MegaLite PARAMOUNT PENDANT Q350 User manual

Table of Contents
Safety Information 2
Specifications 3
Main Power Connection 4
DMX-512 Connection 4
DMX Profile 5
Main Control Menu 11
Size and Weight 13
Rigging the Fixture 14
Cleaning & Maintenance 14
Parts List 14
Warranty 15
Customer Service 16
USER MANUAL

2
Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
2. Replace fuse only with the specified type and rating.
3 Do Not install the unit to close to a heat source.
4. Make sure cable are properly secured
5. Maximum surface operating temperature 140º.
Protection Against Electrical Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
4. This fixture must not be left on for long periods of time.
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
Check that the unit has not been damaged during transport
Protection Against Fire
Protection Against Electrical Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 6.
3. This unit must be earthed. (electronically grounded)
4. This fixture must not be left on for long periods of time.
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.

Technical Information
3
Part Numbers
Fixture
4460-Paramount Pendant Q350
Mechanical Specifications
Housing:
DMX Connectors:
Power Connections:
Metal & Acrylic
XLR 5pin In and Out / Screw Terminal for Permanent Installation
Panel Mount Neutrik True Power In Connection (Nema 5-15 to Neutrik True power male cable included) /
Screw Terminal for Permanent Installation
Thermal: Maximum ambient temperature 104°
Maximum surface temperature 140°
Display:Digital
Secondary Safety: 1” Eye Bolt
Fastening System: Mounting Brace
Lens Angle: 10°
Size:
Weight:43.5lb
Electrical Specifications
Down LED Type: 1 COB LED 200W
Color Type: Red, Green, Blue, Warm White
Side LED Type: 90 SMD LED 1.5W
Color Type: Red, Green, Blue, Warm White
Segment Control: 15 Side 1 Down
Wireless DMX: Wireless Solution Receiving
CCT: 3077K on Warm White
Power Consumption: Universal 100 - 240V 50/60 Hz
Ballast: Electronic
Watts: 358W
Amps: 2.99A
PF: .60
Protocol: DMX 512
RDM: Yes
DMX Channels: 5 Modes of Operation
Mode 4Channel Red, Green, Blue, Warm White
Mode 8Channel Side Red, Green, Blue, Warm White, Bottom Red, Green, Blue, Warm White
Mode 15 Channel Dimmer, Side Red, Green, Blue, Warm White, Bottom Red, Green, Blue, Warm White, Shutter Macro, Macro
Speed, Color Macro, Macro Speed, Side Strobe, Bottom Strobe
Mode 64 Channel 16X R,B,G,WW
Mode 75 Channel Dimmer, Side Red, Green, Blue, Warm White, Bottom Red, Green, Blue, Warm White, Shutter Macro, Macro
Speed, Color Macro, Macro Speed, Side Strobe, Bottom Strobe, 16X R,B,G,WW
Control & Programming

4
Main Power Connection
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 220V automatically
3. This unit must be earthed. (electronically grounded)
4. Replace fuse only with the specified type and rating.
The occupation of the connection-cable is as follows:
DMX-512 Connection
This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to 60Hz
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a 120 Ohm re-
sistor between the (-) and the (+) signal into a 3 or 5 pin XLR plug and plug it in to the last fixture
on the signal run. Pre-manufactured terminator plugs are available for purchase from your Mega-
Lite dealer (P-DMXT).
Cable (USA) Cable (EU) 110V Pin
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
DMX—Input DMX—Output
1. Shield
2. Signal (-)
3. Signal (+)
5
3
4
2
1 1
2
3
4
5
4. N/A
5. N/A
The fixture is equipped with 5 pin XLR cable mounted sockets for DMX input and output. The sockets are wired in paral-
lel. Only use a shielded twisted pair cable designed for RS-485 and 5 pin XLR plugs and connectors in order to connect
the controller with the fixture or the fixture with another.
N
G
L
220V
Live
Live
Ground
DMX1
GAB
G. Ground
A. Signal +
B. Signal -
DMX2
GAB

5
DMX Profile
Paramount Q350 4 Ch Mode
DMX Ch Function Description Value Init
1 LED Color Red LED Intensity (entire fixture) 0-255 255
2 LED Color Green LED Intensity (entire fixture) 0-255 255
3 LED Color Blue LED Intensity (entire fixture) 0-255 255
4 LED Color Warm White Intensity (entire fixture) 0-255 255
Paramount Q350 8 Ch Mode
DMX Ch Function Description Value Init
1 LED Color Red LED Intensity (side fixture) 0-255 255
2 LED Color Green LED Intensity (side fixture) 0-255 255
3 LED Color Blue LED Intensity (side fixture) 0-255 255
4 LED Color Warm White (side fixture) 0-255 255
5 LED Color Red LED Intensity (bottom fixture) 0-255 255
6 LED Color Green LED Intensity (bottom fixture) 0-255 255
7 LED Color Blue LED Intensity (bottom fixture) 0-255 255
8 LED Color Warm White Intensity (bottom fixture) 0-255 255
Paramount Q350 15 Ch Mode
DMX Ch Function Description Value Init
1 Dimmer Dimmer (off to full) 0-255 255
2 LED Color Red LED Intensity (side fixture) 0-255 255
3 LED Color Green LED Intensity (side fixture) 0-255 255
4 LED Color Blue LED Intensity (side fixture) 0-255 255
5 LED Color Warm White Intensity (side fixture) 0-255 255
6 LED Color Red LED Intensity (bottom fixture) 0-255 255
7 LED Color Green LED Intensity (bottom fixture) 0-255 255
8 LED Color Blue LED Intensity (bottom fixture) 0-255 255
9 LED Color Warm White Intensity (bottom fixture) 0-255 255
No Function 0-1
Fade 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16 2-12
Fade 16,15,14,13,12,11,10,9,8,7,6,5,4,3,2,1 13-23
Snap 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16 24-34
10 Shutter Macro Snap 16,15,14,13,12,11,10,9,8,7,6,5,4,3,2,1 35-45 0
(Select Color) Fade 1+15,2+14,3+13,4+12,5+11,6+10,7+9,8 46-56
Snap 1+15,2+14,3+13,4+12,5+11,6+10,7+9,8 57-67
Fade 8,7+9,6+10,5+11,4+12,3+13,2+14,1+15 68-78
Snap 8,7+9,6+10,5+11,4+12,3+13,2+14,1+15 79-89
Fade 1+2+3+4+5+6+7+8 then 9+10+11+12+13+14+15 90-100
Snap 1+2+3+4+5+6+7+8 then 9+10+11+12+13+14+15 101-111

6
Fade 1+2+3+4+5 then 6+7+8+9+10 then 11+12+13+14+15 112-122
Snap 1+2+3+4+5 then 6+7+8+9+10 then 11+12+13+14+15 123-133
Fade 11+12+13+14+15 then 6+7+8+9+10 then 1+2+3+4+5 134-144
Snap 11+12+13+14+15 then 6+7+8+9+10 then 1+2+3+4+5 145-155
10 Shutter Macro Fade 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15 156-166 0
(Select Color) Fade 15,14,13,12,11,10,9,8,7,6,5,4,3,2,1 167-177
Snap 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15 178-188
Snap 15,14,13,12,11,10,9,8,7,6,5,4,3,2,1 189-199
Fade 1+2+3+4+5+6+7+8+9+10+11+12+13+14+15 then 16 200-210
Snap 1+2+3+4+5+6+7+8+9+10+11+12+13+14+15 then 16 211-221
Fade Random (1-15) 222-232
Snap Random (1-15) 232-255
11 Macro Speed Shutter Macro Speed 0-255 0
No Function 0-1
Program 1 2-12
Program 2 13-23
Program 3 24-34
Program 4 35-45 0
Program 5 46-56
Program 6 57-67
Program 7 68-78
Program 8 79-89
Program 9 90-100
Program 1 101-111
12 Color Macro Program 10 112-122
Program 11 123-133
Program 12 134-144
Program 13 145-155
Program 14 156-166
Program 15 167-177
Program 16 178-188
Program 17 189-199
Program 18 200-210
Program 19 211-221
Program 20 222-232
Program 21 232-255
13 Macro Speed Color Macro Speed 0-255 0
No Function 0-1
Strobe (slow to fast) 2-127
14 Side Strobe Strobe Pulse (slow to fast) 128-170 0
(Select Intensity) Random Strobe All (slow to fast) 171-213
Random 1-15 Strobe (slow to fast) 214-255
No Function 0-1
Strobe (slow to fast) 2-127
15 Bottom Strobe Strobe Pulse (slow to fast) 128-170 0
(Select Intensity) Random Strobe All (slow to fast) 171-213
Random 1-15 Strobe (slow to fast) 214-255

Paramount Q3500 64 Ch Mode
DMX Ch Function Description Value Init
1 LED Color Red LED Intensity 1 0-255 0
2 LED Color Green LED Intensity 1 0-255 0
3 LED Color Blue LED Intensity 1 0-255 0
4 LED Color White LED Intensity 1 0-255 0
5 LED Color Red LED Intensity 2 0-255 0
6 LED Color Green LED Intensity 2 0-255 0
7 LED Color Blue LED Intensity 2 0-255 0
8 LED Color White LED Intensity 2 0-255 0
9 LED Color Red LED Intensity 3 0-255 0
10 LED Color Green LED Intensity 3 0-255 0
11 LED Color Blue LED Intensity 3 0-255 0
12 LED Color White LED Intensity 3 0-255 0
13 LED Color Red LED Intensity 4 0-255 0
14 LED Color Green LED Intensity 4 0-255 0
15 LED Color Blue LED Intensity 4 0-255 0
16 LED Color White LED Intensity 4 0-255 0
17 LED Color Red LED Intensity 5 0-255 0
18 LED Color Green LED Intensity 5 0-255 0
19 LED Color Blue LED Intensity 5 0-255 0
20 LED Color White LED Intensity 5 0-255 0
21 LED Color Red LED Intensity 6 0-255 0
22 LED Color Green LED Intensity 6 0-255 0
23 LED Color Blue LED Intensity 6 0-255 0
24 LED Color White LED Intensity 6 0-255 0
25 LED Color Red LED Intensity 7 0-255 0
26 LED Color Green LED Intensity 7 0-255 0
27 LED Color Blue LED Intensity 7 0-255 0
28 LED Color White LED Intensity 7 0-255 0
29 LED Color Red LED Intensity 8 0-255 0
30 LED Color Green LED Intensity 8 0-255 0
31 LED Color Blue LED Intensity 8 0-255 0
32 LED Color White LED Intensity 8 0-255 0
33 LED Color Red LED Intensity 9 0-255 0
34 LED Color Green LED Intensity 9 0-255 0
35 LED Color Blue LED Intensity 9 0-255 0
36 LED Color White LED Intensity 9 0-255 0
37 LED Color Red LED Intensity 10 0-255 0
38 LED Color Green LED Intensity 10 0-255 0
39 LED Color Blue LED Intensity 10 0-255 0
40 LED Color White LED Intensity 10 0-255 0
41 LED Color Red LED Intensity 11 0-255 0
42 LED Color Green LED Intensity 11 0-255 0
43 LED Color Blue LED Intensity 11 0-255 0
44 LED Color White LED Intensity 11 0-255 0
7

45 LED Color Red LED Intensity 12 0-255 0
46 LED Color Green LED Intensity 12 0-255 0
47 LED Color Blue LED Intensity 12 0-255 0
48 LED Color White LED Intensity 12 0-255 0
49 LED Color Red LED Intensity 13 0-255 0
50 LED Color Green LED Intensity 13 0-255 0
51 LED Color Blue LED Intensity 13 0-255 0
52 LED Color White LED Intensity 13 0-255 0
53 LED Color Red LED Intensity 14 0-255 0
54 LED Color Green LED Intensity 14 0-255 0
55 LED Color Blue LED Intensity 14 0-255 0
56 LED Color White LED Intensity 14 0-255 0
57 LED Color Red LED Intensity 15 0-255 0
58 LED Color Green LED Intensity 15 0-255 0
59 LED Color Blue LED Intensity 15 0-255 0
60 LED Color White LED Intensity 15 0-255 0
61 LED Color Red LED Intensity 16 (bottom) 0-255 0
62 LED Color Green LED Intensity 16 (bottom) 0-255 0
63 LED Color Blue LED Intensity 16 (bottom) 0-255 0
64 LED Color White LED Intensity 16 (bottom) 0-255 0
Paramount Q350 15 Ch Mode
DMX Ch Function Description Value Init
1 Dimmer Dimmer (off to full) 0-255 255
2 LED Color Red LED Intensity (side fixture) 0-255 255
3 LED Color Green LED Intensity (side fixture) 0-255 255
4 LED Color Blue LED Intensity (side fixture) 0-255 255
5 LED Color Warm White Intensity (side fixture) 0-255 255
6 LED Color Red LED Intensity (bottom fixture) 0-255 255
7 LED Color Green LED Intensity (bottom fixture) 0-255 255
8 LED Color Blue LED Intensity (bottom fixture) 0-255 255
9 LED Color Warm White Intensity (bottom fixture) 0-255 255
No Function 0-1
Fade 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16 2-12
Fade 16,15,14,13,12,11,10,9,8,7,6,5,4,3,2,1 13-23
Snap 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16 24-34
10 Shutter Macro Snap 16,15,14,13,12,11,10,9,8,7,6,5,4,3,2,1 35-45 0
(Select Color) Fade 1+15,2+14,3+13,4+12,5+11,6+10,7+9,8 46-56
Snap 1+15,2+14,3+13,4+12,5+11,6+10,7+9,8 57-67
Fade 8,7+9,6+10,5+11,4+12,3+13,2+14,1+15 68-78
Snap 8,7+9,6+10,5+11,4+12,3+13,2+14,1+15 79-89
Fade 1+2+3+4+5+6+7+8 then 9+10+11+12+13+14+15 90-100
Snap 1+2+3+4+5+6+7+8 then 9+10+11+12+13+14+15 101-111
8

Fade 1+2+3+4+5 then 6+7+8+9+10 then 11+12+13+14+15 112-122
Snap 1+2+3+4+5 then 6+7+8+9+10 then 11+12+13+14+15 123-133
Fade 11+12+13+14+15 then 6+7+8+9+10 then 1+2+3+4+5 134-144
Snap 11+12+13+14+15 then 6+7+8+9+10 then 1+2+3+4+5 145-155
10 Shutter Macro Fade 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15 156-166 0
(Select Color) Fade 15,14,13,12,11,10,9,8,7,6,5,4,3,2,1 167-177
Snap 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15 178-188
Snap 15,14,13,12,11,10,9,8,7,6,5,4,3,2,1 189-199
Fade 1+2+3+4+5+6+7+8+9+10+11+12+13+14+15 then 16 200-210
Snap 1+2+3+4+5+6+7+8+9+10+11+12+13+14+15 then 16 211-221
Fade Random (1-15) 222-232
Snap Random (1-15) 232-255
11 Macro Speed Shutter Macro Speed 0-255 0
No Function 0-1
Program 1 2-12
Program 2 13-23
Program 3 24-34
Program 4 35-45
Program 5 46-56
Program 6 57-67
Program 7 68-78
Program 8 79-89
Program 9 90-100
Program 1 101-111
12 Color Macro Program 10 112-122 0
Program 11 123-133
Program 12 134-144
Program 13 145-155
Program 14 156-166
Program 15 167-177
Program 16 178-188
Program 17 189-199
Program 18 200-210
Program 19 211-221
Program 20 222-232
Program 21 232-255
13 Macro Speed Color Macro Speed 0-255 0
No Function 0-1
Strobe (slow to fast) 2-127
14 Side Strobe Strobe Pulse (slow to fast) 128-170 0
(Select Intensity) Random Strobe All (slow to fast) 171-213
Random 1-15 Strobe (slow to fast) 214-255
No Function 0-1
Strobe (slow to fast) 2-127
15 Bottom Strobe Strobe Pulse (slow to fast) 128-170 0
(Select Intensity) Random Strobe All (slow to fast) 171-213
Random 1-15 Strobe (slow to fast) 214-255
9

16 LED Color Red LED Intensity 1 0-255 0
17 LED Color Green LED Intensity 1 0-255 0
18 LED Color Blue LED Intensity 1 0-255 0
19 LED Color White LED Intesity 1 0-255 0
20 LED Color Red LED Intensity 2 0-255 0
21 LED Color Green LED Intensity 2 0-255 0
22 LED Color Blue LED Intensity 2 0-255 0
23 LED Color White LED Intensity 2 0-255 0
24 LED Color Red LED Intensity 3 0-255 0
25 LED Color Green LED Intensity 3 0-255 0
26 LED Color Blue LED Intensity 3 0-255 0
27 LED Color White LED Intensity 3 0-255 0
28 LED Color Red LED Intensity 4 0-255 0
29 LED Color Green LED Intensity 4 0-255 0
30 LED Color Blue LED Intensity 4 0-255 0
31 LED Color White LED Intensity 4 0-255 0
32 LED Color Red LED Intensity 5 0-255 0
33 LED Color Green LED Intensity 5 0-255 0
34 LED Color Blue LED Intensity 5 0-255 0
35 LED Color White LED Intensity 5 0-255 0
36 LED Color Red LED Intensity 6 0-255 0
37 LED Color Green LED Intensity 6 0-255 0
38 LED Color Blue LED Intensity 6 0-255 0
39 LED Color White LED Intensity 6 0-255 0
40 LED Color Red LED Intensity 7 0-255 0
41 LED Color Green LED Intensity 7 0-255 0
42 LED Color Blue LED Intensity 7 0-255 0
43 LED Color White LED Intensity 7 0-255 0
44 LED Color Red LED Intensity 8 0-255 0
45 LED Color Green LED Intensity 8 0-255 0
46 LED Color Blue LED Intensity 8 0-255 0
47 LED Color White LED Intensity 8 0-255 0
48 LED Color Red LED Intensity 9 0-255 0
49 LED Color Green LED Intensity 9 0-255 0
50 LED Color Blue LED Intensity 9 0-255 0
51 LED Color White LED Intensity 9 0-255 0
52 LED Color Red LED Intensity 10 0-255 0
53 LED Color Green LED Intensity 10 0-255 0
54 LED Color Blue LED Intensity 10 0-255 0
55 LED Color White LED Intensity 10 0-255 0
56 LED Color Red LED Intensity 11 0-255 0
57 LED Color Green LED Intensity 11 0-255 0
58 LED Color Blue LED Intensity 11 0-255 0
59 LED Color White LED Intensity 11 0-255 0
60 LED Color Red LED Intensity 12 0-255 0
61 LED Color Green LED Intensity 12 0-255 0
62 LED Color Blue LED Intensity 12 0-255 0
63 LED Color White LED Intensity 12 0-255 0
64 LED Color Red LED Intensity 13 0-255 0
65 LED Color Green LED Intensity 13 0-255 0
66 LED Color Blue LED Intensity 13 0-255 0
67 LED Color White LED Intensity 13 0-255 0
68 LED Color Red LED Intensity 14 0-255 0
69 LED Color Green LED Intensity 14 0-255 0
70 LED Color Blue LED Intensity 14 0-255 0
71 LED Color White LED Intensity 14 0-255 0
72 LED Color Red LED Intensity 15 0-255 0
73 LED Color Green LED Intensity 15 0-255 0
74 LED Color Blue LED Intensity 15 0-255 0
75 LED Color White LED Intensity 15 0-255 0
10

Main Control Menu
The control board on the fixture is your interface to access and control
all the functions on the unit. Its digital display gives you a code view of
the options and functions. The following will explain each function and
its options.
11
DMX Address
Press Set Up to select the DMX start channel use the up/down keys, confirm the start
address matches the DMX controller. Press Set Up to confirm the setting
Channel Mode
This function allows you to select the mode in witch you want to control the fixture. Press
Set Up use the up/down keys to select desired DMX channel mode settings. Press Set
Up to confirm the settings.
Wireless DMX
Mode Set Up Up Down
CONTROL BOARD
Paramount Q350
DMX
Address: 001
Channel: 75
DMX
Address: 001
Channel: 75
5 Modes of Operation
Mode 4Channel Red, Green, Blue, Warm White
Mode 8Channel Side Red, Green, Blue, Warm White, Bottom Red, Green, Blue, Warm White
Mode 15 Channel Dimmer, Side Red, Green, Blue, Warm White, Bottom Red, Green, Blue, Warm White, Shutter Macro, Macro
Speed, Color Macro, Macro Speed, Side Strobe, Bottom Strobe
Mode 64 Channel 16X R,B,G,WW
Mode 75 Channel Dimmer, Side Red, Green, Blue, Warm White, Bottom Red, Green, Blue, Warm White, Shutter Macro, Macro
Speed, Color Macro, Macro Speed, Side Strobe, Bottom Strobe, 16X R,B,G,WW
Wireless
Wireless: On
Wireless Unlock
V:1.0
001
64ch
27ºC
Wireless DMX
Channel Mode
DMX Signal
Fixture Temp
Software Version
DMX Start Channel
Wireless
Wireless: On
Wireless Unlock
This Fixture has a Wireless Solutions DMX Signal Receiver built in. You must Purchase
a Wireless Solutions Transmitter to be able to transmit wireless signal. Press Set Up to
start to pair your 2 devices. Select On or Off if you wish to use the wireless DMX receiver.
(Note: DMX Signal will also output signal from the 5pin XLR output)
This function is for unlinking your receiver with the transmitter. And returning the setting
to original factory mode.
Program
This Feature allows you to recall preprograms that are stored in the fixture. You can se-
lect from 22 programs that are selected in the Mode section. These programs can be
speed controlled in the Speed section on the display from 001 to 100. And Strobe speed
and be. Press Set Up to enter use the Up/Down keys to make your selection and Set
Up to confirm
Program
Mode: 17
Speed: 001
Strobe: 00

12
Manual
Manual function allows you to control the intensity of the LED’s side and bottom sepa-
rately via the display. Controls 1-4 are designated for the side led control and controls 5-
8 are for the control of the bottom led. Each section can be controlled by pressing Set
Up and using the Up/Down keys to select the color you would want. When using Manual
function and the unit is powered off and on the selected setting will return.
Manual
2.Green 1 : 255
3.Blue 1 001
4.White 1: 000
5.Red 2: 055
Settings
Fixture Setting, Press Set Up use the Up/Down keys to select what fixture setting you
would like to adjust press Set Up to enter that function.
Settings
1.Curve Select
2.Dimmer Speed
3.Dmx Fail
4.Dmx Sync
5.Lock
6.Fan
7.Factory
Linear
Square Law
Inv Square Law
S-Type
Curve Select: This setting allows you to control the dimming type.
press Set Up use the Up/Down keys to select dim curve type.
Fast
Smooth Dimmer Speed: Select from Fast dimming or Smooth Slower dim-
ming. Press Set Up use the Up/Down keys to select Dimmer Speed.
Off
Hold
Manual
Program
DMX Fail: This Setting allows you to select what function the LEDS
will do if DMX signal is lost during use. Off will turn all Dimmer chan-
nels to the 000 position. Hold will hold the last DMX command re-
ceived. Manual will revert back to the Manual setting. Program will
revert to the setting in the Program section of the display. Press Set
Up use the Up/Down keys to select the DMX Fail Options.
DMX Sync
On
Off
DMX Sync: This function is used with older DMX Controllers that
have a slower DMX Signal refresh rate
Lock
On
Off
Lock: To lock the display access you will need to engage this func-
tion. Press Set Up use the Up/Down keys to select. To Unlock the
display you must Hold the Mode & Set Up button at the same time for
seconds
Fan Speed
Fan Off
Sensor
Fan On
Fan: There is 3 Fan Setting options. Fan Off will leave fan off, but will
reduce the LED intensity once reached a unsafe temperature. Sensor
will engage the fan once needed. Fan On will leave fan turned on at all
times. Press Set Up use the Up/Down keys to select press Set Up to
confirm
Factory
Yes
No
Factory: This function revert all setting to original factory setting.
Press Yes to continue and No to go back.
Information
Will price systems information
Version: 1.0
Temperature:28ºC
Work Time:00056h
UID:63427C53916C

12.25”
(With Decorative Cover)
Size and Weight
Size
41.12” x 12”
Packaged Size
45” x 16.5” x 16.5”
Weight
Net 43.5 lb
Gross 50 lb
13
(Top View)
12”
12”
41.12”
(Bottom View)

Cleaning and Maintenance
Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and
electronics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any
safety problems have to be removed.
Note: There is no serviceable parts inside the device except for the LED’s. Maintenance and service operations are to
be carried out by authorized dealers.
Replacing the fuse: When possible only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by authorized
dealers or trained professional only.
Should you have further questions , please contact your dealer.
14
Parts List
Rigging the Fixture
Caution!
1. The installations must be carried out by an authorized dealer or trained professional.
2. Unit may cause severe injures if you have doubts concerning the safety do not install.
3. Unit is to be 24inches away from flammable materials (decoration material)
4. Use high quality installation equipment to hang unit.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi-
ence including but not limited to calculating working loads, material being used and periodic safety inspections. If you
lack these qualifications, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the projector
has got to be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be
checked at least one time a year by a skilled person.
Accessories
4460ACCDEC DECORATIVE COVER
4460LEN18 18 DEGREE BEAM ANGLE LENS
4460LEN28 28 DEGREE BEAM ANGLE LENS
CAS44602 2 UNIT ROAD CASE
4460LED200 REPLACEMENT LED COB 200W
4460LED1.5 REPLACEMENT LED SMD 1.5W
4460LEDMOD SIDE LED MODULE
4460PCBDRI 200W LED DRIVER
4460PCBMAI MAIN PCB / DISPLAY
4460PCBWIR WIRELESS SOLUTION PCB
4460PCBVOL VOLTAGE PCB
4460LENFRE FRESNEL LENS
4460LENPRI PRIMERY LENS
4460POW POWERSUPPLY
4460FAN FAN
4460ANT WIRELESS ANTENA
4460HOUCLA CLAMP MOUNT
4460HOUACR HOUSING ACRYLIC

MEGA Systems, Inc. Warranty
MEGA SYSTEMS INC (“MSI”) hereby warrants to the original purchaser/owner (“Customer”), MSI products to be free of manufacturing defects
in material and workmanship, for the warranty periods as defined below from the original purchase invoice date. This warranty applies
exclusively to new MSI branded and/or distributed products listed below, purchased from an MSI AUTHORIZED dealer/ reseller. This warranty
is not transferable and may or may not apply to products sold and/or forwarded outside the United States. Please contact MSI for applicable
regional product warranty information.
The purchase of MSI product constitutes the Customer’s acceptance of all warranty terms and conditions as listed in this limited warranty
statement. This warranty provides the Customer with legal rights, which may vary from state to state. Please contact MSI regarding warranty
questions prior to purchasing.
Product / Series
Battery Powered LED!
Moving LED, Hazers!
Outdoor IP-Rated LED!
House Light LED, Decorative LED, Compact LED, iCandy LED,
Theatrical LED, Strobe Wash LED, Follow Spot LED, Production &
House of Worship Control, Architectural Control, Theatrical Control,
Dance Venue & Mobile DJ Control, Direct View LED Displays, and MV
Warranty Period
Six month battery, one year all other components!
One year!
Two years!
Three years
Coverage
1, 2!
2!
3!
4
1. Battery: 183 days/six months 2. Parts and Labor: 365 days/one year 3. Parts and Labor: 730 days/two years 4. Parts and Labor: 1095 days/three years
This limited warranty excludes any defects caused by, resulting from or relating to the following:
Normal wear and tear of lamps, color media, brushes, contact rings, lamp sockets, belts and other parts prone to wear and tear.
Misuse, abuse, improper handling, accident, alteration or attempts to repair by or on behalf of the owner or any person not authorized by MSI.
Damage to the product resulting from acts of God, including, but not limited to, earthquakes, hurricanes, tornados, lightning and other natural disasters,
fire, explosion, flood, riots, civil disorder or any other cause beyond the reasonable control of MSI.
Exposure to harsh or excessively corrosive environmental conditions (whether indoors or outdoors), including, but not limited to, extreme temperatures,
humidity, atmospheric conditions (including salinity or pressure), radiation (UV, infrared or nuclear), shock and conditions which exceed the product’s
Ingress Protection (“IP)” rating.
Use of the product in a manner which exceeds the applicable product specification, including, but not limited to, exposure to excessive, insufficient or
other voltage conditions.
Installation or use of the product not in accordance with the technical documentation, MSI guidelines (as may be posted on its website at
www.megasystemsinc.com from time to time or otherwise designated by MSI or its brands) or applicable building and electrical codes, regulations and
standards.
Failure to maintain the product in accordance with the technical documentation.
Natural degradation and color shift of the LED source over the course of normal product use.
Slight deviations in the specified values of intensity and color that do not affect the functionality of the product.
Use of the product not for its intended purpose.
All warranty claims are evaluated under the terms of this limited warranty. If a product falls within the warranty period and if, upon examination
by MSI it is found to have failed for a covered cause, MSI will, at its sole discretion, repair or replace the defective part or product or reimburse
the purchaser a pro-rated portion of the purchase price based on the percentage of the warranty period still remaining as of the date that the
returned product was received by MSI. Should a replacement part or product be discontinued or unavailable, MSI reserves the right, in its sole
and absolute discretion, to substitute a comparable replacement part or product for the defective part or product. MSI warranty obligation
hereunder is limited solely to the repair or replacement of or reimbursement for the particular parts or products determined by MSI to have
failed for a covered cause within the warranty period. In no event shall MSI be responsible to replace or reimburse purchaser for any products
or portions of a system that MSI determines has not failed for a covered cause within the warranty period, even if such other products or
portions of a system are used together with products being repaired or replaced by MSI under this warranty and the repaired product differs in
brightness, colors or any other attribute after the repair.
Costs of removal, shipping to MSI or its authorized representative and reinstallation are solely the responsibility of the purchaser. If MSI
determines that the product is covered by this limited warranty, it will only pay for parts and labor as indicated by product type. If MSI
determines that the product is not covered by this limited warranty, the purchaser will have the option of paying for the repair (if the product can
be repaired) and the purchaser shall be responsible for the cost of shipping the repaired product back to the purchaser. MSI reserves the right,
in its sole and absolute discretion, to decline any repair.
IN NO EVENT SHALL MEGA SYSTEMS, INC. BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT OR PUNITIVE
LOSS OR DAMAGE OF ANY KIND, INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR REVENUES, LOSS OF USE OF THE
PRODUCT OR ANY OTHER GOODS OR ASSOCIATED EQUIPMENT, DAMAGE TO ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL,
COST OF SUBSTITUTE PRODUCTS, FACILITIES OR SERVICES, DOWN TIME COST, INSTALLATION OR LABOR COSTS, OR CLAIMS
OF THE PURCHASER’S CUSTOMERS, WHETHER BASED ON WARRANTY, CONTRACT OR NEGLIGENCE, ARISING IN CONNECTION
WITH THE SALE, USE OR REPAIR OF THE PRODUCT. MEGA SYSTEMS INC’S MAXIMUM LIABILITY SHALL NOT, IN ANY CASE,
EXCEED THE PURCHASE PRICE OF THE PRODUCT THAT GIVES RISE TO THE CLAIM.
EXCEPT FOR THE LIMITED WARRANTY SET FORTH HEREIN, ALL PRODUCTS SOLD BY MEGA SYSTEMS, INC. ARE SOLD “AS IS”
WITHOUT ANY WARRANTY, EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, INCLUDING, BUT NOT LIMITED TO, IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ALL OF WHICH ARE EXPRESSLY AND
SPECIFICALLY DISCLAIMED BY MEGA SYSTEMS, INC.
15

Mega-Lite
18668 Highway 16N
Helotes, Texas 78023
Ph 210-684-2600 Fax [phone]
www.mega.lighting / [email protected]
Customer Support
Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob-
lem. Please visit our website for any other related technical documents. For service related issue please contact our
service dept.
Monday—Friday 9am to 6pm CST
Voice: 210-684-2600
E-mail: [e-mail]
Document
Version Date Fixture Soware Notes
1.1 10/18/2021 V1.1
Manual Version
Please Visit www.mega.lighting for the most up to date manual version
16
