2Product Overview
The MVT380, an anti-theft vehicle tracker, is specially designed for high-end vehicles to implement real-time monitoring and
provide protection with GPS/GSM/GPRS functions and high stability. The device applies for vehicle tracking and fleet
management. It has the following functions:
Remote listen-in
Two-way calling
Geo-fence alarm
Speeding alarm
Polygonal geo-fence alarm
Towing alarm
It has a built-in 8 MB buffer, which supports automatic storage of GPRS data packets when no GSM signal exists and supports
automatic data packet sending after the GSM signal recovers.
3Product Functions and Specifications
3.1 Product Functions
3.1.1 Position Tracking
GPS + GSM positioning
Real-time location query
Track by time interval
Track by distance
Track by mobile phone
Speeding alarm
Cornering report
3.1.2 Anti-Theft
SOS alarm
GPS antenna cut-off alarm
External power cut-off alarm

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 5 -
GPS blind spot alarm
Remote vehicle fuel/power cut-off
Engine or vehicle door status alarm
Towing alarm
Geo-fence alarm
3.1.3 Other Functions
SMS/GPRS (TCP/UDP) communication (Meitrack protocol)
Built-in 8 MB buffer for recording driving routes
Mileage report
Low power alarm for internal battery
Over-the-Air (OTA) update
Avoiding static drift by checking the engine
3.1.4 Functions of Optional Accessories
Accessory Function
Microphone and speaker Remote listen-in and two-way calling
3.2 Specifications
Item Specifications
Dimension 105 mm x 65 mm x 26 mm
Weight 190g
Power supply DC 11–36 V/1.5 A
Backup battery 400 mAh/3.7 V
Power consumption Standby (sleep) power consumption: 5mA，Working power consumption: 65mA
Operating temperature -20°C to 55°C
Operating humidity 5% to 95%
Working hour 80 hours in power-saving mode
5.7 hours in normal mode
LED indicator 2 indicators showing GSM and GPS status
Button/Switch 1 SOS button (for sending SMSs or dialing)
1 power button
Memory 8 MB buffer
Sensor 3-axis accelerometer (used to wake the device up by vibration and detect towing
alarms)
Frequency band GSM 850/900/1800/1900 MHz
GPS sensitivity -161 dB
Positioning accuracy 2.5m
I/O port 5 digital inputs (3 negative inputs and 2 positive inputs)
2 analog detection inputs
5 outputs

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 6 -
1 USB port
1 speaker or microphone
4MVT380 and Accessories
MVT380 with a
built-in battery
GPS antenna GSM antenna I/O cable + SOS button USB cable CD download card
5Appearance
Power button GPS indicator
GSM antenna
connector
GSM indicator
GPS antenna
connector
Microphone/Speaker USB port Power/Input/Output
port
6First Use
6.1 Installing the SIM Card
1. Loosen the screws, and remove the front cover of the device.

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 7 -
2. Insert the SIM card into the card slot with its gold-plated contacts facing towards the Printed Circuit Board (PCB).
3. Close the cover, and tighten the screws.
Note:
Power off the device before installing the SIM card.
Ensure that the SIM card has sufficient balance.
Ensure that the phone card PIN lock has been closed properly.
Ensure that the SIM card in the device has subscribed the caller ID service if you want to use your authorized phone
number to dial the SIM card.
6.2 Charging the Device
When you use the device for the first time, connect the device's GND (-Black) and Power (+Red) wires to 12 V or 24 V external
power supply for charging. Ensure that the device is charged at least three hours. Eight hours are recommended.
The device can be installed on a vehicle only after it is configured and tested.
6.3 LED Indicator
Press and hold down the power button for 3–5 seconds to start the device.
GPS Indicator (Blue)
Steady on A button or an input is triggered.
Blink (every 0.1 seconds) The device is being initialized or the battery power is low.
Blink (0.1 seconds on and 2.9 seconds off) A GPS signal is received.
Blink (1 second on and 2 seconds off) No GPS signal is received.
GSM Indicator (Green)
Steady on A call is coming in or a call is being made.
Blink (every 0.1 seconds) The device is being initialized.
Blink (0.1 seconds on and 2.9 seconds off) A GSM signal is received.
Blink (1 second on and 2 seconds off) No GSM signal is received.
6.4 Configuring Device Parameters by Meitrack Manager
This section describes how to use Meitrack Manager to configure the device on a computer.
Procedure:
1. Install the USB-to-serial cable driver and Meitrack Manager.
2. Connect the device to a computer with the USB-to-serial cable.

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 8 -
3. Run Meitrack Manager, then the following dialog box will appear:
Turn on the device, then Meitrack Manager will detect the device model automatically and the parameter page will appear
accordingly.
For details about Meitrack Manager, see the MEITRACK Manager User Guide.
6.5 Tracking by Mobile Phone
Call or send the 0000,A00 command by SMS to the device's SIM card number. The device will reply to an SMS with a map link.
Click the SMS link. The device's location will be displayed on Google Maps on your mobile phone.
Note: Ensure that the device's SIM card number has subscribed the caller ID service. Otherwise, the tracking function by mobile
phone will be unavailable.
SMS example:
Now,110727 02:48,V,16,23Km/h,61%,http://maps.google.com/maps?f=q&hl=en&q=22.540103,114.082329
The following table describes the SMS format:
Parameter Description Remarks
Now Indicates the current location. SMS header: indicates the current location or the
alarm type.
110727 02:48
Indicates the date and time in
None

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 9 -
YYMMDD hh:mm format.
V The GPS is invalid. A = Valid
V = Invalid
16 Indicates the GSM signal strength. Value: 1–32
The larger the value is, the stronger the signal is.
If the value is greater than 12, GPRS reaches the
normal level.
23Km/h Indicates the speed. Unit: km/h
61% Indicates the remaining battery power. None
http://maps.google.com/
maps?f=q&hl=en&q=22.5
40103,114.082329
Indicates the map link.
Latitude: 22.540103
Longitude: 114.082329
None
If your mobile phone does not support HTTP, enter the latitude and longitude on Google Maps to query a location.
6.6 Common SMS Commands
6.6.1 Setting Authorized Phone Numbers – A71
SMS sending: 0000,A71,Phone number 1,Phone number 2,Phone number 3
SMS reply: IMEI,A71,OK
Description:
Phone number: A phone number has a maximum of 16 bytes. If no phone numbers are set, leave them blank. Phone numbers
are empty by default.
Phone number 1/2/3: SOS phone numbers. When you call the tracker by using these phone numbers, you will receive SMS
notification about the location, geo-fence alarm and low power alarm.
If you need to delete all authorized phone numbers, send 0000,A71.
When the SOS button is pressed, the tracker dials phone numbers 1, 2, and 3 in sequence. The tracker stops dialing when a
phone number responds.
Example:
Sending: 0000,A71,13811111111,13822222222,13833333333
Reply: 353358017784062,A71,OK

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 10 -
6.6.2 Setting Listen-in Phone Numbers – A72
SMS sending: 0000,A72,Listen-in phone number 1,Listen-in phone number 2
SMS reply: IMEI,A72,OK
Description:
When you call the tracker by using the authorized listen-in phone number, the tracker will answer the call automatically and
enter the listen-in state. In this way, the tracker will not make any sound.
A maximum of two phone numbers can be set. Each phone number has a maximum of 16 digits. If no phone numbers are set,
leave them blank. Phone numbers are empty by default.
If no phone numbers are set and commas are remained, phone numbers set before will be deleted.
If you need to delete all listen-in phone numbers, send 0000,A72.
Example:
Sending: 0000,A72,13844444444,13855555555
Reply: 353358017784062,A72,OK
6.6.3 Setting the Smart Sleep Mode – A73
SMS sending: 0000,A73,Sleep level
SMS reply: IMEI,A73,OK
Description:
When the sleep level is 0 (default value), disable the sleep mode.
When the sleep level is 1, the tracker enters the normal sleep mode. The GSM module always works, and the GPS module
occasionally enters the sleep mode. The tracker works 25% longer in the normal sleep mode than that in the normal working
mode. This mode is not recommended for short interval tracking; this will affect the route precision.
When the sleep level is 2, the tracker enters deep sleep mode. If no event (SOS, button changes, incoming calls, SMSs, or
vibration) is triggered after five minutes, the GPS module will stop, and the GSM module will enter sleep mode. Once an event
is triggered, the GPS and GSM modules will be woken up.
Note: In any condition, you can use an SMS or a GPRS command to disable the sleep mode, and then the tracker exits the sleep
mode and returns back to the normal working mode.
Example:
Sending: 0000,A73,2
Reply: 353358017784062,A73,OK
For details about SMS commands, see the MEITRACK SMS Protocol.
Note:
1. The default SMS command password is 0000. You can change the password by using Meitrack Manager and SMS
command.
2. The device can be configured by SMS commands with a correct password. After an authorized phone number is set, only
the authorized phone number can receive the preset SMS event report.
7Logging In to MS03 Tracking System
Visit http://ms03.trackingmate.com, enter the user name and password, and log in to the MS03. (Purchase the login account
from your provider.)
For more information about how to add a tracker, see the MEITRACK GPS Tracking System MS03 User Guide (chapter 4 "Getting
Started").

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 11 -
The MS03 supports the following functions:
Track by time interval or distance.
Query historical trips.
Set polygonal geo-fences.
Bind driver and vehicle information.
View various reports.
Send commands in batches.
Support OTA updates.
For details, see the MEITRACK GPS Tracking System MS03 User Guide.
8Installing the MVT380
8.1 Installing GPS and GSM Antennas
GSM antenna GPS antenna
Connect the GSM antenna to the connector which is labeled "GSM". The GSM antenna is non-directional, so you can hide it in
any place of a vehicle.
Connect the GPS antenna to the connector which is labeled "GPS". It is recommended that the antenna is facing up to the sky
and the antenna side with words is downwards. Secure the antenna by using double sided tapes.
Note: Do not install the GPS antenna at a metal covered place.
8.2 Installing an I/O Cable
The I/O cable is a 16-pin cable, including the power, analog input, positive input, negative input, and output interfaces.
16
Power output (+)
15
GND out (-)
14
AD Input 2
13
Output 5
12
Output 4
11
Output 3
10
Output 2
9
Output 1
8
Power input (+)
7
GND in (-)
6
AD Input 1
5
Input 5 (+)
4
Input 4 (+)
3
Input 3 (-)
2
Input 2 (-)
1
Input 1 (-)
Pin Number Color Description
1 (IN1) White Digital input 1, negative trigger (SOS button by default)
2 (IN2) White
and
brown
Digital input 2 (negative trigger)
Connect to a door trigger signal cable to detect vehicle door status. (Most Chinese,
Korean, and Japanese cars are negative edge-triggered.)

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 12 -
3 (IN3) White
and red
Digital input 3 (negative trigger)
Detect vehicle door status. (Most Chinese, Korean, and Japanese cars are negative
edge-triggered.)
4 (IN4) White
and
orange
Digital input 4 (positive trigger)
Connect to the vehicle ACC cable by default to detect the vehicle ACC status.
5 (IN5) White
and
yellow
Digital input 5 (positive trigger)
Connect to a door trigger signal cable to detect vehicle door status. (Most European
and American cars are positive edge-triggered.)
6 (AD1) Blue Analog input 1 with 10-bit resolution and valid voltage of 0–6 V.
Connect to an external sensor, such as the fuel level sensor and temperature sensor.
7 (GND) Black Ground wire, connected to the negative electrode of the vehicle battery or to the
negative terminal.
8 (POWER) Red Positive electrode of the power input, connected to the positive electrode of the
vehicle battery. Input voltage: 11–36 V. 1 2 V is recommended.
9 (OUT1) Yellow Output 1
Valid: low level (0 V)
Invalid: open drain
Maximum voltage for output open drain (invalid): 45 V
Maximum current for output low voltage (valid): 500 mA
Connect to an external relay to remotely cut off the vehicle
fuel cable or engine
power supply.
10 (OUT2) Yellow
and
brown
Output 2
Valid: low level (0 V)
Invalid: open drain
Maximum voltage for output open drain (invalid): 45 V
Maximum current for output low voltage (valid): 500 mA
Connect to an external relay to remotely cut off the vehicle fuel cable or engine
power supply.
11 (OUT3) Yellow Output 3
Valid: low level (0 V)
Invalid: open drain
Maximum voltage for output open drain (invalid): 45 V
Maximum current for output low voltage (valid): 500 mA
Connect to an external relay to remotely cut off the vehicle fuel cable or engine
power supply.
12 (OUT4) Yellow
and red
Output 4
Valid: low level (0 V)
Invalid: open drain
Maximum voltage for output open drain (invalid): 45 V
Maximum current for output low voltage (valid): 500 mA
Connect to an external relay to remotely cut off the vehicle fuel cable or engine
power supply.

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 13 -
13 (OUT5) Yellow
and
blue
Output 5
Valid: low level (0 V)
Invalid: open drain
Maximum voltage for output open drain (invalid): 45 V
Maximum current for output low voltage (valid): 500 mA
Connect to an external relay to remotely cut off the vehicle fuel cable or engine
power supply.
14 (AD2) Blue
and
brown
Analog input 2 with 10-bit resolution and valid voltage of 0–6 V.
Connect to an external sensor, such as the fuel level sensor and temperature sensor.
15 (GND) Black Ground wire
It can be used as a ground wire connected to an analog sensor.
16 (POWER) Red Positive pole of the power output. The output voltage is equal to that of pin 8.
Supplies power to an external device.
8.2.1 Power Cable/Ground Wire (Pin 7/8)
Connect the power cable (red) and ground wire (black) to the positive and negative electrodes of the vehicle battery
respectively.
8.2.2 Digital Input (Pin 1/2/3, Negative Trigger)

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 14 -
8.2.3 Digital Input (Pin 4/5, Positive Trigger)
8.2.4 Output Control (Pin 9/10/11/12/13)
Note: The white line of the relay must be connected with the power V+, and the yellow line must be connected with the OUT
line of the equipment. It cannot be connected backwards. If the connection is wrong, the equipment may burn out.

MEITRACK MVT380 User Guide
Copyright © 2018 Meitrack Group All rights reserved. - 15 -
8.2.5 Voltage Formula for the Built-in Battery and Extenal Power Supply
Built-in battery input voltage = (AD4 x 3 x 2)/1024
Battery percentage = [(AD4 - 2114) x 100/492] x 100%
External power supply input voltage =AD5/1024 x 3 x 16
8.2.6 Analog Input (Pin 6/14)
The AD analog input can connect to a sensor whose output voltage ranges from 0 V to 6.6 V.
AD analog voltage = (AD x 3 x 2)/1024
8.3 (Optional) Installing the Microphone and Speaker
8.4 Mounting the MVT380
Tighten the four screws shown in the following figure.
If you have any questions, do not hesitate to email us at [email protected].
