Assembly Instructions & User’s Manual For
Member’s Mark Halstead 7pc Bar Dining Set With Fire Table
Item Number: xxxxxxxx
Model Number: GC-11511-7PC
Customer Assistance (spare/replacement parts): 1-800-691-2824
or Email: [e-mail]
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.

2 | P a g e
Table of Contents
Quality Statement.....................................................................................................................................3
Important Safety Information................................................................................................................3
Before Assembly.............................................................................................................................3
Care & Use.......................................................................................................................................3
Safety Warnings..............................................................................................................................4-5
Package Contents...........................................................................................................................6
Product Information........................................................................................................................6
Components....................................................................................................................................7
Hardware..........................................................................................................................................7
Tools................................................................................................................................................7
Step 1 ..............................................................................................................................................8
Step 2..................................................................................................................................................9
Step 3..................................................................................................................................................9
Loading the propane........................................................................................................................10
Loading the battery..........................................................................................................................10
Gas connection.................................................................................................................................11
Leak Check........................................................................................................................................12
Shutting down the gas.....................................................................................................................13
Gas Cylinder Required.....................................................................................................................13
Warning ......................................................................................................................................14
Danger.........................................................................................................................................14
Furniture Cover.................................................................................................................................15
Warranty Information............................................................................................................................16

3 | P a g e
Quality Statement
Important Safety Information
•Please read all instructions carefully before assembling this product.
•Where applicable, and for your safety, assembly by an adult is strongly
recommended.
•Use only vendor-supplied hardware to assemble this item. Using unauthorized
hardware could jeopardize the structural integrity of the item.
•Hardware may loosen overtime. Periodically check that all connections are tight.
Before Assembly
•Remove all parts and hardware from the box. Place all items on a carpeted or
scratch-free work surface, as this will avoid damaging parts during assembly.
•The shipping box can provide an ideal work surface if none is available.
•Use the components and hardware lists below to identify, inventory and separate
each of the hardware and components included.
•To avoid accidentally discarding small components or hardware, do not dispose
of any packaging or contents of the shipping carton until assembly is complete.
•DO NOT USE power tools unless it is explicitly identified in this manual as
required for use during assembly. Power tools can damage the fasteners,
hardware and/or components.
•Do not fully tighten all fasteners / screws until all parts are in place. Failure to
follow these instructions may cause the fasteners / screws to misalign during
assembly.
Care & Use
•Use a soft, clean cloth that will not scratch the surface when cleaning.

4 | P a g e
Safety Warnings
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

5 | P a g e
Safety Warnings (continued)
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

6 | P a g e
Package Contents
Component
Description
Quantity
Component
Description
Quantity
A
Table top
1
E
M6 Washer
4
B
Table base
1
F
Allen Wrench
1
C
Burner Cover
1
G
8kg Glass beads
1
D
Allen/Hex Bolt
M6x25mm
4
Product Information
Product Dimensions：
Padded Bar Chair: 17.5”x 17.5”x 25.5”(44.5cm x 44.5cm x 64.75cm)
Firepit Table: 72”x 37”x 34.45”(182.9cm x 94cm x 87.5cm)
Product Weight Capacity
Padded Bar Chair: Supports up to 300 lbs. (136 kg)
Firepit Table: Supports up to 925 lbs. (420 kg)
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

7 | P a g e
Components
(A)
Table top
Qty: 1pc
(B)
Table base
Qty: 1pc
(C)
Burner Cover
Qty: 1pc
(G)
8kg Glass beads
Qty: 1pc
Hardware
(D)
Allen/Hex Bolt
M6x25mm
Qty: 4pcs
(E)
M6 Washer
Qty: 4pcs
Tools
(F)
M6 Allen Wrench
Qty: 1pc
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

8 | P a g e
Step 1
(A)
Table top
Qty: 1pc
(B)
Table base
Qty: 1pc
(D)
Allen/Hex Bolt M6x25mm
Qty: 4pcs
(E)
M6 Washer
Qty: 4pcs
(F)
M6 Allen Wrench
Qty: 1pc
Carefully place table top (A) upside down a soft, flat and non-abrasive surface.
Attach the table base (B) to table top (A) with bolts(D) and Washer(E) by using M6 Allen
Wrench(F).
Tighten all the bolts with M6 Allen Wrench(F).
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

9 | P a g e
Step 2
Carefully turn the Firepit table over.
Place the glass beads (G) around the burner.
Step 3
Place Burner Cover onto the fire bowl.
NOTE: Glass beads is not included. When the fire pit is not in use and has cooled
COMPLETELY, cover it with the Burner Cover. DO NOT USE BURNER COVER ON A
HOT FIRE PIT OR WHEN IN USE.

10 | P a g e
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Loading the propane
Open the door
Carefully place the cylinder into the tank rack. Tighten the bolt to hold the cylinder in
Place.
Loading the battery
Unscrew the battery box, insert the negative electrode side of the battery into the
bottom of the battery box
Note: Please follow the above instructions to replace the battery when needed.

11 | P a g e
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Gas connection
Connect the pressure regulator (4#) to the cylinder by rotating the knob(5#) clockwise
until it is fully secured.
Make sure there is no leakage or damage.
The minimum inlet gas 25PSI supply pressure for the purpose of input adjustment;
The maximum inlet gas 250PSI supply pressure.
IMPORTANT:
If the knob (5#) is not properly threaded to the outlet of the cylinder. Gas leak will
possibly occur.

12 | P a g e
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Leak Check
NOTE
1. Make sure the gas control knob (2#) is on the “OFF” position. Open access doors.
2. Make sure the gas cylinder is correctly and security connected to the pressure regulator, with a tight fit.
3. Turn on the gas cylinder valve(7#). Apply 50% soap and 50% water solution to the
gas hose at connections between the knob(5#) and the gas cylinder.
4. If there is a leak, you will see bubbles form. In the case of the leak, turn off the gas
supply, unscrew the connections. Reconnect the gas hose and retest. If the leak
persists, consult the customer service canter for assistance.
5. If the connection is sound, continue to the next step.
LIGHTING
1. Make sure control knob (2#) is on the “OFF” position on the control panel.
2. Open access doors. Turn on gas cylinder valve (7#) to fully opened position.
3. Push and turn the knob (2#) to “HEGH”.
4. Hold igniter (3#) to light the burner. Release the knob after 45 seconds.
If there is no fire turn the control knob to “OFF”, wait 5 minutes and repeat from
step 3 on.
6. Adjust flame to desired flame with the control knob.

13 | P a g e
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
SHUTTING DOWN THE GAS
1. Turn the gas control knob (2#) to “OFF” to shut down appliance.
2. Turn the gas cylinder valve (7#) off when the gas appliance will not be in use.

14 | P a g e
Gas Cylinder Required
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Warning
For outdoor use only.
FUELS USED IN LIQUEFIED PROPANE GAS APPLIANCES, AND THE PRODUCTS
OF COMBUSTION OF SUCH FUELS, CAN EXPOSE YOU TO CHEMICALS
INCLUDING BENZENE, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO
CAUSE CANCER AND CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVE
HARM. For more information go to: www.P65Warnings.ca.gov.
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage.
Read the installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
Do not store or use gasoline or other flammable liquids or vapors in the vicinity of any
other appliance.
An LP cylinder not connected for use shall not be stored in the vicinity of this or any
other appliance.
Do not connect to a remote gas supply.

15 | P a g e
Danger
If you smell gas:
1. Shut off the gas to the appliance.
2. Extinguish any open flame.
3. If the odor continues, keep away from the appliance and immediately call your gas
supplier or fire department.
CARBON MONOXIDE HAZARD
1.This appliance can produce carbon monoxide, which has no odor.
2.Using it in an enclosed space can result in death.
3.Never use this appliance in an enclosed space such as a camper, tent, car or home.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Furniture Cover
Component
Description
Quantity
Component
Description
Quantity
H
Padded bar chair
6
J
Furniture Cover for Dining
set
1
I
Bar dining table
with fire pit
1

16 | P a g e
For maximum protection, use Heavy Duty Furniture Cover (J). Fasten
adjustable cord lock to secure the cover from wind and snug fit.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Warranty Information
This product component has a 5 year guarantee against defects in material and/or workmanship. If you
have any questions regarding the warranty or spare / replacement parts, please call our toll-free number
1-800-691-2824 or email us at [email protected]om
NOTE: Please consider recycling all applicable packaging material.

17 | P a g e
Distributed by Sam’s West Inc.
2101 SE Simple Savings Dr.
Bentonville, Arkansas 72716-0745
Made in China
