Getting to Know Your
AVANT Polar HIT
The AVANT Polar HIT represents a new era of precision Hearing Instrument Testing for your office.
Compact yet rugged, this PC-Based system is USB powered and performs all required ANSI and IEC
tests. A unique feature of the Polar HIT is a rotating test pad, which allows you to generate polar plots
to verify the performance of directional microphones upon delivery and following repairs. The
following section of this manual will familiarize you with the physical features and accessories of the
Polar HIT system.
Front View
Rear View
Note the single high-speed USB 2.0 (backward compatible to USB 1.1) connector, which supplies the
unit with power and transmits software control and data acquisition.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
5
Inside the Test Chamber
Detail view of the Rotating Test Pad

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
6
Setting up the System
Install the Coupler Microphone
The Reference Microphone is pre-installed at the factory and should be flush or nearly flush with the
floor of the rotating test pad.
Carefully install the coupler microphone as shown in the images below. Take care when handling these
components, as they are delicate, precision calibrated instruments.
Install the Coupler Microphone as shown above.
Once the microphones are installed, you must install the Polar HIT Software and Drivers. This procedure
is detailed in the next sections of this manual. If you have difficulty with these steps, contact MedRx
Technical Support at [phone] or 727-584-9600.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
7
Software Installation
Do Not Plug in the AVANT POLAR HITTM USB Cable yet
1. Insert the AVANT HITTM CD-ROM into the
CD drive. Wait until the Setup program
starts.
2. On the Setup screen, choose Install
Avant HIT.
If the Setup program does not start
automatically:
• Open Computer explorer from
Windows Start menu.
• Double Click on the CD Drive icon.
This should open the AVANTTM Setup
screen shown at the top left.
• If it does not, Windows will display a
list of files on the CD ROM.
• Double Click Setup.exe
3. Wait for the program to setup the
InstallShield Wizard.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
8
4. This is the Welcome screen
• Click Next.
5. Read the Software License Agreement.
This important document defines the
acceptable usage of the Polar HIT.
• After reading the Agreement, click
I accept...
• Click Next.
6. This screen indicates the location of the
program files.
• Click Next.
Note: You can install the Software to a
different location, but it is not
recommended.
7. Choose desired Locale
• Click Next.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
9
8. Ready to Install Program.
• Click Install.
9. Wait while the InstallShield Wizard installs
the AvantHIT program.
• Click Next.
10. When the installation is complete, click
Finish.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
10
Driver Installation on
Windows 7 (see page 13 for Windows XP Driver Installation)
Because drivers are loaded to specific USB ports, it is essential that the Polar HIT cable be connected to
the same USB port on your computer each time it is used. It is advisable to mark this port with a label to
assist with identifying it should the cable need to be disconnected.
1. Connect the USB cable from the AVANT POLAR HIT TM to your computer as shown above.
2. Wait for the system to copy and install default drivers. During this process, you will see the following
screen.
3. When this screen appears and all devices
are “Ready to use”, click Close.
4. On the AvantHIT Setup screen, click Install
Drivers.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
11
5. When this screen appears, click Ok.
6. When this window appears and all devices
are “Ready to use”, click Close.
7. If this warning screen appears, click Install
this driver software anyway.
8. On Setup Window click Exit

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
12
Next you need to set the Default Windows sound card settings. This will route all non-AVANTTM Windows
sounds to the internal sound card of your computer. These sounds include event notifications such as
new e-mail and error warnings as well as audio and video playback.
1. Launch the AVANT HIT
software.
2. Open the Advanced Options from
File menu as shown.
3. Open Audio tab.
4. When the audio properties are
configured properly, during driver
installation, the Audio Tab will
appear like the image on the left. If
not, use the pull-down lists to
adjust the settings to match the
image.
5. Click Audio Properties.
• In Windows Sound control panel,
make sure the MedRx Audio
Device is not set as default. If it is
default, change this by clicking on
your system (non-MedRx) audio
device and then choose Set
Default.
NOTE: The internal sound card on
your computer will likely not have
the same name as this screen shot.
Consult your computer’s
documentation for the name of the
internal sound card and set this
control accordingly.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
13
Driver Installation on
Windows XP
Because drivers are loaded to specific USB ports, it is essential that the Polar HIT cable be connected to
the same USB port on your computer each time it is used. It is advisable to mark this port with a label to
assist with identifying it should the cable need to be disconnected.
1. Connect the USB cable from the AVANT POLAR HIT TM to your computer as shown above.
2. Wait for the system to copy and install default drivers. During this process, you will see the following
prompts in your system tray (lower right corner of the screen).
3. After the Window drivers have been
installed, insert the Avant HIT installation
CD into the CD Drive.
4. When this screen appears, click Install
Drivers.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
14
5. When this screen appears, click OK.
6. When the driver signature check screen
appears, click Continue Anyway.
7. When this window appears,
8. Select No, not at this time
9. Click Next.
10. When this screen appears,
11. Select Install the software automatically
(recommended).
12. Click Next.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
15
13. When this screen appears,
14. Click Finish.
Exit the Setup screen when the driver installation is finished.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
16
Next you need to set the Default Windows sound card settings. This will route all non-AVANTTM Windows
sounds to the internal sound card of your computer. These sounds include event notifications such as
new e-mail and error warnings as well as audio and video playback.
1. Launch the AVANT HIT
software
2. Open the Advanced Options as
shown
3. Click on the Audio Tab
4. Click the Audio Properties button
5. Using the pull downs, set the
Sound Playback and Sound
Recording Default devices to the
internal sound card of your
computer.
6. NOTE: The internal sound card on
your computer will likely not have
the same name as this screen shot
(SigmaTelAudio). Consult your
computer’s documentation for the
name of your internal sound card
and set this control accordingly.
7. When the audio properties are
configured properly, the Audio Tab
will appear like the image on the
left. If not, use the pull-down lists to
adjust the settings to match the
image.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
17
Accessories
Couplers
The system includes the couplers and adapters shown below. These will allow you to perform all ANSI
and IEC Hearing Instrument Tests. Also included are two special accessories used only for Polar Plots.
Note: There is a flexible O-ring inside both the 2cc Coupler and the Button Receiver Adapter. These must
remain in place for the couplers to function properly. Replacement O-rings are available from MedRx.
Battery Pills
Battery Pills, also known as Battery Simulators, provide power to the hearing instrument during testing.
The system includes a complete set of Battery Pills as shown below.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
18
EMC Precautions
The Avant Polar Hearing Instrument Test (HIT) box needs special precautions regarding
EMC and needs to be installed according to the following EMC information.
List of all cables and maximum lengths of cables, transducers and accessories:
Transducer / Accessories Maximum Cable length
USB Cable 2.9 meters
Battery Simulators (All Versions) 0.3 meters
Microphones (All Versions) 0.3 meters
Warnings!
• The use of accessories, transducers and cables other than those specified, with
the exception of transducers and cables sold by the manufacturer of the Avant
Polar Hearing Instrument Test box as replacement parts for internal components,
may result in increased emissions or decreased immunity of the Avant Polar
Hearing Instrument Test Box.
• The Avant Polar Hearing Instrument Test Box should not be used adjacent to or
stacked with other equipment. If adjacent or stacked use is necessary, the Avant
Polar Hearing Instrument Test box should be observed to verify normal operation
in the configuration in which it will be used.
• The Avant Polar Hearing Instrument Test Box may be interfered with by other
equipment, even if that other equipment complies with CISPR emission
requirements.
• The Avant Polar Hearing Instrument Test Box does not have life supporting
function
• Portable and mobile RF communications equipment can affect the Avant Polar
Hearing Instrument Test Box.
Guidance and manufacturer’s declaration – electromagnetic emissions
The Avant Polar Hearing Instrument Test box is intended for use in electromagnetic environment specific below. The
customer or the user of the Avant Polar Hearing Instrument Test box should assure that it is used in such an
environment.
Emission test Compliance Electromagnetic environment - guidance
RF emissions
CISPR 11 Group 1 The Avant Polar Hearing Instrument Test box uses RF energy only for its internal function.
Therefore, its RF emissions are very low and
are not likely to cause any interference in nearby
electronic equipment.
RF emissions
CISPR 11 Class B
Harmonic emissions
IEC 61000-3-2 Non applicable
Voltage fluctuations / flicker emissions
IEC 61000-3-3 Non applicable
The Avant Polar Hearing Instrument Test box is
suitable for use in all establishments, including
domestic establishments and those directly
connected to the public low - voltage power
supply network that supplies buildings used for
domestic purposes.

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
19
Guidance and manufacturer’s declaration – electromagnetic immunity
The Avant Polar Hearing Instrument Test box is intended for use in electromagnetic environment specific below. The
customer or the user of the Avant Polar Hearing Instrument Test box should assure that it is used in such an
environment.
Immunity test IEC 60601
test level Compliance level Electromagnetic
environment - guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
+/- 6 kV contact
+/- 8 kV air +/- 6 kV contact +/- 8 kV air Floors should be wood, concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be
at least 30%.
Electrical fast transient /
burst
IEC 61000-4-4
+/- 2 kV for power supply
lines
+/- 1 kV for input / output
lines
+/- 2 kV for power supply
lines
+/- 1 kV for input / output
lines
Mains power quality should
be that of a typical
commercial or hospital
environment.
Power frequency (50/60 Hz)
Magnetic field
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
Guidance and manufacturer’s declaration – electromagnetic immunity
The Avant Polar Hearing Instrument Test box is intended for use in electromagnetic environment specific below. The
customer or the user of the Avant Polar Hearing Instrument Test box should assure that it is used in such an
environment.
Immunity test IEC 60601- test level Compliance level Electromagnetic environment -
guidance
Portable and mobile RF communications
equipment should be used no closer to any
part of the Avant Polar Hearing Instrument
Test box, including cables, than the
recommended separation distance
calculated from the equation applicable to
the frequency of the transmitter.
Recommended separation distance:
Conducted RF
IEC 61000-4-6
3 Veff
3 Veff
d = 1,17 P×
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 2,5 GHz
3 V/m
d = 1,17 P×80 to 800 MHz
d = 2,33 P×800 MHz to 2,5 GHz
Where P is the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and d is the recommended separation
distance in meters (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey a, should be less than the
compliance level in each frequency range
b.
Interference may occur in the vicinity of
equipment marked with the following
symbol:

AH-I-MPHITS-6 MedRx AVANT Polar HIT Installation Manual
Effective 1-30-12
20
NOTE 1 At 80 MHz and 800 MHz, the higher frequency ranges applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically
with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site
survey should be considered. If the measured field strength in the location in which the Avant Polar Hearing
Instrument Test box is used exceeds the applicable RF compliance level above, the Avant Polar Hearing
Instrument Test box should be observed to verify normal operation. If abnormal performance is observed,
additional measures may be necessary, such as reorienting or relocating the Avant Polar Hearing Instrument
Test box.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Recommended separation distances between
Portable and mobile RF communications equipment and the Avant Polar Hearing
Instrument Test box
The Avant Polar Hearing Instrument Test box is intended to use in an electromagnetic environment in which radiated
RF disturbances are controlled. The customer or the user of the Avant Polar Hearing Instrument Test box can help
prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF
communications equipment (transmitters) and the Avant Polar Hearing Instrument Test box as recommended below,
according to the maximum output power of the communications equipment.
Separation distance according to frequency of transmitter
meters
Rated
maximum
output power
of transmitter
W
150 kHz to 80 MHz
d = 1,17 P×
80 MHz to 800 MHz
d = 1,17 P×
800 MHz to 2,5 GHz
d = 2,33 P×
0,01 0,12 0,12 0,233
0,1 0,37 0,37 0,74
1 1,17 1,17 2,33
10 3,7 3,7 7,40
100 11,7 11,7 23,3
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters
(m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output
power rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
