MicroNet SP676C User manual

User’s Manual
Gigabit Smart Switch
Model No.: SP676C/SP684C
World Wide Web: www.micronet.com.tw ; www.micronet.info

2
Table of Content
-------------------------------------------------------------------------------------------------------------------------
1. Introduction................................................................................3
1.1 Package Contents............................................................3
1.2 Features...........................................................................3
1.3 Physical Description.........................................................4
2. Installation .................................................................................5
2.1 Preparing the Site.............................................................5
2.2 Settling the Switch............................................................5
2.3 Connecting to Power........................................................5
2.4 Connecting to Network.....................................................5
3. Web-based Interface Configuration...........................................7
3.1 Setting Up Connection .....................................................7
3.2 Main Menu .......................................................................7
3.3 Configuration..................................................................10
3.3.1 System......................................................................................10
3.3.2 Port ...........................................................................................12
3.3.3 VLAN Mode Configuration........................................................14
3.3.4 Aggregation/ Trunk Configuration.............................................16
3.3.5 Quality of Service......................................................................16
3.3.6 Mirror Configuration..................................................................19
3.3.7 Rate Limit Configuration...........................................................19
3.3.8 SNMP........................................................................................20
3.3.9 Discovery..................................................................................21
3.4.1 Statistics Overview....................................................................21
3.4.2 Detailed Statistics......................................................................22
3.5.1 Restart ......................................................................................24
3.5.2 Factory Default .........................................................................24
3.5.3 Smart Boot................................................................................24
3.5.4 Software Upload .......................................................................25
4. Specifications...........................................................................26
5. Appendix- Command Line Interface ........................................27

3
1. Introduction
Micronet SP676C/SP684C Gigabit Smart Switch delivers wire speed Gigabit performance and
web-based management functions, suitable for high performance workgroups and server
applications. With 16/24 10/100/1000Mbps RJ-45 ports and 4 shared SFP slots for fiber optic
connection, it provides a perfect solution for huge data transmission and preserves the great
flexibility of network infrastructure.
1.1 Package Contents
Before you start installing the device, verify the following items are in the package:
zSP676C/SP684C Gigabit Smart Switch
zQuick Installation Guide
zManual CD
zRS-232 cable
zRack-mount brackets and screws
zPower cord Rubber foot and screws
1.2 Features
Micronet SP676C/SP684C provides the following features:
zCompliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T,
IEEE802.3z 1000Base-LX/SX andIEEE802.3x flow control standards
zSupport IEEE802.1q tag-based VLAN and IEEE802.1p traffic prioritization
zProvide 8K MAC address entries and 16/24 groups of tag-based VLAN table
zProvide 16/24 RJ-45 port of 10/100/1000Mbps and 4 shared SFP slots for fiber extension
zSupport up to 8 ports and 8(16-port)/12(24-port) groups of port aggregation
zSupport QoS function, port base, tag base and DSCP priority
zSupport Rate Limit (ICMP Rate, Broadcast Rate, Multicast Rate)
zSupport Port Mirror
zSupports 340K(16-port)/500K(24-port) bytes buffer Memory
zSupport Jumbo frame 9K bytes
zProvide console port and web-based management interfaces
zProvide Auto-discovery function for easy network management
zSupport SNMP
z19＂Rack mountable
z100 - 240V AC, full range internal power supply

1.3 Physical Description
SP676C Front Panel
SP684C Front Panel
Please refer to the following description for LED indicators and reset button:
Restore Default Button
Use this button to reset the switch or restore factory default settings.
zTo reset the switch, press the button once.
zTo restore factory default settings, press and hold the button for three seconds.
LEDs Status
LED Status Operation
On Power is on.
POWER Off Power is off.
On/Green Connection established.
Blink/Green Transmitting or receiving data.
1000M
Off No link or connected at 10M or 100M
On/Green Connection established.
Blink/Green Transmitting or receiving data.
10/100M
Off No link or connected at 1000M.
Note：The Mini-GBIC slot shares the same LED indicator with the last 4 RJ-45 (copper) ports.
4

5
2. Installation
2.1 Preparing the Site
Select the site that meets the following requirements:
Characteristic Requirement
Temperature (0 to 40˚C) 32 to 104˚F
Humidity 5% ~ 90%, non-condensing
2.2 Settling the Switch
zMounted to 19-inch standard rack
Locate the accessories provided in the product package. Use the rack-mount brackets and
screws to install the switch into any EIA 19” standard rack.
Step 1: Attach the brackets to each side of the chassis.
Step 2: Apply the screws to each side and secure them tightly.
Step 3: Carefully position the switch into the rack.
Step 4: Align the brackets to the side holes on the rack and use rack screws to secure the
chassis with the rack.
zDesktop or any flat surface
The switch can sit on desktop or any flat surface with adequate space and ventilation. If
you want to place it onto a shelf, make sure the shelf can withstand the weight of the
switch.
Step 1: Simply put the switch on the desired place.
Step 2: Ensure the switch receives good ventilation.
Step 3: Proceed to the “Connecting to Power” section.
2.3 Connecting to Power
Locate the provided AC power cord.
Step 1: Connect the AC power cord to the receptacle at the back of the switch.
Step 2: Attach the plug into a standard AC outlet with a voltage ranging from 100 to 240
VAC.
Step 3: The power LED on the front panel will come on then.
2.4 Connecting to Network
zConnecting the Ethernet to the Chassis:
Step 1: First, ensure the power of the switch (and end devices) is turned off.

6
LIt may cause electric shock or any possible harm to you if the power is not switched off.
Step 2: Prepare cable with corresponding connectors for each type of port in use.
Step 3: Connect one end of the cable to the switch and the other end to a desired device.
Step 4: Once the connections between two end-devices are made successfully, turn on the
power.
Note: If you have no modules, please skip this section.
zConnecting the SFP Module to the Chassis:
The optional SFP modules are hot swappable, so you can plug or unplug it before or after
powering on.
Step 1: Verify that the SFP module is the right model and conforms to the chassis
Step 2: Slide the module along the slot. Also be sure that the module is properly seated
against the slot socket/connector
Step 3: Install the media cable for network connection
Step 4: Repeat the above steps, as needed, for each module to be installed into slot(s)
Step 5: Have the power ON after the above procedures are done
In making a switch interconnection, you could use any port to connect another switch with
straight or crossover cable. As all the ports support auto-uplink (MDI / MDI-X) function,
using a straight cable to make a switch-to-switch connection is allowed.
For cable selection, refer to the following table：
Network Speed Connector Cable Type Max. Length
10Mbps RJ-45 Cat. 3, 4, 5 UTP/STP 100 meters
100Mbps RJ-45 Cat. 5 UTP/STP 100 meters
1000Mbps RJ-45 Cat. 5, 5e UTP/STP 100 meters
SFP LC 62.5/125 µm multi-mode fiber
50/125 µm multi-mode fiber
9/125 µm single-mode fiber
220 meters
550 meters
10 kilometers
Note：The SFP slot shares the same LED indicator with the last 4 RJ-45 (copper) ports.

3. Web-based Interface Configuration
SP676C/SP684C provides a web-based interface, allowing users to configure and manage
the switch remotely from web browser.
3.1 Setting Up Connection
In the web browser, enter the IP address “192.168.1.1” as SP676C/SP684C’s URL. Key in
username/password to pass the login step below. The factory default value of
username/password is “admin/admin”.And then, you can enter the main page.
Before you configure this device, make sure the manager PC must be set on the same IP
network as 192.168.1.X and the default subnet mask is 255.255.255.0.
3.2 Main Menu
After you login, the switch shows you the system status information as below and the basic
information of the system. You can select the configuration section by clicking the tabs. It
includes:
Configuration
* System
* Port
* VLAN
* Aggregation
* Quality of Service
* Mirror
* Rate Limit
* SNMP
* Discover
7

Monitoring
* Statistics Overview
* Detailed Statistics
Maintenance
* Restart
* Factory Default
* Smart Boot
* Software Upload
On the left side, the main menu tree for web is listed in the page.According to the function
name in boldface, all functions can be divided into three parts, including “Configuration”,
“Monitoring” and “Maintenance”. The functions of each folder are described in its
corresponded section respectively. As to the function names in normal type are the
sub-functions. When clicking it, the function is performed. The following list is the main
function tree for web user interface.
Configuration
Monitorin
g
Maintenance
Root
To restore the default Values of switch, Click the “Factory Default” Button. If you want to
restart the switch, click the “Restart” Button. To check the connection status of each port
from 1 to 16/24, take a look at the “Status”. To know the detail statistics of one port, click
8

on “Detailed Statistics” button and the window will show.
On the top side, it shows the front panel of the switch. In the front panel, the linked ports
will display green; as to the ports, which are link off, they will be dark.
9

3.3 Configuration
Eleven functions, including System, Port, VLAN, Aggregation Configuration, Quality of
Service, Mirror, Rate Limit, SNMP and Discover is contained in this function folder for
system and network management. Each of them will be described in detail orderly in the
following sections.
10
Configuration
S
ys
t
em
P
or
t
VLAN
A
ggrega
ti
on
Q
ua
lit
y o
f
S
erv
i
ce
Mi
rro
r
R
a
t
e
Li
m
it
SNMP
Di
scove
r
3.3.1 System
System configuration is one of the most important configurations in the switch.
Without the proper setting, network manager will not be able to manage or view the
device. The switch supports manual IP address setting. After applying a new IP
address, a new login page will be started automatically. Please login again to
proceed to other configurations.

Parameter description:
zMAC Address:
It is the Ethernet MAC address of the management agent in this switch.
zS/W Version:
The sfotware version of this switch.
zIPAddress:
Users can configure the IP settings and fill in new values. Then, click <Apply>
button to update. Default: 192.168.1.1
zSubnet Mask:
Subnet mask is made for the purpose to get more network address because any
IP device in a network must own its IP address, composed of Network address
and Host address, otherwise can’t communicate with other devices each other.
But unfortunately, the network classes A, B, and C are all too large to fit for
almost all networks, hence, subnet mask is introduced to solve this problem.
Subnet mask uses some bits from host address and makes an IP address
looked Network address, Subnet mask number and host address. It is shown in
the following figure. This reduces the total IP number of a network able to
support, by the amount of 2 power of the bit number of subnet number (2^(bit
number of subnet number)).
11

Subnet mask is used to set the subnet mask value, which should be the same
value as that of the other devices resided in the same network it attaches.
Default: 255.255.255.0
32 bits
Network ID Host ID
Network ID Host ID
Subnet number
zGateway:
Set an IP address for a gateway to handle those packets that do not meet the
routing rules predefined in the device. If a packet does not meet the criteria for
other pre-defined path, it must be forwarded to a default router on a default path.
This means any packet with undefined IP address in the routing table will be
sent to this device unconditionally. Default: 192.168.1.254
zManagement VLAN:
The VLAN group that is allowed to access the WEB-based management
interface.
zUser name:
The login name. (Default: admin)
zPassword:
The login password. (Default: admin)
zSystem Name:
The name of the device.
To save the configuration of the system, click “Apply” to save
Note: After applying a new IP address, a new login page will be started
automatically. Please login again to proceed to other configurations.
3.3.2 Port
Ports Configuration is applied to change the setting of each port. In this
configuration function, you can set/reset the following parameters, Mode, Flow
Control and Max frame.All of them are described in detail below.
12

Parameter description:
zLink:
Shows the link status of each port. The column lights green with the link speed
while there is valid connection on this port.
zMode:
Select a speed for this port. “Auto Speed” enables auto-negotiation. “Disable”
stop the port from functioning.
zFlow Control
There are two modes to choose in flow control, including Enable and Disable. If
flow control is set Enable, both parties can send PAUSE frame to the
transmitting device(s) if the receiving port is too busy to handle. When it is set
Disable, there will be no flow control in the port. It drops the packet if too much to
handle. Default: Enable
zMax Frame length:
To adjust max frame size. The length is 1518 bytes. The Maximum value can be
up to 9600 bytes.
To save the configuration of the system, click “Apply” to save. You can also click
the “Refresh” button to see the latest status of each port.
13

3.3.3 VLAN Mode Configuration
VLAN divides the network members into groups to reduce packets collisions and
improve the network efficiency. The switch supports 802.1Q tag-based VLAN.
Please follow the instructions to configure.
To add new VLAN groups,
* Fill in a VLAN id from 2 to 4094 in the “VLAN\Port” column.
* Select the ports for each VLAN groups.
* Click the “Apply” button to execute.
To delete a VLAN group
* Clear the members of this VLAN group by clicking those marked checkboxes.
* Clear the VLAN id of the VLAN you want to remove in the “VLAN\Port”
column. (Don’t type N/A. Just leave it blank)
* Click the “Apply” button to execute.
Parameter description:
14
zPVID setting
When the VLAN-enabled switch receives a tagged packet, the packet will be
sent to the port’s default VLAN according to the PVID (port VLAN ID) of the
receiving port.

zPort:
Port Number 1~16/24
zEgress:
Select “tagged” in the drop list to enable the PVID checking and tag inserting
of one port, and select “untagged” to cancel. For example, if an Egress-tagged
port receives an untagged frame, it will be transmitted as a PVID tagged frame.
For the detail tagging status, please refer to the following table.
Untagged Tagged
Packet Frames In Packet Frames Out Packet Frames In Packet Frames Out
Untagged Untagged Untagged Tagged (PVID)
Tagged Untagged Tagged (VID) Tagged (VID)
Pri-tagged Untagged Pri-tagged Tagged (PVID)
zPVID
Port VLAN ID(1~4094)
zFrame
Tagged: block all un-tagged packets from accessing this port.
ALL: All packets are allowed to access this port.
15

3.3.4 Aggregation/ Trunk Configuration
To set up the Port trunk groups, put the ports number into the sameAggregation
group. There are eight groups to choose. Don’t forget to click the “Apply” to save
the setting.
There are three aggregation modes for you to setup, SMAC, DMAC, and XOR.
SMAC mode selects the path of packets according to source MAC while DMAC
mode selects path according to destination MAC. XOR mode calculates the result of
DMAC and SMAC mode to decide the path of pack
3.3.5 Quality of Service
QoS enhances the communication quality by giving different precedence to
classified packets. This switch provides port-based, tag-based and DSCP QoS
modes:
16

Parameter description:
zPort-based mode QoS:
The port-based QoS allows users to configure certain ports as high or low
priority To give priority level for each port:
* Select “Port” in the “Mode” column for those ports that are going to perform
port-based QoS. Click the “Apply” button.
* Click the “Port priority” button. The “Port Priority Setting” page shows up.
* Click on the drop list to specify priority levels.
* Click “Apply” to execute.
zTag based QoS Rule 1:
The Tag based QoS decides packet priority according to the tags that adding on
the packets. To configure Tag Based QoS configuration:
* Select “Tagged” in the “Mode” column for those ports that are going to perform
tag-based QoS. Click the “Apply” button.
* Click the “Tag priority” button. The “Tag Priority Setting” page shows up.
* Select the port that you are going to configure from the drop list.
* Give the priorities as high or low for each Priority Tag types.
* Click the “Apply” button again to execute your configuration.
17

zDSCP mode QoS:
The DSCP mode QoS gives packet priorityby the types of the incoming packets.
We distinguish those packets according to the “Delay”, “Throughput” and
“Reliability” information attaching on the packet. The types are listed as the
following table:
Bit 0 (Delay) Bit 1 (Throughput) Bit 3 (Reliability)
0 (Normal) 0 (Normal) 0 (Normal)
1 (Low) 1 (High) 1 (High)
Note: The device distinguishes packets with DSCP precedence “000(routine)” only.
To configure DSCP Based QoS configuration:
* Select “DSCP” in the “Mode” column for those ports that are going to perform
DSCP-based QoS. Click the “Apply” button.
* Click the “DSCP priority” button. The “DSCP Priority Setting” page shows
up.
* Give the priorities as high or low for each precedence types.
* Click the “Apply” button again to execute your configuration.
18

3.3.6 Mirror Configuration
Mirror Configuration is to monitor the traffic of the network. For example, we assume
that Port A and Port B are Sniffer Port and Monitor Port respectively, thus, the traffic
passed by Port B will be copied to Port A for monitoring.
Parameter description:
zSniffer Port:
Set up the port for monitoring. Valid port is Port 1~16/24 and default is Port 1.
zMonitor Port:
Set up the port for being monitored. Just tick the check box (;) under the port x
and valid port is Port 1~16/24.
3.3.7 Rate Limit Configuration
This “Rate Limit” page allows users to limit the bandwidth for each port and
configure the rules for Storm Control, which limits the flow of broadcast and
multicast
19

3.3.8 SNMP
This device supports SNMP-management, which allows network administrators to
monitor and configure this device with SNMP software. To allow this device to be
managed via SNMP:
*. Select “enable” in the drop list.
*. Specify a trap IP. A trap IP is the destination port for sending trap information,
which is usually the IP address of network administrators.
*. Fill in a name in the “Community Get” column, which is the password for
accessing MIB with read-only authority.
*. Fill in a name in the “Community Set” column, which is the password for
accessing MIB with read and write authority.
20
