Medela Lactina User manual

EFFICIENCY
EN Instructions for use – home use |SV Bruksanvisning –hemmabruk
DA Brugsanvisning –til hjemmebrug |FI Käyttöohjeet –kotikäyttö
NO Bruksanvisning –til hjemmebruk |PL Instrukcja obsługi – użytkowanie w domu
Lactina®

Thank you for choosing the Lactina Breastpump. Breastmilk is the natural choice for your baby, but
there are reasons and situations where breastfeeding is not possible. For over 50 years, it has been
Medela’s conviction that these mothers and babies can be supported. In close co-operation with
breastfeeding experts, Medela, one of the market leaders, has researched and developed breast-
pumps that perfectly meet breastfeeding mothers’ needs. For mothers who insist on the best for
their babies and themselves. Because you care.
Tack för att du valt Lactina bröstpump. Bröstmjölk är det naturliga valet för ditt barn, men det kan
finnas olika anledningar till att man inte kan amma och situationer där det inte går att amma. I över
50 år har det varit Medelas övertygelse att stödja och hjälpa dessa mammor och barn. I nära
samarbete med amningsexperter har Medela, som en av marknadsledarna, bedrivit forskning och
utvecklat bröstpumpar för ammande mammors behov. För mammor som vill ha det bästa för sina
barn och sig själva. För att du bryr dig om.
Tak, fordi du har valgt Lactina-brystpumpen. Brystmælk er det naturlige valg til dit barn, men det er
ikke under alle forhold og i alle situationer, at amning er muligt. I over 50 år har Medela været
overbevist om, at det er muligt at støtte disse mødre og børn. I tæt samarbejde med ammeeksperter
har Medela, der er et af de førende navne på markedet, forsket i og udviklet brystpumper, der
fuldstændigt opfylder ammende mødres behov. Til mødre, der kræver det bedste til deres børn og
sig selv. Fordi det er vigtigt for dig.
Kiitos, että valitsit Lactina-rintapumpun. Rintamaito on luonnollinen valinta lapsellesi, mutta on
syitä ja tilanteita, jotka estävät rintaruokinnan. Medela on jo 50 vuoden ajan ollut vakuuttunut
siitä, että näitä äitejä ja lapsia voidaan tukea. Tiiviissä yhteistyössä rintaruokinnan asiantuntijoiden
kanssa markkinajohtajiin lukeutuva Medela on tutkinut ja kehittänyt rintapumppuja, jotka sopivat
täydellisesti imettävien äitien tarpeisiin. Äideille, jotka vaativat parasta lapsilleen ja itselleen.
Koska välität.
Takk for at du har valgt Lactina brystpumpe. Morsmelk er det naturlige valget for barnet ditt, men
i enkelte situasjoner er amming ikke mulig. Gjennom mer enn 50 år har det vært Medelas overbevisning
at disse mødrene og barna kan hjelpes. Medela er blant de ledende på markedet, og har i tett
samarbeid med eksperter på amming utviklet brystpumper som oppfyller behovene til ammende
mødre. For mødre som insisterer på det beste til sine barn og seg selv. Fordi du bryr deg.
Dziękujemy za wybranie odciągacza pokarmu Lactina. Mleko matki jest najlepsze dla każdego dziecka,
jednak czasami z różnych przyczyn bezpośrednie karmienie piersią nie jest możliwe. Już od ponad 50 lat
firma Medela z wielkim zaangażowaniem wspiera matki i ich nowonarodzone dzieci w takiej sytuacji.
Firma Medela, jeden z liderów rynku, we współpracy z ekspertami w dziedzinie karmienia piersią
przeprowadziła badania i opracowała odciągacze pokarmu, które są optymalnie dostosowane do
potrzeb kobiet karmiących piersią. Dla matek, które pragną tego, co najlepsze dla siebie i swoich
niemowląt. Bo Tobie zależy.

EN
04–31
SV
32–59
DA
60–87
FI
88–115
NL
116–143
PL
144–171

41. Intended use /Population – Contraindication 5
2. Meaning of symbols 6
3. Important safety information 8
4. Product description 10
5. Cleaning 12
5.1 Before using for the rst time and after every use 12
5.2 Before using for the rst time and once a day 14
5.3 Cleaning the breastpump and case 15
5.4 Disinfecting the breastpump 15
6. Preparing for pumping 16
6.1 Assembling the pump set 16
6. Preparing for pumping 18
7. Expression 20
7.1 Preparing for single pumping 20
7.3 Preparing for hands-free expression with the Easy Expression Bustier 22
7.4 Preparing for double pumping 24
7.5 Manual pumping 24
8. Storing and thawing breastmilk 26
8.1 Storage 26
8.2 Freezing 26
8.3 Thawing 26
9. Feeding breastmilk 27
10. Troubleshooting 28
11. Warranty and maintenance/disposal 29
12. Complete care during breastfeeding time 30
13. Technical specications 172
Table of Contents

5
The intended use and indications of breastpumps
Breastpumps are intended to be used by lactating women in the hospital or home
environment for expressing breastmilk. Breastpumps are indicated to alleviate the
symptoms of engorgement by expressing milk. In case of mastitis breastpumps
support the healing process by removing breastmilk from the affected breast.
Breastpumps are indicated to relieve sore and cracked nipples and to bring out at or
inverted nipples. Also breastpumps enable mothers to provide breastmilk for babies
who cannot feed directly at the breast for a variety of reasons such as latch-on prob-
lems, cleft palate or premature babies.
Intended patient population/user
Adolescent paediatric or adult lactating women. Many women nd it convenient, or
even necessary, to use a breastpump to express and store their breastmilk once
they have returned to work, are travelling or are otherwise separated from their baby.
Women are often delighted to learn that a breastpump can be used as a supplement
to breastfeeding and that some pumps are designed to mimic the suckling of a nurs-
ing baby.
Contraindications
There are no known contraindications for the Lactina breastpump.
1. Intended use /Population – Contraindication

6
2. Meaning of symbols
i
The warning symbol identies all instructions that are important for safety.
Failure to observe these instructions can lead to injury or damage to the breastpump.
When used in conjunction with the following words, the warning symbol stands for:
i
Warning
Can lead to serious injury or death.
Caution
Can lead to minor injury.
Note
Can lead to material damage.
Info
Useful or important information that is not related to safety.
Symbols on the packaging
This symbol indicates that the material is part of a recovery/recycling
process.
This symbol indicates a carton package.
This symbol indicates to keep the device away from sunlight.
This symbol indicates to handle the fragile device with care.
°C
This symbol indicates the temperature limitation for operation,
transport and storage.
This symbol indicates the humidity limitation for operation,
transport and storage.
This symbol indicates the atmospheric pressure limitation
for operation, transport and storage.
This symbol indicates to keep the device dry.

7
This symbol indicates that the packaging contains products intended to
come in contact with food according to regulation 1935/2004.
This symbol indicates unique GSI Global Trade Item Numbers (GTIN).
Symbols on the device
This symbol indicates to follow instructions for use.
0123
This symbol indicates the compliance with the essential
requirements of the Council Directive 93/42/EEC of 14 June 1993 concer-
ning medical devices.
This symbol indicates the manufacturer.
This symbol indicates do not dispose the device together with
unsorted municipal waste (for EU only).
This symbol indicates the compliance with additional USA and
Canada safety requirements for medical electrical equipment.
This symbol indicates a type BF applied part.
REF This symbol indicates manufacturer's catalogue number
of the device.
IP21 This symbol indicates the protection against ingress of solid foreign objects
and against harmful effects due to the ingress of water.
This symbol indicates the date of manufacture
(four digits for the year and two digits for the month).
This symbol indicates that the Lactina is a class II device.
This symbol indicates fuse (to identify fuse boxes or their location).

8
3. Important safety information
Failure to follow these instructions/safety information can lead to danger
from the device. Subject to technical changes.
Device
Danger of electrocution! Keep the device dry! Never immerse in water
or other liquids!
The Lactina breastpump is not heat-resistant: keep away from radiators
and open ames.
Do not expose the motor unit to direct sunlight.
There are no user-serviceable parts inside the Lactina.
Repairs must be performed only by an authorised service agency.
Do not repair yourself! No modications to the device are permitted.
Never use a damaged device. Replace damaged or worn parts.
MAX.
3000 h
The operating life of the Lactina breastpump is 3000 hours.
The service life is seven years if used normally.
Electrical use
Separation from the mains is only assured through the disconnection of the
power cord from the wall socket outlet.
Keep the power cord away from heated surfaces.
Do not reach for any electrical device if it has fallen into water.
Unplug immediately.
The Lactina breastpump should never be left unattended
when plugged into a power source.

9
3. Important safety information
Use
Use the Lactina breastpump only for its intended use as described
in this manual.
Never operate an electrical device if it has a damaged power cord,
if it is not working properly, if it has been dropped or damaged,
or dropped into water.
Do not use the Lactina breastpump while bathing or showering.
Do not use the Lactina breastpump while sleeping or overly drowsy.
Do not drive whilst hands-free pumping.
Supervision is necessary when the Lactina breastpump
is used in the vicinity of children.
Contact your lactation consultant or physician if you experience
problems or pain.
Radio frequency communications equipment such as wireless home net-
work devices, mobile phones, cordless telephones and their base stations
and walkie-talkies can affect the Lactina breastpump. Due to electro-
magnetic compatibility (EMC) a distance of at least 1 meter between the
Lactina breastpump and the wireless equipment is recommended.
Important:
l Plastic bottles and component parts become brittle when frozen and
may break when dropped.
l Also, bottles and component parts may become damaged if mis-
handled, e.g. dropped, over-tightened, or knocked over.
l Take appropriate care in handling bottles and components.
l Do not use the breastmilk if bottles or components become damaged.

10
4. Product description
Lactina reusable single or double
pump set (applied parts)
The Lactina single or double pump set is an acces-
sory for the Lactina breastpump. The pump set is
suitable for expression by using the Lactina Select
or Lactina Electric Plus. The pump set must only be
used by one mother; use by more than one mother
could pose a health risk.
The double pump set contains two pieces of each
part except for the parts shown in yellow below.
The pump set contains:
The PersonalFit breastshield, size M (24mm). You
can nd more information on the correct choice of
breastshield at www.medela.com/personalt or scan
the QR code on page 30.
1x lid with opening
810.7062
1x disc
810.0473
1x piston
810.0494
1x PersonalFit™
Connector
810.7088
1x valve head
810.0475 2x valve
membrane
820.7013
1x breastmilk bottle,
150 ml transparent
811.0020 1x cylinder
holder
810.0668
1x silicon tubing
(105 cm)
800.0828
1x stand for
150 ml bottle
810.0462 1x port cap
820.0135
1x protective cap
810.0474
1x vacuum
regulator ring
200.2775
1x PersonalFit™
Breastshield M (24 mm)
(for other breastshield sizes
see Chapter 12, page 30)
810.7084
1x rubber seal
200.2575
1x cylinder
810.0717

11
Accessories available for order can be found on page 30.
Lactina Select
600.0929
Rental pump required: Lactina Select or Lactina Electric Plus
Lactina Electric Plus
600.0930
Only Lactina Select
The Lactina Select has an additional knob for adjusting the pump speed between 40 and 60 cycles
per minute. Select a fast pumping rhythm to stimulate the milk ow. Reduce the speed when the milk
begins to ow.
Power cord
928.5013 Euro
928.5014 AUS/NZ
928.5015 UK
Socket for car
connection cable
Bottle holder
Case
800.0809
Ideal accessories
Calma – the unique breastmilk feeding solution, the ideal way to feed your child expressed breastmilk.
Calma is the result of extensive research and development.
Easy Expression Bustier makes hands-free pumping easier, especially with simultaneous expression
from both breasts. It is available in 4 different sizes (S, M, L, XL).
More information on all Medela products can be found at www.medela.com

12
4
Rinse all parts with cold,
clear water (approx. 20 °C)
for 10 –15 seconds.
Disassemble the pump set into
individual parts (see diagram).
The cylinder holder, piston/
cylinder and tubing do not
normally need to be washed.*
5.1 Before using for the rst
time and after every use
5. Cleaning
l Only use drinking-quality water
for cleaning.
l Take apart and wash all parts that come
in contact with breast and breastmilk
immediately after use to avoid dry up of
milk residues and to prevent growth of
bacteria.
Caution
i
l The pump set requires no maintenance.
l Take care not to damage parts of the
pump set during cleaning.
l If the individual parts of the pump set are
cleaned in a dishwasher, parts may be
discoloured by food pigments. This has
no impact on the function.
lInspect the tubing after each pumping
session for condensation and/or milk.
Follow the instructions on page 28 if
there is condensation or milk in the
tubing.
* Medela recommends to clean all parts
of the pump set (incl. piston/cylinder,
etc.) before used for the rst time as
shown in Chapter 5.2.
Note
1

13
5
3
Dry with a clean cloth or
leave to dry on a clean cloth.
If you clean the individual parts
of the pump set in the dish-
washer, place them on the top
rack or in the cutlery section.
Clean all parts with plenty
of warm water and basic dish-
washer agent (approx. 30 °C).
2
Rinse all parts with cold,
clear water (approx. 20 °C).
or
As an alternative to steps 2, 3 and 4.
6

14
5. Cleaning
Dry with a clean cloth or
leave to dry on a clean cloth.
Disassemble the pump set
into individual parts.
The cylinder holder, piston/
cylinder and tubing do not
normally need to be washed.*
5.2 Before using for the
rst time and once a day
More information on page 12, Chapter 5.1. Steps 2–4
1
3
l Only use drinking-quality water
for cleaning.
l Take apart and wash all parts that come
in contact with the breast and breastmilk
immediately after use to avoid dry up of
milk residues and to prevent growth of
bacteria.
lfor chapter 5.3 Cleaning
the breastpump:
Unplug the breastpump before cleaning.
Caution
i
lfor step 2a (Chapter 5.2):
When boiling, a teaspoon of citric acid
may be added to the water to avoid a
build-up of limescale.
l Store the pump set in a clean bag/con-
tainer until next use. Or store it in clean
paper or a cloth.
lfor step 1 (Chapter 5.3):
Unplug the breastpump before cleaning.
l Do not spray or pour liquid directly onto
the pump.
* Medela recommends to clean all parts
of the pump set (incl. piston/cylinder,
etc.) before used for the rst time as
shown in Chapter 5.2.
Note

15
1
Wipe off the pump and case with
a clean, damp (not wet) cloth.
Water and basic dishwasher
agent or non-abrasive detergent
may be used.
5.3 Cleaning the breastpump
and case
2b
Use QuickClean bags* in
the microwave in accordance
with the instructions.
2a
Cover all parts with water
and boil for ve minutes.
or
* Accessories available for order can be found on page 30.
For more information please refer to www.medela.com
1
Wipe off with a clean, damp
(not wet) cloth. Alcohol based
disinfecting agent may be used.
1
5.4 Disinfecting
the breastpump
disinfect

16
4
Screw the bottle onto
the connector.
6.1 Assembling
the pump set
6. Preparing for pumping
Carefully push the membrane
onto the valve head until
it engages.
1
l Wash hands thoroughly (at least one
minute) with soap and water before
touching the breast, clean pump parts
and clean pump set.
Caution
i
l Use Medela original accessories only.
l Check pump set components for wear
or damage before use.
Note
l Carry out all the steps with care and
assemble the pump set correctly.
Otherwise a good vacuum may not be
achieved.
Info
i

17
56
3
Insert the tubing into
the corresponding opening
in the connector.
Slide the piston into the cylinder.
Push the valve head and
membrane onto the connector.
 Position valve head laterally.
Push the breastshield onto
the connector.
2

18 7
Screw the piston/cylinder
rmly into the cylinder holder.
6. Preparing for pumping
10
Push the piston into the rubber
clamp on the pump arm until
it engages.
lfor step 12 (chapter 6.1):
Use only the power cord that comes
with Lactina.
l Make sure the voltage of the power cord
is compatible with the power source.
Warning

19
Rotate the cylinder holder
until the pin sits in the slot
on the Lactina.
8
Insert the cylinder holder incl.
piston/cylinder vertically into
the opening on the front of
the Lactina.
Insert adapter end of tubing
into opening in cylinder holder.
12
Plug the power cord into
the mains socket.
9
11

20
Insert the port cap into the
unused opening of the cylinder
holder.
7.1 Preparing for
single pumping
7. Expression
1
4
Set the vacuum regulator ring to
minimum.
The Lactina Select has an
additional knob for adjusting
the pumping speed.
lbefore step 2 (chapter 7.1):
Wipe the breast with a warm
annel (do not use alcohol).
lfor step 2 (chapter 7.1):
Answer the following questions to nd
out whether the available breastshield
size will t:
lIs the nipple moving freely in
the tunnel?
lIs minimal or no areolar tissue being
pulled into the tunnel of the
breastshield?
lDo you see a gentle, rhythmical motion in
the breast with each cycle of the pump?
lDo you feel the breast emptying all over?
l Is your nipple pain-free?
If the answer to any of these questions
is “No” or if you experience problems
or pain during expression, consult your
breastfeeding and lactation consultant
or midwife.
lfor step 3 (chapter 7.1):
Do not hold the pump set by the bottle.
This can lead to blockage of the milk
ducts and engorgement.
lfor step 1 (chapter 7.2):
Select a fast pumping rhythm on the
Lactina Select to start the milk ow.
Reduce the speed when the milk begins
to ow.
Caution
