MicroNet SP616EB User manual

Quick Installation Guide
EtherFast 10/100M Switch
Model No.: SP616EB
http://www.micronet.info

Introduction
Micronet SP616EB 10/100M Switch provides powerful,
high-performance Ethernet switch, with all 16 ports capable of 10M
and 100M auto-negotiation operation. With its intelligent addressing
engine, it provides users with a wire-speed filtering and forwarding
of the traffic.All ports support auto-uplink detection, so users don't
have to worry about the cable type. Each port will automatically
communicate for best speed and to run in half- or full-duplex mode.
Store-and-forward switching function prevents damaged packets
and network errors from being passed on into the network.
Package Contents
Before installing the device, please verify the following items are in
the package:
yEtherFast 10/100M Switch
yQuick Installation Guide
yPower cord
1

2
Features
yCompliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
and IEEE802.3x flow control
ySupports speed (10/100Mbps) and duplex mode(Half/Full) and
auto-detection
ySupports MDI/MDI-X auto crossover
ySupports full and half duplex operation on all ports
ySupports back-pressure (Half/Full) and flow control (IEEE 802.3x)
ySupports extensive LED indicators for network diagnostics
yWire-speed packet filtering and forwarding rate
yStore-and-forward architecture filters fragment & CRC error
packets
y10” and 19” rack-mountable

Physical Description
SP616EB front view
Please refer to the following table for LED definition.
LED Status Operation
On Power is on.POWER Off Power is off.
On/Green Connection established.
Blink/Green Transmitting or receiving data.
LNK/ACT Off No link.
3

4
Installation
Installation is easy-- simply connect the cables and the power cord.
The system is ready, and you can use all the features.
Connect each station to the switch by twisted-pair cable. Plug one of
the RJ-45 connectors into a RJ-45 port of the switch, and plug the
other RJ-45 connector into the station’s network adapter. Power on
the switch and then the system is ready.
All ports could be used to connect with another switch. As all the
ports support auto-uplink (MDI / MDI-X) function, user can choose to
use a straight cable or a crossover cable to make a switch-to-switch
connection.
For cable selection, refer to the following table：
Network
Speed Connector Cable Type Max. Length
10BaseT RJ-45 Cat. 3, 4, 5 UTP/STP 100 m
100BaseTX RJ-45 Cat. 5 UTP/STP 100 m
Note: To prevent costly equipment damage and downtime, please
consider installing a surge suppression device or a UPS
(Un-interrupted Power Supply).

5
Specifications
Standard IEEE802.3, IEEE802.3u, IEEE802.3x,
compliant
Interface 16 * 10/100M RJ-45 ports
Cable Connections 10BASE-T: Cat. 3, 4, 5 UTP/STP
100BASE-TX: Cat. 5 UTP/STP
MAC address 8K
Buffer Memory 160K Byte for the whole system
NWay Protocol Network speed:10Mbps and 100Mpbs
Duplex mode: Full and Half
Uplink Auto Uplink (Auto MDI / MDI-X)
Filtering/Forwarding
Rate 10Mbps: 14,880pps/14,880pps 100Mbps: 148,800pps/148,800pps
Emission FCC Class A, CE
Operating Temperature 0o - 40o C (32o - 104o F)
Operating Humidity 10% - 90% (Non-condensing)
Dimension (mm) 267 × 161 × 44
Weight (kg) 1.2
Power Supply 100 ~ 240V AC, 50/60Hz
Full range internal power supply

CE Mark Warning
This equipment complies with the requirements relating to
electromagnetic compatibility, the essential protection requirement
of Council Directive 89/336/EEC on the approximation of the laws of
the Member States relating to electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it
may be possible that information in this document is not up-to-date.
Please check with your local distributors for the latest information.
No part of this document can be copied or reproduced in any form
without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their
respective companies.
Copyright © 2005, All Rights Reserved
P/N:
6
