INFORMATION FOR YOUR SAFETY!
THE FCC REGULATION WARNING (for USA)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Unauthorized changes or modification to this system can
void the user's authority to operate this equipment.
CAUTION
The normal function of the product may be disturbed by
Strong Electro Magnetic Interference. If so, simply reset
the product to resume normal operation by following the
owner's manual. In case the function could not resume,
please use the product in other location.
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe place for future reference.
Power Supply
When removing the electric plug from an outlet, always hold
the plug itself and not the cord.
Do not connect the instrument to an electrical outlet using a
multiple-connector or an AC outlet of voltage other than that
for which your instrument is intended.
Remove the electric plug from the outlet when the
instrument is not to be used for extended periods of time, or
during electrical storms.
Connections
Before connecting the instrument to other devices, turn off
the power to all units. This will help prevent malfunction and
/ or damage to other devices.
Location
Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:
Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields
Interference with other electrical devices
Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable
distance from radios and televisions.
Cleaning
Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into the
instrument. If this happens, remove the electric plug from
the outlet. Then have the instrument inspected by qualified
service personnel.
Disconnect all cables before moving the instrument.
2
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:20

Contents
3
Panel Description
Front Panel....................................................................................................................................4
Rear Panel.....................................................................................................................................4
Setup.............................................................................................................................................6
Part List..........................................................................................................................................6
Setup Guide...................................................................................................................................7
Power Supply.................................................................................................................................8
Connections.................................................................................................................................9
Connecting a pair of Headphones.................................................................................................9
Connecting an Audio Equipment...................................................................................................9
Connecting an MP3/CD Player......................................................................................................9
Connecting a Computer.................................................................................................................9
Adjusting the Volume................................................................................................................10
Listening to the Song................................................................................................................10
Playing Demo song......................................................................................................................10
Playing Song................................................................................................................................10
Practice Song...............................................................................................................................10
Playing Voices ............................................................................................................................11
Selecting Voice.............................................................................................................................11
Playing two Voice Simultaneously................................................................................................11
Playing a Lower Voice..................................................................................................................11
Playing Voice Demo.....................................................................................................................11
Touch Response..........................................................................................................................11
Digital Effects.............................................................................................................................12
Reverb and Chorus Effect............................................................................................................12
EQ Effect..........................................................................................................................12
Metronome..................................................................................................................................12
Tempo...........................................................................................................................................12
Transpose...................................................................................................................................13
Tune.............................................................................................................................................13
Beep Tone...................................................................................................................................13
Troubleshooting.........................................................................................................................14
Specifications.............................................................................................................................14
Appendices.................................................................................................................................15
Voice List......................................................................................................................................15
Song List......................................................................................................................................17
Demo List.....................................................................................................................................18
MIDI Implementation List.............................................................................................................19
.........................................................................................................................4
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:22

SopSax
TenoSax
SwOboe
PanFl
Piano
Piano2
EPiano
EPiano2
Harpsic
Clavi
MBox
Vibraph
Marimba
DrawOr
PercOr
ChurOr
RockOr
Acordio
Harmnic
StStr
StStr2
SynStr
ChoAah
SweetTp
ChurOr2
ReedOr
Panel Description
Front Panel
1
2
3
4
5
4
1. MASTER VOLUME
Adjust the master volume.
2. START/STOP Button
Start/stop the song playing.
3. FUNCTION Button
Hold down this button and press the special keys to
realize different functions.
4. L/R Button
In song mode, you can press [L/R] button to select
which hand to practice.
5. VOICE SELECT Key
Hold down the [FUNCTION] button and press the
key to select a voice.
6. SONG SELECT Key
Hold down the [FUNCTION] button and press the
key to select a song.
7. TEMPO ADJUST Key
Hold down the [FUNCTION] button and press the
key to adjust the current tempo.
8.AUX IN Jack
Connect an external sound source, such as an MP3 or
CD player.
9. AUX OUT Jack
Connect the audio equipment.
10. MIDI IN Interface
Connect the MIDI OUT of other device to the MIDI
IN jack on the rear panel.
11. MIDI OUT Interface
Connect the MIDI IN of other device to the MIDI
OUT jack on the rear panel.
12. USB-MIDI Interface
Connect to a computer.
67
Rear Panel
8 9 121110
MIDI OUT
MIDI IN
AUX OUTAUX IN USB
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:22

EQ
1 2 3
VOICE
DEMO
BEEP
Panel Description
5
13 14 15 16
13. METRONOME Key
Hold down the [FUNCTION] button and press the
[ON/OFF] key to turn the metronome ON or OFF.
Hold down the [FUNCTION] button and press the
other key to select the time signature.
14. REVERB Key
Hold down the [FUNCTION] button and press the
[ON/OFF] key to turn reverb effect ON or OFF.
Hold down the [FUNCTION] button and press the
other key to select the reverb type.
15. CHORUS Key
Hold down the [FUNCTION] button and press the
[ON/OFF] key to turn chorus effect ON or OFF.
Hold down the [FUNCTION] button and press the
other key to select the chorus type.
16. TOUCH Key
Hold down the [FUNCTION] button and press the
key to select different touch response level.
17. EQ Key
Hold down the [FUNCTION] button and press the
key to select the EQ type.
18. TRANSPOSE Key
Hold down the [FUNCTION] button and press the
key to adjust the transpose value from -12 to 12
semitones.
19. TUNE Key
Hold down the [FUNCTION] button and press the
key to adjust the tune value from -50 to 50 (stand
for -100 to 100 cents).
20. VOICE DEMO Key
Hold down the [FUNCTION] button and press the
key to start/stop the voice demo playing.
21. BEEP Key
Hold down the [FUNCTION] button and press the
key to turn the prompt tone ON or OFF.
22. POWER ON / OFF
Turn the power ON or OFF.
17 18 19
15
23. SOFT Pedal
Step on the soft pedal, all notes played on the
keyboard would have a softer effect.
24. SOSTENUTO Pedal
Step on the sostenuto pedal, the notes played
before you step on would have a sustain effect.
25. SUSTAIN Pedal
Step on the sustain pedal, all notes played on the
keyboard would have a longer sustain.
23 24 25
20 21
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:23

Setup
This section contains information about setting up your instrument and preparing to play. Please go through this section carefully
before turning the power on.
Part List
6
Before you proceeding to assemble the stand, get a Philip's
screwdriver (not supplied).
Make sure you have the following parts, which are supplied into
package.
34
5
6
7
8
9
2
1
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
10
11
Piano Body
Right Leg Component
Left Leg Component
Tapping Screw 4x20 (9pcs)
Foot Pedal Unit
Screw 6x40 (4pcs)
Foot Pedal Cable
Rear Board
Hand Screws (2pcs)
Screws M6x12 (2pcs)
Screw Rubber Cap (6pcs)
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:24

Setup
B. Use 9 pieces screw, make the Rear board fixed on the Foot
pedal unit and right leg component, the left leg component
finished in part A on the previous page.
7
C. Put the piano body on the top of the assembly finished in part B,
use 2 pieces of hand screws and 2 pieces of screws M6x12
to stable afterward.
A. Put the foot pedal unit(6) in between the left and right legs
components, use 4 pieces of screws(2 on each side) to
stable the legs onto the foot pedal unit. (Make sure the direction
of the placement is correct before screwing)
Setup Guide
6
11
11
11 6
6
6
11
11
11
4
4
4
9
9
10
10
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:24

SopSax
TenoSax
SwOboe
PanFl
Piano
Piano2
EPiano
EPiano2
Harpsic
Clavi
MBox
Vibraph
Marimba
DrawOr
PercOr
ChurOr
RockOr
Acordio
Harmnic
StStr
StStr2
SynStr
ChoAah
SweetTp
ChurOr2
ReedOr
EQ
1 2 3
VOICE
DEMO
BEEP
Setup
Power Supply
1. Make sure that the piano is turned off. Before you switch your
piano on or off, turn down the volume of piano and any connected
audio equipments first.
2. Connect the power cable to the AC outlet.
3. Press the [POWER] button, the LED display will lights up, that
indicates the piano has power on.
4. If you are ready to turn off the piano, press the [POWER] switch
again.
Notes:
1. In order to save energy, we have designed the “Automatic
Power Off” function to the piano. With this function, the keyboard
will be powered off automatically when being idle for more than 30
minutes. If you want to temporary disable this function, just press
and hold the first white key on the left from keyboard and turn the
power on simultaneously.
2. When the piano is not in use or during thunderstorm, please
disconnect the power for safety purpose.
8
D. After the initial set-up, connect pedal cable in the foot pedal unit
to the bottom-panel PEDAL jack.
7
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:25

Connections
Connecting a pair of Headphones
A standard pair of stereo headphones can be plugged in here for
private practice or late-night playing.
Jack1:
sound can be heard from headphones and speakers of the
instrument.
Jack2: When a pair of headphones is plugged into Jack 2, the internal
stereo speaker system is automatically shut off . The sound can
be heard from headphones.
Note：
Do not listen with the headphones at high volume for long periods of
time. Doing so may cause hearing loss.
When a pair of headphones is plugged into the Jack 1, the
Connecting an Audio Equipment
The rear-panel AUX OUT jack delivers the output of the instrument for
connection to a keyboard amplifier, stereo sound system, a mixing
console, or tape recorder. Use an audio cord to plug into the AUX OUT
jack located on the rear board then plug the other end of the cord into
AUX IN of the amplifier.
Note:
To avoid damaging the speakers, please ensure that the volume has
been set to the minimum level before connecting the power and other
devices.
Connecting a Computer
Connect PC or other USB host devices that support USB audio.
For devices with USB cable, you can simply connect the MIDI/USB
converter to your USB connector on the device and plug the USB cable
into the piano, after the driver is installed and initialization is finished,
you can choose USB Audio Device in the device menu of the software
to transfer midi data.
Note:
Do not select USB audio device in both of input and output setting
together, otherwise the sound overlaps.
9
Connecting an MP3/CD Player
Connect the audio output of an MP3/CD player or other audio source
to the stereo AUX IN jack on the rear panel.
The input signal is mixed with the piano signal, allowing you to play
along.
Jack 1
Jack 2
MIDI OUT
MIDI IN
AUX OUTAUX IN USB
MIDI OUT
MIDI IN
AUX OUTAUX IN USB
MIDI OUT
MIDI IN
AUX OUTAUX IN USB
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:27

Adjusting the Volume
While holding down the [FUNCTION] button, press [L/R] button to
start the demo song playing. And all the LEDs on the panel will flash
simultaneously.
Do it again or press [Start/Stop] button to stop playing, and the LED
will stop flash.
Note:
The keyboard would be disabled when the demo song is playing.
Listening to the Song
10
Rotate the [VOLUME] knob rightwards, the volume increases and vice
verse.
Playing Demo song
Playing Song
There are total 60 songs in this digital piano (see Appendix).
Each song can be practiced in the MELODY OFF mode.
Start Song
While holding down the [FUNCTION] button, press [Start/Stop]
button to start the song playing. All songs will be played in a loop.
Loop
While only press [Start/Stop] button, it will play the current song
repeatedly.
Stop Song
Press [Start/Stop] button to stop the song playing.
Select Song
While holding down the [FUNCTION] button, press corresponding
keys in SONG selection area to select your desired song.
Note:
1. Press [song +] and [song –] keys simultaneously to select the first
song.
2. If you want to select song by the number keys, you should input 2
numbers. For example, if you want to select the eighth song, you
should input “08”.
Practice Song
In the song mode, you can press [L/R] button to select which
hand to practice and the status switch as following.
RL
L ON
R ON
R RL L
L ON L OFF
R OFF R ON
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:27

Selecting Voice
Playing two Voice Simultaneously
11
You can play two voices synchronously on the keyboard by selecting a dual
voice.
While holding down the [FUNCTION] button, press 2 keys simultaneously
in voice selecting area. Press the first key to select the upper voice, press
the second key to select the dual voice.
Notes:
While dual voice is turned on, lower voice would be turned off automatically.
Playing a Lower Voice
While holding down the [FUNCTION] button, select the Lower on the
keyboard. This will select Strings as lower voice and split the keyboard
at F#3 automatically.
Playing Voices
Split Pt
Lower
Touch Response
While holding down the [FUNCTION] button, press a key in the
TOUCH selecting area to select different touch response level.
OFF
1: Soft
2: Medium
3: Hard
SopSax
TenoSax
SwOboe
PanFl
Piano
Piano2
EPiano
EPiano2
Harpsic
Clavi
MBox
Vibraph
Marimba
DrawOr
PercOr
ChurOr
RockOr
Acordio
Harmnic
StStr
StStr2
SynStr
ChoAah
SweetTp
ChurOr2
ReedOr
SopSax
TenoSax
SwOboe
PanFl
Piano
Piano2
EPiano
EPiano2
Harpsic
Clavi
MBox
Vibraph
Marimba
DrawOr
PercOr
ChurOr
RockOr
Acordio
Harmnic
StStr
StStr2
SynStr
ChoAah
SweetTp
ChurOr2
ReedOr
SopSax
TenoSax
SwOboe
PanFl
Piano
Piano2
EPiano
EPiano2
Harpsic
Clavi
MBox
Vibraph
Marimba
DrawOr
PercOr
ChurOr
RockOr
Acordio
Harmnic
StStr
StStr2
SynStr
ChoAah
SweetTp
ChurOr2
ReedOr
SopSax
TenoSax
SwOboe
PanFl
Piano
Piano2
EPiano
EPiano2
Harpsic
Clavi
MBox
Vibraph
Marimba
DrawOr
PercOr
ChurOr
RockOr
Acordio
Harmnic
StStr
StStr2
SynStr
ChoAah
SweetTp
ChurOr2
ReedOr
SopSax
TenoSax
SwOboe
PanFl
Piano
Piano2
EPiano
EPiano2
Harpsic
Clavi
MBox
Vibraph
Marimba
DrawOr
PercOr
ChurOr
RockOr
Acordio
Harmnic
StStr
StStr2
SynStr
ChoAah
SweetTp
ChurOr2
ReedOr
Playing Voice Demo
VOICE
DEMO
BEEP
The instrument features 26 exceptionally realistic voices for you to choose.
Please refer to Voice List.
While holding down the [FUNCTION] button, press corresponding key in
voice selecting area to select the voice you want.
Now, You can play the keyboard and listen to the wonderful voice.
Note:
1.While changing a voice, pay attention to the rules: While holding down
the [function]button, and press the same key again, the voice will be
changed between the upper and lower key. When the upper/lower voice is
on, and then you press another voice key, the corresponding upper/lower
voice will be selected.
2.While voice is selected, the dual voice and lower voice will be turned off
automatically.
While holding down the [FUNCTION] button, press VOICE DEMO key
to start the demo for the selected voice.
Do it again to stop the voice demo playing.
This instrument contains 26 voice demos.
Note:
In voice demo mode,the keyboard will be not available。
VOICE
DEMO
BEEP
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:27

12
Digital Effects
While holding down the [FUNCTION] button, press the corresponding
keys in REVERB and CHORUS effect setting area to select the voice
effect type.
Metronome
Turn on the metronome:
While holding down the [FUNCTION] button, press METRONOME
ON/OFF key to turn the metronome ON or OFF.
Select different time signature:
While holding down the [FUNCTION] button, select a demanded time
signature by pressing the corresponding keys in metronome setting
area. There are 6 types of time signature: 0, 2, 3, 4, 5, 6.
Select metronome voice:
While holding down the [FUNCTION] button, press VOCAL key to
select meteronome voice: human voice and normal voice.
Tempo
While holding down the [FUNCTION] button, press corresponding keys
in TEMPO selection area. You can change the tempo by input number
or using tap tempo, or press tempo +/- keys to change current tempo.
Notes:
1. Press [tempo +] and [tempo –] keys simultaneously to set the tempo
value back to the default (120).
2. The tempo range is :30 ~ 280
3. If you want to change tempo value by the number keys, you should
input 3 numbers. For example, if you want to set the tempo value as
85, you should input “085”.
Reverb and Chorus Effect
EQ Effect
Chorus Value:
OFF
1: Light Chorus
2: Medium Chorus
3: Deep Chorus
4: Flanger
Reverb Value:
OFF
1: Room
2: Small Hall
3: Large Hall
4: Stadium
The equalizer is the function of adjusting the sound value of the gain
spectrum, gain setting can bring a different sound field effect.
This instrument contains 3 sets of equalizer for you to choose.
While holding down the [FUNCTION] button, press the corresponding
keys in EQ setting area to select the EQ type.
EQ Type:
1:Standard
2:Classical
3:Modern
EQ
1 2 3
EQ
1 2 3
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:27

While holding down the [FUNCTION]button, press transpose +/- key to
adjust the transpose value from -12 to 12 semitones.
Note:
Press [transpose +] and [transpose –] keys simultaneously to set the
transpose value back to the default (0 semitone).
Transpose
Tune
13
While holding down the [FUNCTION] button, press tune +/- key to
adjust the tune value from -50 to 50 (stand for -100 to 100 cents).
Note:
Press [tune +] and [tune –] keys simultaneously to set the tune value
back to the default (0 cent).
Beep Tone
While holding down the [FUNCTION] button, press beep key to turn the
Beep Tone ON or OFF. The default setting is ON.
If you turn on the beep tone, you can hear a beep sound when you
press a valid functional key while the [FUNCTION] button is held down.
VOICE
DEMO
BEEP
VOICE
DEMO
BEEP
VOICE
DEMO
BEEP
VOICE
DEMO
BEEP
VOICE
DEMO
BEEP
VOICE
DEMO
BEEP
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:28

Troubleshooting
Problem
The speakers produce a “pop” sound whenever the
power is turned ON or OFF.
No sound when the keyboard is played.
When using a mobile phone, noise is produced.
Possible Cause and Solution
This is normal and is no cause for alarm.
Make sure the voice volumes are set at appropriate levels.
Using a mobile phone in close proximity to the instrument
may produce interference. To prevent this, turn off the
mobile phone or use it further away from the instrument.
Specifications
Keyboard
88 Hammer-Action keys
Polyphony
128
Voice
26
Demo
1
Song
60
Tempo
30-280
Control Button
Power On/Off switch, Volume, Function,
Start/Stop, L/R
14
Control Key
Voice Select Keys, Song Select Keys, Song +/-,
Tempo Tap, Tempo +/-, Tempo Number Keys,
Metronome On/Off, Metronome select keys, Reverb
On/Off, Reverb Type Select Keys, Chorus On/Off,
Chorus Type Select Keys, Touch On/Off, Touch Select
Keys, Transpose, Tune, Vocal, EQ Type Select Keys,
Voice Demo,Beep .
Connectors
Headphones (2 standard. ¼” phone), AUX IN, AUX
OUT, USB, Pedals (Sustain, Soft, Sostenuto), MIDI IN,
MIDI OUT
Power Supply
AC 220~240V, 50Hz, 60W
Speaker
8Ω 20W X 2
8Ω 25W X 2
Weight
55Kg
Dimensions
1376(L) x 452(W) x 1008(H) mm
* All specifications and appearances are subject to
change without notice.
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:28

English Name
Grand Piano
Grand Piano 2
Ele. Piano
Ele. Piano 2
Harpsichord
Clavichord
Music Box
Vibraphone
Marimba
Drawbar Organ
Percussive Organ
Church Organ
Church Organ 2
Reed Organ
Rock Organ
Accordion
Harmonica
Stereo Strings
Stereo Strings 2
Synth Strings
Choir Aahs
Sweet Trumpet
Soprano Sax
Tenor Sax
Sweet Oboe
Pan Flute
Pro.
0
1
4
5
6
7
10
11
12
16
17
19
19
18
18
21
22
48
49
50
52
56
64
66
68
75
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
15
Voice List
No.
Piano
1
2
3
4
5
6
7
8
Chromatic Percussion
9
10
11
12
13
14
15
16
Organ
17
18
19
20
21
22
23
24
Guitar
25
26
27
28
29
30
31
32
Bass
33
34
35
36
37
38
39
40
Strings & Orchestral Instruments
41
42
43
44
45
46
47
Panel Voice List
Name
Acoustic Grand Piano
Bright Acoustic Piano
Electric Grand Piano
Honky-tonk Piano
Electric Piano 1
Electric Piano 2
Harpsichord
Clavi
Celesta
Glockenspiel
Music Box
Vibraphone
Marimba
Xylophone
Tubular Bells
Dulcimer
Drawbar Organ
Percussive Organ
Rock Organ
Church Organ
Reed Organ
Accordion
Harmonica
Tango Accordion
Acoustic Guitar (nylon)
Acoustic Guitar (steel)
Electric Guitar (jazz)
Electric Guitar (clean)
Electric Guitar (muted)
Overdriven Guitar
Distortion Guitar
Guitar Harmonics
Acoustic Bass
Electric Bass (finger)
Electric Bass (pick)
Fretless Bass
Slap Bass 1
Slap Bass 2
Synth Bass 1
Synth Bass 2
Violin
Viola
Cello
Contrabass
Tremolo Strings
Pizzicato Strings
Orchestral Harp
Pro.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
Bank
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
GM Voice List
Bank
100
100
1
100
100
1
1
100
1
1
1
100
1
1
100
1
1
100
100
1
1
100
100
1
100
1
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:28

Voice List
FX 1 (rain)
FX 2 (soundtrack)
FX 3 (crystal)
FX 4 (atmosphere)
FX 5 (brightness)
FX 6 (goblins)
FX 7 (echoes)
FX 8 (sci-fi)
Sitar
Banjo
Shamisen
Koto
Kalimba
Bag Pipe
Fiddle
Shanai
Tinkle Bell
Agogo
Steel Drums
Woodblock
Taiko Drum
Melodic Tom
Synth Drum
Reverse Cymbal
Guitar Fret Noise
Breath Noise
Seashore
Bird Tweet
Telephone Ring
Helicopter
Applause
Gunshot
Standard Set
Room Set
Power Set
Electronic Set
Analog Set
Jazz Set
Brush Set
Orchestra Set
SFX Set
Synth SFX
97
98
99
100
101
102
103
104
Ethnic Misc.
105
106
107
108
109
110
111
112
Percussive
113
114
115
116
117
118
119
120
SFX
121
122
123
124
125
126
127
128
Drums
129
130
131
132
133
134
135
136
137
16
Timpani
String Ensembles 1
String Ensembles 2
Synth Strings 1
Synth Strings 2
Choir Aahs
Voice Oohs
Synth Voice
Orchestra Hit
Trumpet
Trombone
Tuba
Muted Trumpet
French Horn
Brass Section
Synth Brass 1
Synth Brass 2
Soprano Sax
Alto Sax
Tenor Sax
Baritone Sax
Oboe
English Horn
Bassoon
Clarinet
Piccolo
Flute
Recorder
Pan Flute
Blown Bottle
Shakuhachi
Whistle
Ocarina
Lead 1 (square)
Lead 2 (sawtooth)
Lead 3 (calliope)
Lead 4 (chiff)
Lead 5 (charang)
Lead 6 (voice)
Lead 7 (fifths)
Lead 8 (bass + lead)
Pad 1 (new age)
Pad 2 (warm)
Pad 3 (polysynth)
Pad 4 (choir)
Pad 5 (bowed)
Pad 6 (metallic)
Pad 7 (halo)
Pad 8 (sweep)
48
Ensemble
49
50
51
52
53
54
55
56
Brass
57
58
59
60
61
62
63
64
Reed
65
66
67
68
69
70
71
72
Pipe
73
74
75
76
77
78
79
80
Synth Lead
81
82
83
84
85
86
87
88
Synth Pad
89
90
91
92
93
94
95
96
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
0
8
16
24
25
32
40
48
56
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
N\A
N\A
N\A
N\A
N\A
N\A
N\A
N\A
N\A
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:28

Song List
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
Name
Waltz in A Flat Op.39, No.15
The Happy Farmer
Etude
Dance Of The Four Swans From "Swan Lake"
Carmen Suite No.2 Habanera
A Little Polish Dance
Jesus Saviour Pilot Me
Old Macdonald Had A Farm
O Sole Mio
Wedding March From "Lohengrin"
2-Part Invention No.13 In A Minor BWV 784
Turkish March
Italian Polka
Musette
Bourree
To A Wild Rose
Away In A Manger
Fur Elise
Marriage Of Figaro
Angels We Have Heard On High
Waltz
America The Beautiful
Did You Ever See A Lassie
Arabesque
Old France
Santa Claus Is Coming To Town
Music Box Dancer
Symphony No.9 In E Minor Large From "The New World"
Larghetto
French Suites
Mazurka
Minuet 1
Minuet 2
Minuet 3
Minuet In G
Neapolitan Song
Prelude
Salut D' Amour
Pizzicato Polka
Piano Sonata No.11 in A major K331 I. Andante grazioso
Songs Without Words Op30 No .6 F sharp minor Venetian Gondola Song
Duke Aria From “The Rigoletto”
Burgmuller Op.100 No.15 - Ballade
Spinning Song
In The Theatre
Alfredo and Violetta Column Tower Duet
Come Back To Sorrento
Piano Sonatina In F Major
Tchaikovsky Waltz
Military March No.1 In D Major
Als Die Alte Mutter Mich Noch lehrte Singen
17
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:28

No.
52
53
54
55
56
57
58
59
60
Name
Etude on Leger Lines 1
Etude on Leger Lines 2
At the Ball
Dancing Raindrops
From a Story Book
Comin' 'Round the Mountain
Song of the Brook
Puck
Cotton-pickin' Fingers
Song List
Demo List
No.
1
Name
Fantasia
18
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:28

MIDI Implementation List chart
19
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:28

DP70U_G11
0
5
25
75
95
100
aw_DP70EU_Manual_G11_130920
2013󾾠󾾠9󾾠󾾠20󾾠󾾠 15:41:28
