Medline ComfortGlide User manual

USER MANUAL
MSC60090
BLOWER
Comfort Air
GLIDE
®

2
CONTENTS
Important Safeguards and Precautions............................................................3
The Purpose of this Manual...................................................................................4
Product Description – Intended Use ..................................................................4
General safety............................................................................................................4
Device Feature ...........................................................................................................4
Inflating Comfort Glide Air Sheet.........................................................................5
Maintenance & Troubleshooting ..........................................................................6
Cleaning & Disinfection Protocol .........................................................................7
General Disassembly of Parts ..............................................................................7
Specification ...............................................................................................................9
Electromagnetic Compatibility .............................................................................10
Waste Disposal .........................................................................................................13
Storage and Care .....................................................................................................14
Symbols used ............................................................................................................14
Expected Service Life .............................................................................................14
Warranty......................................................................................................................15

3
IMPORTANT SAFEGUARDS
Do not use Comfort Glide Air Blower in the presence of flammable
anesthetics.
Precaution – Comfort Glide Repositioning Sheet:
1. Caregivers must verify that all caster brakes on the bed have been
engaged prior to patient movement.
2. For safety, always use at least two people during patient movement.
3. Never leave patient unattended on an inflated device.
4. Use this product only for its intended use as described in this
manual. Do not use attachments not recommended by the
manufacturer.
5. The Comfort Glide Repositioning sheet is designed to be used with 1
Air Blower.
Precaution – Comfort Glide Air Blower - To reduce the risk of burns,
electrocution, fire or injury to persons:
1. Use this product only for its intended use as described in this
manual. Do not use attachments not recommended by the
manufacturer.
2. Never operate this product if it has a damaged cord or plug, if it
is not working properly, if it is has been dropped or damaged, or
dropped into water.
3. Keep the cord away from heated surfaces.
4. Never drop or insert any object into any openings.
5. Route the power cord in a manner to ensure it is free from hazards.
6. Disconnect from power supply circuit before opening.
7. Keep Comfort Glide Air Blower away from sources of liquid and open
flames.
8. The Air Blower needs to be used with a stable power supply or in
conjunction with a UPS.

4
THE PURPOSE OF THIS MANUAL
This operation manual is mainly focused on the set-up, cleaning and
routine maintenance of the Comfort Glide Air Blower. We
recommend keeping this manual handy to answer questions related
to the system.
PRODUCT DESCRIPTION – INTENDED USE
The Comfort Glide Air Blower is a component of the Comfort Glide air
system designed to help clinicians safely reposition and move patients.
The system has been designed to reduce risks and make patient
repositioning and transfers easier and safer.
GENERAL SAFETY
It is important to read the information in this user manual before you
use your Comfort Glide Air Blower.
Please follow the guidelines below for your added safety and
maintaining system performance.
Avoid exposing the Air Blower to flammable anesthetics.
DEVICE FEATURE
Part Identification: Handle
Air Hose
Power Switch
Power Cord Attachment
Fuses
Power Cord
Collection
Bracket
Power Cord
Carabiner Hook

5
INFLATING COMFORT GLIDE AIR SHEET
a. Patient should be in a supine position with the bed at a 0 degree
incline
b. Place Comfort Glide Air Sheet underneath the patient.
c. Place the Comfort Glide Air Blower directly on flat ground or use the
carabiner to hang the unit on the bed frame.
d. Plug the power cord into the nearest standard wall outlet
e. Connect the air hose to one side of the Comfort Glide Air Sheet air
intake opening and securely fasten into place. Choose the air input
on the side that will permit free movement of the hose.
CAUTION: It is important to routinely inspect power cable to ensure it is
not obstructed or causing a tripping hazard. Check the power cable is not
under strain or damaged.
f. If using for lateral transfer, ensure that transfer surfaces are
touching and lock all wheels.
g. Turn on the green power switch and the air blower will inflate the
Comfort Glide Air sheet. When the Comfort Glide Air sheet is fully
inflated, the sheet is ready to use and the patient can be
repositioned.
h. Ensure patient is centered on the surface prior to deflation.
i. Turn off Air Blower and raise the bed or stretcher rails.
CAUTION: Never leave the patient unattended with the Air Blower on.

6
MAINTENANCE & TROUBLESHOOTING
No daily maintenance is required. It is intended this equipment should
only be serviced by qualified and authorized technical personnel. Please
contact your Medline representative if the below troubleshooting
solutions do not work.
WARNING: Disassembly or attempts to make repairs may void
Manufacturer’s Warranty. Please consult the Statement of Warranty in
this Manual for more information.
If the problem is not resolved, please contact your Medline representative.
Fault/Problem
Description
Possible Root Cause Solution
The Air Blower does
not turn on.
The Air Blower is not receiving
power.
Check power cord plug is securely
connected and fits snugly into the
outlet. Secure plug connection and
turn on Air Blower power switch.
Blown fuses in pump and plug. Check for blown fuses in pump and
plug. Replace fuse if blown.
Power outlet is faulty. Try another power outlet.
Defective Air Blower Unit. Replace with new device.
Contact your Medline
representative.
The Comfort Glide
Repositioning Sheet
cannot be inflated.
Hose not properly connected. Verify that the hose is properly con-
nected to the Air Blower. The hose
has 2 prongs that snap into place to
connect it to the Air Blower unit.
Air Flow is not sufficient. 1. Check hose connection points
and re-connect if needed.
2. Check hose for tears or kinking.
3. Check for punctures or rips in
the Comfort Glide Air Sheet.
4. Check the air filter for re-
strictions. Clean/replace as
necessary.

7
GENERAL DISASSEMBLY OF PARTS
Before disassembling any parts, ensure that the power unit is off and
unplug the power cord from the wall outlet.
1. Changing the air hose:
a. Use a flathead screwdriver to disconnect the prongs on the hose from
the blower unit.
b. Push the hose out to replace with a new one.
CLEANING & DISINFECTION PROTOCOL
1. Please follow your facility’s guidelines for cleaning and disinfecting
the Comfort Glide Air Blower. Ensure that the power unit is off.
2. Unplug the power cord from the wall outlet.
3. Examine the surface of the Air Blower for visible dirt and other
substances.
4. Refer to your Bio-Medical Engineering or Infection Prevention
Department for your facility’s protocol for cleaning and disinfecting.
5. Perform the following steps to clean the power unit and hose fittings:
- Wipe all controls, chassis and hose fittings with a damp cloth and a
mild detergent.
- Air dry all treated surfaces.

8
2. Changing filter:
a. Unscrew 3 screws on the bottom cover.
b. Open the filter cover and identify the filter.
c. Replace the filter and assemble the parts in reverse order.

9
WARNING: Switch off the electrical supply to the pump and disconnect
the power cable from the electrical outlet before cleaning and inspection.
All equipment should be inspected. Any item that is visibly dirty should
be properly cleaned or removed. It is recommended that the system is
cleaned regularly and after each patient use.
SPECIFICATION
Control unit Specification
WARNING: Medical electrical equipment needs special precautions
regarding EMC and needs to be installed according to the EMC
information provided. Careful consideration of this information is
essential when stacking or collocating equipment and when routing
cables and accessories.
WARNING: RF mobile communications equipment can effect medical
electrical equipment.
Model Name Comfort Glide Air Blower
Size in CM (L x W x H) 32.5 X 18 X 24.8
Weight 5 kgs
Air Hose 37mm dia x 1.5m length
Min/Max Pressure 20 ~ 30 mmHg ± 5mmHg
Flow Rate ≥ 2500 L/min
Rated Voltage AC110 - 120V /60Hz
Max Current 10A
Fuse rating F12AH 250V
Protection Type Class II Type B
Environment (Temperature) Operation: 15 oCto 35 oC(59 oFto 95 oF)
Storage: 5 oCto 60 oC(41 oFto 140 oF)
Environment (Humidity) Operation: 30% to 75% non-condensing
Storage: 30% to 90% non-condensing
Filter Air 5 microns
Operation Atmospheric Pressure Range 700 hPa to 1060 hPa
Operation altitude -1017 feet to 9,843 feet
Test Standard IEC60601-1, IEC60601-1-2

10
ELECTROMAGNETIC COMPATIBILITY
Electric devices may interact due to electro-magnetic radiation. We
recommend a safety distance of at least 1 meter, especially for sensitive
equipment. Upon request, we can provide a table with more detailed
electromagnetic information.
Recommended separation distances between
portable and mobile RF communications equipment and the Comfort Glide Air Blower
The Comfort Glide Air Blower is intended for use in an electromagnetic environment in which
radiated RF disturbances are controlled. The customer or the user of the Comfort Glide Air Blower
can help prevent electromagnetic interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and the Comfort Glide Air Blower as rec-
ommended below, according to the maximum output power of the communications equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d = 1,2
80 MHz to 800 MHz
d = 1,2
800 MHz to 2,7 GHz
d = 2,3
0,01 0,12 0,12 0,23
0,1 0,38 0,38 0,73
1 1,2 1,2 2,3
10 3,8 3,8 7,3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation
distance d in meters (m) can be estimated using the equation applicable to the frequency of the
transmitter, where p is the maximum output power rating of the transmitter in watts (W) according
to the transmitter manufacturer.
NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.

11
Manufacturer’s declaration – electromagnetic emissions
The Comfort Glide Air Blower is intended for use in the electromagnetic environment (for profes-
sional healthcare) specified below.
The customer or the user of the Comfort Glide Air Blower should assure that it is used in such an
environment.
Emissions test Compliance Electromagnetic environment-guidance
(for professional healthcare environment)
RF emissions
CISPR 11
Group 1 The Comfort Glide Air Blower uses RF
energy only for its internal function.
Therefore, its RF emissions are very low
and are not likely to cause any interference in
nearby electronic equipment.
RF emissions
CISPR 11
Class A The Comfort Glide Air Blower is suitable for use in
all establishments other than domestic
establishments and those directly connected to
the public low-voltage power supply network that
supplies buildings used for domestic purposes.
Harmonic emissions
IEC 61000-3-2
N/A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
N/A
Manufacturer’s declaration – electromagnetic immunity
The Comfort Glide Air Blower is intended for use in the electromagnetic environment
(for professional healthcare) specified below.
The customer or the user of the Comfort Glide Air Blower should assure that it is used in
such an environment.
Immunity
test
IEC 60601
test level
Compliance
level
Electromagnetic environment
-guidance (for professional
healthcare environment)
Electrostatic
discharge (ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,
±8 kV,±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,
±8 kV,±15 kV
Floors should be wood, concrete
or ceramic tile. If floors are
covered with synthetic material,
the relative humidity should be at
least 30%
Electrical fast
transient/burst
IEC 61000-4-4
± 2 kV for power
supply lines
± 1 kV for input/
output lines
± 2kV for power
supply lines
Not applicable
Mains power quality should be
that of a typical professional
healthcare environment.
Surge
IEC 61000-4-5
± 0.5kV, ± 1kV
line(s) to line(s)
± 0.5kV, ± 1kV,
± 2kV line(s) to earth
± 0.5kV, ± 1kV
line(s) to line(s)
Not applicable
Mains power quality should be
that of a typical professional
healthcare environment.
Voltage Dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
Voltage dips:
0 % UT; 0,5 cycle
0 % UT; 1 cycle
70 % UT; 25/30 cycles
Voltage interruptions:
0 % UT;
250/300 cycle
Voltage dips:
0 % UT; 0,5 cycle
0 % UT; 1 cycle
70 % UT; 30 cycles
Voltage interruptions:
0 % UT; 300 cycle
Mains power quality should be
that of a typical professional
healthcare environment. If the user
of the Comfort Glide Air Blower
requires continued operation
during power mains interruptions,
it is recommended that the
Comfort Glide Air Blower be
powered from an uninterruptible
power supply or a battery.

12
Power frequency
(50, 60 Hz)
magnetic field
IEC 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
60 Hz
The Comfort Glide Air Blower
power frequency magnetic fields
should be at levels characteristic of
a typical location in a typical profes-
sional healthcare environment.
NOTE: UT is the a.c. mains voltage prior to application of the test level.
Manufacturer’s declaration-electromagnetic immunity
Test specifications for ENCLOSURE PORT IMMUNITYto
RF wireless communications equipment
The Comfort Glide Air Blower is intended for use in the electromagnetic environment
(for professional healthcare) specified below.
The customer or the user of the Comfort Glide Air Blower should assure that it is used
in such an environment.
Test
frequency
(MHz)
Band a)
(MHz) Service a) Modulation b)
Maximum
power
(W)
Distance
IMMUNITY
TEST
LEVEL
(V/m)
Compliance
LEVEL
(V/m)
(for professional
healthcare)
385 380-390 TETRA 400 Pulse modulation b)
18 Hz 1 , 8 0 , 3 27 27
450 430-470 GMRS 460,
FRS 460
FM c)±5 kHz
deviation 1 kHz sine 20 , 3 28 28
710
704-787 LTE Band 13,
17
Pulse modulation b)
217 Hz 0 , 2 0 , 3 9 9745
780
810
800-960
GSM 800/900,
TETRA 800,
iDEN 820,
CDMA 850,
LTE Band 5
Pulse modulation b)
18 Hz 20 , 3 28 28
870
930
1720
1700-
1900
GSM 1800;
CDMA 1900;
GSM 1900;
DECT;
LTE Band 1, 3,
4, 25; UMTS
Pulse modulation b)
217 Hz 20 , 3 28 28
1845
1970
2450 2400-
2570
Bluetooth,
WLAN,
802.11 b/g/n,
RFID 2450,
LTE Band 7
Pulse modulation b)
217 Hz 20 , 3 28 28
5240
5100-
5800
WLAN 802.11
a/n
Pulse modulation b)
217 Hz 0 , 2 0 , 3 9 9
5500
5785
NOTE : If necessary to achieve the IMMUNITY TEST LEVEL, the distance between the transmitting antenna
and the ME EQUIPMENT or ME SYSTEM may be reduced to 1 m. The 1 m test distance is permitted by
IEC 61000-4-3.
a. For some services, only the uplink frequencies are included.
b. The carrier shall be modulated using a 50 % duty cycle square wave signal.
c. As an alternative to FM modulation, 50 % pulse modulation at 18 Hz may be used because while it
does not represent actual modulation, it would be worst case.

13
Manufacturer’s declaration – electromagnetic immunity
The Comfort Glide Air Blower is intended for use in the electromagnetic environment
(for professional healthcare) specified below. The customer or the user of the
Comfort Glide Air Blower should assure that it is used in such an environment.
Immunity
test
IEC 60601 test level Compliance level Electromagnetic environment-guidance
(forprofessional healthcare environment)
Conducted
RF
IEC 61000-
4-6
Radiated
RF
IEC 61000-
4-3
3 Vrms:
0,15 MHz – 80 MHz
6 Vrms:
in ISM bands between
0,15 MHz and 80 MHz
80 % AM at 1 kHz
3 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
3 Vrms:
0,15 MHz – 80 MHz
6 Vrms:
in ISM bands between
0,15 MHz and 80 MHz
80 % AM at 1 kHz
3 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
Portable and mobile RF communications
equipment should be used no closer to
any part of the Comfort Glide Air Blower
including cables, than the recommended
separation distance calculated from the
equation applicable to the frequency of the
transmitter.
Recommended separation distance:
d = 1,2
d = 1,2 80 MHz to 800 MHz
d = 2,3 800 MHz to 2,7 GHz
Where P is the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and d is the recommended separation
distance in metres (m).
Interference may occur in the vicinity of
equipment marked with the following
symbol:
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
WASTE DISPOSAL
This Product has been supplied from an environmentally
aware manufacturer that complies with the Waste Electrical
and Electronic Equipment Directive (WEEE).
This product may contain substances that could be harmful
to the environment if disposed of in places (landfills) that are
not appropriate according local regulations. Please be
environmentally responsible and recycle this product through
your recycling facility at its end of life.

14
STORAGE AND CARE
Comfort Glide Air Blower:
Check the power cord and plug for abrasions or excessive wear.
Plug in the unit and verify air flows from the units hose connection ports
Place in box for storage
It is recommended the following guidelines are used whenever this sys-
tem is being stored or transported another location:
Temperature limitations: 5 oC to 60 oC (41 oF to 140 oF)
Relative Humidity: 30% ~90%
SYMBOLS USED
Type B
Applied part
Refer to
Instruction
Manual / Booklet
Keep dry Waste Disposal
SGS certified Class II Equipment
Alternating Current Catalog number
EXPECTED SERVICE LIFE
The Comfort Glide Air Blower has an expected service life of two years.
Replace the air filter every 6 months. Do NOT use unapproved
accessories or attempt to modify, disassemble or otherwise misuse
the device.

15
WARRANTY
The manufacturer warrants this equipment to be free from defects
in material and workmanship for 2 years from the date of delivery.
At Manufacturer’s discretion, we agree to service, repair or replace
any equipment or part found to be defective at no charge.
This warranty excludes equipment damaged through shipping,
tampering, improper maintenance, carelessness, accidents,
negligence, misuse, or which has been altered, repaired or
dismantled other than with the manufacture’s written
authorization and by its approved procedures and by properly
qualified technicians.
In no event shall the manufacturer be liable for any direct, indirect or
consequential damage or loss resulting from the use of equipment.

©2019 Medline Industries Inc. Medline and Comfort Glide are registered trademarks of
Medline Industries, Inc. Made in Taiwan for Medline Industries, Inc., Three Lakes Drive,
Northfield, IL 60093 USA. RC19CMT
Medline Industries, Inc. Three Lakes Drive, Northfield, IL 60093 USA
Medline United States
1-800-MEDLINE (633-5463)
www.medline.com | [email protected]om
