Merit Megatouch Wallette Operating instructions

PM0673-03
FOR TECHNICAL ASSISTANCE:
CONTACT YOUR LOCAL DISTRIBUTOR
For a list of distributors, visit the Merit Entertainment Web site
www.meritgames.com
Megatouch Wallette
and Megatouch Entertainer
Installation & Owner’s Manual

Site Preparation .............................p. 1
Game Description..........................p. 1
CPU Section ...............................p. 1
Cash Door .................................p. 1
GameDiagrams .................................p. 2
General Care
and Maintenance ...........................p. 3-4
Screen Calibration.....................p. 3
MonitorAdjustment
Procedures................................p. 3
General Circuit Board
Handling Information ..................p. 4
CleaningtheCabinet .................p. 4
Cleaning the Touchscreen
Monitor .......................................p. 4
Cleaning the Fans and
Vents .........................................p. 4
Watchdog Timer ........................p. 4
Mounting the Game on a Wall.....p. 5-6
Setting up your
Megatouch Game ..........................p. 7-8
AMI Music Setup............................p. 9-13
Connecting your Own
Speakers and/or Amplifier..........p. 14
Megatouch ION Software
Game Name and Score
Needed for Initial Replay ..............p. 15
Operator Setup Screens
Flowchart.........................................p. 16
Main Menu.......................................p. 17-18
Credits/Pricing Menu ...................p. 19-22
Quick Price Setup......................p. 19
Coin-InMenu ..............................p. 20
Coinless Coin Op Menu .............p. 21-22
Rental Mode ...............................p. 22
Games Menu ..................................p. 23
Game Setup ...............................p. 23
Hi Scores Menu..............................p. 24
View/Clear Hi Scores ...............p. 24
Books Menu....................................p. 24-26
Books Display............................p. 24-25
CashSettlement ........................p. 25-26
System Menu ................................. p. 27
Diagnostics Menu..........................p. 28-29
Hard Drive Self Diagnostics ......p. 29
Presentation Menu .......................p. 30
Operator Ad Screens................p. 30
Promotion Menu............................p. 30-31
MyMerit .....................................p. 30-31
Merit Money ...............................p. 31
PromoCredits ............................p. 31
Megatouch Player and
Operator Keys ................................ p. 32
Wireless Linking ........................... p. 33
Local Tournament Mode.............. p. 34-38
Megatouch Hardware
DIP Switch Settings
in ION Games .................................. p. 39
Troubleshooting ............................p. 40-42
MegaNet® Troubleshooting ........p. 43-44
Replacement Parts List ...............p. 45
Connection Diagrams...................p. 46-48
Warranty and Software License
Agreements
Warranty............................................p. 49
Software License Agreements.........p. 50-55
Table of Contents
©2008Merit Entertainment
Megatouch Entertainer, Megatouch Wallette, Ion 2009, Mega-Lease, Mega-Link, MegaNet, MegaWeb, TournaMAXX and
TournaCHAMP areregistered trademarksofMeritEntertainment. MPEGLayer-3audio codingtechnologylicensedfromFraunhofer
IISandThomson.
Reproductionofthis manual,inany formorby anymeans,isstrictly forbiddenwithoutthe writtenpermissionof MeritEntertainment.

COPYRIGHT© 2008 MERITENTERTAINMENT
Site Preparation
In determining the location for your game,
consideration must be given to a suitable,
grounded electrical outlet. The outlet shall
be installed near the equipment and shall be
easily accessible. Since the game is a com-
puterized device, it should have a separate
circuit, if at all possible. If a separate circuit
is not available, care should be taken to pro-
vide a clean and constant voltage. As a
basic guideline, never connect the unit to a
circuit that also supplies power to freezers,
coolers or other high power consuming and
electricalnoise generating equipment. Place
the unit in a location where nothing will in-
terfere with proper ventilation. The unit
should not be exposed to any dripping or
splashing liquids. Objects filled with liquid
should not be placed on the unit.
NOTE: The unit is not designed to func-
tion in an ambient temperature in ex-
cess of 95ºF or 35ºC.
Game Description
The unit has 2 key-locked compartments:
the CPU section door and the cash door. It
comes equipped with a coin mech and/or bill
acceptor. This model also has couplers in-
stalled in the cash section of the game (see
Figure 5). These are used for broadband
Internet connections and future hardware
upgrades,including linking capabilities. Each
game comes equipped with a wireless USB
adapter which can be used to wirelessly
link two Ion games together by simply turn-
ing the games on. With the addition of a
wireless router, up to four games can be
linked and the game(s) can also connect to
the Internet. The Linksys 802.11B router is
recommended. For more information, see
Wireless Linking.
There is also a rubber grommet included in
the plastic bag with the keys. This must be
installed in the hole in the back plate (see
Figure 3) if you are running the power cord
or other cables through the hole (i.e. if the
game is being flush mounted or mounted
using the Mega-Bracket). To install, route
the power cord through the grommet and
then secure the grommet on the hole in the
back plate.
The Wallette and Entertainer also offer sev-
eral optional kits. AMega-Bracket Mounting
Kit is available for fastening the game to a
table or bar top. There is also a Premium
Sound System Upgrade Kit available (KAV-
109-113-01) for higher quality sound if your
applicationrequiresit. Contactyourdistribu-
tor to check the availability of these kits.
CPU Section
The CPU section is accessible from the front
of the game. The CPU section houses the
LCDmonitor,motherboard,I/Oboard,power
supply, hard drive, and the main harness.
Located on the control board (found inside
the CPU section near the hinge of the CPU
section door) are two internal switches,
SETUP and CALIBRATE (see Figure 1).
Pressing the SETUP button will bring you to
the Megatouch Setup Screen. See the Gen-
eral Care and Maintenance section for
calibration instructions.
Cash Door
The coin mech/coin box/bill acceptor are ac-
cessible from the rear of the game by un-
locking the cash door. Also located inside
this compartment is a metal bracket which
houses speaker terminals and an amplifier
jack to connect your own speakers or am-
plifier, if desired. The cash access section
is key-locked for security purposes. See
Figure 2.
1 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL PM0673-03

COPYRIGHT© 2008 MERITENTERTAINMENT
FIGURE1-WALLETTE/ENTERTAINERWITHCPUSECTIONOPEN
FIGURE2- FRONTANDREARVIEWSOF WALLETTE /ENTERTAINER
Megatouch Wallette and Entertainer Diagrams
SECURITY
KEY
DETAIL VIEW OF
CONTROL BOARD
TOUCHSCREEN
CONTROLLER
CALIBRATE
SETUP
STANDOFF SECURING
COVER PLATE ON
BACK OF CPU SECTION
MONITOR
CONTROLS
MOTHERBOARD
CPU SECTION
LOCK
WIRELESS
ADAPTER HARD DRIVE
POWER
SUPPLY
I/O BOARD
ES KEY
(WALLETTE ONLY)
COVER PLATE
SECURED BY STANDOFF
INSIDE CPU SECTION
WIRELESS ADAPTER
CENTRONICS
UPGRADE
CONNECTOR
USB PORT
CASH DOOR
LOCK
PLAYER / OPERATOR KEY SOCKET
(available on some models)
FRONT VIEW REAR VIEW
CPU SECTION SLID TO THE LEFT
PM0673-03 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL 2

COPYRIGHT© 2008 MERITENTERTAINMENT
General Care and Maintenance
NOTE: THIS GAME MUST ONLY BE SER-
VICEDBY QUALIFIED SERVICE PERSON-
NEL.
CAUTION: THERE ARE HIGH VOLTAGE
PARTS IN THIS GAME. BE CAREFUL
WHEN SERVICING THE INSIDE OF THE
GAME. THE GAME SHOULD ALWAYS BE
UNPLUGGED BEFORE SERVICING.
Touchscreen Calibration
How To Calibrate your Touchscreen:
•Findthe CALIBRATE button onthecon-
trol board inside the CPU section, and
press it to enter screen calibration
mode.
•Touch the center of the first cross that
appears. Once you release your fin-
ger, a second cross will appear.
NOTE: You must hold your finger on
the cross for approximately 2 seconds
for the calibration to be recognized.
•Touch the center of the second cross
that appears on the screen.
•Once the second cross is touched and
released, another cross will appear on
the screen. To test the calibration of
the screen, touch the cross with your
finger and slowly drag your finger
around the screen. The cross should
follow your movement.
•Touch the EXIT button.
If high resolution is enabled, the game will
prompt you to go through the same steps
again for high resolution mode.
Monitor Adjustment Procedure
For adjusting the settings on our monitors,
we suggest following the procedures de-
scribed below. The vertical/horizontal con-
trols and brightness/contrast controls are
located on the control board, inside the CPU
section near the hinge of the door. Pressing
the button labeled Menuon the control board
will show the on-screen display on the moni-
tor. Use the Left and Right buttons to move
through the menu. Touch Menu again to
select the option you want to change. Use
the Left and Right buttons to change the
option. Then select Menu again to deselect
the option. Auto will automatically adjust the
size and brightness. Touch the Exit button
to exit. Adjust the monitor controls until the
screens look as suggested in the following
steps.
1. Set the game to the Checkerz game
screen.
2. Adjust the vertical and horizontal size
and vertical and horizontal position to
make sure that the game screen fills
the monitor screen and that the game
screen is centered.
3. Adjust the brightness and contrast con-
trols until the top sets of checkers are
a rich red and the bottom set are a dark
gray. The feet on the “Checkerz”
character should be white. (Adjusting
the brightness and contrast can also
correct for a lack of sharpness.)
3 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL PM0673-03

COPYRIGHT© 2008 MERITENTERTAINMENT
General Circuit Board Handling
Information
Before handling any boards, observe the
following procedures:
•Prevent Electro-Static Discharge by:
1. Storing the boards in the anti-
static bags in which they are
shipped.
2. Removing any static charge
from your body before handling
the boards.
3. Using a ground strap when
handling the boards.
•When plugging in connectors to the
board, make sure the connector is
inserted straight onto the header and
that the connector covers all header
pins.
•Do not connect any peripheral device
to the board, if the power is still
connected to the peripheral or if power
is already applied to the board.
CAUTION: Be extremely careful when re-
placing the lithium battery on the mother-
board. There is a danger of explosion if the
battery on the motherboard is incorrectly
replaced. Only replace the battery with the
same type recommended by the manufac-
turer. Dispose of used batteries according
to the manufacturer’s instructions.
Cleaning the Cabinet
•The cabinet should be cleaned with a
damp cloth and mild detergent. Always
apply the cleaner to the cloth and not
directly on the game. Liquids could
enterthe cabinet and damage electron-
ics inside.
Cleaning the Touchscreen Monitor
•The touchscreen glass should be
cleaned with a damp cloth and isopro-
pyl alcohol or a non-ammonia cleanser.
Do not use any abrasive or vinegar-
based cleansers, as they will damage
the touchscreen glass.
NOTE: DO NOT USE ANY ABRASIVE
SOLVENTS, ACID OR VINEGAR-BASED
CLEANSERS ON THE MONITOR OR
SIDE DECALS. OVER TIME, SUCH
CLEANSERS COULD HARM THE
TOUCHSCREEN AND ERASE THE DE-
CALS. BE CAREFUL NOT TO USE COM-
MERCIAL CLEANERS CONTAINING
ANY OF THESE SUBSTANCES.
Cleaning the Fans and Vents
•The fans and vents should be cleaned
of any dust and grime on a regular
basis to ensure proper ventilation of
the game.
•To ensure proper operation of the
game, it is important that all fans are
operating correctly and that the airflow
is unobstructed. Make sure nothing is
placed inside the cabinet or next to the
fan vents that would inhibit the flow of
air. Also, if any fans are not operating,
it is important that they be replaced.
Watchdog Timer
This game has been equipped with a fea-
ture that allows it to automatically reboot if it
encounters a problem. When the watchdog
timer is enabled, it will reboot the machine
within 5 minutes after a failure, allowing the
game to automatically reset itself if a prob-
lem arises without needing a technician
present.
If you want to disable the watchdog timer,
set DIP switch 3 on the I/O board to the open
position and reboot the game.
PM0673-03 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL 4

COPYRIGHT© 2008 MERITENTERTAINMENT
1. Make sure the game is turned off and
unplugged.
2. Choose a suitable area to mount the
game, then install an appropriate
screw in the wall to secure the center
of the back plate on the back of the
unit. The screw will go through the
keyholeslot (.400” diameter) in theplate
(see Figure 3). It is recommended you
use screws 2” in length when
mounting the game.
Framed drywall surfaces only:
Keep in mind that at a wall stud must
be used during installation when
mounting the game on a drywall
surface, although it is not necessary
to fasten the center of the game on a
stud. Use wall anchors when
mountingany part of the plate to drywall
only.
NOTE: Be sure to leave enough room
between the head of the screw and the
wall for the thickness of the back plate.
Mounting the Game on a Wall
NOTE: THIS INSTALLATION SHOULD ONLY BE PERFORMED BYAQUALIFIED
SERVICETECHNICIAN.
3. Attach the game to the wall by placing
the keyhole slot over the screw.
4. Unlock the cash door in order to
access the back plate from the inside,
then level the game before tightening
the screw.
5. Continue fastening the game to the wall
with at least 6 more screws through
selected mounting holes (.250”
diameter), spacing them as evenly as
possible.
Framed drywall surfaces only: If
you are mounting the center of the
gameto a wall stud,use the 6 remaining
holes down the center of the back plate
to fasten the game. If you are
mounting one side of the game to a
wall stud, use wall anchors when
fastening the other side.
6. Proceed with Setting up your
Megatouch Game.
CAUTION: The wall must not be a structural, or load-bearing wall. Fol-
low all appropriate precautions while performing this installation.
To mount the unit on a wall, follow the instructions below. If you are connecting Ethernet
or phone cables or connecting your own speakers or amplifier, and wish to route the
wires through the hole in the back of the back plate, connect these cables prior to installing
the game on the wall.
NOTE: The unit can be mounted on either a framed drywall surface using a wall
stud, or on a solid wall surface. Use hardware suitable for supporting 200 lbs. or
greater. Failure to properly support the game could result in personal injury or
damage to the unit. Check with local building and safety codes prior to instal-
lation.
5 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL PM0673-03

COPYRIGHT© 2008 MERITENTERTAINMENT
FIGURE3-INSIDE VIEWOFMEGATOUCHWALLETTE/ ENTERTAINERBACKPLATE
KEYHOLE
SLOT
POWER CORD
ROUTING OPTION
FOR FLUSH WALL AND
MEGA-BRACKET INSTALLATIONS
(SUPPLIED RUBBER GROMMET
MUST BE INSTALLED IF ROUTING
CABLE THROUGH HOLE)
PM0673-03 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL 6

COPYRIGHT© 2008 MERITENTERTAINMENT
FIGURE4-WALLETTE/ENTERTAINERFROMTHELEFT
WITHTHECPUSECTIONSLIDTOTHERIGHT
Setting up your Megatouch Game
1. After installing thegame,makesurethe
power cord is either routed through one
of the openings at the bottom of the
base (see Figure 5), or routed through
the hole in the back plate (see Figure
3). Plug the game into a standard AC
outlet, then close and lock the cash
door.
2. Install the security key(s) following the
instructions provided with the key(s).
3. Slide theCPUsectionto the right to turn
on the power switch mounted to the
back section of the game (see Figure
4) and wait for it to go through its boot-
up sequence. The game will display
the Player Menu Screen.
4. The machine has been preset at the
factory and therefore should not need
to be adjusted, however it is recom-
mended that the screen be calibrated
(see Screen Calibration) and the coin
or bill acceptor(s) be tested.
5. Follow the instructions under AMI
Music Setup to configure the music
settings.
6. There are many custom settings avail-
able for the game. To customize the
settings, follow the software instruc-
tions in this manual.
POWER
SWITCH
LOCATION
7 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATION AND OWNER’S MANUAL PM0673-03

COPYRIGHT© 2008 MERITENTERTAINMENT
FIGURE5- BACKOFWALLETTE/ ENTERTAINER-CASHDOOROPEN
OPENINGS AT
BOTTOM OF BASE
FOR ROUTING WIRES
(BOTH SIDES)
PHONE
COUPLER
ETHERNET
COUPLET
METER
SPEAKER TERMINALS
(if using your own speakers)
AMPLIFIER JACK
(if using you own amplifier)
HOLE USED TO
TIE WRAP AMPLIFIER
& SPEAKER WIRES
BILL ACCEPTOR
COIN MECH
PM0673-03 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL 8

COPYRIGHT© 2008 MERITENTERTAINMENT
AMI Music Setup
In order to set up your Entertainer to play
music directly or to set up your Wallette or
Entertainer to link to anAMI jukebox (allow-
ing customers to view and select jukebox
selections from the game) follow the in-
structions below.
To enable this feature, you will need a
broadband Internet connection, a router
(The Linksys 802.11B router is recom-
mended) and Ethernet cable(s) (if you aren’t
using wireless). It is recommended that
you set up and configure your router prior
to connecting the unit. Once the router is
set up, follow the instructions below.
Entertainer Units Only: In order to continue
with music setup, your Operator Agreement
must be filled out and received by Merit.
Hardware:
1. Wired connections: Turn off and
unplugthe unit and connect anEthernet
cable to the Ethernet coupler inside
the cash door (see Figure 5). Connect
the other end of the cable to the exter-
nal router. Plug in and turn on the unit.
If you are linking the unit to an AMI
jukebox, turn off the jukebox and con-
nect an additional Ethernet cable from
the jukebox’s interior router to the ex-
ternal router.
2. Wireless connections: Plug in and
turn on the unit.
NOTE: When you first turn on an En-
tertainer unit, it will display a mes-
sage indicating it is out of service.
Your game must call into the server in
order for it to function.
Software:
3. Press the SETUP button.
4. Touch the System button, and then
touch AMI Setup, followed by Op-
tions.
NOTE: Apop up box may appear informing
you that a broadband Internet connection
is required. If it does, press, Okay.
5. If you want to play music on the Enter-
tainer, make sure that the box next to
Function as Entertainer is checked.
If you want to link the unit to an AMI
jukebox, make sure that there is not a
check in the box next to the option.
Touch the MAIN MENU button to re-
turn to the Main Menu.
6. Touch the Network button on the Main
Menu. See Figure 6.
9 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL PM0673-03
FIGURE6-MAINMENUSCREEN
7. Next to Internet Connection, select
the LAN option. See Figure 7. For
wired connections, continue with step
8, for wireless, continue with step 11.
FIGURE7-NETWORKMENUSCREEN

COPYRIGHT© 2008 MERITENTERTAINMENT
PM0673-03 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL 10
Ion server connections:
Automatic: This setting is for cable or
DSL connections using dynamic IP
addresses. Contact your Internet service
provider if you are unsure of what kind of
IP address they use.
Manual: This setting is for cable or DSL
connections using static IP addresses.
Contact your Internet service provider if
you are unsure of what kind of IP
address they use.
FIGURE8-ETHERNETINTERNETSETUP
SCREEN
8. Wired Connections Only: Next to
(LAN) Local Area Network Con-
nection (see Figure 7), touch
Ethernet to advance to the Ethernet
Internet Setup Screen (see Figure 8).
At the next screen, depending on how
you are connecting to the server, se-
lecteither Automatic andcontinue with
step 9, or Manual and continue with
step 10.
9. Automatic Connections Only: After se-
lecting Automatic, press the Setup
button. The game will prompt you to
confirm the default Server Name, Pri-
mary DNS and Secondary DNS infor-
mation. Touch the NEXT button to ac-
cept these defaults. Then, touch the
YES button for the game to connect to
the server and complete the registra-
tion process. Confirm that the location
information is correct, then press YES.
Continue with step 13.
10. Manual Connections Only:After select-
ing Manual, press the Setup button.
The game will then prompt you to enter
the Static IP Address. Enter the Ad-
dress given to you by your service pro-
viderand touch the NEXT button. Then,
enter the Gateway given to you by your
service provider and touch the NEXT
button. TheServer Name,PrimaryDNS
Address and Secondary DNS Address
will already be filled out, simply touch
NEXT toaccept the default information.
Then,touchthe YESbuttonfor thegame
to connect to the server and complete
the registration process. After the
game calls in, confirm that the location
information is correct, and press YES.
Continue with step 13.

COPYRIGHT© 2008 MERITENTERTAINMENT
11. Wireless connections Only: Touch
the Wireless button next to (LAN)
Local Area Connection to advance
to the Internet Setup Screen. Touch
Configure Device and choose from
the following options (see Figure 9):
NOTE: If you are using security, only
64 or 128-bit WEP encryption is sup-
ported.
Autodetect Network: The system will find
and connect to the nearest available wire-
less network. This is the easiest way to
connect.
Search for Networks: Looks for all avail-
able wireless connections. Select a con-
nection from the list to proceed.
-Secured connection:Choosing a
“locked” device will prompt a key (pass-
word) request. If it is your own net-
work, use your password to gain ac-
cess. If not, this indicates an outside
network that has been encrypted and
is not accessible.
-Unsecured connection:You will be
promptedto enter interface information.
Accept the default values, or consult a
network advisor to manually configure
these settings.
11 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL PM0673-03
FIGURE9-WIRELESSDEVICESETUP
OPTIONS
Ad-Hoc Network: This is only for linking
games, not for connecting to the AMI server.
Custom Configuration: Touching this but-
ton will prompt the user to enter the SSID
(network name) for manual setup of the
wireless connection.
NOTE: Wireless Internet connection
does not require Manual Configura-
tion. Only users who have changed the
default SSID during router installation
should change the SSID. Consult the
instructions supplied with your wire-
less router for more information.
NOTE: If you have chosen Custom Con-
figuration, you will be prompted to enter
interface information. We suggest you ac-
cept the default values. If you want to manu-
ally configure these settings, consult a net-
work advisor.
12. Wireless connections Only: Once
you have chosen your network con-
nection, touch the <button and then
press Setup from the Wireless Internet
Setup Screen. Touch Yes to confirm
that you want to continue. Then, ac-
cept the default values for the server
name and DNS addresses by touching
Next 3 times. Touch the YES button for
the game to connect to the server and
complete the registration process. Af-
ter the game calls in, confirm that the
location information is correct, then
press YES. Continue with step 13.

COPYRIGHT© 2008 MERITENTERTAINMENT
PM0673-03 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL 12
FIGURE11-AMISETUPSCREEN
13. Toconfirm that a properconnection took
place, touch the MAIN MENU button,
and then touch TournaMAXX. The
game will prompt you to enter the time
zone. Thetimes are listed using Green-
wich Mean Time. Scroll through the list
to find your time zone and select it by
touching it. The game will return to the
TOURNAMAXX MENU. Touch Con-
nection Log. If there were no errors,
you will see “SUCCESSFUL” in the
ConnectionLog (seeFigure10). If there
is an error message, check the trouble-
shooting guide and follow the correc-
tive action to fix the problem.
IMPORTANT: If you are using the Enter-
tainer to play music, your game must make
a successful connection to the server in
order to function. If you attempt to call in,
but the call was not successful, the game
will function for a three-day grace period,
but if a successful call is not made within
those 3 days, it will shut down.
14. Touch the <button on the Connection
Log Screen and then touch Set Up-
date Time. Select a time when the
game is not busy for it to call into the
server. Then, touch the <button and
touch the Update From Server but-
ton to download additional information.
When this is complete, the game will
reboot and ask you to calibrate. Fol-
low the on-screen instructions.
15. Press the Setup button again, then
touch the System button, followed
by AMI Setup. See Figure 11.
NOTE: If the AMI Setup button does not
appear, touch the Options button and go
to page 4 in Options. Touch the box next
to Enable AMI. Then touch the <button
and touch AMI Setup.
FIGURE10-CONNECTIONLOGSCREEN
16a. If you are using the Entertainer to play
music: If you want to assign a differ-
ent name for the unit, touch Set next
toEntertainer Name and assign a name
for your records. Otherwise, touch
Connect next to “Connection Status”.
The game will prompt you to enter the
trigger code. Enter and confirm the
trigger code that was provided with
your security key.
16b. If you are linking the Wallette to anAMI
jukebox: Ensure that the Jukebox ID is
set to connect automatically. Accept
the default values for the Server URL
andAgent Name, and touch Connect.
Then, enter and confirm the AMI En-
tertainment user name and password
created with your initial jukebox ac-
count and utilized for Web site access.
NOTE: If a jukebox is not detected, you
will be prompted to manually config-
ure the jukebox information obtained
from your jukebox setup screen. On
your jukebox, go into “Service”, then

COPYRIGHT© 2008 MERITENTERTAINMENT
13 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL PM0673-03
select the “Diagnostics” and “System
Information” options on screen. En-
ter the MAC Address, exactly as it ap-
pears on the jukebox, into the Juke-
box ID field on your Megatouch. (The
defaulted Server URL and Agent Name
are also listed.) Once the information
is entered, touch “Connect” again on
the AMI Setup screen to proceed.
17. The game will download the files. Un-
der normal circumstances, this could
take 30 to 45 minutes. Merit has a
music catalog download which will de-
crease this time. To download the cata-
log, go to http://www.meritgames.com/
amidatabase.asp. A “Connection
Successful” message will appear
when finished, followed by an option
to enable the link. Touch YES to com-
plete the process. Once the link is
established, you may return to theAMI
Setup screen to disable, test or view
connection details.
If you are using the Entertainer to play
music: You can now log in (using your
AMI user name and password) to your
Operator Web Site (http://
www.amientertainment.net) and se-
lect the albums you want to be down-
loaded to the Entertainer.
18. Touch MAIN MENU at the top of the
screen, then touch Credits/Pricing.
19. Touch AMI Play Cost to configure the
price of music selected from the game.
Use the arrows to set the two-digit
credit cost (e.g., “02” = 2 credits) for
each of the play options: One Song
Play, MOD (Music On Demand), and
Priority Play (“My Song First” - if avail-
able).
NOTE: The cost of one song must be
set to a minimum amount of 33¢. If
your game is set to one credit is equal
to 17¢, each field in the AMI Play Cost
Screen must be at least 2 credits in or-
der to enable music on the game.
20. Touch the Xin the upper right corner
of the screen and confirm that you
want to exit the setup screens by
pressing YES.
Viewing Music Revenue
To view music revenue, use the following
procedure:
1. Press the SETUP button.
2. Touch Books.
3. Touch Cash Settlement Collection.
4. Touch Revenue Details/Cash Out.
5. Locate Entertainer Music or Juke-
box Selector Music revenue.

COPYRIGHT© 2008 MERITENTERTAINMENT
Connecting Your Own Speakers
If desired, you can connect your own speakers. Follow the installation instructions below.
IMPORTANT: The minimum speaker requirements are: 5 watts minimum power handling
at 8 ohm impedance. Failure to use speakers at this rating can cause damage to your
equipment.
1. Turn off and unplug the unit.
2. Unlock and open the CPU section.
3. Unplug the speaker connector from J12 on the I/O board (see Figure 41).
4. Locate the unconnected harness (labeled “EC0349 high level output”) routed near
the J12 location on the I/O board. Connect this harness to J12.
5. Close and lock the CPU section and unlock and open the cash door.
6. Locate the metal bracket inside the cash door (see Figure 5). Press down on the
terminal lever for the left (+) speaker, insert your left (+) speaker wire into the
terminal’s hole and then release the lever to secure the wire. Repeat this process for
the rest of the speaker connections, making sure to connect the positive speaker
leads to the positive outputs and the negative leads to the negative outputs. You
could damage your equipment by reversing these connections. Use the hole in the
metal bracket to tie-wrap the speaker wires to the bracket to prevent unnecessary
strain (see Figure 5).
7. Route the speaker wires through the openings at the bottom of the base and carefully
close and lock the cash door.
Connecting Your Own Amplifier
If desired, you can connect your own amplifier. Follow the installation instructions below.
NOTE: The amplifier must have a 3.5 mm stereo jack in order to plug into the unit.
1. Turn off and unplug the unit.
2. Unlock and open the CPU section.
3. Unplug the speaker connector from the “audio out” jack on motherboard (see Figure
39). Also, locate the jumper on pins 1 & 2 at JP14 on the I/O board (see Figure 41).
Remove the jumper and put it back on pins 2 & 3.
4. Locate the unconnected harness (labeled “EC0350 low level audio”) routed near the
audio out connector on the motherboard. Connect this harness to the audio out
connector on the motherboard.
5. Close and lock the CPU section and unlock and open the cash door.
6. Locate the metal bracket inside the cash door (see Figure 5). Connect your 3.5 mm
stereo jack from your amplifier to the jack labeled “3.5 mm stereo jack, low-level
output”. Use the hole in the metal bracket to tie-wrap the speaker wires to the
bracket to prevent unnecessary strain (see Figure 5).
7. Route the wire through the openings at the bottom of the base and carefully close
and lock the cash door.
PM0673-03 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL 14

COPYRIGHT© 2008 MERITENTERTAINMENT
15 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATION AND OWNER’S MANUAL PM0673-03
Game Name and Score Needed for Initial Replay
Solitaire, Power Solitaire, Lone Star, and Super Lone Star will always offer a replay once the
listed score is attained. The other games have to reach the score listed as well as attain the
high score for the game in order to offer a replay. NOTE:The available games may vary.
11 Ball/11-Up 125,000 Mystery Phrase 325,000
Air Shot No Replay Office Bash 400,000
Avalanche Jack 150,000 Outer Spades 75,000
Backjammin 125,000 Outlaw Poker/Cattle Drive 400,000
Battle 31 125,000 Pack Rabbit (Ion only) 400,000
Battle Command No Replay Pharaoh’s Fortune 45,000
Beer Pong (Ion Only) 200,000 Pharaoh’s 9 No Replay
Beer Pong 21 (Ion Only) No Replay Photo Hunt 400,000
Big Time Roller 60,000 Photo Pop No Replay
Boxdrop 175,000 Pix Mix 350,000
Boxxi 850,000 Power Solitaire 55,000
Breakin’ Bricks 400,000 Power Trivia No Replay
Card/Castle Bandits 200,000 Puck Shot 3,000
Card/Crypt Raiders 175,000 QB Zone 65,000
Card/Jolly Pirates 200,000 Q-Shot 50,000
Chainz2 500,000 Quik Cell 100,000
Chainz2: Puzzler 500,000 Quik Chess 125,000
Checkerz 28,000 Quik Match 400,000
Chip Away 125,000 Quiz Show 45,000
Chug 21 250,000 Race Poker/Motor Match No Replay
Chug Monkey 400,000 Rack ‘Em 200,000
Coco Loco No Replay Rack ‘Em 9 Ball 35,000
Conga Fish (Ion only) No Replay Run 21 250,000
Conquest 30,000 Skeeball 900
Crazy Hearts 65,000 Snapshot 400,000
Deflection 500,000 Space Crusader (Ion only) No Replay
Dodge Bull No Replay Speed Draw 125,000
Domino5 200,000 Spider Kings/13 Spiders 160,000
Draggle Drop 200,000 Sticker Book No Replay
Euchre Nights 5,000 Strip Club No Replay
Fast Traxx (Ion only) 100,000 Sudoku 6 100,000
Feeding Frosty No Replay Super Boxxi 150,000
Four Play 1,500,000 Super Snubbel No Replay
F.M.V. Boxxi (Ion only) No Replay Tai Play 240,000
F.M.V. Strip (Ion only) 400,000 Take 2 110,000
Funky Monkey 110,000 Tennis Ace No Replay
Gender Bender No Replay Texas Hold ‘Em No Replay
Gin Rummy 55,000 Tic Tac Trivia 75,000
GO-O-O-AL No Replay Tri-Towers/Tri-Castles 125,000
Great Solitaire 45,000 Tricky Fish No Replay
Hollywood Match 400,000 Triple Crown Boxing No Replay
Hoop Jones 125 Trivia Treasure No Replay
Ink Rally No Replay Trivia Whiz No Replay
Lookout 400,000 Trivia Whiz 2 No Replay
Lucky 11’s 340,000 Tuxedo Run (Ion only) 400,000
Luxor 500,000 TV Guide Mini Crossword 50,000
Luxor 2 (Ion Only) 500,000 UNO® No Replay
Luxor Survival No Replay UNO® 52 Poker No Replay
Magic Charms 500,000 Video Whiz (Ion only) No Replay
Mega Bowling 125 Vinci-Ball 400,000
Meteor Shower 200,000 Wild 8's/Wild Apes 400,000
MGA Champ. Golf No Replay Word Dojo 375,000
Mini Golf/Crazy Golf No Replay Word Safari 125,000
Monkey Bash No Replay Wordster 100,000
Monster Madness 400,000 Zenword 350,000
Moon Drop 160,000 Zip 21 200,000
My Ex 150,000

COPYRIGHT© 2008 MERITENTERTAINMENT
Setup Operator Keys
Merit Money
Start Time
End Time
Free Game Limit
Set PIN
Options
Enable Merit Money
Enable Promo Credits
Start Time
End Time
Idle Time
Number of Free Credits
Cash Settlement Collection
Revenue Details/Cash Out
Fee Details
Clear/Complete Collection
Dialup Setup
Credits/Pricing
Games
Hi Scores
Books
System
Diagnostics
TournaMAXX
Network
Credit Card
Presentation
Promotion
MegaNet
Internet Connection
LAN Connection
Dialup Setup
Ethernet Setup
Wireless Setup
Options
Network
TournaMAXX
General Info
Set Update Time
Connection Log
Update From Server
Clear Database
Credit Card Setup
Dial-Up Setup
Credit Card Test
Credit Card
Operator Ad Screens
Options
My Merit
Merit Money
Promo Credits
Options
Promotion
Presentation Add/Edit Billboard
Set Start/End Date
Remove Billboard
Remove All Billboards
Credit Card Setup
ISP Phone #
ISP Login
ISP Password
Merchant Login ID
Transaction Key
Operator Ad Screens
Access Phone Number
Login Name
Password
Server Name
1st DNS Address
2nd DNS Address
Use TMaxx ISP
Use My Own ISP
Modem Setup
Games
Books
System
Credits/Pricing
Quick Price Setup
Coin-In
Value of Credit
Pay Per Time
Player Key Cost
Clear Credits
Free Credits
Options
Game Setup
Options
Hi Scores
View/Clear High Scores
Options
Books Display
Cash Settlement Setup
Cash Settlement Collection
Set Time
Security Setup
Set Game Serial No.
Volume Control
Set 6 Star PIN
Data Transfer
Options
Setup Operator Keys
AMI Setup
Main Menu
View/Clear High Scores
(Individual game list)
Clear All Games
Set Key
Erase Key
Erase All Keys
General Info
Name
City, State
Country
Telephone #
Last Attempt
Last Success
Enter Security PIN
Security Setup
Game Setup
Price Display
Freeplay Enabled
Enable Coinless Coin Op
Enable Rental Mode
Puzzles
Cards
Erotic
Strategy
Megalink
New Games
Action
Quiz & Word
Enable All Games Into Menu
Factory Default Games Into Menu
Options
Modem Setup
Auto Detect Network
Search For Networks
Ad-Hoc Network
Custom Configuration
Details
Configure Device
Enable Entertainment Channel
Enable Premium Erotic
Enable Prize Zone
Enable MegaWeb
Enable Operator Website
Enable Hot Topics
Price
Default Games
Clear One
Clear All
Enable All Games
Options
Hot Topics
Time Block Rate
Price
Default Games
Clear One
Clear All
Enable All Games
Entertainment Channel
Prize Zone
Wait for Dial Tone
Dialing Method
Include Area Code
Dialing Prefix
Speed
Sound
Promo Credits
Internet Access Method
Setup
View Player Data
Show Game Play Frequency
Show Player Hi Scores
Backup/Restore
Automatic Wireless Configuration
Setup
Configure Device
My Merit
Ethernet Setup
Wireless Setup
Server Name
1st DNS Address
2nd DNS Address
Setup
IP Address
Mode
Server Name
1st DNS Address
2nd DNS Address
Setup
Enable erotic games
Allow game continue
Enable auto-continue
Show deck cards
Allow bonus replay
Enable easy mode
Continuous bonus round
Linked games enabled
Photo Hunt hints
Trivia rounds/bonus
Show correct answer in Trivia, Power Trivia
and Snap Shot
Enable free game in Solitaire
Split column move in Power Solitaire
Enable free game in Power Solitaire
Category same for all in Power Trivia
Enable consolation question in Power Trivia
Face up cards, player selectable in Tri Towers
Enable Kids Club category
Force Slow Senior Game Play
Sticker Book Timer Options
Disable Questionable Content
Enable 6 Stars
Default Language
Player selectable language
Language buttons have flags
Show games unavailable in current language
Enable theft deterrent
Enable Educational Attract Mode
Enable Attract Mode Sounds
Enable Megatouch Nation
Tournament Mode
Show prize pools on main menu
Enable Hi Resolution
Enable TouchTunes Hi-Resolution Mode
Enable AMI
Enable Light Show
Auto Clear Hi Scores
No Names in Hi Scores
Options
Options
Individual Game
Clear All
Clear One
Price
Cost to continue
Default Games
Clear One
Clear All
Enable All Games
Options
Options
Access Sales
Enabler Videos
Entertainment Channel
Premium Erotic
Prize Zone
MegaWeb
Operator Web Access
Hot Topics
Options
MegaNet
Allow Automatic Reconnect
in Attract Loop
Options
Video Test
I/OTest
Touchscreen Calibration
Touchscreen Test
Checksum Test
System Info
Verify Databases
Hard Drive Self Diagnostics
View System Log
Diagnostics
Operator Setup Screens Flowchart
PM0673-03 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL 16

COPYRIGHT© 2008 MERITENTERTAINMENT
Main Menu
The Main Menu can be accessed by pressing the SETUP button inside the game. Use the
Main Menu to set up all game software options.
NOTE: For help with the Options in any menu section, touch the green “?” buttons
to bring up a help screen.
A summary of the Main Menu functions appears in the following table. For more detail, see
the corresponding sections of the manual.
Main Menu Available Options Information
CREDITS/
PRICING • Quick Price Setup
• Coin-In
• Value of a Credit
• Coinless Coin Op
• Pay Per Time
• Options
• Player Key Cost (Ion Only)
• Clear Credits
• Free Credits
• AMI Play Cost
The Credits Screens allow the operator to set
credit rules for all games, set up the Coin-In
Menu, enable the Coinless Coin Op feature,
enable the Rental Mode feature, set the cost to
purchase player keys (if applicable), select
freeplay mode, and add or clear credits.
Operators can also set up AMI music play cost.
GAMES • Game Setup
• Options In the Games Screens, you can edit the game
list (choose which games are available and in
what category they appear on the Category
Menu), and select options for individual games.
HI SCORES • View/Clear Hi Scores
• Options Touch CLEAR ALL GAMES to clear all high
scores or select a particular game to edit high
scores for that game.
BOOKS • Books Display
• Cash Settlement Setup
• Cash Settlement Collection
The Books Screens display current and lifetime
credits information as well as calculate and
collect the location and operator fees.
SYSTEM • Set Time
• SecuritySetup
• Set Game Serial Number
• Volume Control
• Set 6 Star PIN
• Data Transfer
• Setup Operator Keys
(Ion Only)
• AMI Setup
• Options
Set the game clock, security PIN, serial
number, game volume, 6 star PIN and features,
and system options such as language control, 6
Star Enable, and theft deterrent. Also use this
menu to transfer machine configuration, books
data, and ad screens with a USB Pen and
program Operator keys to enable access to the
setup screens via the key (if applicable). The
AMI Setup option allows operators to configure
their games to connect to the AMI music
server.
FIGURE12-MAINMENU
17 MEGATOUCH WALLETTE/ENTERTAINER INSTALLATIONAND OWNER’S MANUAL PM0673-03
