Permit-Required Conned-Spaces; and 29 CFR, 1910.1030, Bloodborne
Pathogens.
WARNING!
Never enter a conned space without rst testing the air at the top, middle, and bottom of the space.
The air may be toxic, oxygen decient, or explosive. Do not trust your senses to determine if the air is safe.
You cannot see or smell many toxic gases.
WARNING!
Never enter a conned space without the proper safety equipment. You may need a respirator, gas
detector, tripod, lifeline, and other safety equipment.
WARNING!
Never enter a conned space without standby/rescue personnel within earshot. Standby/rescue
personnel must know what action to take in case of an emergency.
WARNING!
Pressurized pipes should only be tapped, cut, or drilled by qualied personnel. If possible,
depressurize and drain the pipe before attempting any installation.
!
!
!
!

30119-50 Rev. 2.2 | 23JUL2020
Page 2
INTRODUCTION
1.0 INTRODUCTION
1.1 Description
The FlowCom Register displays a owmeter’s owrate and volumetric total. Available are optional outputs: scaled pulse
and/or industry standard 4-20mA signal. The FlowCom can be tted to any new or existing Water Specialties propeller
owmeter.
1.2 Features
Meter Mount Models
without Optional Output
Remote Mount Models
without Optional Output
Meter Mount Models
with Optional Output
Remote Mount Models
with Optional Output
Mc Propeller FC101- X X - X - _ _ _ _ - _ _ _ _ _
Output
No Output 00
Open Collector 01
4-20mA, Optically Isolated Pulse * 02
4-20mA, Contact Closure * 03
Open Collector (Quick Connect) 05
Sensus 06
Sensus Open Collector 07
4-20mA, Optically Isolated Pulse Sensus * 08
4-20mA, Relay Sensus * 09
Sensus RM 16
Mounting Style
Sold with Meter M
Retrot (Register only) R
Kit (Register, sensor, cable) K
Retro for W.S. trans. mount RT
Remote
6’ RM06
25’ RM25
50’ RM50
*Output Cable
6’ OC06
25’ OC25
50’ OC50
75’ OC75
100’ OC100
125’ OC125
150’ OC150
Required Options
*Output Cable Option
is ONLY available with
Outputs of 01, 02 or 03.
*These output options require 420mA/DC power.
• Retrots to any existing McCrometer Mc Propeller
Flowmeter
• Four output options: Contact Closure, Open Collector,
Optically Isolated, and 4-20mA Loop
• Unique Units of Measurement for Rate, Total, 4-20mA
and Pulse Outputs
• 6–10 Year Battery Life
• NEMA 4X Enclosure with Non-intrusive Register
Programming
• Remote and Meter-Mounted Models
• Factory sealed enclosure protects electronics
1.3 Model Number Identication

30119-50 Rev. 2.2 | 23JUL2020
Page 3
INSTALLATION
2.0 INSTALLATION
After unpacking the register assembly, verify that the
meter serial number engraved on the enclosure lid is
correct. Then conrm the information on a white label
located on the bottom of the base plate (Figure 1.)
Figure 1. Meter Serial Number Placement
Enclosure lid
Baseplate
944606
2.1 Mechanical-to-FlowCom Conversion Kit Installation - Meter Mount
Note: For remote mount retrot, see section 2.2.
Check the parts received against the parts list and Figure 2 and Figure 3 below. Contact the factory to report any
discrepancies.
Figure 2. Conversion Kit - FC101-00-K, Meter Mount
Parts Diagram Description Quantity Part Number
1 FlowCom Unit 1 FC101-01
2 Propeller Assembly 1
Bagged parts:
3 Separator 1 4-2455-2-D
4 Screw 10-32 x 1.25”Long 2 10730
5 Screw 10-32 x 1.25”Long w/hole 2 10830
6 Sensor 1 4-2745-2
7Reverse Thrust Brg Tool 1 T-2402X-1
8Magnet Wand 2 FC100-M
9 Back Plate 1 2-2731-SS
10 O-Ring (243 Buna) 1 1-1551-38
11 O-Ring (028 Buna) 1 1-1551-2
12 O-Ring (022 Buna) 1 1-1551-24
13 Screw 8-32 x 7/16 SOC HD 8 1-1103-8-7

30119-50 Rev. 2.2 | 23JUL2020
Page 4
INSTALLATION
Figure 3. Conversion Kit - FC101-01-K, FC101-02-K, FC101-03-K, Meter Mount
Parts Diagram Description Quantity Part Number
1 FlowCom Unit 1 FC101-01
2 Propeller Assembly 1
Bagged parts:
3 Separator 1 4-2455-2-D
4 Grounding Kit Instructions 1 30110-18
5 Sensor 1 4-2745-2
6Reverse Thrust Brg Tool 1 T2402X-1
7Magnet Wand 2 FC100-M
8 Back Plate 1 2-2731-SS
9 Screw 10-32 x 1.25”Long 2 10730
10 Screw 10-32 x 1.25”Long w/hole 2 10830
11 O-Ring (243 Buna) 1 1-1551-38
12 O-Ring (028 Buna) 1 1-1551-2
13 O-Ring (022 Buna) 1 1-1551-24
14 Screw 8-32 x 7/16 SOC HD 8 1-1103-8-7
15 Green Wire 1 3-2757-FCW

30119-50 Rev. 2.2 | 23JUL2020
Page 5
INSTALLATION
STEP 2: Remove the totalizer assembly.
Remove the entire totalizer or indicator-totalizer register assembly. Register models with totalizers have four bonnet
screws and models with both the indicators and totalizers have four bonnet screws and two register screws. Remove
the shaft.
Totalizer Assembly
Bonnet Screws
Vertical Shaft
Vertical Shaft
Mounting Screws
Bonnet Screws
Indicator-totalizer
Mounting Screws Indicator-
totalizer
Assembly
Bonnet
For ML and LP meters: Remove the V-shaft by
loosening the two screws holding the V-shaft from
the inside of the meter head.
For MLand LP meterswith extensions andforOF andVF
meters:Pull vertical shaft out only enough (approximately
1”) for removal of miter gear frame assembly so that the
vertical shaft can be used later for pulling the sensor input
cable out of the drop pipe.
STEP 1: Remove the owmeter.
Remove pressure from the pipeline.
Remove the entire owmeter from the pipeline.
CAUTION!
Never remove a meter or top plate assembly while the line is under pressure!
!

30119-50 Rev. 2.2 | 23JUL2020
Page 6
INSTALLATION
Gearbox
Miter Gear Frame Assembly
Miter Gear
Frame Assembly
Mounting Screws
Propeller
Separator-spindle Assembly
For ML, LP, and OF meters:
Remove the miter gear frame assembly by
releasing the four screws out of the back of the
gearbox.
Caution: The gearbox oil will begin draining as
soon as the seal is broken.
Note: See your ow meter’s IOM manual for
instructions on removing the propeller.
For VF meters:
Remove the propeller and the separator-spindle
assembly.
Note: See your ow meter’s IOM manual for
instructions on removing the propeller.
STEP 3: Remove the gearbox assembly.

30119-50 Rev. 2.2 | 23JUL2020
Page 7
INSTALLATION
Back Plate
Mounting
Screws
Back Plate
O-ring
Sensor Assembly
Separator-spindle
Assembly
Vertical Shaft
Pulling Fixture
T-2730-2
Sensor Assembly
Separator-spindle
Assembly
Set Screw
Set Screw
Sensor
Assembly
For ML and LP meters: Push the sensor assembly
through the back of the gearbox all the way into
the separator/spindle assembly. Rotate the sensor
assembly so that the sensor cable can be fed
through gearbox up over the meter head. Put a thin
lm of silicon grease on the O-ring and secure the
back plate of the gearbox with four screws.
Note: Do not twist the back plate. This can cause the
O-ring to be pinched and the meter to leak.
For OF and 24” to 54” ML meters: Attach pulling
xture T-2730-2 to bottom tip of existing vertical
shaft assembly. Tighten both set screws on the
xture with a 0.062 Allen wrench for a secure
connection to the vertical shaft tip. Loop sensor
cable through hook on xture and secure with a
small piece of tape. Keep the sensor cable tight to
allow passage through drop pipe bushings.
For VF meters: Push the sensor assembly all the
way into separator/spindle assembly and then
tighten the set screw to secure the position of the
sensor assembly.
Note: The sensor cable must be positioned as
shown.
Then tie the sensor cable to the magnet end of the
vertical shaft to assist in pulling the cable through.
Leave approximately a 4” tale from the knot to the
end connector so that magnet and cables can pass
through the drop pipe end. At last, reinstall the
propeller and separator/spindle assembly.
STEP 4: Reassemble the gearbox assembly.
Before you begin, make sure the gearbox or drop pipe and separator/spindle assembly are dry and free of oil.

30119-50 Rev. 2.2 | 23JUL2020
Page 8
INSTALLATION
STEP 5: Connecting the sensor wires
The connection shown below is typical of all Water Specialties Electronic Propeller Flow Meters.
a. Clean the meter head surface of all dirt, glue, gaskets, etc.
b. Verify that an O-ring is installed at the bottom of the electronic register base plate.
c. Connect the sensor cable to the in-line terminal blocks.
d. Secure the electronic register to the meter head with the four 1-1/4”long screws provided (Figure18).
e. Spin the propeller and verify that the rate display responds.
a
b
c
d
NOTE: When the FlowCom is attached to the base plate, it can be oriented in four possible ways. This aects
how the register is read when the owmeter is installed in the pipe. Select the orientation you prefer as shown
below in Figure 4.
Figure 4. FlowCom Mounting Orientation
FlowCom oriented in
line with the pipe
FlowCom oriented at
90° with the pipe
Direction of water ow
x4

30119-50 Rev. 2.2 | 23JUL2020
Page 9
INSTALLATION
2.2 Mechanical-to-FlowCom Conversion Kit Installation - Remote Mount
Check the parts received against the parts list and Figure 5 and Figure 6 below. Contact the factory to report any
discrepancies.
For FlowCom models with remote: FC101-00-K, FC101-01-K, FC101-02-K, FC101-03-K with remote mount.
Refer to Figure 5 above.
Parts
Diagram Description Quantity Part Number
1 FlowCom Unit 1 FC101-01
2 Propeller Assembly 1
Bagged parts:
3 Separator 1 4-2455-2-D
4 Sensor 1 4-2745-2
5Reverse Thrust
Brg Tool 1 T2402X-1
6Magnet Wand 2 FC100-M
7 Back Plate 1 2-2731-SS
8Screws, 10-32 x
5/8 FIL HD 41-1115-10- 10B
9 O-Ring (028 Buna) 1 1-1551-2
10 O-Ring (022 Buna) 1 1-1551-24
11 Screw 8-32 x 7/16
SOC HD 8 1-1103-8-7
Figure 5. Conversion Kit for Table Shown Below

30119-50 Rev. 2.2 | 23JUL2020
Page 10
INSTALLATION
Figure 6. Conversion Kit for Tables Shown Below
For FlowCom models FC101-01-R, FC101-02-R, FC101-03-R. Refer to Figure 6 above.
Parts Diagram Description Quantity Part Number
1 FlowCom Unit 1 FC101-01
Bagged parts:
2 Grounding Kit Instructions 1 30110-18
3 Sensor 1 4-2745-2
4Magnet Wand 2 FC100-M
5 Screw 10-32 x 1.25”Long 2 10730
6 Screw 10-32 x 1.25”Long w/hole 2 10830
7 O-Ring (243 Buna) 1 1-1551-38
8Green Wire 1 1-1706-18-1
For FlowCom model FC101-00-R.
Refer to Figure 6 above.
Parts
Diagram Description Quantity Part Number
1 FlowCom Unit 1 FC101-01
Bagged parts:
3 Sensor 1 4-2745-2
4Magnet Wand 2 FC100-M
5Screw 10-32 x
1.25” Long 2 10730
6Screw 10-32 x
1.25” Long w/hole 2 10830
7 O-Ring (243 Buna) 1 1-1551-38
For FlowCom models with remote: FC101-00-R,
FC101-01-R, FC101-02-R, FC101-03-R.
Refer to Figure 6 above.
Parts
Diagram Description Quantity Part Number
1 FlowCom Unit 1 FC101-01
Bagged parts:
2Grounding Kit
Instructions 1 30110-18
3 Sensor 1 4-2745-2
4Magnet Wand 2 FC100-M
8Green Wire 11-1706-
18-1

30119-50 Rev. 2.2 | 23JUL2020
Page 11
INSTALLATION
If the submergible remote mount assembly has not already been
installed in the meter head plate, you need to assemble it. Use
Figure 7 at right as a guide for this step.
a. Follow steps 1 through 4 from section 2.1.
b. Pull the FlowCom remote cable through the assembled
submergible remote mount kit and out through the bottom.
c. Using the inline terminal, connect the FlowCom remote cable
to the sensor cable wires, matching the red wires and the
black wires.
d. Guide the inline terminal block into the neck of the drive
shaft column and screw the submergible remote mount
kit assembly into the neck of the drive shaft column while
holding the remote mount cable. Holding the remote mount
cable will prevent the twisting of the sensor cable inside the
drive shaft column which can cause the cable termination of
the inline terminal block to be pulled apart.
WARNING!
Over tightening the cable compression seal will damage the internal conductors, causing them to be crushed
and shorted together, preventing proper operation.
e. Tighten down the compression on the submergible assembly kit. Tighten only hand tight plus one half turn.
STEP 1: Install submergible remote mount kit in the meter head plate
Figure 7. Submergible Remote Mount
Assembly
a
b
remote cable
sensor cable
submergible
remote
mount kit
in-line terminal
blocks
!

30119-50 Rev. 2.2 | 23JUL2020
Page 12
INSTALLATION
Figure 8. Grounding the FlowCom Remote Mount
NOTE: Figure 8 shows grounding requirements for FlowCom registers that are remote mount,
equipped with 4-20mA, pulse, and/or used with VFD pumps.
MOUNTING SCREWS
TO THE METER HEAD
GREEN WIRE
BOTH ENDS
CRIMPED
SENSOR CABLE
* EARTH
GROUND
4-20 CABLE
ISOLATED +24 V
DC SUPPLY
TYPICAL
SCADA UNIT
(+)
(
−
)
(+)
(
−
)
*INSTRUMENT
CABINET MUST BE
EARTH GROUNDED
RED
BLACK
SHIELD
(SILVER)
GROUND WIRE
JUMPER
NOTE: Grounding schemes
may vary depending upon
site characteristics and
installation complexity.
STEP 2: Test the FlowCom.
Test the conversion by spinning the propeller by hand and ensuring the display changes. Install the meter into the line and
mount the remote FlowCom in a convenient location.
STEP 3: Ground the Flowcom.
Following the Grounding Kit Instructions, connect the ground wire to the Flowcom and other systems that may be attached.
i

30119-50 Rev. 2.2 | 23JUL2020
Page 13
Output Wiring Connection
3.0 OUTPUT WIRING CONNECTION
3.1 Wiring Diagrams
Figure 9. Output Type: 4-20mA Current Loop (Meter-mounted version)
Housing Label:1 (Figure 11)
Instrument
(-)
(-)
(+)
(+)
Isolated
Power Supply
12-40VDC
RED
(
+
)
BLACK
(
-
)
FC100 Output Cable
GND GND
Note: This Side Is Already
Connected Internally To
Ground
Figure 10. Output Type: Optically Isolated Connection
Housing Label: 1 (Figure 11)
(+)
(-)
Power Supply
12-40 VDC
FC100 Output Cable
WHITE
(
+
)
GREEN (-)
PULSE OUT
COMMON
5K
Note: Power Supply Does Not
Have To Be Isolated From The
Ground
4-20mA NPN OC □OPT
12-30V MAX. 50V 50 mA
RED+ BKL - WHT+ GRN -
Checked if Optically Isolated
Figure 11. Enclosure Label 1
“4-20mA / OC”
FC101 Output Cable
FC101 Output Cable

30119-50 Rev. 2.2 | 23JUL2020
Page 14
Output Wiring Connection
Figure 12. Output Type: Open Collector Powered by Instrument with Internal Resistor
Housing Label: 2 (Figure 14)
(+)
PLC or Counter with
Isolated Power Supply
12-40VDC
FC100 Output Cable
(-) WHITE (+)(OC+)
GREEN (-)(OC-)
Notes:
Power Supply Must Be Isolated.
Open Collector Only To Be Used With
Battery-Powered Units.
Figure 13. Output Type: Dry Contact Switch Closure
Housing Label: 2 (Figure 14)
Instruments That
Accept Switch
Closure Inputs,
e.g. Irrigation
Controllers
FC100 Output Cable
WHITE (COMMON)
BROWN (N.C)
GREEN (N.O)
4-20mA RELAY MAX. 30V 1A
12-30V WHT - COMMON
RED+ BKL - GRN - NO BRN - NC
Figure 14. Enclosure Label 2
“4-20mA / Switch Closure”
FC101 Output Cable
FC101 Output Cable

30119-50 Rev. 2.2 | 23JUL2020
Page 15
Output Wiring Connection
*IMPORTANT NOTES: 4-20mA Current Loop In Presence Of Environmental Noise (VFDs, RF Transmitters etc.)
• The +24VDC Power Supply must be isolated by insuring that the -24VDC is NOT tied to earth ground
• To ensure that the power supply for 4-20mA output loop is properly isolated from the earth ground, check voltage
between earth ground and negative power supply terminal. You should see oating values, in approximate range of
4V to 8V.
• The shield for theWiegand sensor must be connected to earth ground. Insure the shield for the sensor is not connected
to VSS.
• To locate good earth ground, measure impedance between any of the non-powered 4-20mA terminals and the chosen
ground spot. The ohmmeter should show a very low reading, lower than 1Ω.
Figure 15. Output Type 4-20mA Current Loop (Remote-mounted version) In The Presence Of
Environmental Noise (VFDs, RF Transmitters, etc.)
*IMPORTANT: SEE NOTES.
Housing Label: 1 (Figure 11)
EB420-02
Board
Wiegand
Sensor
Red to VCC
Black to IO-2

30119-50 Rev. 2.2 | 23JUL2020
Page 16
Output Wiring Connection
3.2 4-20mA Connection To Water Specialties Instrumentation
IN60 – Flow Computer
Connection To Connection
IN60 Term. Strip Pin 16 (Iso. +12 VDC) FC101 Output Cable Red (+)
IN60 Term. Strip Pin 4 (input) FC101 Output Cable Blk (-)
IN41 – 10” Chart Recorder
Connection To Connection
IN41 TB-2 (-) FC101 Output Cable Red (+)
IN 41 TB-2 (+) Separate 24 VDC Supply (+)
Separate 24 VDC Supply (-) FC101 Output Cable Blk (-)
IN48 – 12” Chart Recorder (Sold After 05/1993)
Connection To Connection
IN48 J11 (+) FC101 Output Cable Red (+)
IN48 J11 (-) IN48 J2 (-)
IN48 J2 (+) FC101 Output Cable Blk (-)
IN48 – 12” Chart Recorder (Sold Before 05/1993)
Connection To Connection
IN48 J6 (+) FC101 Output Cable Red (+)
IN48 J6 (-) IN48 J10 (-)
IN48 J10 (+) FC101 Output Cable Blk (-)
250 Ohm resister from IN48 J6 (+) and IN48 J6 (-)

30119-50 Rev. 2.2 | 23JUL2020
Page 17
Output Wiring Connection
3.3 LCD Output Symbol Clarications
The 4-20mA full scale is not dened and the
4-20mA loop is either powered or not powered.
There is no 4-20mA output and the “4-20mA”
symbol is o.
The 4-20mA full scale is dened and the 4-20mA
loop is powered.
There is a 4-20mA output and the “4-20mA”
symbol is on.
The 4-20mA full scale is dened and the 4-20mA
loop is powered, but the output value is over
21.5mA.
There is a 4-20mA output and the “4-20mA”
symbol is ashing.
The pulse increment value is not dened. There is no pulse output and the “PULSE” symbol
is o.
The 4-20mA loop is not powered, the pulse
increment value is dened and the pulse type
is set as an optically-isolated open collector or a
relay switch.
There is no pulse output and the “PULSE” symbol
is ashing.
The 4-20mA loop is not powered, the pulse
increment value is dened and the pulse type is
set as an open collector.
There is a pulse output and the “PULSE” symbol
is on.
The 4-20mA loop is powered, the pulse increment
value is dened and the pulse type is set as an
optically-isolated open collector or a relay switch.
There is a pulse output and the “PULSE” symbol
is on.
The 4-20mA loop is powered, the pulse increment
value is dened and the pulse type is set as an
optically-isolated open collector or a relay switch,
but the output frequency is greater than the limit
of the selected pulse type.
There is a pulse output and the “PULSE” symbol
is ashing.
The battery level is ok. The “BAT” symbol is o.
The 4-20mA loop is either powered or not
powered, and battery level meets low battery
criteria.
The “BAT” symbol is on.
SCENARIO RESULT
FC101 Screen Symbols
Figure: 28
PULSE SYMBOL
BATTERY SYMBOL
FLOW RATE UNIT
FLOW TOTAL MULTIPLIERFLOW TOTAL UNIT
FLOW TOTAL DIGITS
FLOW RATE DIGITS
4-20mA SYMBOL

30119-50 Rev. 2.2 | 23JUL2020
Page 18
PROGRAMMING
4.0 PROGRAMMING
4.1 Accessing The Conguration Menu
Hold the magnetic wand as noted in Figure 27 below. After ve seconds the register will display “Loc-Code”. A lock code of
01000 is required to enter the conguration menu. Use the magnetic wand to input the lock code and then pass the
wand over the“P” symbol to submit the lock code and the conguration menu will appear. The register will switch back to
run mode by either selecting the run mode from the conguration menu or by not activating the conguration menu for
sixty seconds.
Figure 16. Magnetic Wand Activation Points For Conguration Menu
4.2 Document Changes
Each register ships with two silver identication labels. The label contains basic setting information for the register. If
changes are made to the register settings the labels should be marked as required. Forward the changes to the factory so
the records can be updated.
P
Magnetic Activation Point for
Conguration Menu Access
Approx. 7/8”
Loc-Code
NOTE: The lock code
“Loc-Code” is 01000
