Merit Mr. VIPS User manual

COPYRIGHT©2004MERITINDUSTRIES,INC.
PowerSupplyRemoval
1. Turn off and unplug the game.
2. Unlock and remove the rear door.
3. Unplug the IEC connector from the power supply.
4. Disconnect all connections to the main power supply harness.
5. If the power supply is fastened to the game with a metal strap (see Figure 1) and double-sided
tape, remove the 2 screws fastening the strap, then carefully pull the power supply off the
double-sided tape and out of the game. For games without the metal strap, remove the 2
screws fastening the power supply to the game (see Figures 2 and 3).
PowerSupplyInstallation
1. Install the new power supply in the game in the same manner as the old power supply and
fasten it with the existing hardware. If applicable, use double-sided tape to ensure the power
supply is firmly held in place.
2. Reconnect all connections to the main power supply harness.
3. Plug the IEC connector into the new power supply.
4. Replace and lock the rear door.
5. Plug in and turn on the game.
ATTENTION:
OBSERVEPRECAUTIONSFORHANDLINGELECTROSTATIC DEVICES
Removal/Installation of Power Supply -
Mr. VIPS
Troubleshooting Information - Removal/Installation of Major Assemblies - Mr. VIPS
Megatouch FORCE Technical Reference Manual
IEC
CONNECTOR
METAL
STRAP
SCREWS
FASTENING
METAL
STRAP
(TOP AND
BOTTOM)
FIGURE 1 - CLOSEUP OF POWER SUPPLY WITH METAL STRAP

COPYRIGHT©2004MERITINDUSTRIES,INC.
FIGURE2 -CLOSEUPOFPOWERSUPPLYWITHOUTMETALSTRAP
RIGHTFRONTSCREWS
ARELOCATEDHERE,
UNDERTHEWIRES
FIGURE 3 - CLOSEUP OF LEFTREAR BRACKETAND SCREWS
RIGHTFRONTSCREWSARE LOCATEDDIAGONALLY(SEEFIGURE 2)
SCREWSTO
REMOVE
