Medeli DP370 User manual

Owner’s Manual
DIGITAL PIANO
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 1 17/1/4 14:34

INFORMATION FOR YOUR SAFETY!
THE FCC REGULATION WARNING (for USA)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Unauthorized changes or modification to this system can
void the user's authority to operate this equipment.
CAUTION
The normal function of the product may be disturbed by
Strong Electro Magnetic Interference. If so, simply reset
the product to resume normal operation by following the
owner's manual. In case the function could not resume,
please use the product in other location.
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe place for future reference.
Power Supply
When removing the electric plug from an outlet, always hold
the plug itself and not the cord.
Do not connect the instrument to an electrical outlet using a
multiple-connector or an AC outlet of voltage other than that
for which your instrument is intended.
Remove the electric plug from the outlet when the
instrument is not to be used for extended periods of time, or
during electrical storms.
Connections
Before connecting the instrument to other devices, turn off
the power to all units. This will help prevent malfunction and
/ or damage to other devices.
Location
Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:
Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields
Interference with other electrical devices
Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable
distance from radios and televisions.
Cleaning
Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into the
instrument. If this happens, remove the electric plug from
the outlet. Then have the instrument inspected by qualified
service personnel.
Disconnect all cables before moving the instrument.
2
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 2 17/1/4 14:34

Contents
3
DSP Effect...........................................................................21
Reverb Type........................................................................21
Reverb Level........................................................................21
Chorus Type........................................................................21
Chorus Level.......................................................................21
MIDI IN................................................................................21
MIDI OUT.............................................................................22
Touch...................................................................................22
Language............................................................................22
PowerOff.............................................................................22
Register Memory
Registering the Panel Setting..............................................23
Recalling the Registered Panel Settings.............................23
Selecting a Registration Bank.............................................23
Song Recording
Start Recording...................................................................24
Stop Recording...................................................................25
Playback Recording............................................................25
Delete User Song................................................................25
Song
Listening to the songs.........................................................26
Song Control.......................................................................26
Practice the song................................................................26
Restore Factory Setting...............................................26
Connecting USB Flash Drive
USB Flash Drive Operation.................................................27
Play......................................................................................27
Save....................................................................................28
Load....................................................................................28
Delete..................................................................................29
Format.................................................................................29
Keyboard and ASCII Character Relative Table...................29
MIDI
What's MIDI?.......................................................................30
MIDI Terminals.....................................................................30
Downloading Data from the Computer................................30
Troubleshooting.............................................................31
Specifications.................................................................31
Appendices
Voice List.............................................................................32
Style List..............................................................................37
Song List.............................................................................39
Chord List............................................................................41
MIDI Implementation Chart.................................................42
Scale Tuning System...........................................................43
Panel & Display Description
Front Panel............................................................................4
LCD Display...........................................................................4
Rear Panel............................................................................5
Setup
Setup Guide..........................................................................6
Connections
Power Jack............................................................................9
Connecting a pair of Headphones.........................................9
Connecting an Audio Equipment...........................................9
Connecting an MP3/CD Player.............................................9
Connecting a Computer......................................................10
Connecting external MIDI devices.......................................10
Adjusting the Master Volume......................................11
Adjusting the Voice Brilliance....................................11
Playing the Demo Song................................................11
Playing Voices
Playing Voices.....................................................................12
Playing two voices simultaneously-DUAL...........................12
Playing Different Voices with Both hands-LOWER.............12
Twinova.............................................................................13
Auto Accompaniment
Play Auto Accompaniment(rhythm track only).....................13
Play Auto Accompaniment(all tracks)..................................13
Accompaniment Sections....................................................14
Playing Different Accompaniment Sections.........................14
Accompaniment Volume.....................................................15
Chord Fingering..................................................................15
Tempo.................................................................................16
One Touch Setting...............................................................16
Metronome..........................................................................16
Mixer..................................................................................17
Other Functions
Tune....................................................................................18
Transpose...........................................................................18
Split Point............................................................................19
Beat Type............................................................................19
Beat Volume........................................................................19
Harmony Switch..................................................................19
Harmony Type.....................................................................19
Scale Switch........................................................................21
Scale Type...........................................................................21
Scale Root...........................................................................21
EQ Type...............................................................................21
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 3 17/1/4 14:34

Panel & Display Description
4
Front Panel
LCD
1. [VOLUME] Knob
Adjust master volume
2. [BRILLIANCE] Knob
Adjust voice brilliance
3. USB device socket
Insert a USB flash drive
12. [FILL C] button
A Fill-in C plays
13. [FILL D] button
A Fill-in D plays
14. [ACC VOL] button
Adjust ACCOMP volume
15. [TEMPO+/-] button
Adjust the current tempo
17. A.B.C. MODE lamp
Indicate A.B.C. mode status:
on or off
18. FULL RANGE MODE lamp
Show if the full range mode is
on or off
19. LCD
Show all the parameters related
to the current operation
39. [POWER] button
Turn the power on or off
When [SHIFT] key pressed
4. Style button
Enter the style mode
When [SHIFT] key released
4. Style direct button
Select a direct style
5. [FUNCTION+/-] button
Enter function menu
6. [MIXER] button
Enter mixer menu
SONG MODE:
7. [START/STOP] button
Start or stop playing the song
8. [PAUSE] button
Pause the playing song
or start it
9. [REPEAT A/B] button
Set the beginning and the
end for a loop section of a
selected song
10. [REW] button
Rewind the song
11. [FF] button
Fast forward the song
16. [MELODY OFF L/R] button
Use to mute/activate left or
right-hand part, allowing each
part to be practiced separately
STYLE MODE：
7. [START/STOP] button
Start or stop playing the
style
8. [SYNC START] button
Turn the Sync Start on
and off
9. [INTRO/ENDING] button
Play the Intro or Ending
10. [FILL A] button
A Fill-in A plays
11. [FILL B] button
A Fill-in B plays
16. [CHORD MODE] button
Choose chord mode
1. Chord display area
Display chord information.
2. Instant message area
Display the current tempo, measure, memory/O.T.S setting.
3. Status display area
Display the status of function, USB drive, USB, etc.
4. System message display area
Display important messages related to the current operation.
I.e. in voice mode, it displays the voice name and number.
1
56
789 12 13 14 15 16
17
10 11
18
19
24
001
原声大钢琴
186
弦乐合奏
211
小号
226
铜管合奏
244
高音萨克斯
276
甜蜜长笛
286
甜蜜排箫
624
二胡
048
放克电钢琴
062
颤音琴
079
手摇风琴
100
手风琴
108
尼龙吉他
167
小提琴USB设备 双音色
记忆库 存储 M1 M2 M3 M4 单触键设置
下音色
歌曲
双钢琴 八度 节拍器 切换
录音 伴奏音轨 旋律音轨 1旋律音轨 2旋律音轨 3旋律音轨 4旋律音轨 5
示范曲
是
/
016
16拍1
055
慢民谣
095
电子舞曲1
154
波沙诺瓦
172
华尔兹
186
进行曲
203
中国民乐摇滚 调音台
001
8拍民谣
启动 / 停止 同步启动 前奏 / 尾奏 插入 A 插入 B 插入 C 插入 D 伴奏音量
音量 明亮度
暗 亮最小 最大
功能
速度 和弦模式
旋律关闭
左手/右手
自动低音和弦模式
全键盘模式
否
/
339
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 4 17/1/4 14:34

AUX IN MIDI IN MIDI OUTAUX OUT USB
RECORD
Panel & Display Description
Rear Panel
When [SHIFT] key pressed
21. [DEMO] button
Enter demo mode and play
demo songs
25. [VOICE] button
Enter the voice mode
32. [RECORD] button
Enter record mode
33. [ACCOMP] button
Select the accomp track to
record
34~38. MELODY 1-5 button
Select the melody1-5 track
to record
When [SHIFT] key released
21. [SONG] button
Enter song mode and play songs
25. Voice direct button
Select a direct voice
32. [BANK] button
Select a bank to store settings
33. [STORE] button
Register the current panel settings
34~37.M1~M4 button
Recall the registered panel settings
38. [O.T.S] button
Turn one touch setting on and off
40. AUX IN jack
41. AUX OUT jack
42. MIDI IN jack
43. MIDI OUT jack
44. USB jack
45. Soft Pedal
When you step on the soft pedal, all notes
played on the keyboard will have a softer
effect.
46. Sostenuto Pedal
When you step on the sostenuto pedal, the
notes played before you step on the pedal
would have a sustain effect.
47. Sustain Pedal
When you step on the sustain pedal, all
notes played on the keyboard will have a
longer sustain. It also supports the
half-pedal operation. Performing with the
sustain pedal will achieve a smoothly effect.
5
24
2726 28 29 30 31
32 33 34 35 36 37 38
23
22
20
21
20. [USB DEVICE] button
Enter USB DEVICE menu
22. Data dial
Increase and decrease the value
23. [+/YES] button
Increase the value
24. [-/NO] button
Decrease the value
26. [DUAL] button
Turn the Voice R2 on and off
27. [LOWER] button
Turn the Voice L1 on and off
28. [TWINOVA] button
Turn the TWINOVA on and off
29. [OCTAVE] button
Set octave in TWINOVA mode
30. [METRO] button
Turn the metronome on and off
25
Pedal
40 41 42 43 44
45 46
31. [SHIFT] button
Press and hold it to access
secondary functions of other
buttons
47
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 5 17/1/4 14:34

Setup
This section contains information about setting up your instrument and preparing to play. Please go through this section
carefully before turning the power on.
Setup Guide
Before you proceeding to assemble the stand, get a Philip's
screwdriver (not supplied).
Make sure you have the following parts, which are supplied into
package.
810
7 9
6
1
2
3
4
5
6
7
8
9
10
Piano body
Left leg component
Right leg component
Foot pedal
Rear board
Foot pedal cable
Hand screws (4pcs)
Screws M6x45 (4pcs)
Tapping screw 4x15 (8pcs)
Screw caps (4pcs)
1
2
3
6
5
4
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 6 17/1/4 14:34

A. Put the foot pedal unit (4) in between the left and right leg
components (2&3) use 4 pieces of screws (8) (2 on each
side) to stable the legs onto the foot pedal unit. (Make sure
the direction of the placement is correct before screwing)
B. Use 8 pieces screw (9), make the rear board fixed on the
footpedal unit (4) and right leg component (3), the left leg
component (2) finished in part B on the previous page.
C. Put the piano body (1) on the top of the assembly finished in
part B, use 4 pieces of hand screws (7) to stable afterward.
7
Setup
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 7 17/1/4 14:34

D. After the initial set-up, connect pedal cable (6) with the foot
pedal to the bottom-panel pedal jack.
E. Installation is completed now.
Play the piano and enjoy the perfect performance.
8
Setup
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 8 17/1/4 14:34

Power Jack
Power Supply
1. Make sure that the piano is turned off. Before you switch the
piano on or off , turn down the volume of piano and any
connected audio equipments first.
2. Connect the power cable to the AC outlet.
3. Press the [POWER] button, the LCD will display “LOADING...”,
which indicates the piano has powered on.
4. If you are ready to turn off the piano, press the [POWER] button
again.
Notes:
1. The piano will be automatically shut down in about 30 minutes if it
is not used.
2. When the keyboard is not in use or during thunderstorm, please
disconnect the power for safety purpose.
Connecting a pair of Headphones
A standard pair of stereo headphones can be plugged in here for
private practice or late-night playing.
Jack1: when a pair of headphones is plugged into the jack 1, the
sound can be heard from both headphones and speakers of
the instrument.
Jack2: when a pair of headphones is plugged into the jack 2,the
internal stereo speaker system is automatically shut off. The
sound can only be heard from headphones.
Note:
To avoid the risk of hearing loss when using headphones, please
do not play the piano with a high volume level for a long time.
Connecting an Audio Equipment
The rear-panel AUX.OUT jack delivers the output of the instrument
for connection to a keyboard amplifier, a mixing console, or tape
recorder. Use an audio cord to plug into the AUX.OUT jack located
on the rear panel then plug the other end of the cord into AUX.IN of
the amplifier.
Note:
To avoid damaging the speakers, please ensure that the volume
has been set to the minimum level before connecting the power
and other devices.
Connecting an MP3/CD Player
Connect the audio output of an MP3/CD player or other audio
source to the stereo AUX.IN jack on the rear panel.
The input signal is mixed with the piano signal, allowing you
to play along.
Connections
9
VOLUME
MIN MAX
Jack1
Jack2
AUX IN MIDI IN MIDI OUTAUX OUT USB
AUX IN MIDI IN MIDI OUTAUX OUT USB
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 9 17/1/4 14:34

AUX IN MIDI IN MIDI OUTAUX OUT USB
Connecting a Computer
You can use the USB Connector to receive MIDI messages from
computer or transmit MIDI messages to computer.
You can use a commercially available MIDI interface to connect the
piano to the computer via the MIDI connectors.
Note:
Do not set the USB device to be input and output simultaneously
when setting the software on PC. Otherwise the sound will be
overlapped when playing the keyboard.
Connecting external MIDI devices
You can use standard MIDI cables to connect external MIDI
devices.
MIDI IN: Receive MIDI message from an external MIDI device.
MIDI OUT: Transmits MIDI message generated by the instrument.
MIDI THRU: Simply relays the MIDI message received at MIDI IN.
Note:
To avoid damages, please be sure to turn off the power switches
before you disconnect the related devices from the keyboard.
Connections
10
MIDI OUT MIDI IN
MIDI OUTMIDI IN
AUX IN MIDI IN MIDI OUTAUX OUT USB
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 10 17/1/4 14:34

Rotate the [VOLUME] knob to right, the volume increases and vice
versa.
Slide the [BRILLIANCE] knob to right, the voice sounds brighter
and vice versa. You can change the piano brilliance as you wish.
The instrument features 5 wonderful demos. Please refer to Demo List.
1. Holding down the [SHIFT] button, then press the [DEMO] button to
start the demo song playing, and the LCD will display the number
and name of the demo.
2. Beats Flashing
During demo playback, the LED indicator of [START/STOP] will flash
with the current tempo, red for strong beat and green for weak beat.
3. You can use the data dial, [+/YES] / [-/NO]button to select a demo
song.
4. Holding down the [SHIFT] button, then press the [demo] button or
press the [START/STOP] button directly to stop playing and exit the
demo mode.
Note:
1. In demo mode, only the following button functions will be available:
[DEMO], [START/STOP], [ TEMPO+/-], [+/YES], [-/NO], Data dial,
[VOLUME], [BRILLIANCE], and [POWER].
All other buttons and the keyboard function will become invalid.
2. In recording, style or song mode, the LED indicator of
[START/STOP] will flash with the current tempo.
Adjusting the Master Volume
Adjusting the Voice Brilliance
Playing the Demo Song
11
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 11 17/1/4 14:34

The instrument features 600 exceptionally realistic voices. Please
refer to Voices List.
Playing Voices
1. In idle status, holding down the [SHIFT] button, then press one of
the voice direct button to enter the voice mode. LCD will display
the name and number of the current voice and highlights “R1”.
2. Use the data dial, [+/YES]/ [-/NO] button to select the voice you
want to play. You can also use the voice direct button to select a
voice.
3. You can play the keyboard and listen to the wonderful voice.
Note:
When the Dual and Lower functions are on, hold down [SHIFT]
button, then press one of the voice select buttons to shift the voice
source between R1, R2 and L1. The selected one will be highlighted
on LCD.
Playing two voices simultaneously-DUAL
1. In idle mode, press [DUAL] button to turn on dual voice. LCD
displays current voice name and number, and highlights “R2”.
2. When “R2” is highlighted, use the data dial, the [+/YES], [-/NO]
button or voice direct button to select the dual voice you want to
play.
3. Play the keyboard, you will hear two different voices sounded
simultaneously in a layer. It seems like two instruments playing at
the same time.
Note:
When the keyboard has been split, only the right hand area will play
the dual voice.
Play Different Voices with Both
hands-LOWER
1. In idle mode, press [LOWER] button to turn on lower voice. The
keyboard is split into two independent areas, which have different
voices. LCD displays the left hand voice name and number, and
highlights “L1”.
2. When “L1” is highlighted, use the data dial, the [+/YES], [-/NO]
button or voice direct button to select the lower voice you want to
play.
3. Play the keyboard with both hands, and you will hear two different
voices from the two areas.
Note:
The right hand voice does not change when you change lower voice.
Split Point
The Point on the keyboard that separates voice L1 and voice R1/R2 is
called the "split point". The split point is set to F#3/G3 at the factory
setting. However you can set this to any key you want. Please refer to
KeySplit setting for split point.
Playing Voices
12
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 12 17/1/4 14:34

The twinova mode splits the keyboard into two independent areas,
which have the same pitch and voice, for the convenience of
one-to-one teaching.
1. In idle mode, press [TWINOVA] button to turn on twinova. LCD
highlights “TWINOA”. In twinova mode, dual voice and lower
voice are unavailable. The default split point is E3 (32). Press
[TWINOVA] button again you can exit twinova.
2. In twinova mode, the default voice of right hand and left hand is the
upper voice you select before entering twinova mode. Use the data
dial, the [+/YES], [-/NO] button or the voice direct button to choose
voice.
3. In twinova mode, press [OCTAVE] button, LCD temporarily displays
the octave value of twinova. Now you can use the data dial, the
[+/YES], [-/NO] button to set octave value of twinova. The range of
octave is -1 to 1.
Note:
1. In the song playing mode, the twinova is invalid.
2. Please refer to Split Point setting to set the split point.
The auto accompaniment feature puts a full backing band at your
fingertips. To use it, all you have to do is to play the chords with your
left hand using your selected accompaniment style, and then the
accompaniment will automatically play along, instantly following the
chords you play. With auto accompaniment, even a solo performer can
enjoy playing with the backing of an entire band or orchestra.
This keyboard features 240 (including 10 user styles: 231-240) styles
in a variety of musical genres. Try to select some of the different styles
(refer to Style List) and enjoy the auto accompaniment.
Play Auto Accompaniment(rhythm track
only)
1. In idle mode, when pressing [SHIFT] button, press any of the style
direct button to enter the style mode. LCD displays the name and
number of the current style.
2. Use the data dial, the [+/YES], [-/NO] button or the style direct
button to choose style.
3. Press the [START/STOP] button to start the rhythm tracks of the
auto accompaniment. Also you can press [SYNC START] and then
play any key to start the rhythm tracks of the auto accompaniment.
Play Auto Accompaniment(all tracks)
1. In style mode, press [CHORD MODE] button to enter “auto bass
chord” (A.B.C.)mode. The “FINGERED” LED on the panel will light
up. The keyboard is split into two areas. Play chords in the left hand
area.
Press [CHORD MODE] button again to enter “full range” mode. The
“FULL RANGE” LED on the panel will light up. You can play chords
over the entire keyboard in normal fingering.
Twinova
Auto Accompaniment
13
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 13 17/1/4 14:34

Auto Accompaniment
2. Press [SYNC START] button , and then play a chord in the chord
area to start auto accompaniment of all tracks. When you change
a chord, the accompaniment automatically changes.
Alternatively, press [START/STOP] button to start auto accompani-
ment of rhythm track, then play a chord in the chord area. It will start
auto accompaniment of all tracks
Accompaniment Sections
There are various types of Auto Accompaniment sections that allow
you to vary the arrangement of the accompaniment to match the song
you are playing.
They are: Intro, Main (A,B,C,D), Fill (A, B,C,D), and Ending.
By switching among them during your performance you can easily
produce the dynamic elements of a professional sounding
arrangement in your performance.
INTRO Section
The intro is an opening section of the song. When the intro pattern
finished, the system will automatically shift to the main section.
MAIN Section
The main is an important section of the song. And it plays an accom-
paniment pattern and repeat infinitely until another section's button is
pressed.
FILL IN Section
Auto fill in function automatically adds a fill to your performance. When
the fill-in is finished, accompaniment shifts to the Main section
(A,B,C,D).
ENDING Section
Ending is used for the ending of the song. When the ending is
finished, accompaniment automatically stops. The length of the ending
differs depending on the selected style.
Note:
During style playback, hold down one of the FILL [A]-[D] buttons, and
the selected fill-in pattern will play continuously until the button is
released.
When style stops, press one of the FILL [A]-[D] buttons to select a
main section. The corresponding LED will light up.
Playing Different Accompaniment Sec-
tions
1. Press style direct button or use the data dial, [+/YES]/[-/NO] button
to choose style.
2. Press [CHORD MODE] button to enter A.B.C. (auto bass chord)
mode.
3. Press [SYNC START] button.
4. Press [FILL A] button.
5. Press the [INTRO/ENDING] button. Now “A” LED flashes on panel,
the style is ready to play.
6. It will start the accompaniment as soon as you start playing in
Chord section. When the playback of the intro is finished, it
automatically leads into Main A section.
14
SYNC
START
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 14 17/1/4 14:34

Auto Accompaniment
7. Press the [FILL B] / [FILLDC] / [FILL D] button. A fill-in plays,
automatically followed by the Main B/C/D section.
8. Press the [INTRO/ENDING] again will lead it into the Ending
Section. When the ending is finished, the auto accompaniment
automatically stops.
Accompaniment Volume
This function is used to change the volume of all tracks of accompani-
ment.
Press [ACC VOL] button, the LCD will display ACCOMP volume (from
0 to 127). At this time, you can use the data dial, or [+/YES]/[-/NO]
button to adjust accomp volume.
Chord Fingering
How the chords are played or indicated with your left hand (in the
auto accompaniment section of the keyboard) is referred to as
"fingering". There are 2 types of fingerings as described below.
Chord Basics
A chord, in music, is any harmonic set of three or more notes that is
heard as if sounding simultaneously. The most frequently encountered
chords are triads. A triad is a set of three notes that can be stacked in
thirds. When stacked in thirds, the triad's members, from lowest
pitched tone to highest, are called: the Root, the Third, and the Fifth.
Triad Type
There are following basic triad types:
Chord Inversion
We define this chord its root is not in the bass (i.e., is not the lowest
note) as an inversion chord. When the root is in the bass, we call the
chord: root-position chord. If we put the Third and Fifth in the root
position, then it forms “Inversion”, we call this chord “Inversion Chord”.
See the following major triad and its inverted chord.
Chord Name
The chord name contains two parts content: Chord root and Chord
type.
Single Finger
Single-finger makes it simple to produce major, seventh, minor and
minor seventh chords by pressing a minimum number of keys on the
auto accompaniment section.
15
Major Triad
Minor Triad
Augmented
Triad
Diminished
Triad
A root with a major third added above and a perfect fifth
will consist as a “Major Triad”.
A root with a minor third added above and a perfect fifth
will consist as a “Minor Triad”.
A root with a major third added above and an
augmented fifth will consist as an “Augmented Triad”.
A root with a minor third added above and a diminished
fifth will consist as a “Diminished Triad”.
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 15 17/1/4 14:34

Auto Accompaniment
Multi-finger
Multi-finger allows you to play chords in normal fingering. Try playing
the 32 chord types in C scale as listed on the right.
Note:
In full range mode, the entire keyboard will only recognize chords
played in normal fingering.
Tempo
Each style of the instrument has been set with a default or standard
tempo, however, this can be changed by using the [TEMPO+]/
[TEMPO-] buttons.
1. Use the [TEMPO+] or [TEMPO-] button to change the tempo. While
the tempo data is flashing, use the data dial also can change the
tempo.
2. Press the [TEMPO+]/[TEMPO-] buttons simultaneously to restore
the default tempo setting.
One Touch Setting
When One Touch Setting is switched on, you can instantly recall all
auto accompaniment related settings including voices selection and
digital effects simply with a single touch of a button.
1. Press the [O.T.S.] button to turn on the One Touch Setting for
current style.
2. Press one of the one touch setting buttons [M1]-[M4]. Various panel
settings (such as voice, effect, etc.) that match the selected style
can be instantly recalled with just a single button press.
Auto accompaniment is automatically turned on during O.T.S mode.
3. Play the keyboard.
One Touch Setting parameter list:
Part ON/OFF (VOICER1, R2, L1)
Voice Change (VOICER1, R2, L1)
Voice Volume (VOICER1, R2, L1)
Voice Reverb Level (VOICER1, R2, L1)
Voice Chorus Level (VOICER1, R2, L1)
Metronome
Using metronome helps you with beat that guides your playing by
preset tempo.
1. Turn on the metronome
Press the [METRO] button to turn the metronome on.
2. Turn off the metronome
Press the [METRO] button again to turn the metronome off.
3. Metronome beat type setting
Please refer to beat type setting.
Note:
The metronome will respond in the next beat if it is turn on when the
accompaniment is playing.
When recording, metronome beats cannot be recorded.
16
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 16 17/1/4 14:34

Mixer function adjusts separately the volume of different tracks.
1. Press the [MIXER] button.
Now you have entered the menu of mixer. Press the [MIXER] button
repeatedly to select a track to change its volume.
2. To adjust the selected volume setting, please use the data dial or
the [+/YES]/[-/NO] button.
Press [+/YES] and [-/NO] button simultaneously to turn off a track
volume.
Press[+/YES]and[-/NO] button simultaneously again to turn on a
track volume.
The option and parameters are as follows:
Mixer
17
Option
Rhythm slave volume
Rhythm master volume
Bass volume
Chord 1 volume
Chord 2 volume
Chord 3 volume
Phrase 1 volume
Phrase 2 volume
Voice R1 volume
Voice R2 volume
Voice L volume
Disk volume
LCD display
Slave Rhythm:
Master Rhythm:
Bass:
Chord1:
Chord2:
Chord3:
Phrase1:
Phrase2:
Upper1:
Upper2:
Lower:
Disk Vol:
xxx
xxx
xxx
xxx
xxx
xxx
xxx
xxx
xxx
xxx
xxx
xxx
Range
0 - 127
0 - 127
0 - 127
0 - 127
0 - 127
0 - 127
0 - 127
0 - 127
0 - 127
0 - 127
0 - 127
0 - 127
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 17 17/1/4 14:34

Press [FUNCTION+/-] button to enter function menu. The default
option of the menu is "Tune". When you enter the menu next time,
you will find the option is the same as last time. Use [FUNCTION+/-]
button to select the option to set. Use [+/YES]/[-/NO] or data dial to
set parameter of the current menu.
The option and parameters are as follows:
Tune
This function sets the pitch of entire keyboard in 2-cent increments.
1. Press [FUNCTION+/-] button to select tune menu. LCD displays
“Tune: xxx ”. Use [+/YES]/[-/NO] or data dial to change tune value.
Its range is from -50 to 50.
2. Press [+/YES] and [-/NO] simultaneously will set the tune value to
its default setting:000.
Transpose
Transpose function allows the overall pitch of the instrument to be
transposed up or down by a maximum of one octave in semitone
steps.
1. Press [FUNCTION+/-] button to select transpose menu. LCD
displays “Transpose: xxx”. Use [+/YES]/[-/NO] or data dial to
change transpose value. The max transpose is±12 semitones.
2. Press [+/YES]/[-/NO] simultaneously will set the transpose value to
its default setting:000.
Other Functions
18
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
Option
Tune
Transpose
Split Point
Beat Type
Beat Volume
Harmony Switch
Harmony Type
Scale Switch
Scale type
Scale Root
EQ type
DSP Effect
Reverb Type
Reverb Level
Chorus Type
Chorus Level
MIDI IN
MIDI OUT
Touch
Language
Power Off
Default
+00
+00
034
004
090
OFF
Duet
OFF
Pythagor
C
Reset
ON
Hall2
070
Chorus1
000
ALL
001
002
English
030
Range
-50~+50
-12~+12
1~88
0，2~9
0~127
OFF，ON
Duet, 1+5, Octave, CtryDuet, Trio,
Block, 4Close1, 4Close2, 4Open
OFF，ON
Pythagor, Major, Minor, MeanTone,
Werckmei, Kirnberg
C，C#，D，D#，E，F，F#，G，G#，
A，A#，B
Reset, Pop, Rock, Class, Jazz, Dance
OFF，ON
Room1, Room2, Room3, Hall1, Hall2,
Church, Delay, PanDelay
0~127
Chorus1, Chorus2, GM Chrs1, GM
Chrs2, Flanger1, Flanger2,Rotary1,
Rotary2
0~127
1~16，ALL
1~16
OFF，1，2，3
中文，English
OFF，30，60
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 18 17/1/4 14:34

Other Functions
SplitPoint
This function sets the point that separates the entire keyboard to two
sections.
1. Press [FUNCTION+/-] button to select SplitPoint menu. LCD
displays “SplitPt: xxx”. Use [+/YES]/[-/NO] or data dial to change
SplitPoint value. The range of keyspilit: 1~88.
2. Press [+/YES] and [-/NO] simultaneously will set the SplitPoint value
to its default setting: F#3(34).
Note:
When twinova is on, the range of keysplit is C3~C6(28~64). Press
[+/YES] and [-/NO] simultaneously will set the SplitPoint value to its
default setting: E3(32).
Beat Type
1. Press [FUNCTION+/-] button to select BeatType menu. LCD
displays “BeatType: xxx”. Use [+/YES]/[-/NO] or data dial to change
beat type. The range of beat type: 0, 2~9.
2. Press [+/YES] and [-/NO] simultaneously will set the beat type value
to its default setting: 4.
Beat Volume
1. Press [FUNCTION+/-] button to select beat volume menu. LCD
displays “BeatVol: xxx”. Use [+/YES]/[-/NO] or data dial to change
beat volume. The range of beat volume: 0~127.
2. Press [+/YES] and [-/NO] simultaneously will set the beat volume
value to its default setting: 090.
Harmony Switch
1. Press [FUNCTION+/-] button to select harmony switch menu. LCD
displays “HarmonySw: xxx”. Use [+/YES]/[-/NO] or data dial to
change harmony switch status: OFF,ON.
2. Press [+/YES] and [-/NO] simultaneously will set harmony switch to
default setting: OFF.
Playing with harmony:
Turn on the A.B.C function, then play a chord in the left hand area.
When you play in the right hand area, it will automatically add a
harmony effect to the notes.
Harmony types “1+5” and “octave” are always available, while the rest
are effective only when A.B.C is on.
Harmony Type
You can add a variety of harmony notes to the keys you played in the
right-hand section.
1. Press [FUNCTION+/-] button to select harmony type menu. LCD
displays “HarmonyTp: xxx”. Use [+/YES]/[-/NO] or data dial to
change harmony type.
19
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 19 17/1/4 14:34

Other Functions
There are 9 harmony types built into this instrument.
2. Press [+/YES] and [-/NO] simultaneously will set harmony type to
default setting: Duet.
Scale Switch
The equal temperament (has only one tuning method, and is suitable
for keyboard instrument) is commonly used in modern music, based
on this temperament method to make your own composition and
performance. Especially for piano, equal temperament is widely used
and taken for granted. But people used several other scales to
compose and perform before adopting the equal temperament.
1. Press [FUNCTION+/-] button to select scale switch menu. LCD
displays “ScaleSw: xxx”. Use [+/YES]/[-/NO] or data dial to change
Scale switch status: OFF, ON.
2. Press [+/YES] and [-/NO] simultaneously will set scale switch to
default setting: OFF.
Scale Type
1. Press [FUNCTION+/-] button to select scale type menu.
LCD displays “ScaleType: xxx”. Use [+/YES]/[-/NO] or data dial to
change scale type.
There are 6 scale types built into this instrument.
2. Press [+/YES] and [-/NO] simultaneously will set scale type to
default setting: Pythagor.
Scale Root
1. Press [FUNCTION+/-] button to select scale root menu.
LCD displays “ScaleRoot: xxx”. Use [+/YES]/[-/NO] or data dial to
change scale root: C, C#, D, D#, E, F, F#, G, G#, A, A#, B.
2. Press [+/YES] and [-/NO] simultaneously will set scale root to
default setting: C.
20
Parameter
Duet
1+5
Octave
Country Duet
Trio
Block
4 Close 1
4 Close 2
4 Open
LCD Display
Duet
1+5
Octave
CtryDuet
Trio
Block
4Close1
4Close2
4Open
Parameter
Pythagorean
Pure Major
Pure Minor
Meantone
Werkmeister
Kirnberger
LCD Display
Pythagor
Major
Minor
MeanTone
Werckmei
Kirnberg
C
M
Y
CM
MY
CY
CMY
K
Aw_DP370_Manual_G07_161223.pdf 20 17/1/4 14:34
