Miele KM 6395 User manual

Operating and installation instructions
Ceramic cooktops with induction
To avoid the risk of accidents or damage to the appliance, it is essential
to read these instructions before it is installed and used for the first time.
M.-Nr. 09 639 290en - AU, NZ

Warning and Safety instructions .....................................4
Caring for the environment.........................................14
Induction........................................................15
The induction principle .............................................15
Noises ..........................................................16
Pans ............................................................17
Touch display....................................................18
On/Off ........................................................18
Multi .........................................................18
Trio ..........................................................18
Solo ..........................................................18
Operating tips ..................................................19
Settings .......................................................19
Clock / Timer...................................................19
Cooking duration ...............................................19
Minute minder ..................................................19
Main menu ....................................................20
Power levels ...................................................20
System lock....................................................20
System lock for cleaning..........................................20
Back .........................................................21
Pan recognition active ...........................................21
Pan recognised.................................................21
Pan not recognised..............................................21
Practical tips ...................................................21
Residual heat indicators ..........................................21
Before using for the first time.......................................22
Cleaning for the first time............................................22
Using for the first time ..............................................22
Operation .......................................................23
Operating principles ...............................................23
Booster..........................................................23
Contents
2

Safety features ...................................................24
Safety switch-off...................................................24
Overheating protection .............................................24
Tips on saving energy ............................................25
Cleaning and care ................................................26
Problem solving guide ............................................28
Optional accessories..............................................30
Safety instructions for installation...................................31
Safety distances..................................................32
Installation notes .................................................36
Building-in dimensions ...........................................37
Installation ......................................................38
Electrical connection..............................................40
Wiring diagram ...................................................42
After sales service, data plate, warranty ..............................43
Contents
3

This appliance complies with all relevant safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the appliance,
please read these instructions carefully before installation and
before using it for the first time. They contain important notes on
installation, safety, use and maintenance. Miele cannot be held
liable for damage caused by non-compliance with these Warning
and Safety instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Warning and Safety instructions
4

Correct application
~This cooktop is designed for domestic use and for use in similar
environments by guests in hotel or motel rooms, bed & breakfasts
and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
~The appliance is not suitable for outdoor use.
~This appliance must only be used to cook food and keep it warm.
Any other use is not supported by the manufacturer and could be
dangerous.
~This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they have been given
supervision or instruction concerning its use by a person
responsible for their safety.
~Do not modify this appliance.
Warning and Safety instructions
5

Safety with children
~Use the system lock to prevent children switching on the
appliance or altering the settings.
~Small children must be kept away from the appliance unless they
are constantly supervised.
~Older children may only use the appliance if they have been
shown how to use it in a safe way and understand the hazards
involved.
~Children must not be allowed to clean the appliance
unsupervised.
~This appliance is not a toy! To prevent the risk of injury, do not
allow children to play with the appliance or its controls.
~The appliance gets hot when in use and remains hot for quite a
while after being switched off. Keep children well away from the
appliance until it has cooled down and there is no danger of
burning.
~Danger of burning.
Do not store anything which might arouse a child's interest in
storage areas above or next to the appliance. Otherwise they could
be tempted into climbing onto the appliance
~Danger of burning or scalding.
Keep all pans out of reach of children. Turn pan handles inwards
away from the edge of the cooktop. Special cooktop guards are
available from good retail outlets.
~Packaging, e.g. cling film, polystyrene and plastic wrappings,
must be kept out of the reach of babies and children. Danger of
suffocation. Dispose of or recycle all packaging safely as soon as
possible.
Warning and Safety instructions
6

Technical safety
~Installation, maintenance and repair work may only be carried out
by a suitably qualified and competent person in strict accordance
with national and local safety regulations. Installation, maintenance
and repairs by unqualified persons could be dangerous. Miele
cannot be held liable for unauthorised work.
~A damaged appliance can be dangerous. Before installation,
check the appliance for visible signs of damage. Do not use a
damaged appliance.
~The electrical safety of this appliance can only be guaranteed
when correctly earthed. It is most important that this basic safety
requirement is observed and regularly tested, and where there is
any doubt, the household wiring system should be inspected by a
qualified electrician.
~To avoid the risk of damage to the appliance, make sure that the
connection data (fuse rating, frequency and voltage) on the data
plate corresponds to the household supply, before connecting the
appliance to the mains supply.
Consult a qualified electrician if in any doubt.
~Do not connect the appliance to the mains electricity supply by a
multi-socket unit or an extension lead. These do not guarantee the
required safety of the appliance (e.g. danger of overheating).
~For safety reasons, this appliance may only be used after it has
been built in.
~This cooktop must not be installed and operated in mobile
installations (e.g. on a ship).
Warning and Safety instructions
7

~Do not open the casing of the appliance.
Tampering with electrical connections or components and
mechanical parts is highly dangerous to the user and can cause
operational faults.
~While the appliance is under warranty, repairs should only be
undertaken by a service technician authorised by Miele. Otherwise
the warranty will be invalidated.
~Faulty components must only be replaced by genuine Miele
original spare parts. The manufacturer can only guarantee the safety
of the appliance when Miele replacement parts are used.
~If the connection cable is damaged or if the appliance is supplied
without a cable, it must be replaced or fitted with a specialist
connection cable by a suitably qualified electrician (see "Electrical
connection").
~The appliance must be disconnected from the mains electricity
supply during installation, maintenance and repair work.
Ensure that power is not supplied to the appliance until after it has
been installed or until after any maintenance or repair work has been
carried out.
It is only completely isolated from the electricity supply when:
–the mains fuse is disconnected,
–he screw-out fuse is removed (in countries where this is
applicable),
–it is switched off at the wall socket and the plug is withdrawn from
the socket, or it is switched off at the isolator.
Warning and Safety instructions
8

~If the cooktop is fitted with a communication module, in addition
to disconnecting the cooktop, this module must also be
disconnected from the mains electricity during installation and
maintenance of the cooktop as well as while any repair work is being
carried out.
~The cooktop is not intended for use with an external timer switch
or a remote control system.
~Danger of electric shock.
Do not use the cooktop if it is faulty, or if the ceramic surface is
cracked, chipped or damaged in any way. Switch it off immediately,
and disconnect it from the mains electricity supply.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings in a clean condition at all times. Any damage
caused by cockroaches or other vermin will not be covered by the
warranty.
Warning and Safety instructions
9

Correct use
~For people fitted with a heart pacemaker:
Please note that the area immediately surrounding the cooktop is
electromagnetically charged. It is unlikely to affect a pacemaker.
However, if in any doubt, consult the manufacturer of the pacemaker
or your doctor.
~To prevent damage to items which are susceptible to magnetic
fields, e.g. credit cards, digital storage devices, pocket calculators,
etc, do not leave them in the immediate vicinity of the cooktop.
~The appliance gets hot when in use and remains hot for a while
after being switched off. There is a danger of burning until the
residual heat indicators go out.
~You could burn yourself on the hot cooktop. Protect your hands
with heat-resistant pot holders or gloves when handling hot pots and
pans. Do not let them get wet or damp, as this causes heat to
transfer through the material more quickly with the risk of scalding or
burning yourself.
~When the appliance is switched on either deliberately or by
mistake, or when there is residual heat present, there is the risk of
any metal items left on the cooktop heating up, with the danger of
burning.
Depending on the material, other items left on the cooktop could
also melt or catch fire.
Damp pan lids might adhere to the ceramic surface and be difficult
to dislodge.
Do not use the appliance as a resting place.
Switch the cooking zones off after use.
~Do not store any metal items or utensils in a drawer under the
cooktop as they can become hot if the induction cooktop is used
intensively for a long time.
Warning and Safety instructions
10

~Do not allow solid or liquid sugar, or pieces of plastic or
aluminium foil to get onto the cooking zones when they are hot, as
they can damage the ceramic surface when it cools down. If this
should occur, switch off the appliance and scrape off all the sugar,
plastic or aluminium residues from the cooktop whilst still hot, using
a shielded scraper blade. Wear oven gloves.
Allow the cooking zones to cool down and then clean them with a
suitable ceramic cooktop cleaning agent.
~Do not heat up unopened tins of food on the cooktop, as
pressure will build up in the tin, causing it to explode.
~When using an electrical appliance, e.g. a hand-held food
blender, near the appliance, ensure that the cable of the electrical
appliance cannot come into contact with the hot appliance. The
insulation on the cable could become damaged,
~Do not cover the cooktop, e.g. with a cooktop cover, a cloth or
protective foil. The material could catch fire, shatter or melt if the
appliance is switched on by mistake or if residual heat is still
present.
~Oil and fat can overheat and catch fire. Do not leave the
appliance unattended when cooking with oil or fat. If oil or fat does
catch fire, do not attempt to put out the flames with water.
Disconnect the appliance from the mains and use a suitable fire
blanket, saucepan lid, damp towel or similar to smother the flames.
~Do not flambé under a rangehood. The flames could set the
rangehood on fire.
Warning and Safety instructions
11

~Induction heating works extremely quickly, so the base of the pan
could heat up to the temperature at which oil or fat self-ignites within
a very short time. Do not leave the appliance unattended whilst it is
being used.
~Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or substances
in a drawer under the cooktop. Cutlery inserts must be
heat-resistant.
~If the appliance is installed behind a kitchen furniture door, it may
only be used with the furniture door open. Do not close the door
whilst the cooktop in use or whilst there is any residual heat present.
~Do not heat an empty pan.
~Heat oil or fat for a maximum of one minute. Do not use the
Booster function to heat oil or fat.
~Pans which boil dry can cause damage to the ceramic glass. Do
not leave the appliance unattended whilst it is being used.
~Do not use pots or pans on the cooktop with bases with
pronounced edges or ridges. These could scratch or scour the
ceramic glass surface permanently. Only use pots and pans with
smooth bases.
~Grains of salt, sugar and sand (e.g. from cleaning vegetables)
can cause scratches if they get under pan bases. Make sure that
the ceramic surface is clean before placing pans on it.
~Do not place hot items or pans on the touch display as this could
cause damage to the electronics underneath.
Warning and Safety instructions
12

~Do not drop anything on the ceramic surface. Even a light object
could cause damage in certain circumstances.
~This appliance is fitted with a cooling fan. If a drawer is fitted
directly underneath the cooktop, ensure that there is sufficient space
between the drawer and its contents and the underside of the
appliance in order to ensure sufficient ventilation of the cooktop.
Do not store pointed or small items or paper in the drawer. They
could get in through the ventilation slots or be sucked into the
housing by the fan and damage the fan or impair cooling.
~Do not use a steam cleaning appliance to clean this cooktop. The
steam could reach electrical components and cause a short circuit.
~If the cooktop is built in over a pyrolitic oven, the cooktop should
not be used whilst the pyrolitic process is being carried out, as this
could trigger the overheating protection mechanism on the cooktop
(see relevant section).
Warning and Safety instructions
13

Disposal of the packing
material
The transport and protective packing
has been selected from materials
which are environmentally friendly for
disposal and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags, etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance. If
handled or disposed of incorrectly they
could be potentially hazardous to
human health and to the environment.
Please do not dispose of your
appliance with household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your Chartered Agent
for advice.
Ensure that it presents no danger to
children while being stored for
disposal.
Caring for the environment
14

The induction principle
Induction coils are located underneath the ceramic surface.
These coils create a magnetic field when the cooktop is
switched on and a pan is placed on the surface. This
magnetic field works on the base of the pan and heats it up.
The ceramic surface heats up indirectly by the heat given off
by the pan.
Induction heat only works when a ferromagnetic pan is
placed on the ceramic surface (see "Pans"). The induction
cooking zone automatically recognises the size of the pan
Induction heat will not work
–if the pan is unsuitable (non-magnetic base).
– if the diameter of the base of the pan is too small.
– if the pan is taken off the cooktop when it is switched on.
If no pan or an unsuitable pan is placed on the ceramic
surface, the cooktop will switch off automatically after a few
minutes.
Danger of burning.
Do not use the cooktop as a resting place for metal items
(e.g. cutlery). When the appliance is switched on either
deliberately or by mistake, or when there is residual heat
present, there is the risk of the metal items heating up,
with the danger of burning.
Switch the cooktop off after use.
Induction
15

Noises
When using an induction cooking zone, the following noises
can occur in the pan, depending on what it is made of and
how it has been constructed.
–On the higher power levels, it might buzz. This will
decrease or cease altogether when the power level is
reduced.
–If the pan base is made of layers of different materials (e.g.
in a sandwiched base), it might emit a cracking sound.
–Whistling might occur if the Booster function is set when
using several pans which have bases made of layers of
different materials at the same time.
– You might hear a clicking sound from the electronic
switches, especially on lower power levels.
– You might hear a whirring sound when the cooling fan
switches on. It switches on to protect the electronics when
the cooktop is being used intensively. The fan may
continue to run after the appliance has been switched off.
Induction
16

Pans
Suitable pans include:
–stainless steel pans with a magnetic base
–enamelled steel pans
–cast iron pans
Unsuitable pans:
–stainless steel pans without a magnetic base
–aluminium and copper pans
–glass, ceramic or earthenware pots and pans
To test whether a pot or pan is suitable for use on an
induction cooktop, hold a magnet to the base of the pan. If
the magnet sticks, the pan is suitable.
Please be aware that the properties of the pan base can
affect the eveness with which food heats up in the pan.
Pots must have minimum base diameter of 10.0 cm and pans
a minimum base diameter of 14.5 cm.
Often the maximum diameter quoted by manufacturers refers
to the diameter of the top rim of the pot or pan. The diameter
of the base (generally smaller) is more important.
Induction
17

The cooktop is fitted with a touch display. All settings are
selected by touching the display.
Take care to keep the touch display clean and do not
place anything on top of it. The sensors may fail to react or
they could mistake the article or any dirt for a fingertip
contact, thereby activating a function or even causing the
cooktop to switch off automatically (see "Safety
switch-off".)
Do not place hot pans on the sensors. The electronic unit
underneath could get damaged.
On/Off
Long touch:
to switch the cooktop on/off
Short touch:
to switch cooking zones off
Multi
The pan can be placed anywhere you wish. Each pan can be
set its own power level. A maximum of 5 pans can be used at
any one time.
Trio
The surface is divided into three cooking zones, each of
which can be set its own power level.
Solo
The whole surface is set to a single power level, e.g. level 5.
The pan can be placed anywhere you wish.
Touch display
18

Operating tips
Control panel
Cooktop
Settings
Operating mode
Settings
Cooktop Demo mode
- for showroom use only
Diagnositics
- for Service technician use only
Display brightness
Language !
Clock / Timer
The appliance is switched on, no operating mode selected:
Set the time of day
Time must be set in 24-hour mode, e.g. 13:12.
The appliance is switched on, operating mode is selected:
Timer function selected (cooking duration, minute minder).
Cooking duration
At the end of the cooking duration the cooking zone or the
heating for the corresponding pan switches off.
Minute minder
Minute minder for monitoring separate cooking processes.
Touch display
19

Main menu
Select operating mode or menu
Settings
Time of day
Operating tips
On/Off
Power levels
Move your finger along the bar to select the power level.
System lock
Touch the lock symbol for at least 3 seconds to activate or
deactivate the system lock.
Activated
The cooktop cannot be used.
Deactivated
The cooktop can be used.
System lock for cleaning
Touch the lock symbol for 1 second. The system lock is
active for 30 seconds.
Touch display
20
