migear Xtracamwifird User manual



1
CONTENTSPAGE
ContentsPage2
Introduction3
SafetyInstructions3
ImportantSafetyPrecautions4
ProductSpecification5
Contents6
GettingtoknowyourCamera7
UsingtheActionCamera9
ActionCameraOperation 13
WIFIMode20
ConnectingtoPC26
UsingtheRemoteControl27
UsingtheMountingAccessories28
Troubleshooting31


2
INTRODUCTION
CongratulationsonthepurchaseofyournewActionCamera.
Thismanualcontainsimportantsafetyandoperating
information.Pleasereadalltheinformationcarefullybefore
youusethedevicetoavoidaccidentsandkeepitforfuture
reference.Followtheseimportantsafetyandoperation
instructions.
SAFETYINSTRUCTIONS
•TheActioncamerawithoutunderwatercasingshallnot
beexposedtodrippingorsplashingandnoobjectsfilled
withliquids,suchasvases,shallbeplacedoverthe
product.Drylocationuseonly.
•Keepthecameraclean.Neverstoreitnexttoaheat
sourceorindirty,humidorwetplaces.Keepitoutof
directsunlight.

3
•Pressthebuttonsgently.Pressingtoohardcandamage
theproduct.
•Donotusethecamerainanextremelydryenvironment.
•Donotputthecamerainhightemperatureplaces(over
40ºC),especiallynotinacarwiththewindowsclosedin
summer.
•Donotsubjectthecameratoharshimpacts.Donotdrop
theunittoavoiddamage.
•Donotattempttodismantleorrepairthiscamera
yourself.Qualifiedpersonnelshouldperformrepairs.
•Disconnectthecamerafromthepowersourcebefore
cleaning.
•Useadrysoftclothtocleanthiscamera.
•Thisproductisnotintendedforcommercialuse.
Household/personaluseonly.
•Donotdisassemblethisunit.Topreventtheriskof

4
electricshock,donotremovethecover.No
user‐serviceablepartsinside.Referservicingtoqualified
personnel.
•TheUSBcordforthedeviceshouldbeunpluggedfrom
thecomputerwhentheunitisleftunusedforalong
periodoftime.
•Donotsubjecttheproducttoharshimpacts.Donotdrop
theappliance.Thismayresultindamagetotheproduct.
IMPORTANTSAFETYPRECAUTIONS
Inordertopreventprogramfailure,neverdisconnectthe
productsuddenlyfromaPCwhilefiletransferringisin
progress.

DisconnecttheappliancefromPCwhencleaning.Useadry
softclothtocleanthisappliance.Donotdismantletheproduct
orusealcohol,thinnersorbenzenetocleanthesurfaceofthe
product.

5
Attention:Wehavedoneourbesttoproduceacompleteand
accuratemanual.However,wecannotensurethatthereareno
errorsoromissionsduringtheprintingprocess.
PRODUCTSPECIFICATION
•5MPCMOSsensor
•WIFIModuleforwirelessstreamingtoSmartphone
•FreeAppavailablefromGooglePlayoriTunes
•VideoResolution:1080P(1920x1080,30fps),720P
(1280x720,30fps),720P(1280x720,60fps)
•StillImageResolution:12MP,5MP
•Wideanglelens
•FileFormatJPEG,H.264
•LCDStatusDisplayscreen
•ExpandableMicroSDSlotupto32GB
•High‐speedUSB2.0interface
•Built‐in3.7Vrechargeablelithiumbattery

6
•OperationTemperature:‐10°Cto40°C
•StorageTemperature:15°Cto30°C
•WorkswithWindows8,7,VistaandXP,Mac10.2and
above
NOTE:Asaresultofcontinualimprovements,thedesignandspecificationsofthe
productwithinmaydifferslightlyfromtheunitillustratedonthepackaging.
CONTENTS
Pleasemakesurethattheitemsshownbelowareincludedin
thepackage.Shouldanitembemissing,pleasecontactthe
localretailerfromwhichyoupurchasedthisproduct
1. ActionCamera1piece
2. WaterproofCase1piece
3. RechargeableBattery1piece
4. BikeMount1piece
5. HelmetMountandStrap1piece
6. 3mStickerforHelmetMount  1piece

7
7. RemoteControl1piece
8. MountingAdaptorforGoProAccessories 1piece
9. USBCable1piece
10. UserManual1piece
GETTINGTOKNOWYOURCAMERA
DEVICEOVERVIEW

8
1Shutterbutton 2Microphone
3LCDDisplay4Lens
5WifiButton6Power/ModeButton
7IRSensor8MicroUSBPort
9HDMIPort10MicroSDSlot

9
11
ExternalMicrophone
Jack
12
BatteryCoverrelease
switch
13LEDIndicatorlight
USINGTHEACTIONCAMERA
BATTERYINSTALLATION
Pleaseinstallthelithiumbatterycorrectlyasshowninthe
followinggraphic.

10
1. Pushthebatterycoverswitchtotheopenposition
(),andremovethecoverasshowninfigure1.
2. Putthelithiumbatteryintothebatteryslot.Makesurethe
contactsofthebatteryarecorrespondingtothesymbols
ofthecamera().Asshowninfigure2and
figure3.
3. Installthebatterycoverbackinplace,andlocktheswitch
tothelockposition( )tofixthebatteryas
showninfigure4

11
BATTERYOPERATION
1. Makesuretheactioncameraisturnedoff.
2. Tochargetheinternalbattery,connecttheactioncamera
withtheUSBcableprovidedtoacomputer.
3. Thechargingindicatorwilllightupbluewhencharging.
4. Thebatterywillbecomefullychargedafter3‐4hours.
5. Oncefullychargedthechargingindictorwilldisappear.
6. Approximatebatterylifedependingonthesituationis:

1080P30fpswithWIFI50minutes
1080P30fps 110minutes
720P60fpswithWIFI55minutes
720P60fps120minutes




12
INSERTINGMICROSDCARD
Thisactioncameradoesnothaveinternalmemory.
AMicroSD(TF)card(Class10)andabovemustbeinsertedfor
thisactioncameratooperateandrecord.
1. Turnofftheactioncamera
2. FindtheMicroSDcardslot,andtheninserttheMicroSD
card.Asperbelowimage





13
ACTIONCAMERAOPERATION
START‐UP/SHUTDOWN
Pressandholdthepower buttonfor5seconds,thescreen
willdisplay“ON”andbeep.

ToTurntheactioncameraoffPressandholdthepower
buttonfor5seconds,thescreenwilldisplay“OFF”and
beep.


14
NOTE:Theactioncamerahasapowersavingsettingandwill
automaticallyturnitselfoffafter5minsofinactivitytosave
power.
DISPLAYSCREEN
Theactioncamerawillbesettovideomodeinitsdefault
settings.Whenthecameraisturnedonitwoulddisplaythe
below

Videomode
icon
TheDVisinvideorecording
mode.
HI Video
resolution
FullHD:1080p@30fps

15
Recording
time
Standsfor0hourand00
minute.
MicroSD
cardicon
DisplaywhenamicroSDcardis
inserted,otherwisenodisplay.
BatterylevelBatteryisfull
Muteicon
ThecameraisinMutemode,no
Beepwillbeheardwhen
pressingthebuttons.Itdisplays
onlywhenMutemodeis
activated.Toturnon/offthe
mutefunctionpressandhold
theShutterbuttonuntiltheicon
appears.

16
Wi‐FiiconDisplayswhenactivated.
MODES
Theactioncameraprovidesdifferentshootingmodes.Press
thepower buttonrepeatedly;thefollowingmodeswillbe
displayedonthescreen:




17
Video
HIstandsforFullHD
(1920x1080,30fps)video
Lostandsfor720P
(1280x720,30fps)video
HILOstandsfor720P
(1280x720,60fps)video

Photo
HIstandsfor12MPresolution
Lostandsfor5MPresolution

Continuous
shot
Supportstaking3/5/1 0 photos
continuously(onlyviaApp)

Self‐timer
Inself‐timermode,youcanset
0s,2sor10s(onlyviaApp)




18
VIDEORECORDINGMODE
Torecordavideo,pleasecheckwhethertheactioncameraisin
videomode.Iftheiconisnotdisplayedonthescreen,
pressthepower buttonrepeatedlyuntilitappearsand
selectyourdesiredresolution.
1.Tostartrecordingpressandreleasetheshutter button,
theiconand[:]displayedinLCDwillflash.Atthesame
timetheredindicatorwillflashtoo.
Note:theLCDonlydisplaysminutesandhours.
2.Tostoprecordingpressandreleasetheshutter button,
theiconand[:]displayedinLCDwillstopflashing.At

19
thesametimetheredindicatorwillstopflashing.
Note:WhentheMicroSDcardisfull,orthebatteryrunsout,
therecordingwillstopautomatically,andtherecordedvideo
willbesavedbeforetheactioncameraturnsitselfoff.
PHOTOMODE
Totakeaphoto,pleasecheckwhethertheactioncameraisin
photomode.Iftheiconisnotdisplayedonthescreen,
pressthepower buttonrepeatedlyuntilitappearsand
selecteitherHiorLoresolutions.
Pressandreleasetheshutter button,abeepwillbeheard
andtheredindicatorwillflash,meaningaphotohasbeen
taken.
Note:Ifyoutakephotosmorethan999photos,theLCDscreen
