MicroNet SP607FA User manual

User’s Manual
EtherFast 10/100M Smart Switch
Model No.: SP607FA/SP607FB
http://www.micronet.info

1
Table of Content
-------------------------------------------------------------------------------------------------------------------------
1. Introduction...............................................................................2
1.1 Package Contents.............................................................................2
1.2 Features............................................................................................2
1.3 Physical Description..........................................................................3
2. Installation.................................................................................4
2.1 Preparing the Site..............................................................................4
2.2 Settling the Switch.............................................................................4
2.3 Connecting to Power.........................................................................4
2.4 Connecting to Network......................................................................4
3. Configuration.............................................................................6
3.1 Setting UP Connection......................................................................6
3.2 Main Page.........................................................................................6
3.3 Port Setup .........................................................................................6
3.4 IP Setup.............................................................................................7
3.5 VLAN Setup.......................................................................................8
3.6 Password Setup................................................................................9
3.7 Restore Default ...............................................................................10
3.8 Reboot Device.................................................................................10
4. Specifications..........................................................................11

2
1. Introduction
Micronet SP607FA/SP607FB EtherFast 10/100M Smart Switch provides an easy way to boost
your network performance while preserving the flexibility of network infrastructure. With the fiber
optic connection, it can accommodate with FTTX solutions. In addition, an intuitive web-based
management interface makes it simple to monitor port status, configure ports, and even setup
VLAN or port priority.
1.1 Package Contents
Verify your package contains the following items:
SP607FA/SP607FB 10/100M Smart Switch
Quick Installation Guide
Manual CD
Power adapter
Magnetic pad
1.2 Features
Micronet SP607FA/SP607FB provides the following features:
Compliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE802.1q tag-based
VLAN, IEEE802.1p traffic prioritization (CoS) and IEEE802.3x flow control standards
Support auto-link and auto-negotiation for all 6 RJ-45 ports
Support one 100M multi-mode fiber optic connection with ST (SP607FA) or SC (SP607FB)
connector
Provide web-based management interface
Support DHCP client for IP configuration
Support 16 groups of port-based or tag-based (802.1q) VLAN
Support IEEE802.1p tag-based priority to achieve QoS
Support 2 outgoing priority queues, with service ratio of 1:4 (Low:High)
2K MAC address entries
768 KBytes memory buffer
Forward and filter packets at non-blocking, full wire speed

1.3 Physical Description
SP607FA front view
SP607FB front view
SP607FA/SP607FB rear view
Please refer to the following table for LED definition
LED Status Operation
On/Green Power is onPOWER Off Power is off
On 100M link detected10/100M Off 10M link detected
On/Green Link detected
Blink/Green Traffic detected
LINK/ACT
Off No link
On/Green Full duplex
Blink/Green Collision
FDX/COL
Off Half duplex
3

4
2. Installation
2.1 Preparing the Site
Select the site that meets the following requirements:
Characteristic Requirement
Temperature 0 to 40˚C
Humidity 10% ~ 90%, non-condensing
2.2 Settling the Switch
The switch can sit on desktop or be mounted on the wall by magnetism, which two rubber
magnet stands provide.
Step 1: Simply put the two rubber magnet stands on the button of switch.
Step 2: Mount the switch on the wall.
2.3 Connecting to Power
Locate the provided AC power cord.
Step 1: Connect the power adapter to the receptacle at the back of the switch.
Step 2: Attach the plug into a standard AC outlet with a voltage ranging from 100 to 240
VAC.
Step 3: The power LED on the front panel will come on then.
2.4 Connecting to Network
Step 1: First, ensure the power of the switch (and end devices) is turned off.
LIt may cause electric shock or any possible harm to you if the power is not switched off.
Step 2: Prepare cable with corresponding connectors for each type of port in use.
Step 3: Connect one end of the cable to the switch and the other end to a desired device.
Step 4: Once the connections between two end-devices are made successfully, turn on the
power.
SP607FA/B provides 6 RJ-45 ports of 10/100M, plus 1 fiber port of 100M. Just connect
your stations to it and play. These RJ-45 ports support auto-uplink, and you can make
inter-switch connection with no more cross-over cable.
For fiber connections, operation mode is forced to 100M and full duplex without
auto-negotiation. Two alternative models can be selected for different connections:
SP607FA is equipped with ST connector, and SP607FB is equipped with SC connector.

5
For cable selection, refer to the following table：
Network Speed Cable Type Max. Length
10Mbps Cat. 3, 4, 5 UTP/STP 100 meters
Cat. 5 UTP/STP 100 meters100Mbps Fiber, 50 or 62.5/125µm
multi-mode 2000 meters
Note: To prevent costly equipment damage and downtime, please consider installing a
surge suppression device or a UPS (Un-interrupted Power Supply).

3. Configuration
3.1 Setting UP Connection
SP607FA/SP607FB is embedded in an http server, and users can access it by web
browser over Internet. Default system information of SP607FA/B is
IP address: 192.168.0.2 Mask: 255.255.255.0
Login Password: 123
3.2 Main Page
After passing the authentication, the main page appears as below.
On the main page, you can select the configuration by clicking the menu tabs located on
the left side of the UI. It includes:
Port Setup
IP Setup
VLAN Setup
Password Setup
Restore Default
Reboot Device
3.3 Port Setup
On the page, you can view the Port status, and set up the Speed/Duplex mode. All TX
ports can be enabled auto-negotiation with other end of link for 100Full, 100Half, 10Full,
and 10Half. They also can be forced to specified operation modes without
auto-negotiation.
6

3.4 IP Setup
The switch must be assigned an IP address before it can be managed via web browser.
The switch provides two methods for IP configuration:
DHCP mode:
The switch supports DHCP client, and can request a dynamic IP address from the first
discovered DHCP server in the network when boot up. In general, the assigned IP can be
monitored in the client list on the DHCP server. The model name and MAC address of the
switch is referred as the DHCP client ID.
If no DHCP server is discovered after a retry period for about 40 seconds, the
pre-configured static IP is used automatically.
Static mode:
One pre-configured IP address is used when DHCP mode is disabled or when DHCP
mode is enabled and no DHCP server is available.
7

Note: Any changes are only effective after next bootup.
3.5 VLAN Setup
SP607FA/SP607FB supports two modes of VLAN: One is Port-based VLAN, and the other
is 802.1Q tag-based VLAN. There are three necessary configurations for VLAN setup:
VLAN Mode: Port-based or 802.1Q VLAN
VLAN mapping table setup: Setup member ports of VLAN
Port PVID setting: Setup PVID and Tag
Port-based VLAN Mode
This mode supports 16 VLAN groups, Group 0 ~ Group 15.
Select Yes to setup members of VLAN in VLAN mapping table. One port can
belong to more than one VLAN groups.
Per port PVID setting is used for index to VLAN Group table. Packet is inserted
with PVID (ex. 3) of the input port as VLAN ID and new CRC. Then, traffic
forwarding is performed only among all member ports of VLAN group (ex. 3).
8

Note: Tag mode settings are preset with untagged mode for all ports and not changeable
in Port-based VLAN mode. VLAN tag in every input tagged packet is ignored.
802.1Q tag-based VLAN Mode
This mode supports 16 VLAN groups, Group 0 ~ Group 15.
Select Yes to setup members of VLAN in VLAN mapping table. One port can
belong to more than one VLAN groups.
Per port PVID setting is used for index to VLAN Group table when an untagged
packet is received. Packet is inserted with PVID (ex. 3) of the input port as VLAN
ID and new CRC. Then, traffic forwarding is performed only among all member
ports of VLAN group (ex. 3). The tagged packet is received and forwarded with no
change.
For outbound transmission, Tag mode of the output port is applied as follows:
Tagged port: The packet is forwarded with no change.
Untagged port: The VID of the packet is removed and forwarded with new CRC.
Note: To provide more flexibility for LAN administrator in performing web management
task, the internal MNG port which connects to the embedded Http server is disclosed for
PVID configuration. The MNG port is also configured as the member port for all VLAN
groups and untagged port permanently.
3.6 Password Setup
To change password setting, enter your new password and reconfirm the input again. Click
on Apply to apply the new password immediately.
9

3.7 Restore Default
Enter the page of Restore Default and then click on Restore button.
Note: One “RESET” button located on rear panel is used to disable DHCP mode and
restore setting back to default. It is useful when the switch is out of control by loss of IP
address or login password. To make the function work, push the button before the switch is
powered on, and keep until all LEDs light for the second time.
3.8 Reboot Device
The command is used to reboot the switch remotely over the network. Normally, it is used
after IP settings are changed.
10

11
4. Specifications
Standards IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX/FX
IEEE802.3x Flow control
IEEE802.1p Traffic prioritization
IEEE802.1q tag-based VLAN
Interface 6*10/100Mbps RJ-45 ports
1*100M fiber port, ST (SP607FA) or SC (SP607FB)
connector
Cable Connection 10BASE-T: Category 3,4,5 UTP/STP
100BASE-TX: Category 5 UTP/STP
100BASE-FX: Fiber, 50 or 62.5/125µm multi-mode
Data Transfer Rate TX: 10M(Half duplex) / 20M(Full duplex)
100M(Half duplex) / 200M(Full duplex)
FX: 200M(Full duplex)
Features Auto negotiation, Auto Uplink, DHCP client, QoS (802.1p),
VLAN (802.1q & port-based)
Management Web-based HTTP
Switch Fabric 1.4 Gbps
Buffer Memory 768 Kbytes
MAC Address Table 2K entries
Filtering/Forwarding Rate 10Mbps: 14,880pps/14,880pps
100Mbps: 148,800pps/148,800pps
Emission FCC Class A, CE
Operating Temperature 0 to 40˚C
Humidity 10 - 90%, non-condensing
Dimension & Weight 144 × 100 × 26 mm, 0.39 kg
Power Supply External power adapter
7.5V DC, 1.0A
2004/11/04
