MicroNet SP6008P User manual

Communicate via
P/N 2300-0748
Quick Installation Guide
Model No.: SP6008P
8-Port 10/100M PoE Switch
6
5
7
Specifications
SP6008P
Model No.
CE Mark Warning
This equipment complies with the requirements relating to
electromagnetic compatibility of the essential protection requirement
of Council Directive 89/336/EEC on the approximation of the laws of
the Member States. Company has an on-going policy of upgrading
its products and it may be possible that information in this document
is not up-to-date. Please check with your local distributors for the
latest information. No part of this document can be copied or
reproduced in any form without written consent from the company.
WEEE Directive & Product Disposal
At the end its serviceable life ,this product should not be treated
as household or general waste. It should be handed over to the
applicable collection point for the recycling of electrical and
electronic equipment, or returned to the supplier for disposal.
www.micronet.com.tw
Standards
Features
Pin Assignment
and Polarity
PoE Power
Budge
LED Indicators
PoE Power
Output
Power
Adaptor
Dimension
Weight
Reliability MTBF
Environment
IEEE 802.3af/at PoE
IEEE 802.3 10 BaseT
IEEE 802.3u 100 BaseTX
IEEE 802.3x Flow Control
Number of Ports: 8 PoE/PSE ports
Transmission Method: Store and Forward
1/2 (+), 3/6 (-)
120W
Per Port: Link/Act, PoE Act/Status
Per Unit: Power
48V/DC Per Port Output,
15.4 Watts (Up to 30W)
Input: 100~240V/AC, 47~63 Hz
Output: DC56V/2.15A
188 mm x 119 mm x 39mm
0.69 Kg
O
60 k.hrs. at 25 C
O
Operating: -10~45 C.
Humidity Operating: 10~90%

LED indicators
For definitions of LED indicators, please refer to the following table:
Introduction
The SP6008P supports IEEE 802.3af/at standard for Power over
Ethernet (PoE) with the maximum power delivery up to 120 Watts.
That makes it suitable to various applications that demand for
remote power feeding and meet high level requirement for power.
SP6008P is totally equipped with 15.4Watts or 30 Watts per PoE
port, which effectively helps allocate power for connected multiple
devices and enhances network management.
Key Features
8 Port 10/100M Nway (Auto-negotiation) Switch
8 PSE/PoE function ports
Supporting the power 15.4 or 30 W for each PoE port
Auto-learn of networking configuration
Auto-detect full/half-duplex modes for any port
Dedicated full-duplex 200Mbps bandwidth
Store-and-Forward switching methods
IEEE 802.3x flow control for full-duplex and back-pressure flow
control for half-duplex
Non-blocking & Non-head-of-line blocking full wire speed
forwarding
Auto-MDI/MDI-X function for any port
4
3
1 2
LED Status
Power
Indication
On
Off
On
Off
On
Off
Network Speed Cable Type
10M
100M
Max. Length
Cat. 3,4,5,5e UTP/STP
Cat. 5,5e UTP/STP
100 meters
100 meters
Note: To prevent costly equipment damage and downtime, please
consider installing a surge suppression device or a UPS
(Un-interrupted Power Supply).
Note:
Note:
For cable selection, refer to the following table:
Package Contents
Before you start installing SP6008P, please verify the following
package contents:
SP6008P 10/100M PoE Switch
Quick Installation Guide
Power Cord
Tour of the System
Front Panel
LED indicators
Back Panel
Power Switch and Power Cord Connector
Power in ON
Off power
10M
100M
Port is linked to Power Device
No Power Device is connected
10/100M
PoE
Hardware Installation
The setup of the switch can be performed using the following steps:
Step 1: Connect the Power Cord to SP6008P and then to a
power outlet.
Step 2: Connect a RJ-45 Ethernet cable from IEEE802.3af/802.3at
compliant devices (PD) to an available PoE port
of SP6008P.
Note:
Port 1 to Port 8 are used for connecting to PD or PoE splitter for
end devices.
