Mercia Garden Products 01DTOVAX0604SDFW-V1 User manual







 

 
















  



2mm Drill bit
x2 





























































 

















































ANY QUESTIONS?
Scan the QR code to
contact us via our customer
portal.
PLEASE SCAN HERE:


 

8
Some steps within this set of instructions come with an added video guide for your
convenience. These can be accessed via the QR code and used to aid you in constructing that
step. See below for how to use.
You can also nd all the videos on our youtube channel:
https://www.youtube.com/@merciagardenproducts8716/videos
ACCESSING VIDEO GUIDES...
1.Find the QR code within the instruction step...
2. Open camera app...
3. Scan QR code...
4. Watch the video...
On your personal smart device (phone, tablet etc), open your camera app or QR code scanner
app.
To scan the QR code, hold the camera over the QR code so that it can be seen on the screen.
Once the QR code has been registered, follow the prompts on your device to open the video.
(This will vary depending on your device.)
Please note: Ensure to use the back camera of your smart device as this will scan the QR code more
accurately.

The video guide will now be displayed on your smart device.
Parts Needed- No. QTY 1
No. QTY 1
No. QTY 1
Step..... 
Within the instruction step, there will be an icon in the top right that has a QR code in. This
is where the video can be accessed from.
Please note: not every step has a video guide.
Disclaimer: The garden building constructed in the video guides may be
constructed dierently to your building. Please ensure to read your instructions
carefully to avoid error.
ACCESSING VIDEO GUIDES...


 
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Overall Dimensions:
Width = 1842mm
Depth = 1318mm
Height = 1855mm
Base Dimensions:
Width = 1753mm
Depth = 1175mm
01DTOVAX0604SDFW-V1
01DTOVAX0604SDNW-V1
Building Content:
Door Gable QTY 1
AI-01R11OVAGSD1130X1826-V1
Back Gable QTY 1
AI-01R11OVAGP1130X1826-V1
Plain Panel QTY 1
(QTY 2 WINDOWLESS ONLY)
AI-R11OVPP1763X1567-V1
Window Panel QTY 1
(WITH WINDOW ONLY)
AI-01R11OV2CW1763X1567-V1
1 2 3 4
Floor QTY 1
AI-R11OSBF1175X1753-V1
Roof QTY 2
PI-03-0222
Door QTY 1
AI-R11FBMBZBD660X1600-V1
5 6 7
10
11
12
13
14
Fascia 12x60x694mm QTY 4
S1260-694mm
Fixed Window Strip 12x30x546mm QTY 5 (WITH WINDOW ONLY)
S1230-546mm
Cover Trims 12x45x1575mm QTY 4
S1245-1575mm
Ridge Bar 28x28x1707mm QTY 1
F2828-1707mm
Finial QTY 2
SHED DIAMOND FINIAL
8
9
17
Door Beading Strip 12x28x1530mm QTY 2
S1228-1530mm
T Hinge QTY 3
PI-02-1042
Plastic Window Cill
(WITH WINDOW ONLY)
PI-08-0013
Felt
Styrene QTY 2
(WITH WINDOW ONLY)
PI-05-0114
18
20
21
L-Bracket QTY 2
PI-07-0012
16
Turn Button QTY 2
PI-07-0034
19
15
Eaves Frame 28x28x897mm QTY 4
F2828-897mm
Hasp and Staple QTY 1
PI-07-0207
Nail Bag
Felt Tacks x 60
30mm Screw x 98
50mm Screw x 30
40mm Screw x 34


 
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
Take care removing the blocks as to not damage
the panels. Tap with a at headed screwdriver
and hammer.
Dispose of the blocks once removed.
PLEASE SCAN HERE:
Step 1
Parts needed - No. 5 QTY 1
Place the oor (No.5) on a rm and level base,
ensure the base has suitable drainage free from
areas where standing water can collect. See the
front page for base requirements.
5
Step 2
Parts needed - No. 1 QTY 1
No. 7 QTY 1
No. 15 QTY 3
Place the door (No. 7) within the door
aperture opening. Fix the T Hinges (No.15)
onto the door and Door Gable as shown
(taking into account on which side of the
Door Gable opening you want the Door
to open). Ensure that the screws go
through the cladding and into the framing
behind.
21x30mm screws
30mm
screw
Pre drill
hole
1
7
15
Opens from the Left Opens from the Right
IMPORTANT: Pre-drill before xing screws.
**PLEASE NOTE** Before tting the
hinges, ensure the door is in the correct
position depending on which side you
want the door to open. See external
illustrations below which show the doors
internal framing.
PLEASE SCAN HERE:


 
Step 3
Parts needed - No. 2 QTY 1
No. 3, (or 4) QTY 1
Fix the corners of the Back Gable (No.2)
and the Plain Panel (No.3) (or Window
Panel) with 50mm screws as shown in
diagram.
Do not secure the building to the oor
until the roof is tted.
Position the panels so there is equal
spacing between the oor and
cladding on all sides.
**Please note: Whether you have
purchased the with windows
building or no windows building, the
panels are interchangeable. Decide
which works best before assembly.**
3x50mm Screws
3
2
Pre drill
hole
50mm
screw
IMPORTANT: Pre-drill before xing screws.
Use for no
window buildings
3
Step 4
Parts needed - No. 1 QTY 1
No. 4, (or 3) QTY 1
Fix the end of the Window Panel (No.4) (or
Plain Panel) to the corner of the Back Gable
(No.2) with 50mm screws as shown in
diagram.
Fix the corners of the Door Gable (No.1) to
the ends of the Side Panels with 50mm
screws as shown in diagram.
Do not secure the building to the oor until
the roof is tted.
Position the panels so there is equal spacing
between the oor and cladding on all sides.
9x50mm Screws
1
4
Pre drill
hole
50mm
screw
IMPORTANT: Pre-drill before xing screws.
a
a
a
a
a
a
a
a
a
a
Step 5
Parts needed - No. 12 QTY 1
No. 20 QTY 1
Place the ridge bar (No.12)in between
the Door Gable (No.1) and Back Gable
(No.2). Ensure the top corners of the
ridge bar sit ush with the top points of
the Gables. Fix the ridge bar to the gable
using one L bracket (No.20)for each end.
Fix with 4x30mm screws each.
8x30mm Screws
12
20
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
PLEASE SCAN HERE:


 
Step 6
Parts needed - No. 6 QTY 2
No. 13 QTY 4
13
13
6
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
12
6
6
6
12
a
b
Fix the eaves frames (No.13)to each
roof sheet (No.6)using 3x30mm screws
per eave.
Place the Roof Sheets (No.6) on top of
the building making sure the roof sheet
meets the pointed edge of the Gables
(No. 1&2) and it sits well on the top of
the Ridge Bar (No.12).
**The edges of the roof sheets must
be ush with the outer cladding of
the Gables (No. 1&2).**
From the top, x directly through the
roof sheets (No.6) and into the ridge
bar (No. 12) below using 3x30mm
screws per roof sheet.
It is essential that the ridge bar (No. 12)
and the roof sheet (No. 6) pull together
when xed with 30mm screws. You
may require another person pushing
the ridge bar (No. 12) up from below to
achieve this.
22x30mm Screws
a
b
40mm
screw
IMPORTANT: Pre-drill before xing screws.
Step 7
Use 40mm screws to x the roof sheets
(No. 6) down the sides and at the bottom
being sure that the screws attach into the
framing below.
Ensure there is no more than 300mm
between each screw.
18x40mm Screws
Step 8
Once the roof is xed
attach the building to the oor with
50mm screws.
Ensure the screws go through the
panel into the oor framing
18x50mm Screws
50mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.


 
Felt
tacks
18
Step 9
Parts needed - No. 18 QTY 1
Cut the felt (No.18) into 2 sheets at
1900mm (L) x 1000mm (W) and lay onto
the roof in the order shown in the diagram,
ensuring there is 50mm overhang around
the sides.
Once the sheets are laid out secure them in
place using felt tacks at 100mm intervals.
60 x Felt Tacks
100mm
HANDLE
WITH CARE
1 2
3
4
1
2
10
Step 10
Parts needed - No. 10
Fit the Cover Trims (No.10) to the front and back
of the building as shown in the illustration using
30mm screws. Trim the length of the cover trims
to the required size before tting if necessary.
12x30mm Screws
10
10
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
*Cut down
trims to t
Step 11
Parts needed - No. 8 QTY 4
No. 14 QTY 2
Attach the fascias (No.8) to the
roof leaving a slight overhang at
the top.
Fit the fascias (No.8) to the roof
over the felt and secure in place
with 40mm screws as shown.
Fit the Finials (No.14) over the
fascias using 40mm screws.
16x40mm Screws
14
8
8
8
14
8
40mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.


 
Step 12
For a windowless version go to step 12
Parts needed - No. 9 QTY 5
No. 16 QTY 1
No. 19 QTY
Pre drill
hole
30mm
screw
9
9
16
a
b
c
d
SILICONE
SEALANT
9
9
9
Styrene
Window Cill
Cladding
Side View
19
19
a
b
c
d
IMPORTANT: Pre-drill before xing screws.
Fix 2x window strips (No. 9) to the framing
along the outside edge of the window gap
using 3x30mm screws per strip.
Place the plastic cill (No. 16) into the window
panel as shown in the illustration and x with
3x30mm screws per cill.
Fit the styrene sheets (No. 19) on top of the
window cill.
*For added weather protection t your
windows using silicone sealant around the
outside edges.
**When positioning the styrene sheets
ensure there is an equal distance on all
sides.
Attach the remaining 3x window strips (No.
9) to either side of the windows and the
centre. Secure into place using 3x30mm
screws per strip.
18x30mm Screws
PLEASE SCAN HERE:
Step 13
Parts needed - No. 11 QTY 2
Use 4x30mm Screws to x each beading
strip (No.11) onto the door gable
(No.1). Ensure that the screw is parallel
with the door frame when xing the
strip to the door gable as shown in the
close up view.
8x30mm Screws
11
11
30mm
screw
Pre drill
hole
IMPORTANT: Pre-drill before xing screws.

 

Pre drill
hole
30mm
screw
IMPORTANT: Pre-drill before xing screws.
21
Step 14
Parts needed - No. 21 QTY 1
To x the lock in place. Screw the Staple (No. 21)
to the Door Gable making sure that the screws
go into the framing behind.
Check the Hasp (No. 21) is in line with the staple
and screw into the Door making sure that the
screws go into the framing behind.
7x30mm screws.
Step 15
Parts needed - No. 17 QTY 2
Fix the Turn Button (No. 17) onto the
door gable (No.1) using 1x30mm
screw for each one.
2x30mm Screw
17
30mm
screw
IMPORTANT: Pre-drill before xing screws.
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back

