› INSTRUCTION GUIDE
PMR446 TRANSCEIVER
G11V
PUT YOURSELF IN ACTION
PUT YOURSELF IN ACTION

Midland G11V instruction guide | 1
Index
Programming software (optional) 2
Content 2
Main characteristics 3
Main controls and parts of the radio 4
Operations 6
Power on/o and volume adjustment 6
Transmission 6
Monitor 6
Scan 6
Vox 7
Squelch 7
Roger Beep (end of transmission tone) 7
Beep Tone 7
Battery recharge 8
Maintenance 8
Technical specifications 9

2 | Midland G11V instruction guide
Thanks for choosing Midland! G11V is a portable transceiver that is free use in almost all
European countries. For further information, we suggest you to look at the “Restrictions
on the use” chart.
Midland G11V is a multi-task PMR446 transceiver.
Combining the latest technology in radio communication along with a sturdy me-
chanical frame, G11V is the ideal and eective solution for the professionals who
need to stay in touch with the working team (in construction sites, buildings, shows,
trade fairs or hotels) or for leisure users that just want to keep up with friends and
family.
Programming software (optional)
Thanks to Midland Programming software specifically made for G11V, it is possible
to increase the performance of your radio or to reduce its functionality by disabling
some of the default features (CTCSS, TOT...)
For further information, please consult the Programming software manual.
Any attempt to change frequencies or output power of the radio invalidates the
approval.
Content
› 1 G11V transceiver
› 1 belt clip
› 1 wall adaptor
› 1 1600mAh Li-ion rechargeable battery pack
› 1 desktop charger

Midland G11V instruction guide | 3
Main characteristics
› PMR446 Transceiver
› Output power: 500mW
› Channel spacing: 12.5KHz
› Voice announcement
› Built-in VOX function (vocal-activated communication)
› Scan
› Beep keypad
› Roger Beep
› Battery save
› Monitor
› Squelch
Coverage/Range
The maximum range depends on terrain condition and is obtained during use in an
open space.
The only limitation to maximum possible range are environmental factors such as
blockage caused by trees,buildings, or other obstructions. Inside a car or a metallic
constructions, the range can be reduced. Normally the coverage in the city, with
buildings or other obstructions is about 1 or 2 Km. In open space but with obstruc-
tions like trees, leaves or houses the maximum possible range is about 4-6 Km. In
open space, without obstructions and in sight, like for example in mountain, the
coverage can be more than 12 Km.

4 | Midland G11V instruction guide
Main controls and parts of the radio
1. Antenna
2. Encoder: rotate clockwise or counter-clockwise to select the desired channel.
When you select the desired channel you will hear a vocal announcement in-
dicating the channel number (ex. Channel 1, etc..).
3. Power/volume knob- turn clockwise to power on and increase the volume le-
vel. Turn counter-clockwise to decrease the volume level and power o.
4. Speaker
5. Built-in microphone
6. Led indicator:
RED: TX
GREEN: RX
7. PTT: push this button to transmit, release it to receive.
8. Function key 1: Briefly press this button to activate the Monitor function;
keep pressed this button for about 4 sec. to enable the VOX feature. The
radio will emit an acoustic sound each time you press the button to confirm
that the desired function has been activated/deactivated.
9. Function key 2: keep pressed this button for about 4 sec. to activate the
SCAN function. The radio will emit an acoustic sound each time you press
the button to confirm you that the function has been activated/deactivated.
10. External Speaker/Mic Jack- allows the connection with external devices such
as headsets, microphones.

Midland G11V instruction guide | 5
V
V
1
2 3
4
5
6
V
8
9
7
10

6 | Midland G11V instruction guide
Operations
Power on/o and volume adjustment
Rotate the Power/Volume knob clockwise to turn the radio on.
Rotate the control clockwise /counter-clockwise to adjust the volume level as you
prefer.
Rotate the control counter-clockwise till hearing a mechanical “click”, to turn the
radio o.
Transmission
To communicate, all radios in your group must be set to the same channel.
Briefly press the Function key 1 to enable the Monitor feature in order to make sure
that the frequency is not busy, then press the PTT button.
Release the PTT key to receive.
Only one user at a time can talk during radio communications. Therefore, it is important
not to transmit when you are receiving a communication and use the transmission mode
sparingly to allow other users to use the feature.
Transmission consumes a significant amount of energy and should therefore be used
sparingly to prolong the battery life.
If you are unable to contact a station that you have no problems in receiving, the station
may be using CTCSS tones or DCS codes.
Monitor
The Monitor feature is for temporarily excluding (opening) the Squelch, in order to
listen to signals that are too weak to keep the Squelch permanently opened.
Briefly press the Function key 1 to enable such function.
Scan
Keep pressed the Function key 2 for about 4 sec. to enable the SCAN function:
the radio will scan all channels from the channel in use.
Whenever any signal is detected, the radio will suspend the Scan; to resume scan-
ning, press again the PTT button.

Midland G11V instruction guide | 7
Vox
G11V enables hands free conversations through the VOX function: just speak in the
direction of the microphone and the communication will be automatically activated.
The VOX sensitivity can be adjusted in 10 dierent levels (0,1,2,3…9) trough the
programming software:
0 means that the VOX is turned o, 1 is the lowest VOX sensitivity level and 9 is
the highest one.
By default, the VOX sensitivity of G11V is set on level 5.
To activate the VOX feature, keep pressed for about 4 sec. the Function key1.
Squelch
The Squelch function suppresses noises on free channels and allows to receive even
weak signals.
G11V has 10 dierent Squelch levels settable by programming software: 0 means
that the Squelch is turned o; from level 1 to level 9 you will have dierent levels of
noise reduction. The higher is the level, the louder will be the Squelch.
By default, the Squelch level of G11V is set on level 5.
Make sure you do not set an excessively high squelch level because in this case you may
not be able to receive weaker signals. On the other hand an excessively low Squelch value
could enable the Squelch even when no signals are present.
Squelch must always be adjusted when no signals are present.
The Time Out timer is settable from 30 sec to 270 sec. only through the program-
ming software.
This feature is disabled by default.
Roger Beep (end of transmission tone)
When the PTT button is released, the radio will beep to confirm to other users that
you’ve finished your transmission and that they can begin to speak.
Beep Tone
This function permit you to produce a beep tone every time you press a button.

8 | Midland G11V instruction guide
Battery recharge
G11V is equipped for using a 7,4V Li-ion rechargeable battery pack which can be
recharged connecting the socket of the AC/DC wall adaptor to a mains power so-
cket and inserting the jack of the wall adaptor into the desktop charger plug.
It takes 4-5 hours to fully recharge the radio.
For maximum battery life, we recommend charging the battery pack when the
G11V is o and the battery pack is fully discharged.
! Using a dierent battery charger other than the one specified can cause damage to
your device or may even cause explosions and personal injuries.
The Battery power saving feature enables a reduction in consumption of up to 50%.
If it has been set, it comes on automatically when the transceiver does not receive
any signal for more than 7 seconds in order to save the battery life. Power saving can
be set only through Programming software.
Maintenance
Your G11V was designed to fulfill any warranty obligations and to enjoy this product
for many years.
As for all the electronically devices, we recommend you to follow this few sugge-
stions:
› Do not attempt to open the unit. Non-expert handling of the unit may damage
it and/or annul the warranty.
› When using regulated power supply, take notice of power voltage, that must be
between 6V and 8V to avoid damages.
› High temperatures can shorten the life of electronic devices, and warp or melt
certain plastics. Do not store the radio in dusty or dirty areas.
› Keep the Radio dry. Rainwater or damp will corrode electronic circuits.
› If it appears that the Radio diuses peculiar smell or smoke, please shut o its
power immediately and take o the charger or battery from the Radio.
› Do not transmit without antenna.

Midland G11V instruction guide | 9
Technical specifications
General
Frequency range 446.00625- 446.09375 MHz (PMR446)
Working temperature -20°+50°
Operating voltage 7.4V
Operate mode Simplex
Dimensions 100mm×58mm×33mm (without Antenna)
Weight 203g (Battery pack included)
Antenna impedance 50Ω
Duty cycle 5/5/90%
Category B
Transmitter
Frequency stability ±2.5PPM
Output power ≤500mWERD
Max frequency deviation ≤2,5KHz
Audio distortion ≤3%
Adjacent channel power < 60 dB
Spurious radiation Within European legal terms
Occupied bandwidth Within European legal terms
Receiver
RF sensibility < 0.2UV@20 dB SINAD
Audio distortion ≤3%
Audio response 300Hz ÷ 3KHz
Adjacent channel selectivity Within European legal terms
Intermodulation rejection Within European legal terms
Spurious response Within European legal terms
Blocking Within European legal terms
WARNING: Direct plug-in ac/dc power supply must be used for disconnecting the
transceiver from the mains; the desktop charger must be positioned close to the unit
and easily accessible.

10 | Midland G11V instruction guide
Problem solving
Problem Possible Cause Solution
The radio doesn’t switch
on
The battery pack is di-
scharged and/or has not
been installed correctly.
Verify that the battery
pack is charged and that
it has been correctly
installed.
The radio switches o
shortly after it has been
switched on Discharged battery pack. Recharge the battery
pack.
The battery pack does
not recharge
The battery-charger has
not been connected or
installed correctly.
Inspect the connections
of the battery-charger
and the installation of the
batteries.
The radio switches on
but is unable to receive
signals
The site of installation is
too shielded. Move to an another area.
The volume is too low Adjust the volume level.
Incorrect CTCSS or
DCS
Check that the CTCSS
tone or DCS code
corresponds to the one
set by the parties you are
communicating with.
Noise is always present in
reception mode The Monitor function is enabled. Disable the Monitor function.
It is not possible to
communicate with other
parties
An incorrect radio chan-
nel has been selected.
Select the same radio
channel used by the
parties you are commu-
nicating with.
The radio is installed in a
shielded area or is too far
from the party you are
communicating with
Move to another area.
Incorrect CTCSS or
DCS
Check that the CTCSS
tone or DCS code
corresponds to the one
set by the parties you are
communicating with.

Midland G11V instruction guide | 11
Reception is fragmented
and/or disturbed
The signal is very weak. Try temporarily to disable the Squelch by means of
the Monitor feature.
The transmission distance
is excessive and/or
there are obstacles in the
transmission path
Move closer to the party
you are communicating
with or to another area.
Other parties are using
the same channel
Check the trac on the
radio channel by means
of the Monitor feature
and select another chan-
nel if required.
The radio has been
installed too close to
equipment that causes
interference (televisions,
computers, etc.)
Increase the distance
between the radio and
this equipment.
Transmission is not always
possible
The channel is used by
an excessive number of
parties or the transmis-
sion has been barred due
to a busy channel.
Select another channel.
Ask the radio link provi-
der to disable the block
due to busy channel.
VOX causes the radio
to accidentally enable
transmission
The sensitivity and/or
environmental
noise is too high.
Reduce the VOX sen-
sitivity.
The VOX feature
requires speaking in a
loud voice The sensitivity is too low.
If the environmental
noise is not high, increase
the sensitivity or use an
optional microphone.
The autonomy of the
battery pack is limited Commission time is too high.
Try reducing the
transmission time and/or
using a low power.
Logic related faults
(unreadable displayed
symbols, functions
blocked, etc.)
Incorrect setting caused
by a problem with the
power supply.
Recharge the battery
pack

Prodotto o importato da:
CTE INTERNATIONAL s.r.l.
Via. R.Sevardi 7- 42124 Reggio Emilia Italia
www.cte.it - www.midlandeurope.com
L’uso di questo apparato può essere soggetto a restrizioni nazionali (per l’uso in Italia in modalità PMR446, è
richiesta una dichiarazione di possesso. Prima dell’uso leggere attentamente le istruzioni.
Produced or imported by:
CTE INTERNATIONAL s.r.l.
Via. R.Sevardi 7 42124 Mancasale Reggio Emilia Italy
Imported by:
ALAN - NEVADA UK
Unit 1 Fitzherbert Spur Farlington Portsmouth Hants.
P06 1TT - United Kingdom
www.nevada.co.uk
The use of this transceiver can be subject to national restrictions. Read the instructions carefully before
installation and use.
Importado por:
MIDLAND IBERIA, SA
C/Cobalt, 48 - 08940 Cornellà de Llobregat (Barcelona - España)
Tel: [phone] Fax: [phone]
www.midland.es
El uso de este equipo puede estar sujeto a la obtención de la correspondiente autorización administrativa. Lea
atentamente las instrucciones antes de usar el equipo.
Vertrieb durch:
ALAN ELECTRONICS GmbH
Daimlerstraße 1K - D-63303 Dreieich Deutschland
www.alan-electronics.de
Die Benutzung dieses Funkgerätes ist von den landesspezifischen Bestimmungen abhängig. Vor Benutzung
Bedienungsanleitung beachten.
PUT YOURSELF IN ACTION
PUT YOURSELF IN ACTION
