MicroNet SP624R User manual

Quick Installation Guide
EtherFast 10/100M Switch
Model No.: SP624R
http://www.micronet.info

1
Introduction
Micronet SP624R 10/100M Switch provides powerful,
high-performance Ethernet switch, with all ports capable of 10 and
100M auto-negotiation operation. With its intelligent addressing
engine, it provides users with a wire-speed filtering and forwarding
of the traffic.All ports support auto-uplink detection, so users don't
have to worry about the cable type. Each port will automatically
communicate for best speed and to run in half- or full-duplex mode.
Store-and-forward switching prevents damaged packets and
network errors from being passed on into the network.
Package Contents
Before you start installing the device, verify the following items are in
the package:
yEtherFast 10/100M Switch
yQuick installation guide
yRack-mount accessories
yPower cord

2
Features
yCompliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX
and IEEE802.3x flow control
ySupport auto-negotiation function to automatically select optimal
speed (10/100M) and mode (Full/Half Duplex)
ySupport auto uplink, no more cross-over cable
ySupport 802.3x flow control for full-duplex mode and
back-pressure flow control for half-duplex mode
yForward and filter packets at non-blocking, full wire speed
yStandard 19” rack-mount size
y100 - 240V AC, universal internal power supply

3
Physical Description
SP624R front view
Please refer to the following table for LED definition.
LED Status Operation
On Power is on.POWER Off Power is off.
On/Green Connection established.
Blink/Green Transmitting or receiving data.
LNK/ACT Off No link.

4
Installation
yRack Mounting
The switch can be mounted in an EIA standard 19-inch rack,
which can be placed in a wiring closet with other equipment.
Attach the mounting brackets at the switch’s front panel (one on
each side), and secure them with the provided screws. Then, use
screws provided with the equipment rack to mount each switch in
the rack.
yConnecting your network
The switch provides up to 24 ports for 10/100BaseTX. Just
connect each station to the switch by twisted-pair cable. Plug one
RJ-45 connector into a RJ-45 port of the switch, and plug the
other RJ-45 connector into the station’s network adapter. Power
on the switch and then system is ready.
In making a switch interconnection, you could use any port to
connect another switch with straight or crossover cable.
For cable selection, refer to the following table：
Network
Speed Connector Cable Type Max. Length
10BaseT RJ-45 Cat. 3, 4, 5
UTP/STP 100 m
100BaseTX RJ-45 Cat. 5 UTP/STP 100 m
Note: To prevent costly equipment damage and downtime, please
consider installing a surge suppression device or a UPS
(Un-interrupted Power Supply).

5
Specifications
Standard IEEE802.3, IEEE802.3u, IEEE802.3x,
compliant
Interface 24 * 10/100M RJ-45 ports
Cable Connections 10BASE-T: Cat. 3, 4, 5 UTP/STP
100BASE-TX: Cat. 5 UTP/STP
Data Transfer Rate 10M(Half duplex)/20M(Full duplex)
100M(Half duplex)/200M(Full duplex)
Uplink Auto Uplink (Auto MDI / MDI-X)
Switch Fabric 4.8Gbps
Filtering/Forwarding
Rate 10Mbps: 14,880pps/14,880pps 100Mbps: 148,800pps/148,800pps
Emission FCC, CE
Operating Temperature 0o - 40o C (32o - 104o F)
Operating Humidity 10% - 90% (Non-condensing)
Dimension & Weight 441 × 130 × 44 mm
Power Supply 100 ~ 240V AC, 50/60Hz
Full range internal power supply

6
CE Mark Warning
This equipment complies with the requirements relating to
electromagnetic compatibility, the essential protection requirement
of Council Directive 89/336/EEC on the approximation of the laws of
the Member States relating to electromagnetic compatibility.
Company has an on-going policy of upgrading its products and it
may be possible that information in this document is not up-to-date.
Please check with your local distributors for the latest information.
No part of this document can be copied or reproduced in any form
without written consent from the company.
Trademarks:
All trade names and trademarks are the properties of their
respective companies.
Copyright © 2005, All Rights Reserved
P/N: 2300-0355
