MegaLite HELIUS M User manual

EN
7002018806
W-CM011/01Doc. No. Tracking Code: 1400-2460CM-94-452No. Minutes: 05/09/2015Execution Date:
[email protected]www.megalite.com
Instruction for Installation and Utilization of HELIUS M
8
Close!
7
Close!
Close!
Close!
5 Nm
W
(kg)
Cat. No.
M314MU3LED6730-S
M314MU3LED6740-S
M314MU4LED7730-S
M314MU4LED7740-S
M314MU4LED9730-S
M314MU4LED9740-S
7.4
7.4
7.4
7.4
7.7
7.7
Mounting Height
Cx. S = 0.057 m2
max: 15 m
1- For proper utilization of this product and safety, it is mandatory to closely
comply with the directions and notes in this instruction and guide.
2- Earth connection as provided is mandatory.
3- Do not directly touch or impact LED module.
4- Do not stare at LED light source.
5- The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualified person. Always switch
off the power prior to installa-tion, maintenance or repair activities.
407
236
Ø42/48/60
Ø42 mm
G314PJ45
Ø42 mm
G314PJ45

Open!
A
Horizontal pole mounting:
Close the luminaire door:
Vertical pole mounting:
4
10 Nm 10 Nm
1 2 4
3
Pull!
Open!
Electrical connections:
5
L
N
max.120 mm
7 mm
1 2 3
Close!
Up to ±15 degrees angle adjustment, Bubble level feature to precisely align luminaire with horizontal plane
Up to ±15 degrees angle adjustment
3
Open the luminaire door:
1
Open!
2
Open!
B
Pull!
OK
NO
D
Pull!
Pull!
C/1
C/2
Open!
10 Nm 10 Nm
4
1 2
6
31
Close!
Push!
2
Ø 8-12 mm 3X1.5 mm
2
3X2.5 mm
2
60245 IEC 57
