Midland BT MINI User manual
MANUALE D’USO
INSTRUCTION GUIDE
BEDIENUNGSANLEITUNG
MANUAL DE INSTRUCCIONES
GUIDE D’UTILISATION
BT MINI
PREMIUM ESSENTIAL INTERCOM
UK
midlandeurope.com 1
MIDLAND BT MINI
Thank you for choosing the Midland BT Mini, the most simple Intercom
for Scooters and Motorbikes.
With your BT Mini you can listen to stereo music and GPS navigation
voice, place and answer to phone calls, talk with your friends in full
duplex intercom up to a distance of 400 m.
MAIN FEATURES
•
Bluetooth with support for the following protocols:
Headset profile, Hands Free Profile (HFP), A2DP, AVRCP.
•
Frequency: 2.402 ÷ 2.480 GHz
•
Max power: 2.5 mW
•
Intercom Driver – Passenger
•
Intercom Bike to Bike 400 mt (depending on terrain conditions)
•
Connect your phone to receive/place phone calls
•
Listen to Stereo music (A2DP)
•
Connect your GPS for voice street indications
•
Lithium battery with 8 hours talk time
•
Recharge time: app. 2 hours
•
Waterproof
•
DSP Noise cancelling technology
WHAT’S IN THE BOX
BT Mini is available in two dierent versions:
•
Single cod. C1410
•
Twin cod. C1410.01
The single packing includes:
BT Mini unit, audio kit with two 36 mm speakers, wired microphone for
full helmets, book microphone for open helmets, USB-C recharging
cable, spare microphone sponge, velcro pad for speakers and
microphones, bi-adhesive mount.
The twin package includes the same accessories in double version.
DESCRIPTION OF BT MINI
BT Mini is very easy to operate, because all the main features are
managed by the Control button:
1. Open/Close the intercom
2. Answer to incoming phone calls
3. Play/pause the music
The USB type C plug allows both Audio kit and recharging of the unit
(but not at the same time) .
Control
USB-C plug
Volume +
Volume -
UK
midlandeurope.com 1
MIDLAND BT MINI
Thank you for choosing the Midland BT Mini, the most simple Intercom
for Scooters and Motorbikes.
With your BT Mini you can listen to stereo music and GPS navigation
voice, place and answer to phone calls, talk with your friends in full
duplex intercom up to a distance of 400 m.
MAIN FEATURES
•
Bluetooth with support for the following protocols:
Headset profile, Hands Free Profile (HFP), A2DP, AVRCP.
•
Frequency: 2.402 ÷ 2.480 GHz
•
Max power: 2.5 mW
•
Intercom Driver – Passenger
•
Intercom Bike to Bike 400 mt (depending on terrain conditions)
•
Connect your phone to receive/place phone calls
•
Listen to Stereo music (A2DP)
•
Connect your GPS for voice street indications
•
Lithium battery with 8 hours talk time
•
Recharge time: app. 2 hours
•
Waterproof
•
DSP Noise cancelling technology
WHAT’S IN THE BOX
BT Mini is available in two dierent versions:
•
Single cod. C1410
•
Twin cod. C1410.01
The single packing includes:
BT Mini unit, audio kit with two 36 mm speakers, wired microphone for
full helmets, book microphone for open helmets, USB-C recharging
cable, spare microphone sponge, velcro pad for speakers and
microphones, bi-adhesive mount.
The twin package includes the same accessories in double version.
DESCRIPTION OF BT MINI
BT Mini is very easy to operate, because all the main features are
managed by the Control button:
1. Open/Close the intercom
2. Answer to incoming phone calls
3. Play/pause the music
The USB type C plug allows both Audio kit and recharging of the unit
(but not at the same time) .
Control
USB-C plug
Volume +
Volume -
UK
midlandeurope.com2
BT MINI INSTALLATION
Place both speakers in the deep ear pocket of your helmet. You can fix
the speakers using the velcro pad provided in the box.
Place both speakers as much as possible close and centered to your
ears. Place the wired microphone in front of your mouth using the
adhesive Velcro pad.
If you are using the half-boom microphone, fix the boom on the left
side and keep the sponge as closely as possible to your mouth when
wearing the helmet. Be sure the white arrow is facing your mouth.
Place the BT Mini unit on the left side of your helmet using the
adhesive mount available inside the box.
The BT Mini can be easily fitted onto the helmet by sliding it downwards
so that it fits into the slot of the adhesive Mount.
The BTMini is maintained in position thanks to the fixing clip located on
the upper section (A).
To detach BT Mini, simply press the fixing clip (A) and push the unit
upwards.
You can hide the speaker wires under the helmet padding.
CHARGING
Only the USB-C cable is supplied inside the box.
You can charge your BT Mini using any standard USB wall adapter or
PC port. In the box you can find only the USB type C recharging cable.
It takes about 2 hours to fully charge.
A
Bi-adhesive mount
UK
midlandeurope.com2
BT MINI INSTALLATION
Place both speakers in the deep ear pocket of your helmet. You can fix
the speakers using the velcro pad provided in the box.
Place both speakers as much as possible close and centered to your
ears. Place the wired microphone in front of your mouth using the
adhesive Velcro pad.
If you are using the half-boom microphone, fix the boom on the left
side and keep the sponge as closely as possible to your mouth when
wearing the helmet. Be sure the white arrow is facing your mouth.
Place the BT Mini unit on the left side of your helmet using the
adhesive mount available inside the box.
The BT Mini can be easily fitted onto the helmet by sliding it downwards
so that it fits into the slot of the adhesive Mount.
The BTMini is maintained in position thanks to the fixing clip located on
the upper section (A).
To detach BT Mini, simply press the fixing clip (A) and push the unit
upwards.
You can hide the speaker wires under the helmet padding.
CHARGING
Only the USB-C cable is supplied inside the box.
You can charge your BT Mini using any standard USB wall adapter or
PC port. In the box you can find only the USB type C recharging cable.
It takes about 2 hours to fully charge.
A
Bi-adhesive mount
UK
midlandeurope.com 3
BT MINI MAIN FUNCTIONALITY
Midland BT Mini is a full duplex intercom communication system
Driver to Passenger and Bike to Bike communication up to a maximum
distance of 400 mt. (depending on terrain conditions).
In addition you can listen to Stereo music, place and answer to phone
calls or receive voice street indications from the GPS.
If you receive a phone call during an intercom communication, the
intercom is closed and reopens as soon as the phone call is over.
If the intercom communication is open while you are listening to music,
the music will be paused. When the intercom is closed, the music is
automatically resumed.
If you receive a phone call while you are listening to music, the music
will be paused. When the phone call is closed, the music is automatically
resumed.
ATTENTION: Midland BT Mini automatically answers to an incoming
phone call after 8 sec. You can disable this feature and manually answer
to the incoming calls.
Enable auto answer
Vol+ and Vol- for 5 sec. Voice: “Enable”
Disable auto answer
Vol+ and Vol- for 5 sec. Voice: “Disable”
Basic Functionalities
Turn ON Press 1 sec. on Control and Vol- buttons
Voice prompt: “Power on” and “Battery
status”
Turn OFF Press 1 sec. on Control and Vol- buttons
Voice prompt: “Power o”
Volume adjustment Short press on Vol+ or Vol- or keep
pressed
Pairing to a phone/GPS
Start pairing on BT Mini Unit is o: Control for 5 sec
Red and blue LED blink alternately
Voice: “Pairing” when starts,
“Pairing successful” when finished
Start pairing on Bluetooth
devices (phone/GPS/MP3) Searches for Bluetooth device from the
phone or GPS and select “Midland BT
Mini” from the list
PIN (if requested) “0000”
How to use a phone
Answer call Short press on Control button during
incoming call
End call Short press on Control
Reject call Control for 3 sec when ringing
Voice dial Double click on Control button or Vol+
UK
midlandeurope.com 3
BT MINI MAIN FUNCTIONALITY
Midland BT Mini is a full duplex intercom communication system
Driver to Passenger and Bike to Bike communication up to a maximum
distance of 400 mt. (depending on terrain conditions).
In addition you can listen to Stereo music, place and answer to phone
calls or receive voice street indications from the GPS.
If you receive a phone call during an intercom communication, the
intercom is closed and reopens as soon as the phone call is over.
If the intercom communication is open while you are listening to music,
the music will be paused. When the intercom is closed, the music is
automatically resumed.
If you receive a phone call while you are listening to music, the music
will be paused. When the phone call is closed, the music is automatically
resumed.
ATTENTION: Midland BT Mini automatically answers to an incoming
phone call after 8 sec. You can disable this feature and manually answer
to the incoming calls.
Enable auto answer
Vol+ and Vol- for 5 sec. Voice: “Enable”
Disable auto answer
Vol+ and Vol- for 5 sec. Voice: “Disable”
Basic Functionalities
Turn ON Press 1 sec. on Control and Vol- buttons
Voice prompt: “Power on” and “Battery
status”
Turn OFF Press 1 sec. on Control and Vol- buttons
Voice prompt: “Power o”
Volume adjustment Short press on Vol+ or Vol- or keep
pressed
Pairing to a phone/GPS
Start pairing on BT Mini Unit is o: Control for 5 sec
Red and blue LED blink alternately
Voice: “Pairing” when starts,
“Pairing successful” when finished
Start pairing on Bluetooth
devices (phone/GPS/MP3) Searches for Bluetooth device from the
phone or GPS and select “Midland BT
Mini” from the list
PIN (if requested) “0000”
How to use a phone
Answer call Short press on Control button during
incoming call
End call Short press on Control
Reject call Control for 3 sec when ringing
Voice dial Double click on Control button or Vol+
UK
midlandeurope.com4
Redial Double click on Vol- button
(voice: “Redial”)
Cancel redial Short press on Control
Auto answer feature By default the “Auto answer” is
active, that means the BT Mini will
automatically answer to an incoming
call after 8 sec.
How to use a music player
Play/Pause music Press 3 sec on Control button
FWD song Vol+ double click
BWD song Vol- double clilck
Pairing to another BT Mini Unit
Start pairing on both
BT Mini units Unit is in stand by mode, press Vol- for
5 sec on both units, red and blue LED
blink alternately
Voice prompt: “Pairing successful”
when finished
How to use the intercom
Open/Close intercom Short press on Control button
Pairing to another Intercom
It is possible to pair the BT Mini to another model/brand intercom, only
if the other unit supports the Universal Intercom feature.
The BT Mini will use the phone pairing to connect to the Universal
Intercom of the other unit.
Start pairing on
BT Mini Unit Unit is power o
Control for 5 sec
Red and blue LED blink alternate
Start pairing on other
Intercom Follow the manual for “Universal
intercom pairing” on the other unit
How to use the Universal Intercom
Open/Close
Universal Intercom Control double click/Control short
press
Attention: you need to repeat twice the Open command: after you
hear the voice “Device connected”, double click Control again.
Special Action
Reset all pairing Unit is power o: Vol- and Control for
7 sec (LED full blue for 3 sec)
Cancel Pairing When pairing is in progress, double click
on Vol+ , Vol- or Control
Enable auto answer Vol+ and Vol- for 5 sec (voice
“Enable”)
Disable auto answer Vol+ and Vol- for 5 sec (voice
“Diseable”)
UK
midlandeurope.com4
Redial Double click on Vol- button
(voice: “Redial”)
Cancel redial Short press on Control
Auto answer feature By default the “Auto answer” is
active, that means the BT Mini will
automatically answer to an incoming
call after 8 sec.
How to use a music player
Play/Pause music Press 3 sec on Control button
FWD song Vol+ double click
BWD song Vol- double clilck
Pairing to another BT Mini Unit
Start pairing on both
BT Mini units Unit is in stand by mode, press Vol- for
5 sec on both units, red and blue LED
blink alternately
Voice prompt: “Pairing successful”
when finished
How to use the intercom
Open/Close intercom Short press on Control button
Pairing to another Intercom
It is possible to pair the BT Mini to another model/brand intercom, only
if the other unit supports the Universal Intercom feature.
The BT Mini will use the phone pairing to connect to the Universal
Intercom of the other unit.
Start pairing on
BT Mini Unit Unit is power o
Control for 5 sec
Red and blue LED blink alternate
Start pairing on other
Intercom Follow the manual for “Universal
intercom pairing” on the other unit
How to use the Universal Intercom
Open/Close
Universal Intercom Control double click/Control short
press
Attention: you need to repeat twice the Open command: after you
hear the voice “Device connected”, double click Control again.
Special Action
Reset all pairing Unit is power o: Vol- and Control for
7 sec (LED full blue for 3 sec)
Cancel Pairing When pairing is in progress, double click
on Vol+ , Vol- or Control
Enable auto answer Vol+ and Vol- for 5 sec (voice
“Enable”)
Disable auto answer Vol+ and Vol- for 5 sec (voice
“Diseable”)
UK
midlandeurope.com 5
Voice prompt/Beep/Light
ACTION VOICE PROMPT BEEP LED LIGHT
When you turn on the unit Power ON + battery status Blinking Blue
When you turn o the unit Power OFF Blinking Red 3 times
Start pairing Pairing Red /Blue alternate
After pairing Pairing successful
Answer phone call 1 Beep
End phone call 1 Beep
Reject phone call 2 Beep
Voice command 1 Beep
Redial Redial
Play/Pause 1 Beep
FWD 1 Beep
BWD 1 Beep
Intercom open 1 Beep
Intercom close 2 Beep
Adjust volume 1 Beep
Charging Blinking red
Full charge Full blue
Enable auto answer Enable
Disable auto answer Disable
UK
midlandeurope.com6
WARRANTY
The warranty lasts 24 months for the main device and 6 months for the
accessories (batteries, chargers, antennas, headsets, microphones).
For further information about the warranty, please visit:
www.midlandeurope.com
EUROPEAN CE NOTICE CERTIFICATION
AND SAFETY APPROVAL INFORMATION
This product is CE marked according to the RED directive 2014/53/UE
and is free use in all the EU countries.
Users are not permitted to make any changes or modifications to the
device.
Modifications which are not expressly approved by the producer
invalidate the warranty card.
For further information, please go to our website:
www.midlandeurope.com
Other manuals for BT MINI
3
Table of contents
Other Midland Conference System manuals
