Miditech MIDI controller keyboard User manual

Owners Manual
0,',67DUW
0,',67DUW0,',67DUW
0,',67DUW
>>>Picture : Start-Keyboard Design.jpg

2
Preface
Congratulations on purchasing the PLGLVWDUW master MIDI controller
keyboard. It is one of the finest products of its kind, made after
extensive research into what customers require from a MIDI
Controller.
When using your PLGLVWDUW in conjunction with a computer and
appropriate music software, you will be able to discover the wonderful
world of Computer Music, with a set of complete musical instruments
from your sound card or workstation.
This manual is written to help you become familiar with the features
of the PLGLVWDUW. Please read the manual carefully to discover all the
features of your PLGLVWDUW. After reading the manual, you will have
a clear understanding of how to transmit different MIDI messages to
other instruments and equipment. For ease of use of MIDI
implementation, we strongly recommend you to have the manual at
hand when you are using the keyboard, especially if you are new to
the world of MIDI.

3
Contents
Preface........................................................................................ 2
Contents..................................................................................... 4
Backpanel connections................................................................. 4
Something you should know before using the MIDI functions .. 5
Switching on ...............................................................................6
Pitch Bend- and Modulation-Wheels ........................................... 7
Specifications .............................................................................8
MIDI Implementation................................................................. 9

4
Contents
>>>Picture : Start-Keyboard Design + descript.jpg
Backpanel Connections
>>>Picture : Backpanel.jpg

5
- Something you should know before using the MIDI Functions -
MIDI is the acronym for Musical Instrument Digital Interface,
which makes all digital musical instruments equipped with this
standardised interface capable of exchanging their MIDI data or talk
to each other !
To explain how MIDI works on your instrument in more detail,
the following illustrations will outline the MIDI functions of the
PLGLVWDUW, which allow you to connect the keyboard to other MIDI
instruments. The versatile MIDI capability of the PLGLVWDUW will
offer you tremendous power in a MIDI environment.

6
Switch ON
There are two ways to power the unit:
1. Use 15-pin cable to sound card in computer.
2. Use external adapter: Plug output jack of proper AC adapter into
the DC socket in the rear panel. Then slide power switch to ON.
Notes:
•When you play on the keyboard, notes and its velocity message
will be transmitted.
•Note number corresponding to the most left key is 36.
•The unit will transmit initial program number 0to the
equipment connected to PLGLVWDUW immediately.

7
Use of the Pitch Bend-Wheel:
Roll upward the pitch Bend wheel wheel to increase the pitch or roll
downward the wheel to lower the pitch smoothly by transmitting pitch
bend message ranging of 0 to 127. Normally, the wheel stays on its
centre position, i.e. no bending.
Use of the Modulations-Wheel:
Roll upward Modulation wheel to add modulation effect ranging of 0
to 16383. The resolution of transmitted data is 128 bit. When the
wheel stays on its lowest position, no modulation message is
transmitted.

8
Specifications:
Model: PLGLVWDUW
Keyboard 49 touch sensitive Keys
Wheels Pitch Bend Wheel
Modulation Wheel
Dimensions 82,3 x 19,5 x 7 cm
Weight 3,4 Kg
Connectors MIDI OUT (DIN),
Sustain Pedal
Gameport /SUB-D(MIDI and power by PC
sound card)
power adaptor
Switch backpanel ON / OFF
•Design and specifications subject to change without notice.
•No liability for printing mistakes

9
MIDI Implementation:
