OPERATION AND
MAINTENANCE MANUAL
Alterra MAXX Long Term Care Bed
FCEALTMAXX
This product is not made with natural rubber latex.
Packaging / Handling Instructions see Page 8.

2FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
TABLE OF CONTENTS
ENTRAPMENT......................................................................................................................... Page 3
Summary of FDA’s Dimensional Recommendations.......................................................... Page 4
SPECIAL NOTES AND WARNINGS ....................................................................................... Page 5
SAFETY SUMMARY AND OPERATING INFORMATION...................................................... Page 6
SPECIFICATIONS..................................................................................................................... Page 7
LOCATING THE SERIAL NUMBER......................................................................................... Page 7
PACKAGING AND HANDLING ............................................................................................... Page 8
INSTALLING OPTIONAL HEAD AND FOOTBOARDS .......................................................... Page 9
INSTALLING OPTIONAL ASSIST RAILS ............................................................................... Page 10
BED OPERATION..................................................................................................................... Page 12
ELECTRONICS ......................................................................................................................... Page 12
BATTERY BACKUP.................................................................................................................. Page 13
TROUBLESHOOTING.............................................................................................................. Page 17
ACUATOR REPLACEMENT..................................................................................................... Page 18
BED SCHEMATIC..................................................................................................................... Page 20
REPLACEMENT PARTS .......................................................................................................... Page 21
REORDER GUIDE..................................................................................................................... Page 19
MAINTENANCE....................................................................................................................... Page 24
MAINTENANCE SCHEDULE................................................................................................... Page 26
WARRANTY INFORMATION ................................................................................................. Page 28

1-800-MEDLINE (633-5463) |medline.com 3
ENTRAPMENT
WARNING: REDUCING ThE RISk OF ENTRAPMENT
Proper patient assessment and monitoring, along with proper maintenance and use of the
hospital bed system is required to reduce the risk of entrapment. The term “hospital bed
system” encompasses the bed frame and its components, including the mattress, side rails,
head and footboards and accessories to the bed. Variations in bed rail dimensions and
mattress thickness, size and/or density could increase the risk of entrapment.
The FDA and The Hospital Bed Safety Workgroup (HBSW) have developed written guidance
that outlines specific potential entrapment zones in hospital bed systems, “Hospital Bed
System Dimensional and Assessment Guidance to Reduce Entrapment”. The entrapment
zones represent the relationship of the various bed system components which are under the
control of the bed user and the healthcare facility. Compliance to the FDA guidelines to reduce
entrapment risk is ultimately the responsibility of the bed user and the healthcare facility. It
is strongly recommended that all personnel involved with hospital bed system maintenance,
service or use, should understand the FDA Guidelines. Visit the FDA website at http://www.
fda.gov to acquire a copy of the guidelines and learn about the risks of entrapment.
The Medline FCEALTMAXX bed system and corresponding rails (FCE1232RSR, FCE1232RSRN,
FCE1232RSRXT, FCEQRSIDE and FCE1232ABN) meet or exceed the FDA guidelines and are in
accordance with this document for recommended Zones 1-4 when used with Medline brand
mattresses.
The FDA guidance document also recognizes potential entrapment Zone 6, the area between
the head or foot board and the side rail, but has not yet determined proper dimensions or
requirements for safety in this zone. The document references standard IEC60601-2-38 as
a source for measurements in this area, but the FDA has not completed harmonization with
the measurements in this IEC document. The Medline side rails listed above does meet the
dimensional requirements for the Zone 6 area that are defined by IEC60601.

4FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
SUMMARy OF FDA’S DIMENSIONAL
RECOMMENDATIONS
Key zones of the bed Dimensions
Gaps within the rail (Zone 1) <120 mm (< 4 3/4 “)
Under the rail, between rail
supports or next to a single rail
support (Zone 2)
< 120 mm (< 4 3/4 “)
Between rail and mattress
(Zone 3)
<120 mm (< 4 3/4 “)
Under the rail, at the ends of
the rail (Zone 4)
<60 mm (< 2 3/8 “) AND >60° angle

1-800-MEDLINE (633-5463) |medline.com 5
SPECIAL NOTES AND WARNINGS
WARNINGS/CAUTION NOTICE in this manual applies to hazards or unsafe practices which
could result in personal injury and/or property damage.
NOTICE
The information in this document is subject to change without notice. Check all parts for
shipping damage and test before using. DO NOT USE IF DAMAGED. Contact Medline Industries
Inc. Customer Service (1-800-MEDLINE) and the freight carrier for further instruction.
Technical information regarding the bed will be available upon request. This bed has been
tested and inspected prior to shipment.
CAUTION
DO NOT OPERATE THIS BED WITHOUT FIRST READING AND UNDERSTANDING THIS
MANUAL. IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS, CAUTIONS AND
INSTRUCTIONS, CONTACT YOUR MEDLINE SALES REP OR MEDLINE CUSTOMER SERVICE
BEFORE USING THIS EQUIPMENT OTHERWISE INJURY OR DAMAGE MAY RESULT.
• DO NOT use near explosive/flammable gases
• Possiblefirehazardwhenusedwithoxygenadministeringequipmentotherthannasalor
masked types.
• Whenadministeringoxygenwithnasalormaskequipment,oxygenorairtubingMUST
be routed and secured properly to ensure tubing does not become entangled, pinched or
severed during operation of bed.
• ClosesupervisionisnecessarywhenthisproductisusedbyornearCHILDREN OR PEOPLE
WITH DISABILITIES.
• NEVER PERMIT ANYONE UNDER THE BED AT ANYTIME.
• Whenoperatingormovingthebed,ALWAYSensuretheindividualinthebedispositioned
properly within the confines of the bed.
• DO NOT allow extremities to protrude over the side of the or between the rails when
performing the bed functions.
• DO NOT move the bed while it is still plugged into the wall.
• DO NOT use the bed for anything other than its intended use.
• USE Extreme caution when using any functions of the bed near IV Poles or any other
furniture.
SAVE ThESE INSTRUCTIONS
SERVICE/MAINTENANCE PERSONNEL: The bed is a heavy piece of equipment. It is strongly
recommended that any servicing or maintenance of the bed be performed by two or more
personnel.

6FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
SAFETy SUMMARy
AND OPERATING INFORMATION
• Afterinstallationandbeforeuse,ensureallattachedhardwareissecurelytightened
• Handpendantcordmustberoutedandsecuredproperlytoensurecorddoesnotbecome
entangled, pinched, or severed during normal bed operation.
• Keepallmovingpartsfreefromobstruction(i.e.blankets/sheets,heatingblankets/pads,
tubing, wiring, etc.) or with any other products that use electric cords which could get
tangled around the bed, side rails or legs during operation of bed.
• TheAlterraMAXXbedisequippedwith TWO brakes locks; one on the head end of the
bed and one on the foot end. To operate the brake locks, press down on the red pedal
from either side of the bed. To unlock, press the green foot pedal from either side of the
bed. ALWAYS use the brake locks EXCEPT when moving the bed. Pads can be adjusted by
rotating them clockwise or counter-clockwise to ensure proper contact with floor.
• ThesiderailsareNOT intended to be used as a patient restraint. If necessary, a physician
or healthcare professional should be consulted for other means of safe restraint.
• Besuretofullylocksiderails/assistbarsinthefullyupordownposition.Failuretolock
the accessories may result in unintentional movement and injury to patient or caregiver.
• Whenusingsiderails,excessivesidepressurecancausetherailstodeformorbreak.DO
NOT USE side rails as handles to move the bed.
• NEVER permit more than 1 person in or on bed at any time. The safe working load for this
bed is rated at 600-lbs.
• Bodyweightshouldbeevenlydistributedoverthesurfaceofthebed.
• ApersonSHOULD NOT lay, sit or lean in such a way that his or her entire body weight is
placed only on the RAISED head or foot sections of the bed. This includes ASSISITING the
user in repositioning or transferring in or out of bed.
• DO NOT ALTER THE PLUG ON THE ELECTRICAL CORD. If the plug does not fit the existing
outlet, a correct outlet should be installed by a licensed electrician. NEVER operate the unit
if it has a damaged cord or plug.
• UNPLUG the power cord when performing any maintenance (including cleaning) on the
bed.
• DO NOT open or disassemble any factory sealed electronics. If these units are opened, the
warranty is void.
• DO NOT permit excessive prolong activation of the bed’s electrical function (duty cycle).
Exceeding the rated duty cycle of the electronics may cause damage or failure of bed
function.
(Duty Cycle = 10%: 2min on; 18min off)
• Ifallfourbedcastersarenotlocked,bedmovementmayoccurwithlittleornoresistance.
Always activate caster locks during patient transfer (patient movement in or out of the
bed) or use of the bed brake locks on the head and foot ends.
• Thebedisintendedforindooruseonly.
• DO NOT cover the bed’s power cord with rugs, carpet, etc.

1-800-MEDLINE (633-5463) |medline.com 7
• Inspectthebedfordamageandnormaloperationperiodically.Reportanydamage,
abnormal operation, unusual noise or odor immediately to the maintenance department
and discontinue use of the bed.
SPECIFICATIONS
Bed Deck Length Adjustable from 80” to 88”
Bed Deck Width Adjustable from 36” to 42”
Overall Width (Including Side Rails) 41” – 47” depending on width selected &
side rails mounted
Overall Length with Foot Lock Extended 92”
Overall length with Foot Lock Retracted 88-1/2”
Minimum Bed Deck Height 7-3/4”
Maximum Bed Deck Height 30-1/4”
Maximum Safe Working Load* 600-LBS
Maximum Back Angle 70-Degrees +/-3
MaximumKneeAngle 28-Degrees +/-3
Trendelenburg/Reverse Trendelenburg Angle 10-Degrees +/-2
Bed Electronics Comply with IEC60601-2 EMC requirements
* This includes weight of the resident/patient and all other accessories including but not
limited to mattresses, head/foot boards, side rails, etc.
ELECTRICAL SPECIFICATIONS
Power: 120 V.A.C., 2A, 60HZ
Duty Cycle: 10% Max. (2 min. on./18 min off)
LOCATING ThE SERIAL NUMBER
• Theserialnumberlabelislocatedonthecenteroftheleftsidebedframe.
• Pleasehavetheserialnumberandmodelnumberofthebedavailablewhencalling
Medline Customer Service for parts and/or troubleshooting.

8FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
PACkAGING/hANDLING
RECEIVING
It is imperative that all shipments are inspected within 5 days in order to make a freight claim
for any concealed damage.
1. Count cartons before signing shipping papers.
2. Compare the number of cartons shipped with the number actually received.
3. Visually inspect all cartons for any damage.
4. If number of packages shipped and received do not match up or if there is any damage to
carton, note on freight bill and have driver sign acknowledging the claim and notify your
Medline sales rep or Medline Customer Service (1-800-MEDLINE).
UNPACkING
CAUTION: The bed is extremely heavy; unpack with two or more people.
1. Remove bands and top
2. With at least TWO people, remove the bed from the carton by lifting underlying and
rotating frame of bed so the casters are facing down. Place it on level ground next to the
carton.
** If at this point, you discover concealed damage, immediately contact Medline Customer
Service and take photographs to document the damage for the freight claim.
3. Inspect plug and cord for any cuts or damage. If there isn’t any damage, plug in the bed and
elevate the bed deck to a comfortable working height.
4. Cut the cable ties only holding bed deck sections to the bed frame, being careful not to
damage cords or cables. DO NOT cut all cable ties from the bed. Cable ties are needed to
hold bed wiring in place.
5. Insert the wall guard into the head section H-frame using a rubber mallet if necessary. The
wall guard includes C clips that allow you to extend the wall guard out and hold it in place.
This allows for additional distance from the wall.
Wall Guard Fully Inserted Wall Guard Extended for added distance

1-800-MEDLINE (633-5463) |medline.com 9
INSTALLING OPTIONAL hEAD AND FOOTBOARDS
Tools Required: Philips Screw Driver, Rubber Mallet
Materials Required: Head and Footboards
The FCEALTMAXX bed comes with the necessary hardware to mount head/footboards to
the frame. When ordering head/footboards from Medline, they come with four pre-drilled
mounting holes.
hEADBOARD INSTALLATION
1. Locate and install screwcap inserts into each hole (this may require a rubber mallet). Use
caution as to not damage the surface of the head/footboard. The surface with the screw
inserts visible will be the inside of the headboard.
2. Position two L-brackets on the outside of the headboard with the “L” facing inwards.
3. Align both holes of the L-brackets with the top and bottom holes in the headboard.
4. Insert and hand tighten each 40mm pan-head screw through all four holes.
5. Slide the L-brackets into the mounting tubes on the head end of the bed. The bracket
should rest in place with the snap buttons.
6. Fully tighten each mounting screw on the L brackets.
7. Tighten knobs under each mounting tube to provide additional support.
FOOTBOARD INSTALLATION
1. Locate and install screw inserts into each hole (this may require a rubber mallet). Use
caution as to not damage the surface of the footboard. The surface with the screw inserts
visible will be the outside of the footboard.
2. Position two L-brackets on the inside of the footboard with “L” facing inward.
3. Align the both holes of the L-brackets with the top and bottom holes in the footboard.
4. Insert and hand tighten each 40mm pan-head screw through all four holes.
5. Slide the L-brackets into the mounting tubes on the foot end of the bed. The bracket should
rest in place with the snap buttons.
6. Fully tighten each mounting screw on the L brackets.
7. Tighten knobs under each mounting tube to provide additional support.

10 FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
INSTALLING OPTIONAL ASSIST RAILS
Tools Required: Adjustable Pliers
Materials Required: Assist Rails (FCE1232RSRN, FCE1232RSRXT, FCEQRSIDE, FCE1232ABN)
CAUTION: Follow the installation instructions carefully and check that all hardware/
fasteners are properly installed and tight. Failure to do so may result in unexpected movement
of the rails and could result in patient or caregiver injury
FCE1232RSRN, FCE1232RSRXT, FCEQRSIDE, or FCE1232ABN
1. 1. The side rail mounting rods come pre-installed on the head and foot sections of the
Alterra MAXX bed.
2. Tighten each mounting rod using a 5mm Allen wrench and a ½” open end wrench.

1-800-MEDLINE (633-5463) |medline.com 11
BED OPERATION
Bed functions are operated with an 11-button (5-function) hand pendant. Button functions
on the hand pendant are identified with universal icons. The hand pendant comes with a soft
hook on the back side for suspending the control on assist rails or headboards.
The hand pendant can be plugged into either side of the bed. To properly connect the
pendant, align the arrows on the bed’s connection and the pendant plug; firmly press the two
pieces together, then flip down the retaining lock.

12 FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
CAUTION: Prior to raising or lowering the bed and/or assist rails, ensure that the cord for the
hand pendant has not become entangled in bed parts. The cord should be kept clear or moving
parts at all times.
The bed has a rolling base that allows it to be rolled or locked at any height. The Alterra MAXX
bed is equipped with TWO brakes locks; one on the head end of the bed and one on the foot
end. To operate the brake locks, press down on the red pedal from either side of the bed. To
unlock,pressthegreenfootpedalfromeithersideofthebed.ALWAYSusethebrakelocks
EXCEPT when moving the bed. Pads can be adjusted by rotating them clockwise or counter-
clockwise to ensure proper contact with floor. Secure the individual locking casters.
CAUTION
If all four casters are not locked, swivel and wheel rotation will allow bed motion with little
or no resistance. This can result in loss of balance, fall and personal injury. Ensure that all
four casters are locked to avoid any bed movement during resident transfer and/or use. The
central locking mechanism can be used for most situations where locking casters are needed.
However, movement near the head section of the bed may still result if force is applied. The
bed will be most secure if the head end casters are locked along with the central lock and/or
foot end casters.
ELECTRONICS
CONTROL BOx
The picture below shows the various control box connections with actuators, hand pendant
and battery backup.

1-800-MEDLINE (633-5463) |medline.com 13
BATTERy BACkUP
In the event of a power failure, the bed comes standard with a battery backup feature that
enablesthebedtobeloweredwithoutACpower.Keepthebatterybackuppluggedinto
control box to ensure activation. Battery must be charged for a minimum of 12 hours prior to
use.
The battery backup unit will recharge when AC power is reestablished.
CAUTION
• Improperhandlingand/orexposuretoheatcouldresultinbodilyinjury.
• Thebatteryback-upisafactorysealedunit.DO NOT ATTEMPT to open/repair unit.
• Containssealedleadbattery.Batterymustberecycled.
REPLACING BATTERy
Tools Required: Flat Head Screw Driver, T25 Torx Screw Driver
CAUTION
Follow the installation instructions carefully and check that all hardware/fasteners are
properly installed and tight.
1. Disconnect AC power
2. Remove the control box cover by using a flat head screw driver. Insert the screwdriver into
the control box cover slot marked “INSERT TO OPEN”. The control box cover should now
slide away from the control box.
3. Unplug the battery backup cable from the control box. Please refer to page 13 for the
battery backup cable location on the control box.
4. Cut and remove all cable (zip) ties holding the battery backup cable.
5. Using a T25 Torx screwdriver remove the all 4 mounting screws. Support the battery when
removing the last screw. Use caution the battery backup weighs approximately 4 pounds.
6. Using a T25 Torx screwdriver install the new battery backup unit with all 4 mounting
screws.
7. Carefully route the battery backup cable from the battery to the control box. Please make
sure the cable does not get pinched or cut during normal bed operation.
8. Secure cable in place with zip-ties
9. Reconnect the battery backup cable into the control box port.
10. Replace the control box cover.
11. Reconnect AC power

14 FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
UNDER BED LIGhTING
The Alterra MAXX comes standard with LED lighting located under the center of the bed deck
on both sides. The LED lighting can be turned on using the hand pendant. The LED lighting can
assist with illuminating the surrounding areas of the bed when transitioning in/out of the bed.
BED DECk ADjUSTMENTS
The Alterra MAXX comes standard with integrated width and length adjustments to allow the
bed to widen from 36” to 39” or 42”, as well as lengthen from 80” to 84” or 88”.
To adjust the width of the bed, compress the two black handles under the bed deck section,
and pull the bed deck section to the desired width.
CAUTION
Prior to putting the bed in use, ensure that each bed deck extension piece is locked in place
and set to the same width in order to ensure for proper mattress support.
CAUTION: Do not make any adjustments while a person is in the bed.
To adjust the length of the bed, remove the mattress retainers from each corner of the bed
end that you desire to lengthen (both head and foot ends can be lengthened). Gently pull
down on the black knob and turn it ¼ turn in either direction so that the knob lock is released.
Repeat step for the other side of the bed end. Pull the bed deck out slightly and turn the black
knobs ¼ turn the opposite direction so that the knob lock will fall into place. Slowly pull the
bed deck out until the knob locks fully engage into place. Re-insert the mattress retainers into
each corner of the bed.

1-800-MEDLINE (633-5463) |medline.com 15
CAUTION
Prior to putting the bed in use, ensure that each bed deck extension piece is locked in place.
CASTER GUIDES
The Alterra MAXX is equipped with two swing down caster positioning guides located at the
head end of the bed. The caster positioning guides will keep the casters straight when flipped
down, to eliminate one swivel point and allow for ease of bed movement.

16 FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
hEAD SECTION kICkSTAND
The Alterra MAXX is equipped with a kickstand for holding up the head section of the bed for
easy access to the power cord and bed control box.
NEVER use the kickstand while anyone is in the bed. The kickstand is used for Maintenance
ONLY.
CAUTION: Make sure the kickstand is secure before reaching under the bed

1-800-MEDLINE (633-5463) |medline.com 17
TROUBLEShOOTING
Symptom Possible
Cause
Remedy/Solution
None of the func-
tions work
Hand pendant?
Is hand pendant
plugged in?
Plug in hand pendant
Did you try another
pendant from working
bed
Use different hand
pendant from a
working bed
Does the bed
have staff
control?
Are the lock-out
functions engaged?
Disengage lock-out
functions
Is the staff control
wired to the control
box properly?
Plug hand pendent
directly into “HB”
port of control box
Power?
Is the bed plugged into
an outlet?
Plug bed into wall outlet
Is the power outlet on
a switch?
Turn switch on, check fuse
box, or try another wall
outlet
Verify bed power source
(outlet) is adequate for
bed electrical rating
Has the power cord
become loose from the
control box
Insert power cord fully
into control box
Is the power cord
damaged?
Replace power cord
Functions work but
bed moves slowly Power?
Is the bed plugged into
an outlet?
Plug bed Into wall outlet
Is the power outlet on
a switch?
Turn switch on, check fuse
box, or try another wall
outlet
Verify bed power source
(outlet) is adequate for
bed electrical rating
Has the power cord
become loose from the
control box?
Insert power cord fully
into control box
Is the power cord
damaged?
Replace power cord
Grinding noise
heard from one of
the actuators
Actuator gear is
stripped
Actuator gear is
stripped, replace
actuator
Replace actuator

18 FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
TROUBLEShOOTING (CONTINUED)
Symptom Possible
Cause
Remedy/Solution
One of the actuators
is not functioning
Hand pendant?
Try another pendant
from working bed
Use a different hand
pendant from a working
bed
Actuator?
Insert actuator cord
into another working
port of the control box
If bed still isn’t functioning,
replacing acuator
Actuator cable? Verify actuator cable is
not damaged
If damaged, or Cut replace
actuator cable
Verify actuator cable
plug is inserted
completely in actuator
and control box
Push actuator cable plug
firmly into actuator/con-
trol box
Control Box
Insert actuator cord
into another working
port on the control box
If actuator works on a dif-
ferent port of the control
box
Verify it is not a hand pen-
dant issue
Replace the control box
Bed is not level
when operating
High-Low functions
Bed load is not evenly
distributed
Raise or lower bed to its
maximum or minimum
height
Actuators operate
but wrong move-
ment occurs
Control box
wiring?
Actuators are plugged
into the wrong ports
Plug actuators into proper
ports on control box
Replace control box
IF USE OF THIS TROUBLE SHOOTING GUIDE DOES NOT CORRECT THE PROBLEM, PLEASE CALL
MEDLINE TECHNICAL SUPPORT AT 1-800-MEDLINE.
CAUTION
SERVICE / MAINTENANCE PERSONNEL
The bed is a heavy piece of equipment. It is strongly recommended that any servicing or
maintenance of the bed be performed by two or more personnel.

1-800-MEDLINE (633-5463) |medline.com 19
ACTUATOR REPLACEMENT
hEAD AND FOOT ACTUATORS
1. Unplug the bed from AC power.
2. Unplug the actuator cable.
3. Remove the clevis pin, cotter pin and spacers from both the motor and piston sides of the
actuator.
Attention: Note the location of all bushings, washers, cable ties, wire routing and hardware for
proper reassembly.
4. Install the new actuator at the motor end first then piston end, using the original clevis pin,
cotter pin and any spacers that were removed in Step 3. Installing the motor end first will
reduce possible damage to spindle and piston mechanism of the actuator.
5. Plug in the actuator cable.
6. Reconnect AC power.
7. Test the bed by raising and lowering the head and foot sections
hIGh-LOW ACTUATORS
CAUTION
• RemoveALLaccessoriesmountedtothebed(assistrails,assistbarsandheadand
footboards). Failure to do so could result in the bed being unstable causing injury.
• Thebedmustbeturnedonitssidebeforereplacingactuators.Aminimumoftwopeople
are required to turn bed on its side.
• Fullyelevatethebeddeckandheadsectionbeforeturningthebedonitssidetocreatea
more stable work platform.
1. Remove all accessories mounted to the bed (assist rails, assist bars and head and
footboards).
2. Elevate the bed to its highest position and raise the head and foot sections.
3. Unplug the bed from AC power.
4. With at least TWO people, carefully turn the bed on its side.
5. Remove the clevis pin, cotter pin and spacers from both the motor and piston sides of the
actuator.
Attention: Note the location of all bushings, washers, cable ties, wire routing and hardware for
proper reassembly.
8. Install the new actuator at the motor end first then piston end, using the original clevis pin,
cotter pin and any spacers that were removed in Step 5. Installing the motor end first will
reduce possible damage to spindle and piston mechanism of the actuator.
6. Plug in the actuator cable.
7. With at least TWO people, carefully return the bed to the upright position.
8. Reconnect AC power.

20 FCEALTMAXX (PIC-xxxxx) | Revision: 01/09/17
9. Re synchronize the self leveling hi low motors by lowering the bed to its lowest position
and holding the elevation down button on the hand pendant an additional 5 seconds after
the bed has reached its lowest elevation
10. Test the bed by raising and lowering elevation.
NOTE: When replacing head and foot actuators, special care needs t be taken to secure all
wiring with cable ties as necessary to reduce strain from the actuator cables. Ensure that
cable do not get caught on any moving parts.
BED SChEMATIC
